Panasonic DVD-LX9 - Portable DVD Player User manual

Portable DVD/SD/CD Player
Operating Instructions
Model No. DVD-LX9
®
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
DCIN9V
CHG
∫;1
:9
r
s
65
123
456
7890
S10
Í
SETUP
TOPMENU
DISPLAY
MENU
RETURN
GROUPPAGEVOLUME
A.SURROUNDANGLE
AUDIO
SUB
-TITLE
PLAYMODEDVD/SD
CANCEL
AUDIO/VIDEO
RQT6915-3B
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Before connecting, operating or adjusting this product, please read these instructions completely.
Please keep this manual for future reference.
Note
“EB” on the packaging indicates the United Kingdom.
EB EG GCS
The illustration shows the unit for the
United Kingdom, Continental Europe,
Australia and N.Z..
Region number
The player plays DVD-Video marked with labels containing the region number or “ALL”.
Region
For the United Kingdom and Continental Europe
For Asia
For Australia and N.Z.
Number
2
3
4
2ALL 35
2
Example: For the United Kingdom and Continental Europe
GN
rqt6915-2bp01.qxd04.12.142:35PMページ1

3
RQT6915
2
RQT6915
Caution for AC Mains Lead
(For United Kingdom)
(“EB”area code model only)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three
pin mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please
ensure that the replacement fuse has a rating of
5-ampere and that it is approved by ASTA or
BSI to BS1362.
Check for the ASTA mark Ïor the BSI mark Ì
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be
used until a replacement cover is obtained.
A replacement fuse cover can be purchased
from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET OUTLET
IN YOUR HOME THEN THE FUSE
SHOULD BE REMOVED AND THE PLUG
CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF
PLUG IS INSERTED INTO ANY
13-AMPERE SOCKET.
If a new plug is to be fitted please observe the
wiring code as stated below.
If in any doubt please consult a qualified
electrician.
IMPORTANT
The wires in this mains lead are coloured in
accordance with the following code:
Blue: Neutral, Brown: Live
As these colours may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows:
The wire which is coloured Blue must be
connected to the terminal which is marked with
the letter N or coloured Black or Blue.
The wire which is coloured Brown must be
connected to the terminal which is marked with
the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER
WIRE TO THE EARTH TERMINAL WHICH IS
MARKED WITH THE LETTER E, BY THE
EARTH SYMBOL ÓOR COLOURED GREEN
OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF—KEEP
DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the
type of AC mains plug (figures A and B).
Confirm the AC mains plug fitted and follow the
instructions below.
Illustrations may differ from actual AC mains
plug.
1. Open the fuse cover with a screwdriver.
Fuse cover
Figure A
Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A
Figure B
2. Replace the fuse and close or attach the fuse
cover.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT
REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT
EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING
AND THAT NO OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHALL BE
PLACED ON THE APPARATUS.
CAUTION!
≥ DO NOT INSTALL OR PLACE THIS UNIT
IN A BOOKCASE, BUILT-IN CABINET OR
IN ANOTHER CONFINED SPACE. ENSURE
THE UNIT IS WELL VENTILATED. TO
PREVENT RISK OF ELECTRIC SHOCK OR
FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY
OTHER MATERIALS DO NOT OBSTRUCT
THE VENTILATION VENTS.
≥DO NOT OBSTRUCT THE UNIT’S
VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS,
CURTAINS, AND SIMILAR ITEMS.
≥DO NOT PLACE SOURCES OF NAKED
FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
≥
DISPOSE OF BATTERIES IN AN
ENVIRONMENTALLY FRIENDLY MANNER.
[For\Asia]
THIS UNIT IS INTENDED FOR USE IN
TROPICAL CLIMATES.
ADVARSEL!
DETTE PRODUKTET ANVENDER EN
LASER.
BETJENING AV KONTROLLER,
JUSTERINGER ELLER ANDRE INNGREP
ENN DE SOM ER BESKREVET I DENNE
BRUKSANVISNING, KAN FØRE TIL
FARLIG BESTRÅLING.
DEKSLER MÅIKKE ÅPNES, OG FORSØK
ALDRI ÅREPARERE APPARATET PÅ
EGENHÅND. ALT SERVICE OG
REPARASJONSARBEID MÅUTFØRES
AV KVALIFISERT PERSONELL.
ADVARSEL:
FOR ÅREDUSERE FAREN FOR BRANN,
ELEKTRISK STØT ELLER SKADER PÅ
PRODUKTET, MÅDETTE
APPARATET IKKE UTSETTES FOR
REGN, FUKTIGHET, VANNDRÅPER
ELLER VANNSPRUT. DET MÅHELLER
IKKE PLASSERES GJENSTANDER FYLT
MED VANN, SLIK SOM
BLOMSTERVASER, OPPÅAPPARATET.
ADVARSEL!
≥APPARATET MÅIKKE PLASSERES I
EN BOKHYLLE, ET INNEBYGGET
KABINETT ELLER ET ANNET LUKKET
STED HVOR
VENTILASJONSFORHOLDENE ER
UTILSTREKKELIGE. SØRG FOR AT
GARDINER ELLER LIGNENDE IKKE
FORVERRER
VENTILASJONSFORHOLDENE, SÅ
RISIKO FOR ELEKTRISK SJOKK
ELLER BRANN FORÅRSAKET AV
OVERHETING UNNGÅS.
≥APPARATETS
VENTILASJONSÅPNINGER MÅIKKE
DEKKES TIL MED AVISER,
BORDDUKER , GARDINER OG
LIGNENDE.
≥PLASSER IKKE ÅPEN ILD, SLIK SOM
LEVENDE LYS, OPPÅAPPARATET.
≥BRUKTE BATTERIER MÅKASSERES
UTEN FARE FOR MILJØET.
NORSK
DETTE APPARATET ER BEREGNET TIL
BRUK UNDER MODERATE
KLIMAFORHOLD.
Marking sign is located on bottom of the unit.
This product may receive radio interference
caused by mobile telephones during use. If
such interference is apparent, please
increase separation between the product
and the mobile telephone.
THIS UNIT IS INTENDED FOR USE IN
MODERATE CLIMATES.
[For\the\United\Kingdom,\Continental\Europe,]
[Australia\and\N.Z.\
The socket outlet shall be installed near the
equipment and easily accessible or the
mains plug or an appliance coupler shall
remain readily operable.
rqt6915-2bp02-25.qxd04.7.29:25AMページ2

5
RQT6915 Getting Started
4
RQT6915 Getting Started
Table of contents
Basic
Operations
Playing discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Playing SD cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Playing the programs or play lists on DVD-RAM . . . . . . . . . . . . 22
WMA/MP3, CD text and JPEG navigation menus . . . . . . . . . . . . 23
≥Playing HighMAT discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Convenient features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
≥Starting play from a selected program, title, track or picture . . . . . 26
≥Selecting still pictures—Page Skip . . . . . . . . . . . . . . . . . . . . . . . . 26
≥Rotating pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
≥Selecting groups to play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
≥Changing the play sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
≥A-B Repeat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
≥Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
≥Marker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Increasing your enjoyment of movies . . . . . . . . . . . . . . . . . . . . . 29
≥Advanced Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
≥Changing soundtracks, subtitle languages and angles . . . . . . . . . 30
Advanced
Operations
Changing the monitor settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
≥Changing the size of the picture. . . . . . . . . . . . . . . . . . . . . . . . . . . 31
≥Picture quality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using GUI screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
≥Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
≥Progress indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
≥Disc information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
≥Unit information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using this unit with other equipment . . . . . . . . . . . . . . . . . . . . . . 35
≥Enjoying more powerful sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
≥Using this unit with a television . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
≥Watching video from a video camera. . . . . . . . . . . . . . . . . . . . . . . 37
≥Recording to digital recording equipment or cassette tapes . . . . . 38
Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
≥Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
≥Language code list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Reference
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Getting Started
Caution for AC Mains Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Disc and Card information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Control reference guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Adjusting the angle of the LCD. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Preparing the multi cradle and power supply . . . . . . . . . . . . . . . 12
≥Multi cradle (AC adaptor) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
≥Battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
≥Car adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
The remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
≥Unless otherwise indicated, illustrations in these operating instructions are of the unit for
the United Kingdom, Continental Europe, Australia and N.Z..
≥Operations in these instructions are described mainly with the main unit, but you can do the
operations on the remote control if the controls are the same (➡page 10).
Accessories
Please check and identify the
supplied accessories.
Use numbers indicated in
parentheses when asking for
replacement parts.
∏Remote control . . . . . . . . . . . . . . . . . . . . . 1
∏[For\Asia]
∏(N2QAJC000005 or
∏N2QAJC000012)
∏[For\others]
∏(N2QAJC000006 or
∏N2QAJC000009)
∏Button-type battery. . . . . . . . . . . . . . . . . . 1
∏for remote control
∏(for replacement, ➡page 15)
∏Audio/video cable . . . . . . . . . . . . . . . . . . . 1
∏[For\Asia]
∏(K2KA6CB00003)
∏[For\others]
∏(RFE0133)
∏AC adaptor. . . . . . . . . . . . . . . . . . . . . . . . . 1
∏[For\Australia\and\N.Z.]
∏(RFEA905W-2W)
∏[For\others]
∏(RFEA905W-1W)
∏AC mains lead . . . . . . . . . . . . . . . . . . . . . . 1
∏[For\the\United\Kingdom] [For\others]
∏(RJA0053-3X) (RJA0019-2X)
∏[For\Australia\and\N.Z.]
∏(RJA0035-K)
∏Rechargeable battery pack . . . . . . . . . . . 1
∏(attached upon shipment)
∏(for replacement, ➡page 13)
∏Multi cradle . . . . . . . . . . . . . . . . . . . . . . . . 1
∏(RAQ0032B)
∏Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . 2
∏(RYQ0446-S)
Note
The included AC mains lead and AC adaptor
are for use with this unit only. Do not use them
with other equipment.
The LCD
Some of the LCD’s pixels (less than 0.01 %) may light constantly or fail to light. This is
normal and does not indicate a malfunction.
VAROITUS!
LAITTEEN KÄYTTÄMINEN MUULLA KUIN
TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA
TAVALLA SAATTAA ALTISTAA
KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE.
VAROITUS:
TULIPALO-, SÄHKÖISKUVAARAN TAI
TUOTETTA KOHTAAVAN MUUN
VAHINGON VÄHENTÄMISEKSI EI
LAITETTA SAA ALTISTAA SATEELLE,
KOSTEUDELLE, VESIPISAROILLE TAI
ROISKEELLE, EIKÄ NESTETTÄ
SISÄLTÄVIÄ ESINEITÄ, KUTEN
ESIMERKIKSI MALJAKOITA, SAA
ASETTAA LAITTEEN PÄÄLLE.
VAROITUS!
≥ÄLÄ ASENNA TAI LAITA TÄTÄ
LAITETTA KABINETTITYYPPISEEN
KIRJAKAAPPIIN TAI MUUHUN
SULJETTUUN TILAAN, JOTTA
TUULETUS ONNISTUISI. VARMISTA,
ETTÄ VERHO TAI MIKÄÄN MUU
MATERIAALI EI HUONONNA
TUULETUSTA, JOTTA VÄLTETTÄISIIN
YLIKUUMENEMISESTA JOHTUVA
SÄHKÖISKU- TAI TULIPALOVAARA.
≥ÄLÄ PEITÄ LAITTEEN
TUULETUSAUKKOJA
SANOMALEHDELLÄ, PÖYTÄLIINALLA,
VERHOLLA TAI MUULLA
VASTAAVALLA ESINEELLÄ.
≥ÄLÄ ASETA PALAVAA KYNTTILÄÄ TAI
MUUTA AVOTULEN LÄHDETTÄ
LAITTEEN PÄÄLLE.
≥HÄVITÄ PARISTOT LUONTOA
VAHINGOITTAMATTOMALLA
TAVALLA.
SUOMI
TÄMÄ LAITE ON TARKOITETTU
KÄYTETTÄVÄKSI
LEUDOSSA ILMASTOSSA.
rqt6915-2bp02-25.qxd 04.12.14 2:39PM ページ4

7
RQT6915 Getting Started
6
RQT6915 Getting Started
Precautions
Do not rest the unit on your lap for a long
time while using it. The unit can become hot
and cause burns.
Read these operating instructions carefully
before using the unit. Follow the safety
instructions on the unit and the applicable safety
instructions listed below. Keep these operating
instructions handy for future reference.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
9) Protect the AC mains lead from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
10) Only use attachments/accessories specified
by the manufacturer.
11) Use only with the cart,
stand, tripod, bracket, or
table specified by the
manufacturer, or sold with
the apparatus. When a cart
is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
12) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
13) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as AC mains lead or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not
operate normally, or has been dropped.
Batteries
1. Battery pack (Lithium ion battery pack)
1. ≥Use this unit to recharge the battery pack.
1. ≥Do not use the battery pack with equipment
other than the specified player.
1. ≥Do not use the player outside if it is
snowing or raining. (The battery pack is not
waterproof.)
1. ≥Do not get dirt, sand, liquids, or other
foreign matter on the terminals.
1. ≥Do not touch the plug terminals (iand j)
with metal objects.
1. ≥Do not disassemble, remodel, heat or throw
into fire.
1. ≥Do not store the battery pack in
temperature over 60 oC.
2. Button-type battery (Lithium battery)
1. ≥Insert with poles aligned.
1. ≥Do not touch the terminals (iand j) with
metal objects.
1. ≥Do not disassemble, remodel, heat or throw
into fire.
1. ≥Keep out of reach of children.
If any electrolyte should come into contact with
your hands or clothes, wash it off thoroughly
with water.
If any electrolyte should come into contact with
your eyes, never rub the eyes.
Rinse eyes thoroughly with water, and then
consult a doctor.
3. Disposing of the batteries
Check and follow your local regulations before
disposal.
AC adaptor
This AC adaptor operates on AC between 100 V
and 240 V.
But
≥Obtain a suitable plug adaptor if the plug does
not fit the AC mains socket.
To prevent damage
Avoid the following;
≥Spraying flammable insecticides near the unit.
≥Pressing the LCD.
≥Touching the lens and other parts of the laser
pickup.
Do not use the unit in the following places;
≥Where the temperature is below 5 oC or above
35 oC. (Operating the unit beyond this range
can cause the protection circuitry to function
and render the unit inoperable.)
≥Sandy places such as beaches.
≥On top of cushions, sofas, or hot equipment
such as amplifiers.
Precautions for Listening
with the Headphones or
Earphones
≥Do not play your headphones or earphones at
a high volume. Hearing experts advise against
continuous extended play.
≥If you experience a ringing in your ears,
reduce volume or discontinue use.
≥Do not use while operating a motorized
vehicle. It may create a traffic hazard and is
illegal in many areas.
≥You should use extreme caution or temporarily
discontinue use in potentially hazardous
situations.
≥Even if your headphones or earphones are the
open-air type designed to let you hear outside
sounds, don’t turn up the volume so high that
you can’t hear what’s around you.
CAUTION!
DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR
EQUIVALENT TYPE RECOMMENDED BY
THE MANUFACTURER. DISCARD USED
BATTERIES ACCORDING TO THE
MANUFACTURER’S INSTRUCTIONS.
www.panasonic.co.uk (for UK customers only)
≥Order accessory and consumable items for your product with ease and confidence by telephoning our
Customer Care Centre Mon–Friday 9:00am–5:30pm. (Excluding public holidays.)
≥Or go on line through our Internet Accessory ordering application.
≥Most major credit and debit cards accepted.
≥All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd.
≥It couldn’t be simpler!
Customer Care Centre
For UK customers: 08705 357357
For Republic of Ireland customers: 01 289 8333
Technical Support
For UK customers: 0870 1 505610
This Technical Support Hot Line number is for Panasonic PC software related products only.
For Republic of Ireland, please use the Customer Care Centre number listed above for all enquiries.
For all other product related enquiries, please use the Customer Care Centre numbers listed above.
For United Kingdom and Republic of Ireland
rqt6915-2bp02-25.qxd04.7.29:25AMページ6

9
RQT6915 Getting Started
8
RQT6915 Getting Started
∫Discs that cannot be played
DVD-ROM, CD-ROM, CDV, CD-G, iRW,
DVD-RW, CVD, SACD, Divx Video Discs, Photo
CD, DVD-RAM that cannot be removed from
their cartridge, 2.6-GB and 5.2-GB DVD-RAM,
and “Chaoji VCD” available on the market
including CVD, DVCD and SVCD that do not
conform to IEC62107.
∫Video systems
≥This unit can play PAL and NTSC, but your
television must match the system used on the
disc.
≥PAL discs cannot be correctly viewed on an
NTSC television.
≥This unit can convert NTSC signals to PAL60
for viewing on a PAL television (➡page 39,
Video—NTSC Disc Output).
≥Output is interlace (576I), when playing PAL
discs.
∫Built-in decoders
This unit can play discs with these symbols.
Disc and Card information
∫To clean discs
DVD-Audio, DVD-Video, Video CD, CD
Wipe with a damp cloth and then wipe dry.
DVD-RAM, DVD-R
≥Clean with an optional DVD-RAM/PD disc
cleaner (LF-K200DCA1, where available).
≥Never use cloths or cleaners for CDs, etc.
∫Handling precautions
≥Do not write on the label side with a ball-point
pen or other writing instrument.
≥Do not use record cleaning sprays, benzine,
thinner, static electricity prevention liquids or
any other solvent.
≥Do not attach labels or stickers to discs.
≥Do not use discs with exposed adhesive from
tape or left over peeled off stickers.
≥Do not use scratch-proof protectors or covers.
≥Do not use discs printed with label printers
available on the market.
Use discs with the above logos and that conform to specifications. The unit cannot play other discs correctly.
Do not use irregularly shaped discs (e.g. heart-shaped), as these can damage the unit.
It may not be possible to play CD-R, CD-RW, DVD-R and DVD-RAM in all cases due to the type of
disc or condition of the recording.
∫Playing DVDs and Video CDs
The producer of these discs can control how
they are played so you may not always be able
to control play as described in these operating
instructions (for example if the play time is not
displayed or if a Video CD has menus). Read
the disc’s instructions carefully.
∫CD-R and CD-RW discs
This unit can play CD-R/RW (audio recording
disc) recorded with CD-DA, video CD, SVCD
(conforming to IEC62107), WMA, MP3, or JPEG.
Close the session or finalize after recording.
See page 24 for more information about
WMA, MP3, and JPEG.
HighMAT discs (➡page 25)
∫DVD-R discs
Panasonic DVD-R recorded and finalized on a
Panasonic DVD video recorder or DVD video
camera are played as DVD-Video on this unit.
∫DVD-RAM discs
The DVD-RAM you can play on this unit are
those recorded with DVD video recorders, DVD
video cameras, personal computers, etc. using
Version 1.1 of the Video Recording Format (a
unified video recording standard).
≥Remove discs from their cartridges before use
and return them when you are finished,
making sure that the labels of the disc and
cartridge face the same way.
≥Some parts of the disc, for example where one
program ends and another begins, may not
play smoothly.
∫Discs that can be played
Cards
∫Cards that can be played
Discs
DVD-RAM
[RAM]
DVD-Audio
[ V -A]
DVD-Video
DVD-R
[ V -V]
Video CD
SVCD
(conforming
to IEC62107)
[VC ]
CD
[CD]
CD-R/RW
—
[WMA] [MP3] [JPEG]
≥SD logo is a trademark.
≥Portions of this product are protected
under copyright law and are provided
under license by ARIS/SOLANA/4C.
SD Memory Card
SD
≥Play may not be possible sometimes due to
the condition of the data.
≥Operation is not guaranteed with
MultiMediaCard.
≥Do not eject the card or unplug the AC adaptor
while the unit is using the card. This can
corrupt your data.
∫Handling precautions
Do not detach the label and do not attach other
labels.
rqt6915-2bp02-25.qxd04.7.29:25AMページ8

11
RQT6915 Getting Started
10
RQT6915 Getting Started
Control reference guide
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASE
VIDEOAUDIO
OPTOUT
1
2
65 7 8 9:
OPEN
A.SURROUND
MONITOR MODE
PICTURE MODE
DVD/SD
=
>
<
@
;
?
TOP MENU DISPLAY
SEARCH
VOL
MENU RETURN
RETURN
OFF ON
E
G
H I J
D
A
B
C
F
DCIN 9V Ë
34
DC IN 9V
3
RELEASE
K
19-inch wide screen LCD
2Stereo speakers
3DC IN terminal (DC IN) . . . . . . . . . . . . . . 12
4Headphone jack (Ë). . . . . . . . . . . . . . . . 16
5Standby indicator (Í) . . . . . . . . . . . . . . 13
6Charge indicator (CHG) . . . . . . . . . . . . . 13
7Remote control signal sensor
8Card slot . . . . . . . . . . . . . . . . . . . . . . . . . 19
9Video output/input§terminal
(VIDEO) . . . . . . . . . . . . . . . . . . . . . . . . . . 36
:Audio output/input§, Optical digital
output terminal
(AUDIO, OPT OUT) . . . . . . . . . . . . . . 35, 36
;Disc lid open button (OPEN) . . . . . . . . . 16
<Advanced surround button
(A.SURROUND). . . . . . . . . . . . . . . . . . . . 29
=Monitor mode button
(MONITOR MODE) . . . . . . . . . . . . . . . . . 31
>Picture mode button
(PICTURE MODE) . . . . . . . . . . . . . . . . . . 31
§Input is only for Asia.
?Skip buttons (:, 9) . . . . . . . . . . . . 17
@Input select button . . . . . . . . . . . . . . . . . 16
[For\the\United\Kingdom , \Continental\Europe , \
[Australia\and\N.Z.\
(DVD/SD)
[For\Asia]
(DVD/SD/AUX)
AShuttle dial (6SEARCH 5) . . . . . . 17
BTop menu button
(TOP MENU) . . . . . . . . . . . . . . . . . . . 17, 22
CMenu button (MENU) . . . . . . . . . 17, 22, 38
DCursor jockey (3, 4, 2, 1)/
Enter button (ENTER) . . . . . . . . . . . . . . 17
Move the cursor jockey in the direction you
want to move the cursor.
You can turn the cursor jockey’s light on and
off (➡page 31, “BLUE LED”).
EDisplay button (DISPLAY) . . . . . . . . 13, 32
FVolume buttons (VOL r, s) . . . . . . . . . 16
GReturn button (RETURN) . . . . . . . . . . . . 17
HPause button (;) . . . . . . . . . . . . . . . . . . 17
IStop/Off button (∫, –OFF) . . . . . . . . . . 17
JPlay/On button (1, ON) . . . . . . . . . . . . . 16
KRelease lever (2RELEASE) . . . . . . . . . 12
∫Main unit
∫Multi cradle
Left side Right side
∫Remote control
∫;1
:9
rs
65
123
456
7890
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
GROUP PAGE VOLUME
A.SURROUND ANGLE AUDIO SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
L
M
N
B
C
<
A
Q
R
E
G
O
S
@
TH
D
U
V
?
W
F
LSetup button (SETUP) . . . . . . . . . . . . . . 38
MStandby/on switch (Í). . . . . . . . . . . . . . 17
NStop button (∫). . . . . . . . . . . . . . . . . . . . 17
OAudio button (AUDIO) . . . . . . . . . . . . . . 30
Numbered buttons (1–9, 0, S10). . . . . . 17
QGroup button (GROUP) . . . . . . . . . . . . . 26
RPage button (PAGE). . . . . . . . . . . . . . . . 26
SPlay mode button (PLAY MODE) . . . . . 27
TPlay button (1). . . . . . . . . . . . . . . . . . . . 16
UAngle button (ANGLE) . . . . . . . . . . . 26, 30
VSubtitle button (SUBTITLE). . . . . . . . . . 30
WCancel button (CANCEL). . . . . . . . . . . . 27
Although it is not labeled [ENTER], the
cursor jockey on the remote control
functions the same as the cursor jockey on
the main unit. Press it to enter selections.
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
PORTABLEDVD
/
SD
/
CDPLAYER
DVD-LX9
DVD-RAMVIDEOPLAYBACK
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/TV/SD/AUX
OPEN
CH
AUDIO
/
VIDEO
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
CHG
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
SDCARD:PUSHRELEASEVIDEO
CHG
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
SDCARD:PUSHRELEASEVIDEO
CHG
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
PORTABLEDVD
/
SD
/
CDPLAYER
DVD-LX9
DVD-RAMVIDEOPLAYBACK
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
AUDIO
/
VIDEO
SDCARD:PUSHRELEASEVIDEO
CHG
AUDIO
OPTOUT
AUDIO
OPTOUT
AUDIO
OPTOUT
Open the LCD
Traditional Viewing
Slide
Click!
Enhanced Angle Viewing
Note
Close the LCD when moving the unit.
Do not carry by the LCD.
Compact viewing
Adjusting the angle
of the LCD
Change the angle of the LCD to suit your
viewing style.
Buttons and terminals such as 3function the same as the controls on the unit.
rqt6915-2bp02-25.qxd04.7.29:25AMページ10

When the unit is on and powered by the battery
pack
Press [DISPLAY].
The battery display appears on the LCD for a
few seconds to show the approximate remaining
charge.
(Appears automatically when there is f
a few minutes of charge remaining.) ----------}
≥Press [RETURN] to clear the GUI screens.
∫If the unit is not to be used for a
long time
≥Detach the battery pack. (Even if the unit is off,
it still uses some power. This can drain the
battery completely and lead to a malfunction.)
≥Recharge the battery pack when you are
ready to use it again.
13
RQT6915 Getting Started
12
RQT6915 Getting Started
∫To confirm the battery charge
Preparing the multi cradle and power supply
Household mains
socket
Fit so unit
clicks firmly
into place.
The unit is in the standby condition (the [Í]
indicator lights) when the AC mains lead is
connected. The primary circuit is always
“live”as long as the AC adaptor is
connected to an electrical outlet.
≥Charge the battery pack before using it for the
first time.
≥Use together with the optional battery pack
(➡page 14) for longer play.
≥For replacement (CGR-H604)
(Available from Panasonic dealers.)
∫To recharge
∫(When the unit is off)
Attach the unit to the multi cradle (➡left).
≥You can also connect the AC adaptor directly
to the player to recharge the battery.
[Recharging]
CHG
Full Low Recharge
Battery pack (Lithium ion battery pack)
∫Recharging and play times
Times shown are approximate. Actual times
depend on operating conditions.
Recharging [at 20 oC]: 4 (13) hours
Play (in hours, at room temperature, using
headphones)
[CHG] lights
[Í] goes out
Recharging is complete when [CHG] goes
out. ([Í] lights.)
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PIC
TUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
RETURN DISPLAY
When using only the player
Connect the AC adaptor directly to the player’s
DC IN terminal.
≥Times for when used along with the optional
battery pack are in parentheses.
≥To change the LCD brightness (➡page 31).
SPEAKER
HAUT
PARLEUR
COMPONENTVIDEO OUT S VIDEO
OUT
(480P/480I)
YP B P R
SUB
WOOFER
CENTRE SORROUND
AUDIOOUT VIDEO
OUT
5.1ch
2ch(MIX)
FRONT
RLRL
R4≠L
+
-
+
-
SPEAKER
HAUT
PARLEUR
4≠
Push the levers and insert the wires.
Light gray
No line
Black line
Dark gray
DCIN 9V
Ë
DC IN 9V
1
2
DC IN
DC IN
4Attach to cradle.
(When the unit is off)
Make sure built-in battery
is attached.
Multi cradle (AC adaptor)
(Continued on the next page)
BEFORE USE
Make sure the built-in battery is attached
whenever you use the unit.
DCIN 9V
PULL
Ë
Remove the
insulation sheet
FOR UNITED KINGDOM ONLY
READ THE CAUTION FOR THE AC
MAINS LEAD ON PAGE 2 BEFORE
CONNECTION.
1Unwind speaker wire,
then fit the wire back
into the groove of the
speaker base.
2Twist and pull off the vinyl tip.
3Connect the speakers.
Caution
Use the speakers only with the
recommended system. Failure to do so
may lead to damage to the connected
equipment and/or the speakers, and may
result in the risk of fire. Consult a
qualified service person if damage has
occurred or if you experience a sudden
change in performance.
≥To conserve power
When the unit is not going to be used for a long
time, disconnect the AC mains lead from the
mains socket.
The unit consumes a small amount of power
(approx. 0.9 W, when in the multi cradle) when
in standby mode.
∫To detach
(When the unit is off)
Pull the lever so the unit lifts off the cradle.
RELEASE
VIDEO AUDIO
OPTOUT
SDCARD : PUSH RELEASE
DVD
SD
j5
2.5 (7.5)
3 (9)
0 (factory
preset)
2 (6)
2.5 (7.5)
i5
1.5 (4.5)
2 (6)
LCD brightness level
LCD off
3.5 (10.5)
8 (24)
rqt6915-2bp02-25.qxd04.7.29:25AMページ12

15
RQT6915 Getting Started
14
RQT6915 Getting Started
Car adaptor (optional)
[For\the\United\Kingdom,\Continental\Europe,]
[Australia\and\N.Z.\
Note
≥Read the car adaptor’s operating instructions
carefully.
≥In the interests of the traffic safety, do not
perform operations on the unit or watch video
while driving a vehicle.
≥You can enjoy sound through your car audio
system by connecting a car stereo cassette
adaptor (part number SH-CDM10A) to this
unit’s headphone jack.
DC IN 9V Ë
Ë
DC IN
To the cigarette
lighter socket
Car adaptor
Part number DY-DC95
This unit (Left side)
Preparing the multi cradle and power supply
12
3
Face +upwards.
Aim at the sensor,
avoiding obstacles, at a
maximum range of 7 m
directly in front of the unit.
30˚30˚
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
Remote control
signal sensor
7 m
The remote control
∫Battery (Lithium battery)
Replacement: CR2025
∫Use
1
This unit (Bottom)
Battery pack
Part number CGP-H501
2
1
∫To attach the optional battery
pack (When the unit is off)
Use together with built-in battery pack.
1
2
Bottom
Slide and hold.
1
2
∫To attach (When the unit is off)
∫To detach the built-in battery
pack (When the unit is off)
Battery pack (Lithium ion battery pack)
Bottom
Push the battery so
it clicks into place.
2
DC IN
≥Connect the AC adaptor directly to the player’s
DC IN terminal to recharge the battery pack.
∫To detach (When the unit is off)
Slide and hold.
Slide the pack so it
clicks and locks into place.
rqt6915-2bp02-25.qxd04.7.29:25AMページ14

17
RQT6915 Basic Operations
16
RQT6915 Basic Operations
[RAM] [ V -A] [ V -V] [VC ] [CD] [WMA] [MP3] [JPEG]
Preparations
≥Open the LCD (➡page 11).
≥[RAM] Remove discs from their cartridges.
[1] Press [OPEN] to open the disc
lid and insert a disc.
Playing discs
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
PORTABLEDVD
/
SD
/
CDPLAYER
DVD-LX9
DVD-RAMVIDEOPLAYBACK
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
AUDIO
/
VIDEO
DCIN9V
CHG
Close the disc lid by hand.
[2] Press and hold [1, ON] to
start play.
The unit comes on automatically.
≥When a source other than DVD is
selected
≥Press [DVD/SD] to select “DVD”and
press [1] (Play).
≥If the disc contains both audio data
(WMA and MP3) and JPEG
≥Check “Mixed Disc-Audio&Stills”setting
in the SETUP menu (➡page 42). Select
“Stills (JPEG)”or “Audio (MP3/WMA)”,
then open and close the lid so the unit
reads the disc again.
≥[CD] [WMA] [MP3] [JPEG]
≥GUI screens (➡page 32) and disc
information [[WMA] [MP3] [CD]
(CD text only)] appear on the display.
[3] Adjust the volume.
Using headphones
Turn down the volume before connection,
and then adjust the level.
Clicks
The menu language is set to English, but
you can change it as follows (➡page 40,
Display—Menu Language). English is used
in the examples.
[For\the\United\Kingdom,\Continental\Europe,\
[Australia\and\N.Z.\
English>French/German/Italian/Spanish/
Portuguese/Swedish/Dutch
[For\Asia] English>French/Spanish
∫;1
:9
rs
65
123
456
7890
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
GROUP PAGE VOLUME
A.SURROUND ANGLE AUDIO SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
Í
∫1
6 5
82 17
DVD/SD
∫, -OFF
3421
ENTER
65
TOP MENU
MENU
RETURN
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
Ë
[1]
;
[2] [3]
Label up.
(With double-sided discs,
load so the label for the side
you want to play is facing up.)
Note
≥If “$”appears on the LCD
≥The operation is prohibited by the unit or disc.
≥Discs continue to rotate while menus are
displayed even after playing an item. Press [∫]
when you finish to preserve the unit’s motor.
Headphones
3.5 mm stereo
≥Play may not be possible when you hold the
unit at different angles.
To turn the unit off
Press and hold [∫, –OFF] until “OFF”appears
on the LCD.
Turning the unit on and off with the remote
control
Press [Í].
≥You cannot use the remote control to turn the
unit on when powered by the battery pack.
Auto standby function
The unit automatically turns off after being
stopped for 15 minutes (5 minutes when the
battery pack is being used).
Chapter Review [ V -V]
The following message appears immediately
after you press [1] (Play).
([For\Asia] “Press PLAY to Preview Chapters”)
Press [1] (Play) while the message is displayed
and the beginning portions of each chapter up
to the current one are played. Full play resumes
from the point where you stopped play.
(This feature works only within a title.)
If you do not press [1] (Play), the message
disappears and play starts from where you
stopped it.
Press PLAY to Chapter Review
Numbered
buttons
Press [∫].
“!”flashes on the display. Press [1] (Play) to restart from this position or [∫] to
clear it.
DVD-Video: Press [1] (Play) again to review chapters (➡below).
Press [;].
Press [1] (Play) to restart.
Press [:] (backward) or [9] (forward).
Group skip [JPEG]
Use [4] (backward) or [3] (forward).
OMain unitNTurn the shuttle dial.
OMain unitNRelease the shuttle dial to restart play.
ORemote controlNPress [6] (backward) or [5] (forward).
ORemote controlNPress [1] (Play) to restart play.
You can turn off the sound during search (➡page 40, Audio—Audio during Search).
While paused
OMain unitNTurn the shuttle dial.
ORemote controlNPress [6] (backward) or [5] (forward).
≥Press [1] (Play) to restart play.
While paused, use [2] (backward) or [1] (forward).
Move and hold to change in succession.
Or, press [;] repeatedly for forward frame-by-frame.
Use [3, 4, 2, 1] to select an item and [ENTER] to confirm.
Or, press the numbered buttons.
To return to the menu
[ V -A] Press [TOP MENU]. [ V -V] Press [TOP MENU] or [MENU].
[VC ] Press [RETURN].
Stop
Pause
Skip
Search
Slow-
motion
Frame-
by-frame
Menus
Notes
≥The speed of search and slow-motion increases up to 5 steps.
≥Slow-motion and frame-by-frame only work on moving pictures.
When playing Video CDs
≥You cannot move backwards during frame-by-frame and slow-motion.
≥Turning the shuttle dial or pressing buttons to perform skip, search or slow-motion may take
you to a menu screen.
rqt6915-2bp02-25.qxd04.7.29:25AMページ16

19
RQT6915 Basic Operations
18
RQT6915 Basic Operations
Playing SD cards SD
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
Ë
82 17
[1]
[2]
;
∫, -OFF
TOP MENU
[3] [4]
DVD/SD
[1] Insert and slide the card until
it clicks into place.
MENU
RETURN
SPLAY
VOL
ON
SDCARD: PUSHRELEASE
≥To remove, press on the center of the
card to unlock, then pull straight out.
[2] Press and hold [1, ON] to turn
the unit on.
When a source other than SD is
selected
Press [DVD/SD] to select “SD”.
[3] 1Use [3, 4] to select the
mode and press [ENTER].
2Use [3, 4, 2, 1] to select
a file and press [ENTER].
[PICTURE]
Press [:, 9] to show other
pictures.
[4] Adjust the volume.
Using headphones
Turn down the volume before connection,
and then adjust the level.
To stop and return to the list
Press [∫].
To pause play
Press [;] during play.
Press [1] (Play) to restart play.
To change the mode
Press [TOP MENU] then select the mode.
To turn the unit off
Press and hold [∫, –OFF] until “OFF”appears
on the LCD.
Turning the unit on and off with the remote
control
Press [Í].
≥You cannot use the remote control to turn the
unit on when powered by the battery pack.
Note
≥Menus and pictures may take some time to
appear.
≥When outputting to other equipment:
≥–There is no video output on units for the
United Kingdom, continental Europe,
Australia and N.Z..
≥–The video output is NTSC on units for Asia.
[MUSIC]
If you have attached still pictures to an audio file
(using SD-Jukebox Ver. 3.0) the unit can also
show the first of these pictures.
Headphones
3.5 mm
stereo
Do not face the slot towards your face when
inserting and removing cards. The slot
mechanism has a spring so the card may
eject with force.
You can play the following types of data recorded on an SD Memory Card:
Still pictures [PICTURE]
JPEG files taken on digital cameras conforming to DCF
standards (set down by the Japan Electronics and
Information Technology Industries Association).
Moving pictures [MPEG4]
MPEG4 files (ASF format) taken on a digital video camera
or SD Multi AV Device.
Music [MUSIC]
MP3 and AAC audio files recorded with “Panasonic Media
Manager”or “SD-Jukebox”, software included with
Panasonic SD Multi AV Device and SD Audio Player.
Voice [VOICE]
G.726 files recorded on a digital video camera or
SD Multi AV Device.
LOCK
Beveled edge
Label
Some files are not compatible with this unit and cannot be played back. For example:
–Moving picture files recorded using a digital still camera with moving picture function
–IC recorder voice files etc
SD Memory Card




MPEG4
MUSIC
VOICE



MODE SELECT
rqt6915-2bp02-25.qxd04.7.29:25AMページ18

21
RQT6915 Basic Operations
20
RQT6915 Basic Operations
Playing SD cards SD
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
3421
ENTER
1
MENU
:9
[PICTURE]
While a picture is displayed
Press [1] (Play).
The pictures appear for five seconds each
starting at the picture where you started.
[PICTURE] [MPEG4] [MUSIC] [VOICE]
The settings you make here are maintained
even if you switch the unit to standby.
While stopped
Press [MENU].
Actual menus depend on the mode.
E.g., MPEG4
[MPEG4] [MUSIC]
1. While the menu is on the screen
1. Press [3, 4] to select “REPEAT”.
2. Press [2, 1] to select the item you want to
repeat.
1. ALL§()1 FILE/MUSIC()OFF
1. ^============J
§[MUSIC]
§Repeats all the tracks in a play list if you have
selected a play list.
[PICTURE] [MPEG4] [MUSIC] [VOICE]
Choose whether to show information such as
the recording date and elapsed time.
1. While the menu is on the screen
1. Press [3, 4] to select “DISPLAY”.
2. Press [2, 1] to switch it on or off.
Slideshow—show still
pictures one after another
Skipping files
Fast forward and rewind—
SEARCH
[PICTURE] [MPEG4] [MUSIC] [VOICE]
During play
Press [:] or [9].
Each press increases the number of skips.
[MPEG4] [MUSIC] [VOICE]
During play
Press and hold [:] or [9].
[MPEG4]
The elapsed play time changes but the picture
stills during search.
≥If the elapsed play time doesn’t appear, set
DISPLAY to ON (➡right).
Play resumes when you reach the beginning of
a file.
[VOICE]
There are two search speeds.
Accessing other features
with the menus
Repeat play
Switching the on screen
display on and off
[MUSIC]
You can play the play lists you created with
“SD-Jukebox”.
1. While the menu is on the screen
1. Press [3, 4] to select “SELECT PLAYLIST”
and press [ENTER].
Example:
2. Press [3, 4] to select the play list and press
[ENTER].
Select the first play list Ato play all the tracks
recorded on the card.
[MPEG4]
1. While the menu is on the screen
1. Press [3, 4] to select “SCREEN”.
2. Press [2, 1] to change the size.
1. FULL (zoom)()NORMAL
≥Picture quality worsens and parts of the
picture may be cut off when you select “FULL”.
To close the menu screen
Press [MENU].
Playing play lists Zooming pictures
∫Recording to an SD card on a computer
You can copy still and moving pictures to your SD card by connecting it to a computer with a
USB Reader/Writer (BN-SDCAP) or PC card adapter (BN-SDABP).
Create folders as shown below.
Naming files
JPEG still pictures
Example:
MPEG 4 moving
pictures
Example:
≥SD_VOICE and SD_AUDIO are hidden folders
created when you record voice or audio files, and
play automatically on other equipment.
≥This unit needs the folders on SD cards to play the
files. Do not delete them on your computer.
≥“DCIM”, “SD_VIDEO”, “SD_VOICE”and “SD_AUDIO”are necessary to play files but have no
effect on operation.
≥You may be unable to play some files due to the origin of the copy, or the naming of folders
and files.




SETUP MENU
SCREEN
REPEAT
DISPLAY
FULL
OFF
ON




SELECT PLAYLIST
DefaultPlaylist
PLAYLIST1
PLAYLIST2
A
DCIM
100CDPFP
PRL001
SD_VIDEO
SD_VC100
SD_VOICE
SD_AUDIO
root
JPEG files
MPEG4 files
Voice files
Music files
IMGA 0001.JPG
MOL001.ASF
Four
characters Three characters
(numerals 0 to 9 and
letters A to F:
hexadecimal name)
Four
numbers
Ensure that none of the files in a folder have
the same last 4 (or 3) characters. Files so
named cannot be played.
rqt6915-2bp02-25.qxd04.7.29:25AMページ20

NextPrev Tree
Group: 001 Penguins Picture: filename00..
SELECT
ENTER RETURN
G 1
P 1
Total 1
SELECT
NUMBER
09
JPEG ALBUM
7
6
1 2 3
4
8
5
9
23
RQT6915 Basic Operations
22
RQT6915 Basic Operations
1Press [TOP MENU].
Selecting programs to play
—DIRECT NAVIGATOR
DIRECT NAVIGATOR
Date CH On
Contents Program Title
12/23(SAT)
12/26(TUE)
1/12(FRI)
1/24(WED)
2/20(TUE)
101
42
2
3
54
125
21:02
14:35
20:00
19:30
19:05
SELECT
ENTER RETURN
No
Saturday feature
Auto action
Sunday Cinema
Music
Baseball
SELECT
NUMBER
09
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
3421
ENTER
RETURN
MENU
TOP MENU
WMA/MP3, CD text and JPEG navigation menus
2Use [3, 4] to select the play
list.
3Press [ENTER].
3. Use [3, 4, 2, 1] to select a scene and
press [ENTER].
3. ≥If there are more than 9 scenes, use [3,
4, 2, 1] to select “Next”and press
[ENTER]. Select “Prev”to move back.
≥You can also select items with the remote
control’s numbered buttons.
≥Select an item to start play
≥Programs and play lists: Press the numbered
buttons.
≥To select a two-digit number:
e.g. “25”:[S10]>[2]>[5]
≥Scene list pages: Press the numbered buttons
then press [ENTER].
≥e.g. “25”: [2]>[5]>[ENTER]
To display information about a program or
play list
1. Select the program or play list and move the
cursor jockey [1].
2. (For play lists) Use [3, 4] to select
“Contents”and press [ENTER].
Use [2, 1] to show other programs or play
lists.
To clear the list
DIRECT NAVIGATOR: Press [TOP MENU].
Play list: Press [MENU].
(The unit returns to the condition it was in before
you called up the list.)
To return to the previous screen
Press [RETURN].
Note
≥Titles appear only if you have entered them.
≥You cannot change titles.
PLAYLIST
SELECT
ENTER RETURN
1 10/17 0:46:35 028
NextPrev 001/004
SELECT
NUMBER
09
1 0:00:19 2 3
654
987
1. Select the play list and move the cursor
jockey [1].
2. Use [3, 4] to select “Scene List”and press
[ENTER].
Page/Total pages
2Use [3, 4] to select the
program.
The selected program plays in the
background.
3Press [ENTER].
Playing a play list
You can play a group of scenes, a play list,
created on other equipment such as a DVD
video recorder.
1Press [MENU].
Playing the programs or play lists on DVD-RAM
[RAM]
Playing specific scenes
PLAYLIST
No Date Length Title Contents
1
2
3
4
0:46:35
0:09:15
0:12:32
0:07:30
SELECT
ENTER RETURN
10/17
10/24
11/29
12/22
SELECT
NUMBER
09
12 3
654
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
TOP MENU RETURN 3421
ENTER
: 9
[WMA] [MP3] [CD] (CD text only) [JPEG]
If the disc contains both audio data (WMA
and MP3) and JPEG
Check “Mixed Disc-Audio&Stills”setting in the
SETUP menu (➡page 42). Select
“Stills (JPEG)”or “Audio (MP3/WMA)”, then
open and close the lid so the unit reads the disc
again.
1Press [TOP MENU].
WMA/MP3 Audio navigation menu
JPEG Album display
2Use [3, 4] to select the track
or [3, 4, 2, 1] to select the
picture, and press [ENTER].
To show other pages, use [3, 4, 2, 1]
to select “Prev”or “Next”and press
[ENTER].
≥“0”indicates the track currently playing.
To exit the menu
Press [TOP MENU].
Track title search
[WMA] [MP3] [CD] (CD text only)
Example: finding a track including the word
“LOVE”.
1While the menu is displayed
Use [3, 4] to select “Find”
and press [ENTER].
Another Pineapple
Board The Golden Ship
Fall In The Frozen
Violet Sky
Pink Island
NextFindPrev
6
7
8
9
10
SELECT
ENTER RETURN
SELECT
NUMBER
09
Find
A
2Use [3, 4] to select “L”and
press [ENTER].
Only uppercase appear but the search
also includes lower case. Characters
change in alphanumeric order each time
you press [3].
≥Press [:, 9] to skip between A, E,
I, O and U.
≥Use [2] to erase a character.
≥You can enter numbers with the
numbered buttons.
Repeat this step to enter “O”, “V”, and “E”.
3Use [1] to select “Find”and
press [ENTER].
The search results screen appears.
4Use [3, 4] to select the track
and press [ENTER].
≥You can erase the asterisk ( ) to search for
the first word in a title.
To return to the menu
Press [RETURN].
001 Both Ends Freezing
002 Lady Starfish
003 Life on Jupiter
004 Metal Glue
005 Paint ItYellow
006 Pyjamamama
007 Shrimps from Mars
008 Starperson
009 Velvet Cuppermine
010 Ziggy Starfish
NextPrev
1
2
3
4
5
6
7
8
9
10
No Group: 001 My Favorite Tree
Find
SELECT
ENTER RETURN
G 1
T 1
Total 1
SELECT
NUMBER
09
MENU
rqt6915-2bp02-25.qxd04.7.29:25AMページ22

25
RQT6915 Basic Operations
24
RQT6915 Basic Operations
WMA/MP3, CD text and JPEG navigation menus
RETURN DISPLAY
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
DVD/SD
CHG
SDCARD:PUSHRELEASEVIDEOAUDIO
OPTOUT
MENU
TOP MENU 3421
ENTER
To use the contents screen
to find a track [CD] (CD text only)
To use the tree screen to find
a group [WMA] [MP3] [JPEG]
You can use the text information recorded on
these discs to find a track to play.
1While the menu is displayed
Use [1] while a track is
highlighted to display the
contents screen.
SELECT
ENTER RETURN
T 10 /14
MENU Contents
Track 10 Title/Artist
Pink Island
Long John Platinum
Disc Title/Artist
SHIPWRECKED
ORIGINAL SOUNDTRACK
2Use [2, 1] to move through
the tracks and press [ENTER].
1While the menu is displayed
[WMA] [MP3]
Use [1] while a track is
highlighted to display a tree
screen.
[JPEG]
Use [3, 4, 2, 1] to select
“Tree”and press [ENTER].
2Use [3, 4] to select a group
and press [ENTER].
The audio navigation menu/album display
for the group appears.
To return to the menu
Press [RETURN].
Note
[WMA]
≥You cannot play WMA files that are copy
protected.
≥WMA files must have the extension “.WMA”or
“.wma”.
[MP3]
≥This unit is not compatible with ID3 tags.
≥If you play an MP3 track that includes still
picture data, it will take some time before the
music itself starts playing and the elapsed time
will not be displayed during this time. Even
after the track starts, the correct play time will
not be displayed.
≥MP3 files must have the extension “.MP3”or
“.mp3”.
[JPEG]
≥To view JPEG files on this unit:
≥–Take them on a digital camera that meets
the DCF (Design rule for Camera File
system) standard. Some digital cameras
have functions that are not supported by the
DCF standard like automatic picture rotation
which may render a picture un-viewable.
≥–Do not alter the files in any way or save
them under a different name.
≥–Ensure they have the extension “.JPG”,
“.jpg”, “.JPEG”, or “.jpeg”.
≥This unit cannot display moving pictures,
MOTION JPEG and other such formats, still
pictures other than JPEG (e.g. TIFF) or play
associated sound.
[WMA] [MP3] [JPEG]
≥Discs must conform to ISO9660 level 1 or 2
(except for extended formats).
≥This unit is compatible with multi-session but if
there are a lot of sessions it takes more time
for play to start. Keep the number of sessions
to a minimum to avoid this.
Windows Media, and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
WMA is a compression format developed by
Microsoft Corporation. It achieves the same
sound quality as MP3 with a file size that is
smaller than that of MP3.
Naming folders and files
At the time of
recording, prefix
folder and file
names with 3-digit
numbers in the
order you want to
play them (this
may not work at
times).
002 group
001
001 group
001 track.mp3
002 track.mp3
003 track.mp3
003 group
001 track.mp3
002 track.mp3
003 track.mp3
001 track.mp3
002 track.mp3
003 track.mp3
004 track.mp3
e.g. MP3
root
Tree
G 8/16
MP3 music
001 My favorite
001 Brazilian pops
002 Chinese pops
003 Czech pops
004 Hungarian pops
005 Liner notes
006 Japanese pops
007 Mexican pops
008 Philippine pops
009 Swedish pops
001 Momoko
002 Standard number
001 Piano solo
002 Vocal
SELECT
ENTER RETURN
G 8
T 14
Total 123
SELECT
NUMBER
09
MENU
You cannot select groups that
contain no compatible files.
HighMAT and the HighMAT
logo are either trademarks or
registered trademarks of
Microsoft Corporation in the
United States and/or other
countries.
A menu appears after you insert the disc.
Press [3, 4, 2, 1] to select then
press [ENTER].
When you press [ENTER]:
Menu: Takes you to the next menu
which shows play lists or
another menu.
Play list: Play starts.
≥To return to the menu screen
≥Press [TOP MENU].
≥To return to the menu above the current
one
≥Press [RETURN].
≥To change the menu background
≥Press [DISPLAY].
≥The background changes to the one recorded
on the disc.
∫Selecting from the lists
1While playing
Press [MENU].
2Use [2] then [3, 4] to switch
between the play list, group
and content lists.
3Use [1] then [3, 4] to select
an item and press [ENTER].
≥To exit the list screen
≥Press [MENU].
Note
Disable HighMAT disc play to use random and
program play.
To use program/random play
1. In the SETUP menu, set “HighMAT”to
“Disable”(➡page 42).
2. Reinsert the disc and perform the necessary
operations (➡page 27).
Playlist
Group
Less and less
And when I was born
Quatre gymnopedies
You've made me sad
I can't q it him
2
3
4
5
6
No Content title
SELECT
NUMBER
09
All By Artist
Content
Group 1
Few times in summer
1
Playing
Playing HighMAT discs
HighMAT (High performance Media Access
Technology) is a new standard for storing audio,
image, and video data files on CD media. When
you create a HighMAT CD using compliant PC
software, you can make playlist settings and
also record text information such as titles and
artist names. File searching is made easy using
CDs recorded in HighMAT through use of a
versatile navigation system. CDs recorded in
HighMAT can also be played on your PC.
This unit is compatible with HighMAT discs
containing WMA, MP3, or JPEG data. There are
some differences from other WMA/MP3/JPEG
discs.

27
RQT6915 Basic Operations
26
RQT6915 Basic Operations
Convenient features
Starting play from a
selected program, title,
track or picture
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3] [JPEG]
Remote control only
Press the numbered buttons to
select the item ([WMA] [MP3] [JPEG] and
press [ENTER]).
Play starts from the selected item.
To select a 2-digit number
e.g. 25: [S10]>[2]>[5]
e.g. 25: [WMA] [MP3] [JPEG]
e.g. 25: [2]>[5]>[ENTER]
If the GUI screens are on the LCD
(➡page 32)
≥This works only when stopped with some
discs.
≥When playing DVD-Audio and you want to
start play from a track in a different group,
select the group first (➡right).
Selecting still pictures—
Page Skip
[DVD-A]
During play
Press [PAGE].
The page changes each time you press the
button.
∫;1
:9
r
s
65
123
456
7890
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
GROUP PAGE VOLUME
A.SURROUND ANGLE AUDIO
SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
PLAY MODE
ANGLE
CANCEL
65
GROUP
PAGE
1
3421
ENTER
Numbered
buttons
Rotating pictures
[JPEG]
Remote control only
While a picture is displayed
1Press [ANGLE].
2Use [3, 4] to select “Rotate
right”or “Rotate left”and
press [ENTER].
The picture rotates ninety degrees each
time you do this.
≥The rotation is canceled when you open the
disc lid, select another source, or switch the
unit to standby.
To clear the popup screen
Press [ANGLE].
Selecting groups to play
[DVD-A] [WMA] [MP3] [JPEG]
1Press [GROUP].
e.g. MP3
2Use [3, 4] to select the group
number and press [ENTER].
3Use [3, 4] to select the
track/picture number and
press [ENTER].
≥You can also select the group and
track/picture number with the numbered
buttons.
[DVD-A]
≥Playing all the groups in succession
(➡page 27, All group play)
≥Playing bonus groups
Some discs contain bonus groups. If a
password screen appears after selecting a
group, enter the password with the numbered
buttons. Refer also to the disc’s jacket.
11118
Group No. Track No. in disc
Track No.
in group
Total No. of
tracks on disc
≥[DVD-V] Some items cannot be selected.
≥[DVD-A] If you select bonus groups, you
will have to enter a 4-digit password.
2Press the numbered buttons
to select a track or a chapter
([WMA] [MP3] and press [ENTER]).
≥Repeat steps 1and 2to program other
items.
≥Times are not displayed when
programming DVD-Video and
WMA/MP3.
Changing the play
sequence
[DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
Remote control only
While stopped
Press [PLAY MODE].
The display changes each time you press the
button.
[A] All group ([DVD-A])_)[B] Program
^=OFF(=[C] Random(}
PROGRAM
Choose a title and chapter, then press ENTER.
No Time
TC
Press PLAY to start
Play
Clear
Clear all
SELECT
ENTER RETURN
1
SELECT
NUMBER
09
3Press [1] (Play).
≥[DVD-V] Some items cannot be played
even if you programmed them.
To add, change, or clear items
1 Use [3, 4] to select the program number
(No).
2 Do steps 1and 2to add or change items.
Press [CANCEL] to clear an item (or use
[3, 4, 2, 1] to select “Clear”and press
[ENTER]).
≥Press [6] or [5] to change pages.
To clear the whole program
Move to “Clear all”with [3, 4, 2, 1] and press
[ENTER]. The whole program is also cleared
when you open the disc lid, select another
source, or switch the unit to standby.
To select an item using the cursor jockey
Press [ENTER] and [3, 4] to select an item,
then press [ENTER] again to register the
number. All the items on a disc, a title or a
group are selected when you select “ALL”.
Random Playback
Title
Press PLAY to start
2
All group play
Program play
[DVD-A]
The unit plays tracks in all the groups on a disc.
Press [1] (Play).
You can select up to 32 items to play in the
order you choose.
1[DVD-A] [DVD-V] [WMA] [MP3]
Press the numbered buttons
to select a group or a title.
e.g. DVD-Video
[A]
[B]
To exit the all group/program/random mode
Press [PLAY MODE] while stopped until the all group/program/random play screen disappears.
[DVD-A]
≥You can select more than one group.
≥To enter all groups, select “All”using
[2, 1] and press [ENTER].
≥To deselect a group, press the
numbered buttons corresponding to the
group you want to clear.
≥If you select bonus groups, you will have
to enter a 4-digit password.
2Press [1] (Play).
≥[DVD-V] Some titles cannot be selected.
Random play
[C]
1[DVD-A] [DVD-V]
Press the numbered buttons
to select a group or a title.
e.g. DVD-Video
rqt6915-2bp26-48.qxd04.7.29:29AMページ26

29
RQT6915 Basic Operations
28
RQT6915 Basic Operations
Repeat play
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3] [JPEG]
During play
Do steps 1to 4on page 32 to select the desired
repeat play mode.
[RAM]
Program (PG)()Entire disc (A)()OFF
^------------------------------------------------------------J
During play list play
Scene (S)()Play list (PL)§1()OFF
^--------------------------------------------------------J
[DVD-A] [WMA] [MP3]
Track (T)()Group (G)§2()OFF
^--------------------------------------------------J
[DVD-V]
Chapter (C)()Title (T)§2()OFF
^-------------------------------------------------J
[VCD] [CD]
Track (T)()Entire disc (A)()OFF
^------------------------------------------------------J
[JPEG]
Group (G)()OFF
§1“PL”is not displayed while playing a specific
play list scene.
§2“All (A)”during all group, program and
random play.
≥You can also repeat play of content (“C”) and
group (“G”) on HighMAT discs.
If the Video CD has playback control
1. Press [∫].
2. Press the numbered buttons to select a track
to start play (➡page 26).
3. Select the repeat mode (➡above).
Note
≥This only works if the disc’s elapsed play time
is shown in the GUI screens (➡page 33).
≥You cannot use repeat play to repeat an entire
DVD-Video, an entire WMA/MP3/JPEG disc or
all the play lists on a DVD-RAM.
∫To repeat only your favorite
tracks/chapters
[DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
Start program play (➡page 27) and select “A”
(➡above).
OFF
Convenient features Increasing your
enjoyment of movies
Repeat Mode
Marker
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3] [JPEG]
You can mark up to 5 positions to play again.
[RAM]: 999 positions
[RAM]:If places have been marked (e.g., with a
DVD video recorder), they are displayed.
1Do steps 1 to 3 on page 32 to
select “Marker”.
2Press [ENTER].
[RAM] Use [1] to select “¢”.
The unit is now ready to accept markers.
3Press [ENTER] to mark a
position.
To recall a marker: [2, 1] ➡[ENTER]
To erase a marker: [2, 1] ➡[CANCEL]
To mark another position: [2, 1] ➡[ENTER]
[RAM]
To mark the eleventh point and beyond
1. Use [2, 1] to select the marker pin icon.
2. Use [3, 4] to select “11–20”.
You can select the next group when the current
group is full.
≥This feature doesn’t work while using a play
list.
≥The markers are ordered by time. This means
that the marker numbers can change when
you add and erase markers.
≥You can clear existing markers, but they are
restored when you open the disc lid, select
another source or switch the unit to standby.
Note
≥This feature doesn’t work during program and
random play.
≥Markers you add clear when you open the disc
lid, select another source, or switch the unit to
standby.
1–10
OFF
Marker
Advanced Surround
[RAM] [DVD-V] [VCD] (2-channel or over only)
Enjoy a surround-like effect with 2 speakers
(SP) (on other equipment) or headphones (HP).
If the disc has surround effects, the effect is
broadened and sound seems to come from
virtual speakers on either side.
Preparation
Turn off the surround effects on the other
equipment.
Press [A.SURROUND].
Each time you press the button:
e.g. SP
1(Natural)>2(Emphasized)>OFF (Cancel)
^---------------------------------------------------------}
To change the mode
[2]>[3, 4] to select “SP”or “HP”.
Optimum seating position
SP 1 SP 2

SP OFF

Note
≥Output from this unit will be in stereo (two
channels) when Advanced Surround is on.
≥Turn Advanced Surround off if it causes
distortion.
OWhen using the
television’s
speakersN
Distance Au
Television’s width
Distance A
Television
Speaker Speaker
Seating
position
3 or 4 times
distance A
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASE
VIDEOAUDIO
OPTOUT
3421
ENTER
A.SURROUND
A-B Repeat
[RAM] [DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
You can repeat a section between point A and
point B within an item.
During play
1Do steps 1 to 3 on page 32 to
select “A-B Repeat”.
2Press [ENTER] to specify start
point A and end point B.
Each time you press the button
[-) Point A specified
l;
lPoint B specified (A-B repeat starts)
l;
{= Normal play
Note
≥This feature works only within a program/track/
title.
≥The unit automatically determines the end of a
program/track/title as point B when the end of
the program/track/title is reached.
≥Subtitles around point A or B may fail to
appear.
OFF
Play Menu
A-B Repeat
Play Menu
Play
Menu
∫;1
123
456
7890
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
A.SURROUND ANGLE AUDIO
SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
CANCEL
3421
ENTER
∫
Numbered
buttons
rqt6915-2bp26-48.qxd04.7.29:29AMページ28

[RAM] [DVD-A] [DVD-V] [VCD]
During play
Press [AUDIO].
[DVD-V]
The number changes each time you press the
button.
[DVD-A]
[RAM] [VCD]
Each time you press the button:
LR>L>R
^-------------}
≥You can also use this button to turn the vocals
on and off on karaoke discs. Read the disc’s
instructions for details.
≥Play restarts from the beginning of the
soundtrack when playing DVD-Audio and
DVD-RAM soundtracks that are accompanied
by still pictures.
≥Even if a second soundtrack isn’t recorded on
a DVD-Audio, two soundtrack numbers will
normally be shown when you press [AUDIO].
The soundtrack currently playing is number 1.
≥Refer to [B] on page 33 for audio signal type
details.
30
RQT6915 Basic Operations
31
RQT6915 Advanced Operations
Changing the monitor settings
Changing the size of the
Select how to show 4:3-aspect pictures on the
LCD.
Press [MONITOR MODE].
Each time you press the button:
NORMAL_-)FULL_-)ZOOM_-]
^-OFF (no picture)<JUST(---------}
The picture mode and size
The picture shown on the LCD depends on the
mode and the size recorded on the disc
(➡below).
≥If you are not using the LCD on this unit, select
“OFF”to conserve power.
≥(The [Í] indicator flashes.).
≥The LCD turns off if you close it.
≥“NORMAL”is the best setting to show
16:9-aspect pictures.
Picture quality
1Press [PICTURE MODE].
2Use [3, 4] to select the item.
3 Use [ 2 , 1 ] to select the setting.
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASE
VIDEOAUDIO
OPTOUT
3421
ENTER
PICTURE MODE
MONITOR MODE
Changing soundtracks,
subtitle languages and angles
Some discs have multiple soundtracks, subtitle
languages and camera angles, and you can
change these during play.
≥“–” or “––” is displayed instead of the language
number in circumstances such as when no
language is recorded on the disc.
[VCD] (SVCD only)
Soundtrack and subtitle numbers may change even
if corresponding soundtracks are not recorded.
3/2.1 ch
Digital
1 English
192k24b 2ch
LPCM
1
1
[DVD-A] (Moving picture part) [DVD-V]
[VCD] (SVCD only):
You can change the subtitle number and turn
the subtitles on and off.
[RAM]: You can turn the subtitles on and off.
During play
Press [SUBTITLE].
The number changes each time you press the
button.
≥In some cases, the subtitle language is not
changed to the selected one immediately.
To clear/display the subtitles
1. Press [SUBTITLE].
2. Press [1]. ([DVD-A] [DVD-V] [VCD])
3. Press [3, 4] to select “ON”or “OFF”.
∫Changing the position and
brightness of the subtitles
[DVD-A] [DVD-V]
1. While the subtitle icon is on the
screen, use [2, 1] to highlight
“Subtitle Position”or “Subtitle
Brightness”.
2. Use [3, 4] to adjust.
≥Adjust position between 0 and j60 in 2 unit
steps.
≥For brightness, select “Auto”so the brightness
adjusts automatically against the background,
or a level between 0 and j9.
1
English
ON
1
Increasing your enjoyment of movies
Soundtrack playing
Sound track selected
BRIGHT
COLOUR
SHARP
GAMMA
AI MODE
BLUE LED
-5 05
OFFON
OFFON
∫To clear the screen
Press [PICTURE MODE].
BRIGHT
Brightens the picture.
≥Power consumption increases with the
≥level of brightness.
COLOUR
Adjust the shade of the picture's color.
SHARP
Adjusts the sharpness of the edges of the
horizontal lines.
GAMMA
Adjusts the brightness of dark parts of the picture.
AI MODE
Make a clear distinction between black and white.
BLUE LED
Turn the cursor jockey’s light on and off.
≥The cursor jockey flashes during some
operations, even if you select “OFF”.
∫;1
123
456
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
A.SURROUND ANGLE AUDIO
SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
ANGLE
AUDIO SUBTITLE
3421
ENTER
Soundtracks
Subtitles
[DVD-A] [DVD-V]
During play
Press [ANGLE].
The number changes each time you press the
button.
Angles
Note
These changes are effective only for this unit’s LCD. Make changes to the television’s settings if you
have connected one.
NORMAL
FULL
Stretched
horizontally.
ZOOM
Stretched vertically
and horizontally.
JUST
Fills the screen for
a more natural
picture.
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Te quiero
Mode
Disc
4:3
4:3
Letterbox
00
Subtitle Brightness
Subtitle Position
Íindicator
rqt6915-2bp26-48.qxd04.7.29:29AMページ30

32
RQT6915 Advanced Operations
33
RQT6915 Advanced Operations
Disc information
aPG: Program number [RAM]
PL: Playlist number [RAM]
T: Title number [DVD-V]
T: Track number [VCD] [CD]
G: Group number
[DVD-A] [WMA] [MP3] [JPEG]
bC: Chapter number [DVD-V]
T: Track number [DVD-A] [WMA] [MP3]
P: Picture number [JPEG]
cTime [RAM] [DVD-A] [DVD-V] [VCD] [CD]
≥Use [3,4] to show the elapsed play time
or remaining time.
[DVD-A] [VCD] [CD]
[)Elapsed play time
l:;
lRemaining time for the track
l:;
{)Remaining time for the disc/group
[RAM] [DVD-A] [DVD-V]
≥Select a position to start play by specifying
a time with the numbered buttons and
press [ENTER].
Elapsed play time
[VCD] (SVCD only) [WMA] [MP3]
For display only, cannot be changed.
dSoundtrack language
(See [A] right for language abbreviations.)
Audio signal type
(See [B] right for details.)
Audio Mode (➡page 30, Soundtracks)
Karaoke vocal on/off (Karaoke DVD only)
[DVD-V]
Solo: OFF or ON
Duet: OFF, V1iV2, V1 or V2
Current bitrate [WMA] [MP3]
Current sampling frequency [WMA] [MP3]
eSubtitle language
(See [A] right for language abbreviations.)
Subtitles on/off
[RAM] [DVD-A] [DVD-V] [VCD] (SVCD only)
ON()OFF
Track Information on/off
[WMA] [MP3] [CD] (CD text only)
ON()OFF
Picture information [JPEG]
Date()Full()OFF
^=======J
fAngle number (➡page 30)
gMenu play [VCD]
Indicates whether menu play (playback
control) is on or off.
hTrack/picture number in disc
Total number of tracks/pictures on disc
[WMA] [MP3] [JPEG]
iStill picture number [DVD-A]
Selected picture is shown during play.
jSlideshow setting [JPEG]
ON()OFF
Slideshow timing [JPEG]
0 sec–30 sec
g
d
128kbps
44.1kHz
12 18
cehd
i
Page
1
Slideshow
ON 5 sec
j
[A] Audio/Subtitle language
ENG: English POR: Portuguese
FRA: French RUS: Russian
DEU: German JPN: Japanese
ITA: Italian CHI: Chinese
ESP: Spanish KOR: Korean
NLD: Dutch MAL: Malay
SVE: Swedish VIE: Vietnamese
NOR: Norwegian THA: Thai
DAN: Danish ¢: Others
[B] Signal type/data
LPCM/PPCM/ÎDigital/DTS/MPEG:
Signal type
k (kHz): Sampling frequency
b (bit): Number of bits
ch (channel): Number of channels
e.g.: 3/2 .1ch
.1: Low frequency effect
(not displayed if there is no
signal)
.0: No surround
.1: Mono surround
.2: Stereo surround (left/right)
.1: Center
.2: Front leftiFront right
.3: Front leftiFront
rightiCenter
GUI (Graphical User Interface) screens contain
information about the disc or unit. These menus
allow you to perform operations by changing
this information.
Common procedures
1Press [DISPLAY].
Each time you press the button:
Disc information >Progress indicator
:;
Original display <Unit information
(➡step 2)
[Unit\information\only]
While the leftmost icon is highlighted
2
Use [3, 4] to select the menu.
Each time you use the cursor jockey:
Play menu () Picture menu
ee
uu
Display menu () Audio menu
3Use [2, 1] to select the item.
4Use [3, 4] to select the
setting.
≥Items with “3”or “4”above and below
can be changed by [3, 4].
≥Press [ENTER] if the setting does not
change after using [3, 4].
≥Some items require different operations.
Read the explanations on the following
pages.
Using GUI screens
For your reference
≥Depending on the condition of the unit
(playing, stopped, etc.) and the type of
software, there are some items you cannot
select or change.
≥When numbers are displayed (e.g.title No.),
the numbered buttons (remote control) are
also effective for setting. After entering
numbers, press [ENTER] to register the
setting.
To clear the icons
Press [RETURN] until they clear.
∫To change the position of the icons
1. Use [2, 1] to select the Bar position
icon.
2. Use [3, 4] to move the icons.
2. (There are 5 positions.)
Progress indicator
Indicates how far you have played through an
item.
e.g. [DVD-V]
aCurrent position
bCondition–play, pause, or slow/search
cChanging the time display
[RAM] [DVD-A] [DVD-V] [VCD] [CD]
≥Use [3,4] to show the elapsed play time
or remaining time.
Elapsed play time
[VCD] (SVCD only) [WMA] [MP3]
For display only, cannot be changed.
Changing play speed
[DVD-A] (Moving picutre part) [DVD-V]
(Dolby Digital only)
You can slow down or speed up play.
Use [2] (slower) or [1] (faster).
There are five speeds:
k
0.8 ,.k 0.9 ,.k 1.0 (normal speed) ,.k 1.2 ,.k 1.4
≥After you change the speed:
≥–Output is in stereo.
≥–You cannot use Advanced Surround.
≥–Digital output switches to PCM.
≥–Sound is stereo as long as “k1.0”is orange.
To return to normal play
Press [1] (Play).
SEARCH
ENTER
OFF
MENU
RETURN
TOPMENUDISPLAY
VOL
ON
A.SURROUND
MONITORMODE
PICTUREMODE
DVD/SD
OPEN
CHG
SDCARD:PUSHRELEASE
VIDEOAUDIO
OPTOUT
RETURN
3421
ENTER
DISPLAY
1
rqt6915-2bp26-48.qxd04.7.29:29AMページ32

35
RQT6915 Advanced Operations
34
RQT6915 Advanced Operations
Unit information
Play menu Display menu
aA-B Repeat (➡page 28)
bRepeat Mode (➡page 28)
cPlay mode display
[DVD-A] [DVD-V] [VCD] [CD] [WMA] [MP3]
---: Normal play
PGM: Program play
RND: Random play
ALL: All group play ([DVD-A])
dMarker (➡page 29)
Picture menu
N
480P
Auto1
c
ba
a4:3 Aspect
[RAM] [DVD-A] [DVD-V] [VCD] [JPEG]
Select how to show images made for 4:3
aspect screens on a 16:9 aspect television.
Normal: laterally stretches images made
for a 4:3 screen.
Auto: expands suitable 4:3 letterbox
images to fill more of the screen.
Other images appear in full in the
center of the screen.
Shrink: images appear in the center of the
screen.
Zoom:
expands all images to fill the
screen.
≥If your television has a similar feature, use
it instead for a better effect.
bZoom [RAM] [DVD-A] (Moving picture part)
[DVD-V] [VCD]
Change the zoom ratio so the picture expands
to the optimum size to fill the screen.
To select the aspect ratio:
[ENTER]>[2, 1]>[ENTER]
[>4:3 Standard()European Vista(----]
uv
Cinemascope2 16:9 Standard
ef
{>Cinemascope1()American Vista(-}
To make fine adjustments to the zoom
ratio: [3, 4]
k1.00–k2.00
cSubtitle Position/Brightness (➡page 30)
dBitrate Display [RAM] [DVD-A] [DVD-V] [VCD]
ON()OFF
During play: Shows the average bitrate
(approximate values) of the
video being played
While paused: Shows the data volume of
the frame and type of
picture (I/P/B ➡page 43,
Glossary)
To change the bitrate display:
0
Normal
0
dba c
1.00
t
Using GUI screens
aPicture Mode
[RAM] [DVD-A] [DVD-V] [VCD] [JPEG]
N: Normal mode
C1: Mellows images and enhances detail in
dark scenes.
C2: Sharpens images and enhances detail
in dark scenes
bVideo output mode
[RAM] [DVD-A] [DVD-V] [VCD] [JPEG]
480I: Interlace video
480P: Progressive video
¢: Progressive output not possible with
PAL signals.
≥
You can change the video output mode only
when “Progressive Out (Component)”in the
SETUP menu is set to “Enable”(
➡ page 39).
cTransfer mode [RAM] [DVD-A] [DVD-V] [VCD]
Select the method of conversion for progressive
output to suit the type of material being played
(Film and video
➡ page 43, Glossary).
Auto1 (normal): for viewing film material
Auto2:
for viewing film material (the same as
Auto1, but able to convert 30-frame-
per-second progressive video)
Video: for video material
Audio menu
Enjoying more powerful sound
Enjoy the powerful movie theater and hall-like sound available with multiple channel audio found on
DVDs by connecting an amplifier and speakers.
Note
≥The equipment connections described are examples.
≥Peripheral equipment and optional cables sold separately unless otherwise indicated.
≥Before connection, turn off all equipment and read the appropriate operating instructions.
Change the settings in “Audio”(➡page 40).
To enjoy stereo or Dolby Pro Logic
Connect a digital amplifier or system
component, and change the settings in “Audio”
(➡page 40).
Connecting to a receiver or
amplifier with built in
decoders (Digital connection)
VIDEO
OUT
SUB
WOOFER
CENTRE SORROUND
AUDIO OUT VIDEO
OUT
5.1ch
2ch (MIX)
FRONT
RLRL
L
+
-
SPEAKER
4≠
OPTICAL
CENTRESUB-
WOOFER
SURROUND
(L)
FRONT
(R)(R) (L)
AUDIO, OPT OUT
Amplifier
Speakers (Example)
You can enjoy surround sound by
connecting three or more speakers.
Optical fiber cable
Do not bend sharply.
Connecting to a receiver or amplifier with 5.1 audio input terminals
(Analog connection)
Change “Speaker Setting”(➡page 40).
≥Use this connection to enjoy multi channel LPCM DVD-Audio.
Audio cable
This unit (Right side)
Using this unit with other equipment
aAdvanced Surround (➡page 29)
bDialogue Enhancer [DVD-V]
(Dolby Digital/DTS, 3-channel or over only)
ON()OFF
The volume of the dialogue from the center
channel is raised when you select “ON”.
Current bitrate A record of bitrates for
a sampling period.Average bitrate
f[2, 1]
v
Bitrate
Cur. 7.507 Mbps
Ave. 6.730 Mbps
5.0
Mbps
9.438 Mbps
Multi cradle
Note
≥You can only use DTS Digital Surround decoders that are compatible with DVD.
≥There is no audio output when using a digital connection.
SD
rqt6915-2bp26-48.qxd04.7.29:29AMページ34

37
RQT6915 Advanced Operations
36
RQT6915 Advanced Operations
Using this unit with other equipment
Using this unit with a television
VIDEO IN
AUDIO IN
L
R
SORROUND
AUDIO OUT VIDEO
OUT
5.1ch
2ch (MIX)
FRONT
LRL
L
+
-
SPEAKER
4≠
Television
Audio/video cable
(not included)
yellowred white
Right side
Note
≥The speakers do not have magnetic shielding. Do not place near televisions, personal computers,
magnetized cards (bank cards, commuter passes, etc.) or other devices easily influenced by
magnetism.
≥Volume may be lower when playing DVDs than when playing other discs or during TV broadcasts.
If you turn the volume up, reduce it again so that a sudden increase in output does not occur.
Press [DVD/SD/AUX] to select “AUX”.
Control play on the camera.
Auto standby function (➡page 17) does not work while the “AUX”mode is on. Turn the unit off when
you have finished using it.
Note
Only output from NTSC system cameras can be shown.
yellow
yellow
black white
red
Audio/video cable
(included)
This unit (Right side)
Video camera
Before connecting, turn off all equipment and read the appropriate operating instructions.
Do not connect the player through your video cassette recorder. The picture may not be played
back correctly due to the copy guard.
Audio/video cable (included)
SPEAKER
COMPONENT VIDEO OUT S VIDEO
OUT
(NTSC : 480P/480I , PAL : 5761)
YP B P R
SUB
WOOFER
CENTRE SORROUND
AUDIO OUT VIDEO
OUT
5.1ch
2ch (MIX)
FRONT
RLRL
R
4≠
+
-
Television’s
COMPONENT
VIDEO IN
terminals
Television’s
S VIDEO IN
terminal
COMPONENT VIDEO OUT terminal
These terminals can be used for either interlace or
progressive output and provide a purer picture than the S
VIDEO OUT terminal. Connection using these terminals
outputs the color difference signals (PB/PR) and luminance
signal (Y) separately in order to achieve high fidelity in
reproducing colors. The description of the component video
input terminals depends on the television or monitor (e.g.
Y/PB/PR, Y/B-Y/R-Y, Y/CB/CR). Connect to terminals of the
same color.
S VIDEO OUT terminal
The S video terminal achieves a
more vivid picture than the VIDEO
OUT terminal by separating the
chrominance (C) and luminance
(Y) signals. (Actual results depend
on the television.)
Video cable (not included)
S video cable (not included)
When making this connection, ensure you connect the audio cables to the corresponding audio input
terminals on the television.
Note
There is no video output when connected with the COMPONENT VIDEO OUT terminal.
To enjoy progressive video
1. Connect to the component video input terminals on a 480P compatible television. (Video will not
be displayed correctly if connected to an incompatible television.)
2. In SETUP menu, set “Progressive Out (Component)”to “Enable”(➡page 39).
3. Change “Video output mode”to “480P”(➡page 34).
≥All televisions manufactured by Panasonic and that have 480P input connectors are compatible.
Consult the manufacturer if you have another brand of television.
≥If the unit is connected to the television through VIDEO OUT or S VIDEO OUT, output will be
interlace, irrespective of the settings.
Watching video from a video camera For Asia only
SD
Enjoying higher
picture quality
yellow
red
white
yellow
black
yellowred white
Connecting the multi cradle
Connecting the player
[For\the\United\Kingdom\and\Continental\Europe]
Use the RCAJ adaptor (not included) if your TV has a 21-pin SCART terminal.
RCAJ adaptor (not included)
To the television’s
21-pin SCART
terminal
red
yellow
white
black
yellow
Audio/Video cable (included)
To [AUDIO, OPT OUT]
To [VIDEO]
You can connect the
audio cable to the
2-channel audio input
terminals of an analog
amplifier or system
component to enjoy
stereo or Dolby Pro
Logic.
Multi cradle
rqt6915-2bp26-48.qxd04.7.29:29AMページ36

39
RQT6915 Advanced Operations
38
RQT6915 Advanced Operations
This chart shows the settings for this unit. Change the settings to suit your preference and to
suit the unit to the environment in which it is being used. These settings are retained in
memory until they are changed, even the unit is turned off.
≥Underlined items are the factory presets.
∫;1
:965
123
456
7890
S10
Í
SETUP
TOP MENU DISPLAY
MENU
RETURN
A.SURROUND ANGLE AUDIO
SUB
-TITLE
PLAY MODE DVD/SD
CANCEL
RETURN
3421
ENTER
SETUP
CANCEL
Changing settings
Numbered
buttons
Common procedures
1Press [SETUP] to show the
menus.
Disc
SELECT
Audio
Subtitle
Menus
Ratings
English
English
Automatic
Level 8
SETUP
TAB
2Press [2, 1] to select the
menu’s tab.
The screen changes to display the menu.
Disc()Video()Audio
Others(===)Display
3Press [3, 4] to select the
item and press [ENTER].
4Press [3, 4, 2, 1] to select
the option and press [ENTER].
The screen now shows the menu again.
To return to the previous screen
Press [RETURN].
When you are finished
Press [SETUP].
For your reference
Press [MENU] on the main unit to access the
SETUP menus while stopped (unless a
DVD-RAM is loaded).
Using this unit with
other equipment
Recording to digital
recording equipment or
cassette tapes
≥Digital recording
You can record the digital signal directly to
digital recording equipment.
Connect the recording equipment with an optical
fiber cable (➡page 35).
Note
≥With DVD, the following conditions must be
met: athe disc doesn’t have protection
preventing digital recording, and bthe
recording equipment can handle signals with a
sampling frequency of 48 kHz.
≥You cannot record WMA/MP3.
When recording DVDs, make the following
settings.
Advanced Surround: OFF (➡page 29)
PCM Down Conversion: Yes (➡page 40)
Dolby Digital/DTS Digital Surround/MPEG§:
PCM (➡page 40)
§[For\Asia] MPEG is not available.
≥Analog recording
You can record to a cassette deck or other
recording equipment. There are no limitations
on recording analog signals as there are with
digital signals.
Connect the recording equipment to
AUDIO, OPT OUT on the player with the
audio/video cable (included) (➡page 36)
Or
FRONT L R [2ch (MIX)] on the multi-cradle
(➡page 36).
[In the SETUP menu, set “Speaker Setting”to
“2-channel”(➡page 40).]
e
ue u
Menus
Disc
Video
Items
Audio
Choose the preferred audio language.
English Original§1Other¢¢¢¢§3
Subtitle
Choose the preferred subtitle language.
Automatic§2English Other¢¢¢¢§3
Menus
Choose the preferred language for disc menus.
English Other¢¢¢¢§3
Ratings
Set a ratings level to limit DVD-Video play.
8 No Limit
1 to 7: Prohibits play of DVD-Video with corresponding ratings recorded on them.
0 Lock All
§1The original language of each disc will be selected.
§2If the language selected for “Audio”is not available, subtitles of that language will
automatically appear if available on that disc.
§3Input a code number with the numbered buttons (➡page 42).
TV Aspect
Choose the setting to suit your television and preference.
4:3 Pan&Scan: Regular television
(to view 16:9 software in the pan and scan style)
4:3 Letterbox: Regular television
(to view 16:9 software in the letterbox style)
16:9: Wide-screen television
Use the television’s screen modes to change the way the picture is
shown.
Progressive Out (Component)
Choose “Enable”to enable progressive output.
Disable Enable (NTSC Disc Only)
Still Mode
Specify the type of picture shown when paused.
Automatic Field Frame
NTSC Disc Output
Choose whether PAL60 or NTSC signals are output during playback of NTSC discs
(➡page 8, Video systems).
PAL60: When connected to a PAL television.
NTSC: When connected to an NTSC television.
(For Asia: “NTSC”is the factory preset.)
Language Options
[For\the\United\Kingdom ]
[Continental\Europe \Australia]and\N.Z.]
French German Italian
Spanish Portuguese
Swedish Dutch
[For\Asia]
French Spanish

Entering a password
The password screen is shown when you select levels 0 to 7.
1. Input a 4-digit password with the numbered buttons.
1. ≥If you enter a wrong number, press [CANCEL] to erase it.
2. Press [ENTER].
1. ≥Do not forget your password.
3. Press [ENTER] to confirm the 4 digits.
≥Now, when you insert a DVD-Video that exceeds the ratings limit you set, a
≥message appears on the screen. Follow the on-screen instructions.
rqt6915-2bp26-48.qxd04.7.29:29AMページ38
