Panasonic LNG251RKR User manual

SHD00400BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: November 2008 1
Light Emitting Diodes
LNG251RKR
Square Type
4.0 mm ×2.0 mm
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD70 mW
Forward current IF25 mA
Pulse forward current *IFP 150 mA
Reverse voltage VR4 V
Operating ambient temperature Topr –25 to +85 °C
Storage temperature Tstg –30 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IO0.25 0.5 mcd
Reverse current IRVR= 4 V 5 µA
Forward voltage VFIF= 20 mA 2.2 2.8 V
Peak emission wavelength λPIF= 20 mA 700 nm
Spectral half band width Δλ IF= 20 mA 100 nm
0
10
20
30
40
50
01.7 1.9 2.1 2.3 2.5 −20 20 40 60 80 100
020 40 60 80 100
10
1
3
5
10
0.03
0.01
0.5
0.05
0.1
0.3
1
30
50
100
30
50
100
300
500
1 000
0
20
40
60
80
100
700600 800 900
1 3 5 10 30 50 100
0
20 2040 4060 6080 80100 100
0°10°10°20°20°
30°30°
40°40°
50°50°
60°60°
70°70°
80°80°
80°
60°
40°
20°
90°90°
Y
X
Y
X
IOIFIFVF
IFTa
Directive characteristics
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
Relative luminous intensity (%)
Forward current IF(mA)
Lighting Color
Red

SHD00400BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LNG251RKR
2
Package (Unit: mm)
LLXFTN2SK510
2.54
1 2
2.0 ±0.2
4.0 ±0.2
0.45 ±0.1
0.5 ± 2.0
5.62
±0.1
3.3 ± 3.0
0.1
5.1
2− 0.7 Max
2− 0.45 ± 0.1
DER
EDL
OST
ON.x
aM2
Pin name
1: Anode
2: Cathode
