Precise colour reproduction
Moist-disinfection
Energy-efficient
Operating room monitor
Medical-grade Full HD monitors
EJMLA26Z2 and EJMLA32Z2
Perfection in colour
32‘‘
26‘‘

EJMLA26Z2 AND EJMLA32Z2 PAGE 2
• Ultimate true colours through IPS technology
and LED backlighting
• Dual Display mode (two sources displayed in parallel)
and autonomous image orientation – choose between
PIP and POP mode
• Programmable buttons allowing quick selection of
functions and modes
• Ten user profiles for preconfiguring action of the
required image /function settings
• IPX2 protection. The monitor surfaces can be moist-
disinfected and the monitor is safe against spray
• Low energy consumption through ‘Power Save Mode’
(the monitor switches to stand-by after 30 seconds
without video signal)
• It can be controlled remotely via a RS-232C
or GPI port
• Low thermal output helps to keep operating
room temperatures constant
• Multiple HD inputs and outputs
• Front panel protection supports panel lifetime
• Cable cover included with the EJ-MLA32Z2
• Medically approved for operating rooms
(MDD Class 1, EN 60601-1, EN 60601-2)
Optional accessories
• Smooth height adjusting, tilting and
pivoting monitor stand
• Power adaptor extension cable (in 10 m)
• Cable cover optionally available for EJ-MLA26Z2
32‘‘
26‘‘
Because every moment is essential
EVERY DETAIL COUNTS IN THE OPERATING Room. Panasonic’s new 2D models are its third generation
of medical-grade monitors. The monitors are the perfect assistant for minimally invasive procedures. The
latest development from Panasonic: EJ-MLA26Z2 and EJ-MLA32Z2 Full HD monitors.
Precise image reproduction: operating room monitors display
images brilliantly, flicker-free and fadeless in Full HD.

EJMLA26Z2 AND EJMLA32Z2 PAGE 3
Optimal design for use in
operating theatres
Compact AC adaptor
A compact AC adaptor makes installation easier, especially in
ceiling supply units and cart housings.
Bezel with rounded corners
Panasonic pays detailed attention to safety when it manufac-
tures its operating room monitors. One example of this is the
rounded shape of the bezel. These operating room monitors
save space with their optional bases and slim design.
Hygienic design
The back panel is designed without ventilation openings so it
protects the unit against moisture ingress when disinfecting
it. Cable cover enables connections to be hidden away safely
and tidily.
Range of application:
the casing is narrow
and light and has
rounded corners to
make things safer
in operating room.
Compact:
the AC adaptor is
light and can be easily
installed anywhere.
Clinical cleanliness:
the entire surface can
be cleaned quickly
using a moist cloth
and disinfectant.
Dual Display – one monitor, two images
Picture-out-of-Picture:two images shown
next to one another
Picture-in-picture: one picture shown
inside the other
THE EJMLA26Z2 AND EJMLA32Z2* OPERATING ROOM MONITORS can display two input images
simultaneously, such as an operation image and reference image. There are two display modes available:
picture-in-picture (PIP) and picture-out-of-picture (POP). The size and position of what is displayed on the
screen can be adjusted to suit your needs.
* Available from spring 2016

EJMLA26Z2 AND EJMLA32Z2 PAGE 4
Energy efficient
High performance coupled with low energy consump-
tion is the idea behind the sophisticated design of Panasonic’s
operating room monitors. Low power consumption is achieved
by features such as the newly developed ‘Power Save Mode’ –
the monitor switches to stand-by after 30 seconds of no video
signal. Furthermore, Panasonic’s operating room monitors
reduce heat output to a minimum. This allows temperatures in
operating rooms to remain calculable and constant – without
putting any extra burden on the air-conditioning systems.
Forty years of Healthcare experience
FADELESS, HYGIENIC, EFFICIENT. Surgical teams in the operating room depend upon the most advanced
technologies. Imaging applications have developed to an essential aid. This is where Panasonic Healthcare
comes in, with more than 40 years of experience in medical technology, and continuous development of
operating room monitors.
Precision colour reproduction: intensive reds allow for easy identifica-
tion of inflammation and lesions..
Reduced thermal output: the recommended temperature in German
operating rooms is a constant 22–26° Celsius.
Quick and clinically clean: the operating room monitor can be
moist-disinfected and easily wiped with a cloth.
Precise colour reproduction
EJ-MLA26Z2 and EJ-MLA32Z2 the medical-grade mon-
itors are equipped with IPS technology. Using these advanced
panels, images on the monitor can be viewed in the same quality
from almost any angle – the display can be seen from a full 178
degrees. The display provides ideal conditions for operating
rooms where doctors and their teams are in different positions
and rely on wide viewing angles. Precise image reproduction
displays content in high contrast and depicts structures in
the truest possible colours. Especially intensive reds make it
easy to recognise inflammation and lesions. Even brightness
produced by LED backlighting refines these high-contrast,
fadeless images.
IPX2 standard for moist disinfection
Panasonic’s operating room monitors comply with the
IPX2 standard, which means they are protected against drip-
ping water, dust and, above all, contamination through bacteria
and viruses. This makes our operating theatre monitors quick
and easy to clean: their surfaces can be moist-disinfected
and remain clinically clean with very little effort. Panasonic’s
operating room equipment therefore fulfill the demands of
hospitals and achieves perfect results even under enormous
time pressure.

1
2
3 4 5 6 7 8 9 10
11
12
13
14 15
16
EJMLA26Z2 AND EJMLA32Z2 PAGE 5
Clear operating panel for intuitive operation
A clearly organised operating panel with five programmable
buttons for quick access to the saved functions. The pre-settings
can be operated even when wearing surgical gloves.
Connections and ports
With up to 17 different inputs and outputs (incl. 3G-SDI), the
display is compatible with every conventional system, allowing
flexible usage.
Operation, connections and service
Picture shows the EJ-MLA32Z2
1 DC in
2 DC out 5V 1A
3 S-Video in/out
4 Video in/ out (BNC)
5 Y/G in/out (BNC)
6 Pb / B in/out (BNC)
7 Pr / R in/out (BNC)
8 SYNC in / out (BNC)
9 GPI in (D-Sub 9 Pin)
10 RS-232 in (D-Sub 9 Pin)
11 HD15 in (Mini D-Sub 15 Pin)
12 SDI 1 in / out (BNC)
13 SDI 2 in / out (BNC)
14 Earthing/ equipotential bonding
15 DVI-D 1 in
16 DVI-D 2 in/ out
(HDCP-compliant)
Customer service
Panasonic operating room monitors are renowned for their superior durability. Despite this, Panasonic believes in the
medical philosophy of ‘being prepared for the case’ and provides its customers with a comprehensive service. If necessary, the
company will provide immediate repairs and replacement equipment.
Picture shows the EJ-MLA32Z2

EJMLA26Z2 AND EJMLA32Z2 PAGE 6
General Information EJ-MLA26Z2 EJ-MLA32Z2 (Available from spring 2016)
Power consumption DC 24V, 69W DC 24V, 72W
Dimensions (W×H×D) 643 mm ×396 mm × 87 mm 776 mm × 473 mm × 114 mm
Weight 7,7 kg 13,7 kg
Front bezel color white white
Mounting standard Vesa 100 Vesa 200
Imaging specs
Panel LCD IPS Pro Panel LCD IPS Panel
Image size (diagonal) 26 Zoll (66 cm) 31,5 Zoll (80 cm)
Resolution Full HD, 1.920 × 1.080 Full HD, 1.920 × 1.080
Aspect ratio 16:9 16:9
Luminance 500 cd /m² 500 cd/m²
Contrast ratio 1.4 00:1 1.20 0:1
Viewing angle (hor. /vert.) 178° /178° (CR>10) 178° /178° (CR>10)
Backlight LED LED
Inputs
SDI input 1 3G / HD/SD BNC type 2 3G / HD/SD BNC type
DVI-D 1 (HDCP conform) 2 (DVI 2 HDCP conform)
HD15 -1 D-sub 15 Pin
Video 1 BNC type 1 BNC type
RGB / YPB / YPR 1 Mini-D-Sub (15 Pol) 1/ 1 /1 BNC type
SYNC -1 BNC type
S-Video 1 mini DIN 4 Pin 1 mini DIN 4 Pin
Outputs
SDI output 1 3G / HD/SD BNC type 2 3G / HD/SD BNC type
DVI-D 11 (HDCP conform)
Video 1 BNC type 1 BNC type
RGB / YPB / YPR -1/ 1 /1 BNC type
SYNC -1 BNC type
S-Video - 1 mini DIN 4 Pin
DC 5V 1A 5V 1A
Remote Control
RS-232C 1 D-sub 9 Pin 1 D-sub 9 Pin
GPI 1 D-sub 9 Pin 1 D-sub 9 Pin
Power adapter
Dimensions (W×H×D) 160 mm × 37 mm × 64 mm 160 mm × 37 mm × 64 mm
Weight Approx. 0,7 kg Approx. 0,7 kg
Extension cable 10 m 10 m
Languages
Operation menu English, French, German, Italian, Japanese, Spanish
Manual English (printed), French, German, Italian, Japanese, Spanish (CD)
Features
HD Dual display switchable between SDI- and DVI- input switchable between SDI- and DVI- input
Dual display Available in PIP and POP Available in PIP and POP
Rotation / Flipping 180° /90° /270° Rotation,
Horizontal flipping
180°/90° /270° Rotation,
Horizontal flipping
Efficiency Power safe mode Power safe mode
Hygiene IPX2 standard: moist disinfection IPX2 standard: moist disinfection
Standards FDA Class1 (USA)
CMDR Class1 (Canada)
MDD Class1 (Europe)
EN 60601-1
EN 60601-1-2
CE (MDD)
FDA Class1 (USA)
CMDR Class1 (Canada)
MDD Class1 (Europe)
EN 60601-1
EN 60601-1-2
CE (MDD)
Specifications
