Panasonic PT-DW830K System manual

1/20
Product Number : PT-DW830K/DW830W
PT-DW830LK/DW830LW
Product Name : DLP™Projectors
As of May 2013. Specifications and appearance are subject to change without notice.
SFD13M005
SPEC FILE

SPEC FILE
PT-DW830K/DW830W/DW830LK/DW830LW
DLP™Projectors
As of May 2013
SFD13M005
2/20
Main unit
Power supply
Power consumption 120–240 V AC, 50/60 Hz
DLP™ chip Panel size
Display method
Pixels
Lens PT-DW830K/DW830W
PT-DW830LK/DW830LW
Lamp
Screen size
Brightness*2
Center-to-corner uniformity*2
Contrast*2
Resolution
HDMI/DVI-D
RGB
YPBPR(YCBCR)
Video/S-Video
Optical axis shift
120–240 V AC, 10–5.2 A, 50/60 Hz
1,030 W (1,060 VA) (0.3 W with STANDBY MODE set to ECO*1, 3 W with
STANDBY MODE set to NORMAL)
16.5 mm (0.65 in) diagonal (16:10 aspect ratio)
DLP™ chip × 1, DLP™ system
1,024,000 (1,280 × 800) × 1, total of 1,024,000 pixels
Powered zoom/focus lenses (1.8–2.5:1), F 1.7–1.9, f 25.6– 35.7 mm
Optional powered zoom/focus lenses and fixed-focus lens
420 W UHM lamps (× 2)
1.27–15.24 m (50 – 600 inches) (1.27– 5.08 m (50– 200 inches) with the
ET-DLE055), 16:10 aspect ratio
8,500 lumens (dual lamp, LAMP MODE: NORMAL)
90%
10,000:1 (full on/full off, in dynamic iris 3 mode)
1,280 × 800 pixels (Input signals that exceed this resolution will be
converted to 1,280 × 800 pixels.)
fH: 15–100 kHz, fV: 24–120 Hz, dot clock: 25–162 MHz
fH: 15–100 kHz, fV: 24–120 Hz, dot clock: 162 MHz or lower
525i (480i): fH15.75 kHz; fV60 Hz,
625i (576i): fH15.63 kHz; fV50 Hz,
525p (480p): fH31.50 kHz; fV60 Hz,
625p (576p): fH31.25 kHz; fV50 Hz,
750 (720)/60p: fH45.00 kHz; fV60 Hz,
750 (720)/50p: fH37.50 kHz; fV50 Hz,
1125 (1035)/60i: fH33.75 kHz; fV60 Hz,
1125 (1080)/60i: fH33.75 kHz; fV60 Hz,
1125 (1080)/50i: fH28.13 kHz; fV50 Hz,
1125 (1080)/25p: fH28.13 kHz; fV25 Hz,
1125 (1080)/24p: fH27.00 kHz; fV24 Hz,
1125 (1080)/24sF: fH27.00 kHz; fV48 Hz,
1125 (1080)/30p: fH33.75 kHz; fV30 Hz,
1125 (1080)/60p: fH67.50 kHz; fV60 Hz,
1125 (1080)/50p: fH56.25 kHz; fV50 Hz
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Vertical: +60% (powered), horizontal: ±10% (powered)
NOTE: Optical axis shift function cannot be operated when used with the ET-DLE055.
Specifications
Scanning frequency
Keystone correction range
Installation
Vertical ±40° (±30° with the ET-DLE085/ET-DLE055)
Ceiling/floor, front/rear
Terminals HDMI IN
DVI-D IN
HDMI 19-pin × 1, Deep Color, compatible with HDCP,
VGA (640 × 480) – WUXGA*4(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
DVI-D 24-pin × 1, DVI 1.0 compliant, HDCP compatible,
for single link only
525i(480i)*3, 625i(576i)*3, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p
VGA (640 × 480) – WUXGA*4(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
525i(480i)*3, 625i(576i)*3, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p

SPEC FILE
DLP™Projectors
3/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
RGB 1 IN
R, G, B
Y, P B, PR(Y, CB, CR)
S-Video signal
RGB 2 IN
R, G, B
Y, P B, PR(Y, CB, CR)
VIDEO IN
3D SYNC 1 IN/OUT
3D SYNC 2 OUT
BNC × 5
R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic
NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.
Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms
Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
D-sub HD 15-pin (female) × 1
R: 0.7 Vp-p, 75 ohms,
G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
B: 0.7 Vp-p, 75 ohms
HD, VD/SYNC: TTL, high impedance, positive/negative automatic
NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.
Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms
BNC × 1, 1.0 Vp-p, 75 ohms
BNC × 1, 1.0 Vp-p, 75 ohms
Input: TTL, high impedance. Output: TTL, max. 10 mA
BNC × 1, 1.0 Vp-p, 75 ohms, TTL, max. 10 mA
connection, 100Base-TX, compatible with Art-Net, compliant with
PJLink™ (class 1), Deep Color, compatible with HDCP,
VGA (640 × 480) – WUXGA*3(1,920 × 1,200),
dot clock: 25 MHz –162 MHz
NOTE: Compatible with non-interlaced signals only.
525i(480i)*3, 625i(576i)*3, 525p(480p), 625p(576p), 750(720)/60p,
750(720)50p, 1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p,
1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p, 1125(1080)/60p,
1125(1080)/50p
REMOTE 2 IN
LAN/DIGITAL LINK
D-sub 9-pin × 1 for external control (parallel)
RJ-45 × 1 for network and DIGITAL LINK (video/network/serial control)
SERIAL IN
SERIAL OUT
REMOTE 1 IN
REMOTE 1 OUT
D-sub 9-pin (female)
(female)
× 1 for external control (RS-232C compliant)
D-sub 9-pin (male) × 1 for link control
M3 jack × 1 for wired remote control
M3 jack × 1 for link control
(RS-232C compliant)
Power cord length
Cabinet materials
Dimensions (W × H × D) PT-DW830K/DW830W
PT-DW830LK/DW830LW
Weight* PT-DW830K/DW830W
PT-DW830LK/DW830LW
Operation noise*2
6
Operating temperature
Operating humidity
3.0 m (9 ft 10 in)
Molded plastic
498 × 200*5× 556 mm
(19-19/32 × 7-7/8*5× 21-7/8 inches) (with supplied lens)
498 × 200*5× 513 mm
(19-19/32 × 7-7/8 *5× 20-3/16 inches) (without lens)
Approx. 18.3 kg (40.3 lbs) (with supplied lens)
Approx. 17.6 kg (38.8 lbs) (without lens)
40 dB (dual lamp operation, LAMP MODE: NORMAL),
35 dB (dual lamp operation, LAMP MODE: ECO)
0– 45 °C (32 –113 °F)*7
10%–80% (no condensation)

SPEC FILE
DLP™Projectors
4/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.
*1 When the STANDBY MODE is set to ECO, network functions such as power on over the LAN network will not operate, and the serial output terminal
cannot be used. Also, only certain commands can be received for external control using the serial terminal.
*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*5 With
*6 Average value. May differ depending on models.
legs at shortest position.
*7 The operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when the fan control is set to High Altitude mode (for altitudes from 1,400 m
to 2,700 m (4,593 ft to 8,858 ft) above sea level). Also, if the ambient temperature exceeds 40 °C (104 °F) (35 °C (95 °F) in High Altitude mode)
when the projector is being used with Lamp Select set to Dual and Lamp Power set to High, the light output may be reduced approximately
20% to protect the projector.
*8 Operation range differs depending on environments.
Supplied accessories
Optional accessories
Digital interface box
Zoom lens (1.4– 2.0:1)
Zoom lens (2.4– 3.8:1)
Zoom lens (3.8– 5.7:1)
Zoom lens (5.6– 9.0:1)
Fixed-focus lens (0.8:1)
Ceiling mount bracket
Power cord (× 1) (× 2 for PT-DZ870EK/DZ870EW/DZ870ELK/DZ870ELW)
Wireless/wired remote control unit (× 1)
Batteries for remote control (AAA type × 2)
Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring
& Control Software) (× 1)
ET-YFB100G
Zoom lens (0.8–1.0:1) ET-DLE085
ET-DLE150
ET-DLE250
ET-DLE350
ET-DLE450
ET-DLE055
ET-PKD120H (for high ceilings)
ET-PKD120S (for low ceilings)
Remote control unit
Power supply
Operation range*8
Dimensions (W × H × D)
Weight
3 V DC (AAA type battery × 2)
Approx. 30 m (98 ft 5 in) when operated from directly in front of the
signal receptor
48 × 145 × 27 mm (1-28/32 × 5-23/32 × 1-1/16 inches)
Approx. 102 g (3.6 oz) (including batteries)
Smoke cut filter
Replacement lamp unit
Replacement lamp unit for portrait mode
Attachment for ceiling mount bracket ET-PKD120B
ET-SFD120
ET-LAD120
ET-LAD120W (Twin Pack)
ET-LAD120P
ET-LAD120PW (Twin Pack)
*3 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal)
*4 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).

498 (19/32)
513 (20-3/16)
43
(1-11/16)
556 (21-7/8)
21
(13/16)
95
(3-3/4)
179 (7-1/16)
200 (7-7/8)
442 (13/32) 432 (17)
28
(1-3/32)
SPEC FILE
DLP™Projectors
5/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Dimensions
unit : mm (inch)
NOTE: This illustration is not drawn to scale.
The illustration shows the PT-DW830K/DW830W.
Terminals
1
8 9 10 11 12 13
234 567
1 Remote 1 input
2 Remote 1 output
3 Remote 2 input
4 Serial input
5 Serial output
6 3D sync 1 input/output
7 3D sync 2 output
8 Video input
9 RGB 1 input
10 RGB 2 Input
11 DVI-D input
12 HDMI input
13 LAN/DIGITAL LINK connector
DIGITAL LINK
3D SYNC
IN/OUT OUT
VIDEO IN

SPEC FILE
DLP™Projectors
6/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Standard setting-up position
Caution:
• All construction work should be done by a qualified technician.
• When mounting to the ceiling, use the special mounting bracket. Furthermore, in order to prevent it from falling
down from the ceiling, use the supplied wire on the mounting bracket.
*1
451.5–531.5*2
(17-25/32– 20-15/16)
100 (3-15/16)
100
(3-15/16)
unit : mm (inch)
*1 When the lens protrudes to the maximum.
84 mm (3-5/16 in) with the ET-DLE085
43 mm (1-11/16 in) with the supplied lens
44 mm (1-23/32 in) with the ET-DLE150
27 mm (1-1/16 in) with the ET-DLE055
*2 Adjustable in 40 mm (1-9/16 in) steps.
NOTE:
Illustrations show the projector
installed using optional ceiling mount
bracket ET-PKD120H, optional bracket
assembly ET-PKD120B and an optional lens.
This illustration is not drawn to scale.
*2
340–420
(13-3/8–
16-17/32)
45 mm (1-25/32 in) with the ET-DLE250
51 mm (2 in) with the ET-DLE350
95 mm (3-3/4 in) with the ET-DLE450
Projected image
EE
Lower edge of projected image
Upper edge of projected image
L
Projected image
L
L
269244
(10-19/32)(9-19/32)
ø60.5
370
(14-9/16)
259
(10-3/16)

SPEC FILE
DLP™Projectors
7/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min.[m] [in] max.
ET-DLE080
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.07
-0.08
-0.09
-0.11
-0.12
-0.14
-0.16
-0.20
-0.27
-0.34
-0.40
-0.54
-0.67
-0.81
0.34
0.40
0.47
0.54
0.61
0.67
0.81
1.01
1.35
1.68
2.02
2.69
3.37
4.04
0.87
1.06
1.24
1.42
1.61
1.79
2.16
2.71
3.63
–
–
–
–
–
0.34
0.40
0.47
0.54
0.61
0.67
0.81
1.01
1.35
–
–
–
–
–
2.12
2.55
2.98
3.42
3.85
4.28
5.15
6.45
8.61
10.78
12.95
17.28
21.61
25.94
1.09
1.32
1.54
1.77
2.00
2.22
2.68
3.36
4.49
5.62
6.76
9.02
11.29
13.56
2.70
3.26
3.81
4.37
4.92
5.48
6.59
8.25
11.03
13.81
16.58
22.13
27.68
33.23
4.06
4.89
5.72
6.55
7.38
8.20
9.86
12.35
16.49
20.63
24.77
33.06
41.34
49.62
6.11
7.36
8.61
9.86
11.11
12.36
14.86
18.61
24.85
31.10
37.35
49.84
62.33
74.82
9.60
11.57
13.55
15.53
17.51
19.49
23.45
29.38
39.28
49.17
59.06
78.85
98.64
118.43
1.45
1.75
2.05
2.35
2.65
2.95
3.55
4.45
5.95
7.45
8.96
11.96
14.96
17.96
0.87
1.05
1.24
1.42
1.60
1.78
2.15
2.70
3.62
4.53
5.45
7.28
9.11
10.94
1.91
2.31
2.71
3.11
3.50
3.90
4.70
5.89
7.88
9.86
11.85
15.83
19.80
23.78
2.54
3.07
3.59
4.12
4.64
5.17
6.21
7.79
10.41
13.03
15.65
20.90
26.14
31.39
4.00
4.83
5.65
6.48
7.31
8.13
9.79
12.27
16.40
20.53
24.67
32.94
41.20
49.47
5.96
7.21
8.46
9.71
10.96
12.22
14.72
18.47
24.73
30.99
37.25
49.76
62.28
74.80
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE080
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.2
-0.3
-0.3
-0.4
-0.4
-0.4
-0.5
-0.7
-0.9
-1.1
-1.3
-1.8
-2.2
-2.7
1.1
1.3
1.6
1.8
2.0
2.2
2.7
3.3
4.4
5.5
6.6
8.8
11.0
13.3
2.9
3.5
4.1
4.7
5.3
5.9
7.1
8.9
11.9
–
–
–
–
–
1.1
1.3
1.6
1.8
2.0
2.2
2.7
3.3
4.4
–
–
–
–
–
6.9
8.4
9.8
11.2
12.6
14.0
16.9
21.2
28.3
35.4
42.5
56.7
70.9
85.1
3.6
4.3
5.1
5.8
6.5
7.3
8.8
11.0
14.7
18.4
22.2
29.6
37.0
44.5
8.9
10.7
12.5
14.3
16.2
18.0
21.6
27.1
36.2
45.3
54.4
72.6
90.8
109.0
13.3
16.0
18.8
21.5
24.2
26.9
32.4
40.5
54.1
67.7
81.3
108.4
135.6
162.8
20.1
24.2
28.3
32.3
36.4
40.5
48.7
61.0
81.5
102.0
122.5
163.5
204.5
245.5
31.5
38.0
44.5
51.0
57.4
63.9
76.9
96.4
128.9
161.3
193.8
258.7
323.6
388.5
4.7
5.7
6.7
7.7
8.7
9.7
11.6
14.6
19.5
24.5
29.4
39.2
49.1
58.9
2.8
3.5
4.1
4.7
5.3
5.9
7.1
8.9
11.9
14.9
17.9
23.9
29.9
35.9
6.3
7.6
8.9
10.2
11.5
12.8
15.4
19.3
25.8
32.4
38.9
51.9
65.0
78.0
8.3
10.1
11.8
13.5
15.2
16.9
20.4
25.5
34.2
42.8
51.4
68.6
85.8
103.0
13.1
15.8
18.5
21.3
24.0
26.7
32.1
40.2
53.8
67.4
80.9
108.1
135.2
162.3
19.5
23.6
27.8
31.9
36.0
40.1
48.3
60.6
81.1
101.7
122.2
163.3
204.3
245.4
Projection distance for 16:10 aspect ratio screen
Unit: feet
Unit: meters
• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.
• The zoom lens characteristics may cause slight image distortion.
• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.
• The brightness varies depending on the zoom setting.
Note: When the ET-DLE055 is mounted, the optical lens shift function cannot be used.

SPEC FILE
DLP™Projectors
8/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min.[m] [in] max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.14
-0.16
-0.19
-0.22
-0.25
-0.27
-0.33
-0.41
-0.55
-0.69
-0.82
-1.10
-1.37
-1.64
0.31
0.37
0.44
0.50
0.56
0.62
0.75
0.93
1.25
1.56
1.87
2.49
3.11
3.74
0.90
1.09
1.28
1.46
1.65
1.84
2.22
2.79
3.73
–
–
–
–
–
0.31
0.37
0.44
0.50
0.56
0.62
0.75
0.93
1.25
–
–
–
–
–
2.18
2.62
3.07
3.51
3.96
4.40
5.29
6.63
8.86
11.08
13.31
17.76
22.21
26.67
1.12
1.35
1.59
1.82
2.05
2.29
2.75
3.45
4.62
5.78
6.94
9.27
11.60
13.93
2.78
3.35
3.92
4.49
5.06
5.63
6.77
8.49
11.34
14.19
17.04
22.75
28.46
34.16
4.18
5.03
5.88
6.73
7.58
8.44
10.14
12.69
16.95
21.21
25.46
33.98
42.49
51.00
6.29
7.57
8.85
10.14
11.42
12.71
15.27
19.13
25.55
31.97
38.39
51.23
64.07
76.91
9.87
11.90
13.94
15.97
18.01
20.04
24.11
30.21
40.38
50.54
60.71
81.05
101.39
121.73
1.49
1.80
2.11
2.42
2.72
3.03
3.65
4.58
6.12
7.66
9.21
12.29
15.38
18.46
0.89
1.08
1.27
1.46
1.65
1.84
2.21
2.78
3.72
4.66
5.60
7.48
9.36
11.24
1.97
2.38
2.79
3.19
3.60
4.01
4.83
6.05
8.10
10.14
12.18
16.27
20.36
24.44
2.62
3.15
3.69
4.23
4.77
5.31
6.39
8.01
10.70
13.40
16.09
21.48
26.87
32.26
4.11
4.96
5.81
6.66
7.51
8.36
10.06
12.61
16.86
21.11
25.36
33.86
42.35
50.85
6.13
7.42
8.70
9.99
11.28
12.56
15.14
19.00
25.43
31.86
38.29
51.16
64.02
76.89
Screen size
(diagonal)
min. max. min. max.
Zoom
Zoom
lenses
Fixed-focus
Fixed-
focus
lens
Distance to screen (L) Height from the edge
of screen to
center of lens (H)
min. max. min. max. min. max.
ET-DLE150
Zoom lens
min. max.
ET-DLE085
Zoom lens
Supplied lens ET-DLE250
Zoom lens
ET-DLE350
Zoom lens
ET-DLE450
Zoom lens
ET-DLE055
Fixed-focus
lens
1.27
1.52
1.78
2.03
2.29
2.54
3.05
3.81
5.08
6.35
7.62
10.16
12.70
15.24
[m] [in]
50
60
70
80
90
100
120
150
200
250
300
400
500
600
/
/
/
/
/
/
/
/
/
/
/
/
/
/
–
–
–
–
–
–
–
–
–
–
–
–
–
–
-0.5
-0.5
-0.6
-0.7
-0.8
-0.9
-1.1
-1.3
-1.8
-2.3
-2.7
-3.6
-4.5
-5.4
1.0
1.2
1.4
1.6
1.8
2.0
2.5
3.1
4.1
5.1
6.1
8.2
10.2
12.3
2.9
3.6
4.2
4.8
5.4
6.0
7.3
9.1
12.2
–
–
–
–
–
1.0
1.2
1.4
1.6
1.8
2.0
2.5
3.1
4.1
–
–
–
–
–
7.1
8.6
10.1
11.5
13.0
14.4
17.4
21.7
29.1
36.4
43.7
58.3
72.9
87.5
3.7
4.4
5.2
6.0
6.7
7.5
9.0
11.3
15.1
19.0
22.8
30.4
38.1
45.7
9.1
11.0
12.9
14.7
16.6
18.5
22.2
27.8
37.2
46.6
55.9
74.6
93.4
112.1
13.7
16.5
19.3
22.1
24.9
27.7
33.3
41.6
55.6
69.6
83.5
111.5
139.4
167.3
20.6
24.8
29.0
33.3
37.5
41.7
50.1
62.7
83.8
104.9
125.9
168.1
210.2
252.3
32.4
39.1
45.7
52.4
59.1
65.7
79.1
99.1
132.5
165.8
199.2
265.9
332.6
399.4
4.9
5.9
6.9
7.9
8.9
9.9
12.0
15.0
20.1
25.1
30.2
40.3
50.5
60.6
2.9
3.5
4.2
4.8
5.4
6.0
7.3
9.1
12.2
15.3
18.4
24.5
30.7
36.9
6.5
7.8
9.1
10.5
11.8
13.2
15.8
19.9
26.6
33.3
40.0
53.4
66.8
80.2
8.6
10.3
12.1
13.9
15.7
17.4
21.0
26.3
35.1
44.0
52.8
70.5
88.2
105.9
13.5
16.3
19.1
21.9
24.6
27.4
33.0
41.4
55.3
69.3
83.2
111.1
139.0
166.8
20.1
24.3
28.6
32.8
37.0
41.2
49.7
62.3
83.4
104.5
125.6
167.8
210.0
252.2
Projection distance for 16:9 aspect ratio screen
Unit: feet
Unit: meters
• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.
• The zoom lens characteristics may cause slight image distortion.
• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.
• The brightness varies depending on the zoom setting.
Note: When the ET-DLE055 is mounted, the optical lens shift function cannot be used.

SPEC FILE
DLP™Projectors
9/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Calculation of the projection distance
For a screen size different from the above, use the equation below to calculate the projection distance.
• Distances calculated with the above equations will include a slight error.
minimum L (m) = (diagonal screen size in inches) × 0.0183 - 0.0471
maximum L (m) = (diagonal screen size in inches) × 0.0227 - 0.0442
minimum L (m) = (diagonal screen size in inches) × 0.0300 - 0.0540
maximum L (m) = (diagonal screen size in inches) × 0.0433 - 0.0498
minimum L (m) = (diagonal screen size in inches) × 0.0398 - 0.0746
maximum L (m) = (diagonal screen size in inches) × 0.0555 - 0.0725
minimum L (m) = (diagonal screen size in inches) × 0.0524 - 0.0800
maximum L (m) = (diagonal screen size in inches) × 0.0828 - 0.0792
minimum L (m) = (diagonal screen size in inches) × 0.0827 - 0.1351
maximum L (m) = (diagonal screen size in inches) × 0.1249 - 0.1346
minimum L (m) = (diagonal screen size in inches) × 0.1251 - 0.3017
maximum L (m) = (diagonal screen size in inches) × 0.1979 - 0.2991
(fixed focus) L (m) = (diagonal screen size in inches) × 0.0184 - 0.0476
ET-DLE085
ET-DLE150
Supplied lens
ET-DLE250
ET-DLE350
ET-DLE450
ET-DLE055
Aspect ratio 16:9
Aspect ratio 16:10
minimum L (m) = (diagonal screen size in inches) × 0.0188 - 0.0471
maximum L (m) = (diagonal screen size in inches) × 0.0233 - 0.0442
minimum L (m) = (diagonal screen size in inches) × 0.0309 - 0.0540
maximum L (m) = (diagonal screen size in inches) × 0.0445 - 0.0498
minimum L (m) = (diagonal screen size in inches) × 0.0409 - 0.0746
maximum L (m) = (diagonal screen size in inches) × 0.0571 - 0.0725
minimum L (m) = (diagonal screen size in inches) × 0.0539 - 0.0800
maximum L (m) = (diagonal screen size in inches) × 0.0851 - 0.0792
minimum L (m) = (diagonal screen size in inches) × 0.0850 - 0.1351
maximum L (m) = (diagonal screen size in inches) × 0.1284 - 0.1346
minimum L (m) = (diagonal screen size in inches) × 0.1286 - 0.3017
maximum L (m) = (diagonal screen size in inches) × 0.2034 - 0.2991
(fixed focus) L (m) = (diagonal screen size in inches) × 0.0189 - 0.0476
ET-DLE085
ET-DLE150
Supplied lens
ET-DLE250
ET-DLE350
ET-DLE450
ET-DLE055

SPEC FILE
DLP™Projectors
10/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
H
(Width of
projected image)
V
(Height of
projected image)
0.6V
0.1H0.1H
Standard postition
of projected image
H
(Width of
V
(Height of
projected image)
0.6V
0.1H0.1H
Standard postition
of projected image
Shift range
Optical axis shift function allows to shift the position of a projected image as shown below.
• Floor mount
(When the lens except the ET-DLE085 is mounted.)
• Ceiling mount
(When the lens except the ET-DLE085 is mounted.)
H
(Width of
projected image)
V
(Height of
projected image)
0.6V
0.5V
0.1H0.1H
Standard postition
of projected image H
(Width of
projected image)
V
(Height of
projected image)
0.6V
0.5V
0.1H0.1H
Standard postition
of projected image
• Floor mount
(When the ET-DLE085 is mounted.)
• Ceiling mount
(When the ET-DLE085 is mounted.)
• The ET-DLE055 has a fixed short-focus lens. Therefore, the lens shift function provided in the main unit cannot be used.

SPEC FILE
DLP™Projectors
11/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
-15°
+15°
Installable angle
Install the projector at an angle within the range shown below.
• Vertical direction
The projector may be installed at a vertical
angle of 360°.
• Horizontal direction
The projector may be installed at a horizontal
angle of ±15°.
-15°
+15°
• Vertical direction in portrait mode with the
ET-LAD120P/LAD120PW mounted
The projector may be installed at a vertical
angle of ±15°.
• Horizontal direction in portrait mode with
the ET-LAD120P/LAD120PW mounted
The projector may be installed at a horizontal
angle of ±15°.
NOTE: The projector cannot be vertically installed all by itself. Also, the terminal side must face downward when vertically installed.
360°
-15°
+15°

SPEC FILE
DLP™Projectors
12/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
List of compatible signals
The signals that can be input to this projector are shown in the table below. Horizontal scanning fre-
quencies of 15 kHz to 100 kHz, vertical scanning frequencies of 24 Hz to 120 Hz, and a dot clock of
162 MHz maximum can be input.
NOTE: The native resolution of this projector is 1,920 × 1,200 pixels. If the display resolution of the input signal is different from the
native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.
Display mode Display
resolution
(dots)*
Scanning frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
Format
720 × 480i
720 × 576i
720 × 480i
720 × 576i
720 × 483
720 × 576
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 400
640 × 480
800 × 600
832 × 624
1024 × 768
1152 × 864
1152 × 870
15.7
15.6
15.7
15.6
31.5
31.3
45.0
37.5
33.8
28.1
27.0
28.1
33.8
67.5
56.3
31.5
37.9
31.5
35.0
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
49.7
39.6
48.4
56.5
60.0
65.5
68.7
81.4
98.8
53.7
64.0
67.5
77.1
68.7
59.9
50.0
59.9
50.0
59.9
50.0
60.0
50.0
60.0
50.0
24.0
27.0 48.0
25.0
30.0
60.0
50.0
70.1
85.1
59.9
66.7
72.8
75.0
85.0
56.3
60.3
72.2
75.0
85.1
74.6
50.0
60.0
70.1
75.0
81.6
85.0
100.0
120.0
60.0
70.0
74.9
85.0
75.1
−
−
13.5
13.5
27.0
74.3
148.5
25.2
31.5
25.2
30.2
31.5
31.5
36.0
36.0
40.0
50.0
49.5
56.3
57.3
51.9
65.0
75.0
78.8
86.0
94.5
113.3
139.1
81.6
94.2
108.0
119.7
100.0
NTSC/NTSC4.43/PAL-M/PAL60
PAL/PAL-N/SECAM
525i (480i)
625i (576i)
525p (480p)
625p (576p)
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
VGA400
VGA480
SVGA
MAC16
XGA
MXGA
MAC21
VIDEO/S-VIDEO
YCBCR/RGB
720(1440) × 480i
720(1440) × 576i
15.7
15.6
59.9
50.0
27.0
525i (480i)
625i (576i)
HDMI/DVI-D
YCBCR/RGB/
HDMI/DVI-D
YPBPR/RGB/
HDMI/DVI-D
HDMI/DVI-D/RGB
*The “i” appearing after the resolution indicates an interlaced signal.

SPEC FILE
DLP™Projectors
13/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Display mode Display
resolution
(dots)*1
Scanning frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
Format
1280 × 720
1280 × 768
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
37.1
44.8
76.3
92.6
39.6
47.8
47.4
60.3
68.6
41.3
49.7
49.3
62.8
71.6
60.0
52.4
64.0
72.3
78.2
80.0
91.1
47.7
39.6
54.1
64.0
65.2
65.3
78.8
82.2
55.9
46.3
75.0
65.3
54.1
55.6
66.6
67.2
61.8
74.0
74.6
49.8
59.9
100.0
120.0
49.9
59.9
60.0
74.9
84.9
50.0
59.8
59.9
74.9
84.9
60.0
50.0
60.0
66.3
72.0
75.0
85.0
59.8
49.9
50.0
60.0
60.0
60.0
60.0
72.0
75.0
59.9
49.9
60.0
50.0
49.9
59.9
60.0
49.9
60.0
59.9
60.5
74.5
131.8
161.6
65.3
79.5
68.3
102.3
117.5
68.0
83.5
71.0
106.5
122.5
108.0
88.0
108.0
125.0
135.1
135.0
157.5
85.5
69.0
99.9
108.0
122.6
121.8
149.3
155.9
106.5
86.8
162.0
146.3
119.5
141.5
138.5
173.0
158.3
154.0
193.3
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366×768
SXGA+
WXGA+
UXGA60
WSXGA+
1920×1080
WUXGA
RGB/HDMI/DVI-D
RGB
RGB/HDMI/DVI-D
RGB
*2
*2
*2
*2
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
NOTE: DIGITAL LINK and HDMI inputs share the same compatible signal.

SPEC FILE
DLP™Projectors
14/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
List of compatible 3D signals
The 3D signals that can be input to this projector are shown in the table below.
Yes
Yes
Yes
–
–
Yes
Yes
–
Yes
–
––
Yes
Yes
–
Yes Yes
–
Yes
–
Yes
–
Display mode Display
resolution
(dots)*1
Scanning
frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz) Frame
packing
HDMI
Side by
side*2Top and
bottom
Side by
side*2
DVI
Top and
bottom
Line by
line
Frame
sequen-
tial
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 480
800 × 600
1024 × 768
1152 × 864
1280 × 720
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
45.0
37.5
33.8
28.1
27.0
27.0
28.1
33.8
67.5
56.3
31.5
37.9
39.6
48.4
81.4
98.8
53.7
37.1
44.8
76.3
92.6
39.6
47.8
47.4
41.3
49.7
49.3
60.0
52.4
64.0
47.7
39.6
54.1
64.0
65.2
65.3
55.9
46.3
75.0
65.3
54.1
55.6
66.6
61.8
74.0
60.0
50.0
60.0
50.0
24.0
48.0
25.0
30.0
60.0
50.0
59.9
60.3
50.0
60.0
100.0
120.0
60.0
49.8
59.9
100.0
120.0
49.9
59.9
60.0
50.0
59.8
59.9
60.0
50.0
60.0
59.8
49.9
50.0
60.0
60.0
60.0
59.9
49.9
60.0
60.0
50.0
49.9
59.9
49.9
60.0
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
148.5
148.5
25.2
40.0
51.9
65.0
113.3
139.1
81.6
60.5
74.5
131.8
161.6
65.3
79.5
68.3
68.0
83.5
71.0
108.0
88.0
108.0
85.5
69.0
99.9
108.0
122.6
121.8
106.5
86.8
162.0
146.3
119.5
141.5
138.5
158.3
154.0
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
VGA480
SVGA
XGA
MXGA
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366 × 768
SXGA+
WXGA+
UXGA60
WSXGA+
1920 × 1080
WUXGA
*3
*3
*3
*3
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compatible with half-resolution signals.
*3 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
–
Yes Yes Yes
Yes
Yes Yes Yes
–
––– – –
––– – – –
–
Yes
–
Yes
Yes Yes Yes Yes Yes Yes
–
Yes
–

SPEC FILE
DLP™Projectors
15/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Yes
–
Yes
–
Yes
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
–
Yes
Yes
–
––
––
Yes Yes
Yes Yes
Yes
Display mode Display
resolution
(dots)*1
Scanning
frequency
H
(kHz)
V
(kHz)
Dot clock
frequency
(MHz)
RGB1/RGB2
Side
by
side*2
Top
and
bottom
Simul-
taneous
Simul-
taneous
HDMI
& DVI
RGB1
&
RGB2
Line
by
line
Frame
sequen-
tial
1280 × 720
1920 × 1080i
1920 × 1080
1920 × 1080i
1920 × 1080
640 × 480
800 × 600
1024 × 768
1152 × 864
1280 × 720
1280 × 768
1280 × 768
1280 × 800
1280 × 800
1280 × 960
1280 × 1024
1366 × 768
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1080
1920 × 1080
1920 × 1200
1920 × 1200
45.0
37.5
33.8
28.1
27.0
27.0
28.1
33.8
67.5
56.3
31.5
37.9
39.6
48.4
81.4
98.8
53.7
37.1
44.8
76.3
92.6
39.6
47.8
47.4
41.3
49.7
49.3
60.0
52.4
64.0
47.7
39.6
54.1
64.0
65.2
65.3
55.9
46.3
75.0
65.3
54.1
55.6
66.6
61.8
74.0
60.0
50.0
60.0
50.0
24.0
48.0
25.0
30.0
60.0
50.0
59.9
60.3
50.0
60.0
100.0
120.0
60.0
49.8
59.9
100.0
120.0
49.9
59.9
60.0
50.0
59.8
59.9
60.0
50.0
60.0
59.8
49.9
50.0
60.0
60.0
60.0
59.9
49.9
60.0
60.0
50.0
49.9
59.9
49.9
60.0
74.3
74.3
74.3
74.3
74.3
74.3
74.3
74.3
148.5
148.5
25.2
40.0
51.9
65.0
113.3
139.1
81.6
60.5
74.5
131.8
161.6
65.3
79.5
68.3
68.0
83.5
71.0
108.0
88.0
108.0
85.5
69.0
99.9
108.0
122.6
121.8
106.5
86.8
162.0
146.3
119.5
141.5
138.5
158.3
154.0
VGA480
SVGA
XGA
MXGA
1280 × 720
1280 × 768
1280 × 800
MSXGA
SXGA
1366 × 768
SXGA+
WXGA+
UXGA60
WSXGA+
1920 × 1080
WUXGA
*3
*3
*3
*3
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 Compatible with half-resolution signals.
*3 Compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/24p
1125 (1080)/24sF
1125 (1080)/25p
1125 (1080)/30p
1125 (1080)/60p
1125 (1080)/50p
NOTE: DIGITAL LINK and HDMI inputs share the same compatible signal.

SPEC FILE
DLP™Projectors
16/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Serial connector
The serial connector complies with RS-232C. To control the projector from a personal computer, com-
mands must be input through communication software, based on the format and satisfying the commu-
nication conditions shown below.
Basic format
Transmission from the computer begins with STX, then the ID, command, parameter, and ETX are sent
in this order. Add parameters according to the details of control.
Communication conditions (factory setting)
Pin assignments and signal names
D-sub 9-pin (female) Serial input
Description
NC
Send data
Receive data
NC
Ground
Signal name
–
TXD
RXD
–
GND
No.
1
2
3
4
5
Description
NC
Connected internally
Connected internally
NC
Signal name
–
CTS
RTS
–
No.
6
7
8
9
Pin assignments and signal names
D-sub 9-pin (male) Serial output
Description
NC
Receive data
Send data
NC
Ground
Signal name
–
RXD
TXD
–
GND
No.
1
2
3
4
5
Description
NC
Connected internally
Connected internally
NC
Signal name
–
RTS
CTS
–
No.
6
7
8
9
CAUTION
• It may not be possible to send or receive commands for about 10 to 60 seconds when the lamp is first turned on. If this
occurs, wait for 60 seconds, then try sending or receiving again.
• When sending multiple commands, be sure to wait for at least 0.5 second after receiving a response from the projector before
sending the next command.
• Additional time is sometimes required for response due to processing inside the projector. Set the time-out period for com-
mand response to 10 seconds or more.
• When using two or more units:
1) Set different IDs for each unit.
2) Designate only one unit as RESPONSE (ID ALL) ON and the rest as RESPONSE (ID ALL) OFF.
3) Each group should have only one RESPONSE (ID GROUP) ON and the rest should be RESPONSE (ID GROUP) OFF.
Start
(1 byte)
End
(1 byte)
Colon
(1 byte)
Semicolon
(1 byte)
(2 byte)
ID designator
01 to 64: Address number
0A to 0Z: Group ID
ZZ: All units (ID ALL)
ID: 2 characters
(2 bytes) Parameters
(undefined length)
Command
(3 bytes)
(Control and/or query commands)
STX ETXC1 P1 P2 ... PnC2A D I1 I2 C3 :;
Signal level
Synchronization method
Baud rate
Parity
Character length
Stop bit
X parameter
S parameter
RS-232C-compliant
Start-stop synchronization
9,600 bps
None
8 bits
1 bit
None
None

SPEC FILE
DLP™Projectors
17/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Control commands
Command : Parameter Function Callback
PON
POF
IIS:DL1
IIS:HD1
IIS:DVI
IIS:RG1
IIS:RG2
IIS:VID
LPM:0
LPM:1
LPM:2
LPM:3
VXX:RYC1=+00000
VXX:RYC1=+00001
OLP:0
OLP:1
VSE:1
VSE:2
VSE:5
VSE:6
VSE:10
OSH:0
OSH:1
OAS
VPM:NAT
VPM:STD
VPM:DYN
VPM:CIN
VPM:GRA
VPM:DIC
VXX:DLVI0=+00000
VXX:DLVI0=+00001
VXX:DLVI0=+00002
VXX:DLVI0=+00003
TSD:y1y2y3y4m1m2d1d2w
TST:h1h2m1m2s1s2
OOS:0
OOS:1
Standby power on
Standby power off
DIGITAL LINK
HDMI
DVI
RGB 1
RGB 2
Video
Dual (two lamps)
Single lamp
Lamp 1
Lamp 2
RGB/YCBCR/RGB
S-Video
Normal
Eco
Standard/VID Auto
4:3
16:9
HV fit
V fit
Shutter off
Shutter on
Natural
Standard
Dynamic
Cinema
Graphic
DICOM
Off
1
2
3
Date setting
Time setting
On-screen display off
On-screen display on
POWER (STANDBY)
INPUT SELECT
LAMP SELECT
Lamp power
ASPECT RATIO
SWITCHING
RGB INPUT SETTING
SHUTTER
AUTO SETUP
PICTURE MODE
SYSTEM DAYLIGHT VIEW
DATE
TIME
ON SCREEN
PON
POF
IIS:DL1
IIS:HD1
IIS:DVI
IIS:RG1
IIS:RG2
IIS:VID
LPM:0
LPM:1
LPM:2
LPM:3
VXX:RYC1=+00000
VXX:RYC1=+00001
OLP:0
OLP:1
VSE:1
VSE:2
VSE:5
VSE:6
VSE:9 H fit VSE:9
VSE:10
IIS:DL1:HD1
IIS:DL1:HD2
IIS:DL1:PC1
IIS:DL1:PC2
IIS:DL1:SVD
HDMI 1
HDMI 2
Computer 1
Computer 2
S-Video
IIS:DL1:HD1
IIS:DL1:HD2
IIS:DL1:PC1
IIS:DL1:PC2
IIS:DL1:VID Video IIS:DL1:VID
IIS:DL1:SVD
OSH:0
OSH:1
OAS
VPM:NAT
VPM:STD
VPM:DYN
VPM:CIN
VPM:GRA
VPM:709 Rec.709 VPM:709
VPM:DIC
VXX:DLVI0=+00000
VXX:DLVI0=+00001
VXX:DLVI0=+00002
TSD:y1y2y3y4m1m2d1d2w
TST:h1h2m1m2s1s2
OOS:0
OOS:1
Cable specifications
* Do not send PON, POF, or OSH commands continuously in a short period of time. Doing so may burst the lamp or shorten the lamp replacement cycle.
* When a command that cannot be executed during standby mode is sent, the projector will send an ER401 command in reply.
When an ET-YFB100G
digital interface box is
connected, the
ET-YFB100G input
switches at the same time
as input is switched to the
digital link input.
OTE:10
OTE:3200
Default
3200K
COLOR TEMPERATURE
OTE:10
OTE:9 User 2 OTE:9
OTE:4 User 1 OTE:4
OTE:3200
OTE:9200
OTE:9300
3200K
3200K
OTE:9200
: : :
OTE:3300 3200K OTE:3300
OTE:9300

SPEC FILE
DLP™Projectors
18/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Status request commands
Command:Parameter Function DescriptionCallback
QPW
QSH
QIN
QOS
QST
Q$L:1
Q$L:2
QSL
QPM
QVX:DLVI0
QTM:0
QTM:1
QTM:2
QGD
QGT
Main power status
Shutter function status
Input signal status
On-screen display status
Projector run time
Lamp 1 run time
Lamp 2 run time
Lamp operation mode status
Picture mode status
System daylight view status
Temperature status
Date setting status
Time setting status
Off
On
Off
On
DIGITAL LINK
HDMI
DVI
RGB 1
RGB 2
Video
Off
On
00000h–99999h
0000h–9999h
0000h–9999h
Dual (two lamps)
Single lamp
Natural
Standard
Dynamic
Cinema
Graphic
DICOM
Off
1
2
3
p0 = Intake air
p1 = Around lamp
p2 = Optics module
yyyymmdd (day of week)*2
hhmmss *3
000
001
0
1
DL1
HD1
DVI
RG1
RG2
VID
Input channel for ET-YFB100G digital
interface box during digital link
input selection
HDMI 1
HDMI 2
Computer 1
Computer 2
Video
S-Video
DL1:HD1
DL1:HD2
DL1:PC1
DL1:PC2
DL1:VID
DL1:SVD
0
1
Eco
QLP Lamp power mode status Normal
0
1
p1p2p3p4p5
p1p2p3p4
p1p2p3p4
0
1
lamp 1
2
lamp 2
3
NAT
STD
DYN
CIN
GRA
Rec. 709
709
DIC
DLVI0=+00000
DLVI0=+00001
DLVI0=+00002
DLVI0=+00003
p1p2p3p4/p5p6p7p8*1
y1y2y3y4m1m2d1d2w
h1h2m1m2s1s2
*1 p1p2p3p4: Celsius (°C), p5p6p7p8: Fahrenheit (°F)
*2 Day of week: Monday = 1, Tuesday = 2, ... Sunday = 7
*3 Set the date and time to UTC (universal time coordinated).
*When a wrong command is sent, the projector will send an ER401 or ER402 command in reply.
Command example
To set the on-screen display off, send the command as shown below.
ADZZ OOS : 0; ETX
ID Address Command
STX
Start Parameter End
NOTE: When sending commands without parameters, a colon (:) is not necessary.

SPEC FILE
DLP™Projectors
19/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Notes on projector placement and operation
The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the
following precautions.
1. Never place objects on top of the projector.
2. Make sure there is an unobstructed space of 500 mm (1 feet 8 inches) or more around the projec-
tor’s exhaust openings.
3. Do not stack projector units directly on top of one another for the purpose of multiple (stacked)
projection. When stacking projector units, be sure to provide the amount of space indicated below
between them. These space requirements also apply to installations where only one projector unit
is operating at one time and the other unit is used as a backup.
4. Make sure that nothing blocks the projector’s air intake and exhaust openings. Also, install the pro-
jector so that cool or hot air from other air conditioning equipment does not flow directly toward
the projector’s air intake or exhaust openings.
5. Do not install the projector in an enclosed space. If it is necessary to install it in an enclosed
space, add a separate ventilation system. If ventilation is insufficient, hot air will accumulate at the
intake opening. This may cause the projector’s protective circuit to interrupt projector operation.
6. If the projector is installed in an enclosed space, ensure that the projector’s intake and exhaust
openings are not blocked. Take particular care to ensure that hot air from the exhaust openings is
not sucked into the intake openings.
7. When installing the projector in any manner other than floor mounting with the adjuster legs, use
the six threaded ceiling mount holes (screw diameter: M6, projector interior thread length: 12 mm)
to secure the projector.
500 mm (1 ft 8 in)
or more
500 mm (1 ft 8 in)
or more
500 mm (1 ft 8 in)
or more
Do not stack projector
units directly on top of
one another.
100 mm
(3-15/16 in)
or more
Do not support
the projector unit
by its top while
it is in use.

SPEC FILE
DLP™Projectors
20/20
PT-DW830K/DW830W/DW830LK/DW830LW
As of May 2013
SFD13M005
Operating the projector continuously
1. If the projector is to be operated continuously for one week, use the dual-lamp optical system's alternat-
ing lamp operation (lamp relay) function. The projector cannot be operated continuously one week in
dual-lamp mode. Allow a minimum of two hours per day of non-operation time for each lamp if the pro-
jector is to be operated continuously for more than one week.
2. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short
periods.
Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.
Product availability differs depending on region and country. This product may be subject to export control regulations.
DLP and the DLP logo are trademarks of Texas Instruments.
P
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
JLink is a registered trademark, or a trademark application has been filed, in Japan, the United States, and other countries and regions.
All other trademarks are the property of their respective trademark owners.
Direction of air intake and exhaust
Intake
Exhaust
