SNMP MIB manual
for i-PRO camera
Ver. 3
Panasonic i-PRO Sensing Solutions Co., Ltd.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
2
Change history
Version
Date
Chapter #
Comment
Trigger
3
6/10/2020
Added MIB explanation for Trap
Trap function added
2.1
10/18/2019
First release

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
3
Copyright Notice
This document is copyright protected and Panasonic i-PRO Sensing Solutions Co., Ltd. reserves
all titles and rights in the document. Nobody can copy, reproduce, distribute, or modify this
document in any way without the prior written consent of Panasonic i-PRO Sensing Solutions
Co., Ltd..

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
4
Table of contents
1. Introduction ......................................................................................................... 5
Definition........................................................................................................ 6
Target devices................................................................................................. 7
2. Overview of SNMP support for i-PRO cameras............................................................ 8
SNMP version.................................................................................................. 9
PDU-type........................................................................................................ 9
3. MIBs supported by i-PRO cameras ......................................................................... 10
Standard MIB................................................................................................ 11
Extended MIB of Panasonic Corporation ............................................................ 12
PANASONIC-MIB...................................................................................... 12
PANA-NCE-SEC........................................................................................ 13
PANA-SECURITY-MIB................................................................................ 15
PANA-CAM-MIB........................................................................................ 15
PANA-CAMTRAP-MIB ................................................................................ 42
4. Trap format ........................................................................................................ 45
SNMP general trap ......................................................................................... 46
trap native events.......................................................................................... 48
I. Appendix............................................................................................................ 50
A) extended MIB tree structure............................................................................ 50

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
5
1. Introduction
This document describes the setting information necessary for the network monitoring system
to monitor the camera using the SNMP protocol, and tips for the network administrator to
perform camera maintenance.
This document does not provide detailed descriptions of SNMP specifications or standard MIBs.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
6
Definition
Word
definition
SNMP
Simple Network Management Protocol
SNMP agent
In this document, it is a network camera.
SNMP manager
An SNMP client that can monitor an SNMP agent.
Network
monitoring
system
A system for monitoring devices connected to a network. Although the
status of network devices can be obtained not only by SNMP but also by
other methods, in this document, what has a function as an SNMP
manager is expressed as a network monitoring system.
Network
administrator
An administrator who receives network device error notifications issued
by the network monitoring system and performs maintenance according
to each device.
Native event
Event notification function that already exists in i-PRO cameras. The
settings can be changed by setting screen accessed and displayed by a
web browser, CGI, or a dedicated setting tool. Existing events include
terminal alarms, motion detection alarms, and command alarms.
MIB
Management Information Base
Standard MIB
MIB as defined in RFC
Extended MIB
Object ID .iso (1) .org (3) .dod (6) .internet (1) .private (4) .enterprises
(1). A MIB that defines: MIBs extended for i-PRO cameras can be
downloaded from the web page.
Object
What is uniquely defined in the MIB.
Object Name
The name of the Object.
Object ID (OID)
An ID that uniquely defines an Object when communicating with SNMP.
Index
A row heading in an SNMP table.
Version
This document refers to SNMP Version.
PDU-Type
How to get the value using SNMP. There are Get, get-next, get-response,
set, trap, inform, etc.
Panasonic
(Corporation)
Company name.
PANASONIC(-
MIB)
Name of the MIB that defines the object ID that Panasonic Corporation
applied for in the extended MIB
Panasonic
Object name defined in the PANASONIC-MIB.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
7
Target devices
The devices mentioned in this document are i-PRO EXTREME series and WV-SUD638.
This document describes the features in the latest firmware version.
The differences in functions for each model will be explained in the next chapter.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
8
2. Overview of SNMP support for i-PRO cameras
Below is a summary of the SNMP Version and PDU type support status for each model.
WV-SUD638
I-PRO EXTREME series
Version
PDU-Type:Get
PDU-Type:Set
PDU-Type:Trap
V1
Available
Not supported
Not supported
V2c
Available
Not supported
Notifiable*1
V3
Available
Not supported
Not supported
*
1
The following models do not support Trap : WV-U1113, WV-U1114, WV-U1130, WV-
U1132, WV-U1133, WV-U1134, WV-U1142, WV-U1532L, WV-U1533, WV-U1542L, WV-
U2114, WV-U2130L, WV-U2132L, WV-U2134, WV-U2140L, WV-U2142L, WV-U2530L, WV-
U2532L, WV-U2540L, WV-U2542L
Version
PDU-Type:Get
PDU-Type:Set
PDU-Type:Trap
V1
Available
Not supported
Not supported
V2c
Available
Not supported
Not supported
V3
Not supported
Not supported
Not supported

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
9
SNMP version
i-PRO EXTREME series supports v1, v2c, v3 GET. It also supports v2c Trap.
WV-SUD638 and WV-SUD638B support GET of v1 and v2c.
PDU-type
The PDU-Types supported by i-PRO cameras are shown below.
Get, Get-next, Gret-bulk:
For i-PRO camera, you can get the value of SNMP object by GET request using SNMP v1,
v2c. The i-PRO EXTREME series also supports GET of SNMPv3.
i-PRO cameras can return get-response to Get, get-next and get-bulk requests.
Trap:
You can configure the i-PRO camera to use SNMP v2c for TRAP notification. You can get the
value of the SNMP object by receiving the TRAP notification.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
10
3. MIBs supported by i-PRO cameras
The i-PRO camera responds with standard MIB (mainly mib-2) and extended MIB (panasonic).
This chapter describes the response contents of the standard MIB supported by the camera
and the OID of the extended MIB.
Overview of SNMP responses that i-PRO cameras respond to:
+ iso(1)
| + org(3)
| | + dod(6)
| | | + internet(1)
| | | | + mgmt(2)
| | | | | + mib-2(1)
| | | | | | + system(1)
| | | | | | + interfaces(2)
| | | | | | + ip(4)
| | | | | | + icmp(5)
| | | | | | + tcp(6)
| | | | | | + udp(7)
| | | | | | + snmp(11)
| | | | | | + ipv6MIB(55)
| | | | | | + ifMIB(31)
| | | | + snmpV2(6)
| | | | | + snmpModules(3)
| | | | | | + snmpUsmMIB(15)
| | | | | + enterprises(1)
| | | | | | + panasonic(258)
| | | | | | | + panasonicNetCeCommon(1)
| | | | | | | | + panaNceEq(2)
| | | | | | | + securityProducts(5100)
| | | | | | | | + nwCamera(100)
| | | | | | + nema(1206)

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
11
Standard MIB
i-PRO cameras support OID responses defined by the following standard MIBs at maximum.
SNMPv2-MIB
IF-MIB
IP-MIB
TCP-MIB
UDP-MIB
RFC1213-MIB
IPV6-MIB
IF-MIB
SNMPv2-MIB
SNMP-FRAMEWORK-MIB
SNMP-MPD-MIB
SNMP-USER-BASED-SM-MIB
SNMP-VIEW-BASED-ACM-MIB
The i-PRO camera does not support the following MIBs when requested with v1 and v2c.
SNMP-FRAMEWORK-MIB
SNMP-MPD-MIB
SNMP-USER-BASED-SM-MIB
SNMP-VIEW-BASED-ACM-MIB

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
12
Extended MIB of Panasonic Corporation
The i-PRO camera responds to the extended OID 258 acquired by Panasonic Corporation as
defined in this chapter.
The response OID changes depending on the camera's ability and status. For example, a
camera without PTZ function does not return a response to the OID defined for PTZ cameras
in the MIB.
For details on how to input the extended MIB, refer to the manual of the monitoring system
you are using.
PANASONIC-MIB
PANASONIC-MIB is OID 258 for Panasonic Corporation that has been applied to IANA,
Defines .iso (1) .org (3) .dod (6) .internet (1) .private (4) .enterprises (1) .panasonic (258).
SNMPv2-SMI and SNMPv2-TC are required to interpret this MIB.
There is no definition of OID that the camera can respond to in this MIB.
This MIB is required to read PANA-NCE-SEC, PANA-SECURITY-MIB, and PANA-CAM-MIB.
+ iso(1)
| + org(3)
| | + dod(6)
| | | + internet(1)
| | | | + private(4)
| | | | | + enterprises(1)
| | | | | | + panasonic(258)

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
13
PANA-NCE-SEC
PANA-NCE-SEC defines .iso (1) .org (3) .dod (6) .internet (1) .private (4) .enterprises
(1) .panasonic (258) .panasonicNetCeCommon (1) And 4 responsive OIDs are defined.
To read this MIB, PANASONIC-MIB, SNMPv2-SMI, and SNMPv2-TC are required.
Summary of MIBs defined in PANA-NCE-SEC:
.iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).panasonic(258)
+ panasonic(258)
| + panasonicNetCeCommon (1)
| | + panaNceEq(2)
| | | + panaNceEqGeneral(1)
| | | | + panaNceEqGeneralVendorName(1)
| | | | + panaNceEqGeneralModel(2)
| | | | + panaNceEqGeneralDayTime(10)
| | | | + panaNceEqGeneralSerialNum(13)
panaNceEqGeneralVendorName(1)
objectName
panaNceEqGeneralVendorName
object id
.1.3.6.1.4.1.258.1.2.1.1
SYNTAX RANGE
DisplayString (SIZE (0..63))
DESCRIPTION
Vendor name
“Panasonic”
panaNceEqGeneralModel(2)
objectName
panaNceEqGeneralModel
object id
.1.3.6.1.4.1.258.1.2.1.2
SYNTAX RANGE
DisplayString (SIZE (0..47))
DESCRIPTION
Model number

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
14
panaNceEqGeneralDayTime(10)
objectName
panaNceEqGeneralDayTime
object id
.1.3.6.1.4.1.258.1.2.1.10
SYNTAX RANGE
DateAndTime
DESCRIPTION
Current time of the device
▪Restrictions
-12 hours notation, but can't get AM and PM
panaNceEqGeneralSerialNum(13)
objectName
panaNceEqGeneralSerialNum
object id
.1.3.6.1.4.1.258.1.2.1.13
SYNTAX RANGE
DisplayString (SIZE (0..47))
DESCRIPTION
Serial number of the device

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
15
PANA-SECURITY-MIB
This MIB defines securityProducts(5100) under panasonic(258).
To read this MIB, PANASONIC-MIB, SNMPv2-SMI, and SNMPv2-TC are required.
There is no definition of OID that the camera can respond to in this MIB.
This MIB is required to read the PANA-CAM-MIB.
.iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).panasonic(258)
+ panasonic(258)
| + securityProducts(5100)
PANA-CAM-MIB
To read this MIB, PANASONIC-MIB, PANA-SECURITY-MIB, SNMPv2-SMI, and SNMPv2-TC are
required.
Summary of MIBs defined in PANA-CAM-MIB:
+ panasonic(258)
| | + nwCamera(100)
| | | + camCapabilities(1)
| | | | + camInformation(1)
| | | | + powerSupply(2)
| | | | + imageSensor(5)
| | | | + rs485(7)
| | | | + inputOutputTerminal(8)
| | | | + camOther(9)
| | | | + storage(10)
| | | | + temperatureSensor(11)
| | | | + image(12)
| | | | + ptz (13)
| | | | + wiper(14)
| | | | + irLED(15)
| | | | + fan(16)
| | | | + heater(17)
| | | | + defroster(18)

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
16
3.2.4.1. General
General Information
PANA-CAM-MIB
+ panasonic(258)
| + securityProducts(5100)
| | + nwCamera(100)
| | | + camCapabilities(1)
| | | | + camInformation1)
| | | | | + camType(2)
| | | | | + camFisheye(5)
| | | | | + hardwareSelfDiagnosisMain(6)
| | | | | + hardwareSelfDiagnosisCamera(7)
| | | | | + camHourMeter(9)
camType
objectName
camType
object id
.1.3.6.1.4.1.258.5100.100.1.1.2
SYNTAX RANGE
DisplayString (SIZE (0..255))
DESCRIPTION
Camera type
▪Response example
-"fixed", "dome", "fixed_dome"
camFisheye
objectName
camFisheye
object id
.1.3.6.1.4.1.258.5100.100.1.1.5
SYNTAX RANGE
DisplayString (SIZE (0..255))
DESCRIPTION
In the case of a fisheye camera, respond “yes”.
▪Only fisheye cameras respond

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
17
hardwareSelfDiagnosisMain, hardwareSelfDiagnosisCamera
Self check
objectName
hardwareSelfDiagnosisMain
object id
.1.3.6.1.4.1.258.5100.100.1.1.6
SYNTAX RANGE
DisplayString (SIZE (0..255))
DESCRIPTION
Hardware1 Self check
objectName
hardwareSelfDiagnosisCamera
object id
.1.3.6.1.4.1.258.5100.100.1.1.7
SYNTAX RANGE
DisplayString (SIZE (0..255))
DESCRIPTION
Hardware2 Self check
▪Recommended monitoring method
-Normal when all values are 0-, and abnormal status if a number other than 0 is
answered. It is recommended to get a value every few hours and monitor the change
of the value
▪When an error notification is received from the network monitoring system
-Refer to the instruction manual for each model
camHourMeter
objectName
camHourMeter
object id
.1.3.6.1.4.1.258.5100.100.1.1.9
SYNTAX
RANGE
DisplayString (SIZE(0..4))
DESCRIPTION
Years and months since the camera was manufactured.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
18
3.2.4.2. Power
PANA-CAM-MIB
+ panasonic(258)
| + securityProducts(5100)
| | + nwCamera(100)
| | | + camCapabilities(1)
| | | | + PowerSupply(2)
| | | | | + pwState(1)
| | | | | + pwSupplyCount(2)
| | | | | + pwSupplyCountLimit(3)
| | | | | + pwType(6)
pwState
objectName
pwState
object id
.1.3.6.1.4.1.258.5100.100.1.2.1
SYNTAX RANGE
INTEGER { OK(1), Disabled(2), Warning(3), Failed(4) }
DESCRIPTION
Power status
Responds with a value other than 1 (OK) when the number of power ON times exceeds Limit
times.
▪Recommended monitoring method
-Check at periodic power-on or restart timing due to setting changes, etc.
pwSupplyCount
objectName
pwSupplyCount
object id
.1.3.6.1.4.1.258.5100.100.1.2.2
SYNTAX RANGE
Unsigned32
DESCRIPTION
Power-on count
pwSupplyCountLimit
objectName
pwSupplyCountLimit
object id
.1.3.6.1.4.1.258.5100.100.1.2.3
SYNTAX RANGE
Unsigned32
DESCRIPTION
The limit value of pwSupplyCount.
Responds when pwState is other than 1 (OK) when the number of power ON times exceeds
Limit times.
▪Note
-Currently, the value setting is not supported.

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
19
pwType
objectName
pwType
object id
.1.3.6.1.4.1.258.5100.100.1.2.6
SYNTAX RANGE
INTEGER { ok(1), Disabled(2), warning(3), Failed(4) }
DESCRIPTION
The type of power supply currently in use.
▪Recommended monitoring method
-WV-X6533L, WV-S6532L, WV-X6531N, WV-X6511N, WV-SUD638
○Connect to the correct power supply and check if there is any change during
operation from the response string obtained first.
-Fixed cameras, fisheye cameras, cameras other than those listed above
○Even if the power is disconnected, there is no functional limitation as long as PoE
is connected.
○If you want to check for unintended power supply replacement, perform regular
monitoring.
▪When an error notification is received from the network monitoring system
-WV-X6533L, WV-S6532L, WV-X6531N, WV-X6511N, WV-SUD638
○The power cable is disconnected. The temperature control function such as fan or
heater may be disabled. Make sure that the camera is connected to the correct
power.
-Fixed cameras, fisheye cameras, cameras other than those listed above
○The power supply type has been changed during operation. Check if this change is
intended

SNMP MIB manual for i-PRO camera
Panasonic i-PRO Sensing Solutions Co., Ltd.
20
3.2.4.3. imageSensor
PANA-CAM-MIB
+ panasonic(258)
| + securityProducts(5100)
| | + nwCamera(100)
| | | + camCapabilities(1)
| | | | + ImageSensor(5)
| | | | | + imgSensorNumber(1)
imgSensorNumber
objectName
imgSensorNumber
object id
.1.3.6.1.4.1.258.5100.100.1.5.1
SYNTAX RANGE
Unsigned32
DESCRIPTION
Number of image sensors
