Natural-like 3D effect
Bright and flicker-free image
Parallax adjustment function
Compatibility with popular 3D formats
Switchable between 2D and 3D
EJ-MDA32E-K
3D Medical Full HD
LCD Monitor

Natural-like 3D eect
Excellent 3D eect and image quality are best suitable for end oscopic surgery allowing quick recognition of aected areas an d
smooth saturation procedures. Bright icker-free images throug h light weight 3D glasses greatly reduce 3D related nausea and
eye fatigue. Fine adjustment of 3D eect is possible with inc luded parallax adjustment function.
Excellent image quality
Advanced IPS (In-Plane-Switching) technology allows accurate co lor reproduction and consistent performance not aected by
environment of usage, which improves eciency in operation p rocedures in combination with better visibility with large scre en and
full-screen display mode function.
Flexible switching to 2D
Panasonic's medical 3D LCD monitor features exible selection from 2D/3D modes and multiple display modes via OSD,
function key, GPI and RS232C interfaces.
Enter the world of Panasonic
3D Medical Images
The new Medical 3D Full HD LCD Monitor makes an
incredible viewing experience for surgeons possible.
Take advantage during more complicated surgeries
as well as medical trainings and increase eciency
through an optimum of three-dimensional orienta-
tion. The natural-like 3D eect and excellent image
quality is suitable for endoscopic surgery as well as
microscopy. Due to light weight polarized glasses a
good wearability is assured in any situation.
Medical 3D LCD Monitor: EJ-MDA series
3D Feature
∙ Technology: Passive 3D with Xpol ®polarization lter
∙ Compatible 3D Input Format:
∙ 3D Input Terminal: HD-SDI / DVI-D
∙ 3D Function: Odd/even line selection / Parallax adjustment
∙ 3D displayable Input Signal:
1080/60p(DVI), 1080/50p(DVI), 1080/30p, 1080/25p, 1080/24p, 1080/24PsF
1080/60i, 1080/50i, 720/60p, 720/50p
Xpol is registered trademark of Arisawa Co., Ltd
Line-by-line Top & bottom
R
L
Side-by-side
RL
Dual stream
RL
Authorized Dealer

General EJ-MDA32U-K
Power (Internal) AC100-120/200-240V±10% 50/60Hz
Power Consumption 100V-240V / 1.44A-0.64A
Dimensions (HxWxD) 473 x 776 x 114 mm
Weight 15 kg
Cabinet Color Front: Black / Back: White
Image Specications
Size (Diagonal) 32.0“ (81 cm)
LCD Panel IPS-Pro
View Area 698 x 393 mm
Aspect Ratio 16:9
Pixel 1920 x 1080
Number of Colors 16.77 million
View Angle (2D mode) V:178 H:178; (3D mode) V: 26-28 (typ) H:178
Luminance 400 cd/m2 (typ.)
Contrast 1000:1 (typ.)
Response Speed
Rise: Black > White
Fall: White > Black
8 ms (typ.) / 6 ms (typ.)
Features
IPS Wide view angle with IPS panel
HD Dual Input HD-SDI 2 input / DVI-D 2 input: independent display mode
Reverse Display 180°/90°/270° rotation
Still Mode Temporary still mode
OSD Language English / Spanish / Italian / German / French
Image processing 10bit
Input
HD/SD-SDI 2 input, BNC x 2
DVI-D 2x 24 pin input / input 1: with HDCP; input 2: without HDCP
HD15 1 input, Dsub 15 pin
YPbPr/RGB 1 input, BNC x 5, Y/G, Pb/B, Pr/R, CSYNC/HD, VD
Video 1 input, BNC x 1
Y/C 1 input, miniDin 4 pin x 1
Output
HD/SD-SDI 2 output, BNC x 2
DVI-D 1 output without HDCP
YPbPr/RGB 1 ouput, BNC x 5, Y/G, Pb/B, Pr/R, CSYNC/HD, VD
Video 1 output, BNC x 1
Y/C 1 output, miniDin 4 pin x 1
Remote
RS232C 1 connector, Dsub 9 pin
GPI 1 GPI
Frequency
Frequency Horizontal: 31.4 ~ 75 kHz, Vertical: 56.2 ~ 85.1 kHz
Dot Clock 25.1– 162 MHz
Signal Level
HD/SD-SDI 800 mV ± 10%
DVI-D TMDS single link
HD15 R/G/B: 0.7 Vpp, HD/VD: TTL
YPbPr/RGB R/G/B: 0.7 Vpp, HD/VD: TTL, Y:1 Vpp, Pb: 0.7 Vpp, Pr: 0.7 Vpp
Video Video 1 Vpp
Y/C Y: 1 Vpp, C: 0.286 Vpp (NTSC Burst), 0.3 Vpp (PAL Burst)
Mounting
VESA 200 x 200 mm
Compilance
EN60601-1, EN60601-1-2, CE(MDD)
Attachment
Access AC Cord
Operating Instructions Yes (English / Spanish / Italian / German / French)
3D Glasses Circular polarized glasses (not part of supply)
Data subject to change without notice. as at 2011
Medical 3D LCD Monitor Specication

Medical 3D LCD Monitor Specication
Terminal
1Power supply
2S-Video-Input (4-pin, Mini, DIN)
3Video-Input (BNC-Type)
4Y/G-Input (BNC-Type)
5Pb/B-Input (BNC-Type)
6Pr/R
7SYNC/HD-Input (BNC-Type)
8VD-Input (BNC-Type)
9GPI-Input (D-Sub 9-pin)
10 HD 15-Input (Mini-D-Sub, 15-pin)
11 RS-232C-Input (D-Sub 9-pin)
12 SDI 1/2-Input (BNC-Type)
13 potential equalisation pin
14 DVI-D 1/2-Input (DVI-D)
15 Loop-Through SDI 1/2
16 Loop-Through DVI-D2
1 2
1615
4 6 83 5 7 9 10 11 12 1413
Appearance
Rear SideScrew holes
Screw holes
117
200
896
200 539
Unit: mm Front view
Back view
