Panasonic i-Pro WV-SP306 User manual

Before attempting to connect or operate this product, please read these
instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Lens: Option
(This illustration represents WV-SP306.)
WV-SP306
Installation Guide
Network Camera
Model No. WV-SP306, WV-SP305
WV-SP302
WV-SP306E, WV-SP305E
WV-SP302E

2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The lightning flash with arrow-
head symbol, within an equilat-
eral triangle, is intended to alert
the user to the presence of
uninsulated "dangerous volt-
age" within the product's enclo-
sure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instruc-
tions in the literature accompa-
nying the appliance.
WARNING:
• Apparatus shall be connected to a mains sock-
et outlet with a protective earthing connection.
• The mains plug or an appliance coupler shall
remain readily operable.
• To prevent fire or electric shock hazard, do not
expose this apparatus to rain or moisture.
• The apparatus should not be exposed to drip-
ping or splashing and that no objects filled
with liquids, such as vases, should be placed
on the apparatus.
• All work related to the installation of this prod-
uct should be made by qualified service per-
sonnel or system installers.
• For PERMANENTLY CONNECTED
APPARATUS provided neither with an all-pole
MAINS SWITCH nor an all-all pole circuit
breaker, the installation shall be carried out in
accordance with all applicable installation
rules.
• The connections should comply with local
electrical code.
The serial number of this product may be found
on the surface of the unit.
You should note the model number and serial
number of this unit in the space provided and
retain this book as a permanent record of your
purchase to aid identification in the event of
theft.
Model No.
Serial No.
NOTE: This equipment has been tested and
found to comply with the limits for a Class A digi-
tal device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed
and used in accordance with the instruction man-
ual, may cause harmful interference to radio com-
munications.
Operation of this equipment in a residential area
is likely to cause harmful interference in which
case the user will be required to correct the inter-
ference at his own expense.
FCC Caution: To assure continued compliance,
(example - use only shielded interface cables
when connecting to computer or peripheral
devices). Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
For U.S.A
For U.S.A
This Class A digital apparatus complies with
Canadian ICES-003.
For Canada
Power disconnection. Unit with or without ON-OFF
switches have power supplied to the unit whenev-
er the power cord is inserted into the power
source; however, the unit is operational only when
the ON-OFF switch is in the ON position. Unplug
the power cord to disconnect the main power for
all units.
UL listed model No.
WV-SP306, WV-SP305, WV-SP302

3
We declare under our sole responsibility that the product
to which this declaration relates is in conformity with the
standards or other normative documents following the
provisions of Directives 2006/95/EC and 2004/108/EC.
Nosotros declaramos bajo nuestra única responsabilidad
que el producto a que hace referencia esta declaración
está conforme con las normas u otros documentos
normativos siguiendo las estipulaciones de las directivas
2006/95/CE y 2004/108/CE.
Noi dichiariamo sotto nostra esclusiva responsabilità che
il prodotto a cui si riferisce la presente dichiarazione
risulta conforme ai seguenti standard o altri documenti
normativi conformi alle disposizioni delle direttive
2006/95/CE e 2004/108/CE.
Wir erklären in alleiniger Verantwortung, daß das Produkt,
auf das sich diese Erklärung bezieht, mit den folgenden
Normen oder normativen Dokumenten übereinstimmt.
Gemäß den Bestimmungen der Richtlinie 2006/95/EC
und 2004/108/EC.
Nous déclarons sous notre propre responsabilité que le
produit auquel se réfère la présente déclaration est
conforme aux normes spécifiées ou à tout autre
document normatif conformément aux dispositions des
directives 2006/95/CE et 2004/108/CE.
Wij verklaren als enige aansprakelijke, dat het product
waarop deze verklaring betrekking heeft, voldoet aan de
volgende normen of andere normatieve documenten,
overeenkomstig de bepalingen van Richtlijnen 2006/95/
EC en 2004/108/EC.
Vi erklærer os eneansvarlige for, at dette produkt, som
denne deklaration omhandler, er i overensstemmelse
med standarder eller andre normative dokumenter i følge
bestemmelserne i direktivene 2006/95/EC og 2004/108/
EC.
Vi deklarerar härmed vårt fulla ansvar för att den produkt
till vilken denna deklaration hänvisar är i
överensstämmelse med de standarder eller andra
normativa dokument som framställs i direktiv nr 2006/95/
EC och 2004/108/EC.
Ilmoitamme yksinomaisella vastuullamme, että tuote, jota
tämä ilmoitus koskee, noudattaa seuraavia standardeja
tai muita ohjeellisia asiakirjoja, jotka noudattavat
direktiivien 2006/95/EC ja 2004/108/EC säädöksiä.
Vi erklærer oss alene ansvarlige for at produktet som
denne erklæringen gjelder for, er i overensstemmelse
med følgende normer eller andre normgivende
dokumenter som følger bestemmelsene i direktivene
2006/95/EC og 2004/108/EC.

4
Contents
Important safety instructions...................................................................................................... 5
Limitation of liability.................................................................................................................... 6
Disclaimer of warranty................................................................................................................ 6
Preface ....................................................................................................................................... 6
About notations ......................................................................................................................... 7
Main functions............................................................................................................................ 7
About the user manuals ............................................................................................................. 8
System requirements for a PC ................................................................................................... 9
Trademarks and registered trademarks...................................................................................... 10
About copyright and license....................................................................................................... 10
Network security ........................................................................................................................ 10
Precautions ................................................................................................................................ 11
Precautions for Installation......................................................................................................... 14
Major operating controls ............................................................................................................ 16
Lens mounting............................................................................................................................ 17
Insert/remove an SDHC/SD memory card ................................................................................. 20
Installation .................................................................................................................................. 21
Connection ................................................................................................................................. 25
Configure the network settings .................................................................................................. 29
Troubleshooting.......................................................................................................................... 31
Specifications............................................................................................................................. 32
Standard accessories................................................................................................................. 35

5
Important safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instruc-
tions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other appara-
tus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combi-
nation to avoid injury from tip-over.
S3125A
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

6
Limitation of liability
THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF
THE THIRD PARTY'S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL
ERRORS. CHANGES ARE ADDED TO THE INFORMATION HEREIN, AT ANY TIME, FOR THE
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S).
Disclaimer of warranty
IN NO EVENT SHALL Panasonic System Networks Co., Ltd. BE LIABLE TO ANY PARTY OR ANY
PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT,
FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY DAMAGE AND LOSS, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT,
SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE
PRODUCT;
(2) PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE USE OR NEGLIGENT
OPERATION OF THE USER;
(3) UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT BY THE
USER;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE NOT DISPLAYED, DUE TO
ANY REASON OR CAUSE INCLUDING ANY FAILURE OR PROBLEM OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE, ARISING
OUT OF THE SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT BY ANY PERSON OR ORGANIZATION
BEING A PHOTOGENIC SUBJECT, DUE TO VIOLATION OF PRIVACY WITH THE RESULT OF
THAT SURVEILLANCE-CAMERA'S PICTURE, INCLUDING SAVED DATA, FOR SOME
REASON, BECOMES PUBLIC OR IS USED FOR THE PURPOSE OTHER THAN
SURVEILLANCE;
(7) LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE.
The network cameras WV-SP300 series are designed to operate using a PC on a network
(10BASE-T/100BASE-TX).
By connecting to a network (LAN) or the Internet, images and audio from the camera can be moni-
tored on a PC via a network.
Preface

7
Main functions
H.264/MPEG-4 and JPEG triple encoding
H.264/MPEG-4 dual stream output and JPEG output can be simultaneously provided.
* Either H.264 or MPEG-4 is selectable.
Wide dynamic range function
This function compensates brightness so that it produces clearer images even if objects have vari-
ous illumination intensities.
Important:
 • Whenthewidedynamicrangefunctionisactivated,noisemaybeincreasedinthedarkareaof
the object.
WV-SP306
 • Maximumimagecapturesize(1280x960(Aspectratioof4:3),1280x720(Aspectratioof
16:9))
 • Compatiblewiththeautobackfocus(ABF)function,colormode/black&whitemodeswitch-
ing
WV-SP305
 • Maximumimagecapturesize(1280x960(Aspectratioof4:3),1280x720(Aspectratioof
16:9))
 • Compatiblewiththefocusassist(F.A.)function,simpleblack&whitemode
WV-SP302
 • Maximumimagecapturesize(800x600(Aspectratioof4:3),640x360(Aspectratioof16:9))
 • Compatiblewiththefocusassist(F.A.)function,simpleblack&whitemode
Note:
 • It is necessary to configure the network settings of the PC and its network environment to
monitor images from the camera on the PC. It is also necessary to install a web browser on the
PC.
About notations
The following notations are used when describing the functions limited for specified models.
The functions without the notations are supported by all models.
SP306
The functions with this notation are available when using the model WV-SP306.
SP305
The functions with this notation are available when using the model WV-SP305.
SP302
The functions with this notation are available when using the model WV-SP302.

8
Auto back focus (ABF) function
SP306
AutoBackFocus(ABF)ensureseasyinstallationandstablefocusinbothcolorandblack&white
modes.
Focus assist (F. A.) function
SP305
SP302
During the manual focus adjustment, this function indicates the best focus position.
Color mode / black & white mode switching available
SP306
Images will be displayed clearly even at night since the camera will be automatically switched from
the color mode to the black and white mode under low illumination condition.
Important:
 • The operatingsound mightbeheardduringthe mode change, howeveritdoes not indicate
any malfunction.
Power over Ethernet function
When connecting with a PoE (Power over Ethernet) device, power will be supplied by simply con-
necting a LAN cable. (IEEE802.3af compliant)
Interactive communication with audio
By using the audio output connector and the microphone in connector, receiving audio from the
camera on a PC and transmitting audio from the PC to the camera is available.
SDHC/SD memory card slot equipped
It is possible to save H.264 videos and JPEG images on the SDHC/SD memory card manually at
an alarm occurrence or on a web browser.
It is also possible to save JPEG images at a network failure occurrence. (Download is possible.)
* Recommended SDHC/SD memory card (☞page 34)
About the user manuals
There are 2 sets of operating instructions for the WV-SP306, WV-SP305, WV-SP302 (NTSC model),
WV-SP306E, WV-SP305E, WV-SP302E (PAL model) as follows.
 • InstallationGuide:Explainshowtoinstallandconnectdevices.
 • Operating Instructions (PDF): Explains how to perform the settings and how to operate this
camera.
Adobe®Reader®is required to read these operating instructions (PDF) on the provided CD-ROM.
When the Adobe®Reader®is not installed on the PC, download the latest Adobe®Reader®from
the Adobe web site and install it.
"WV-SP306, WV-SP305, WV-SP302" or "SP306, SP305, SP302" shown in the instructions and
illustrations used in these operating instructions indicate the WV-SP306, WV-SP305, WV-SP302,
WV-SP306E, WV-SP305E, WV-SP302E.
The screens used in these operating instructions show the case of NTSC model.

9
System requirements for a PC
CPU: Intel®CoreTM 2 Duo 2.4 GHz or faster recommended
Memory: 512 MB or more (A minimum of 1 GB memory is required when using
Microsoft®Windows®7 or Microsoft®Windows Vista®.)
Network Interface: 10BASE-T/100BASE-TX 1 port
Audio interface: Sound card (when using the audio function)
Monitor: Image capture size: 1 024 x 768 pixels or more
Color: 24-bit True color or better
OS: Microsoft®Windows®7 Professional (64-bit)
Microsoft®Windows®7 Professional (32-bit)
Microsoft®Windows Vista®Business SP1 (32-bit)
Microsoft®Windows®XP Professional SP3
Web Browser: Windows®Internet Explorer®8.0
(Microsoft®Windows®7 Professional (32-bit/64-bit))
Windows®Internet Explorer®7.0
(Microsoft®Windows Vista®Business SP1 (32-bit))
Microsoft®Internet Explorer®6.0 SP3
(Microsoft®Windows®XP Professional SP3)
Other: CD-ROM drive
(It is necessary to read the operating instructions and use the software on
the provided CD-ROM.)
DirectX®9.0c or later
Adobe®Reader®
(It is necessary to read the operating instructions on the provided CD-ROM.)
Important:
 • When using a PC that does not meet the above requirements, displaying of images may
become slower or the web browser may become inoperable.
 • Audio may not be heard if a sound card is not installed on a PC. Audio may be interrupted
depending on the network environment.
 • Microsoft®Windows®XP Professional 64-bit Edition is not supported.
 • When using IPv6 for communication, use Microsoft®Windows®7 or Microsoft®Windows
Vista®.
Note:
 • Referto"NotesonWindowsVista®/ Windows®7" (PDF) for further information about system
requirements for a PC and precautions when using Microsoft®Windows®7 or Microsoft®
Windows Vista®.

10
Network security
As you will use this unit connected to a network, your attention is called to the following security
risks.
qLeakage or theft of information through this unit
wUse of this unit for illegal operations by persons with malicious intent
eInterference with or stoppage of this unit by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself
against the above network security risks.
 • Usethisunitinanetworksecuredbyafirewall,etc.
 • IfthisunitisconnectedtoanetworkthatincludesPCs,makesurethatthesystemisnotinfect-
ed by computer viruses or other malicious entities (using a regularly updated anti-virus pro-
gram, anti-spyware program, etc.).
 • Protectyournetworkagainstunauthorizedaccessbyrestrictinguserstothosewhologinwith
an authorized user name and password.
 • Applymeasuressuchasuserauthenticationtoprotectyournetworkagainstleakageortheftof
information, including image data, authentication information (user names and passwords),
alarm mail information, FTP server information and DDNS server information.
 • Aftertheunitisaccessedbytheadministrator,makesuretoclosethebrowser.
 • Changetheadministratorpasswordperiodically.
 • Do not install the camera in locations where the camera or the cables can be destroyed or
damaged by persons with malicious intent.
Trademarks and registered trademarks
About copyright and license
 • Microsoft,Windows,WindowsVista,InternetExplorer,ActiveXandDirectXareeitherregistered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
 • IntelandIntelCorearetrademarksorregisteredtrademarksofIntelCorporationintheUnited
States and other countries.
 • Adobe,theAdobelogo,andReaderareeitherregisteredtrademarksortrademarksofAdobe
Systems Incorporated in the United States and/or other countries.
 • SDHClogoisatrademark.
 • Other names of companies and products contained in these operating instructions may be
trademarks or registered trademarks of their respective owners.
Distributing, copying, disassembling, reverse compiling, reverse engineering, and also exporting in
violation of export laws of the software provided with this unit are expressly prohibited.

11
Precautions
Refer installation work to the dealer.
Installation work requires technique and experi-
ences. Failure to observe this may cause fire,
electric shock, injury, or damage to the prod-
uct.
Be sure to consult the dealer.
Stop the operation immediately when
something is wrong with this product.
When smoke goes up from this product or the
smell of smoke comes from this product, stop
the operation immediately and contact your
dealer.
Turn the power off immediately and contact
qualified service personnel for service.
Do not attempt to disassemble or modify
this product.
Failure to observe this may cause fire or electric
shock.
Consult the dealer for the repair or inspections.
Do not insert any foreign objects.
This could permanently damage the apparatus.
Turn the power off immediately and contact
qualified service personnel for service.
Select an installation area that can sup-
port the total weight.
Selecting an inappropriate installation surface
may cause the product to fall down or topple
over, resulting in injury.
Installation work shall be started after sufficient
reinforcement.
Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause a
fall of the product resulting in injury.
Consult the dealer for the inspections.
Do not use this product in an inflammable
atmosphere.
Failure to observe this may cause an explosion
resulting in injury.
Avoid installing this bracket in the loca-
tions where salt damage occurs or corro-
sive gas is produced.
Otherwise, the mounting portions will deterio-
rate and accidents such as a fall of this product
may occur.
The measures of protection against a fall
of this product shall be taken.
Failure to observe this may cause a drop result-
ing in injury.
Be sure to install the safety wire.
The exclusively designed mount bracket
shall be used.
Failure to observe this may cause a drop result-
ing in injury or accidents.
Use the exclusively designed mount bracket for
installation.
The screws and bolts shall be tightened to
the specified torque.
Failure to observe this may cause a drop result-
ing in injury or accidents.
Do not install this product in locations
subject to vibration.
Loosening of mounting screws or bolts may
cause a fall of the product resulting in injury.
Install this product in a location high
enough to avoid people and objects from
bumping the product.
Failure to observe this may cause a drop result-
ing in injury or accidents.
Do not strike or give a strong shock to this
product.
Failure to observe this may cause fire or injury.
Do not rub the edges of metal parts with
your hand.
Failure to observe this may cause injury.

12
Turn the power off when do wiring of this
product.
Failure to observe this may cause electric
shock.
In addition, short circuit or wrong wiring may
cause fire.
Turn the power off when cleaning of this
product.
Failure to observe this may cause injury.
[Precautions for use]
This system is designed to be used
indoors. This product is not operable out-
doors.
This product has no power switch.
When turning off the power, turn off a circuit
breaker.
To keep on using with stable performance
Do not use this camera in hot and humid con-
ditions for a long time. Failure to observe this
causes component degradation resulting in life
shortening of this product. (Recommended
operating temperature: +35 °C {95 °F} or
lower)
Do not expose this camera to direct heat
sources such as a heater.
Handle this camera with care.
Do not drop this camera, nor apply shock or
vibration to this camera. Failure to observe this
may cause trouble.
About the PC monitor
Displaying the same image on a CRT type
monitor for a long time may damage the moni-
tor. It is recommended to use a screen-saver.
When an error is detected, this product
will restart automatically.
This product will be inoperable for around 2
minutes after the restart just as when the power
is turned on.
Product disposal/transfer
Images saved on the SDHC/SD memory card
may lead to personal information leakage.
When it is necessary to dispose or give this
product to someone, even when for repair,
make sure that there is no data on the hard
disk drives.
Cleaning this product body
Be sure to turn off the power before cleaning.
Do not use strong abrasive detergent when
cleaning this camera. Otherwise, it may cause
discoloration.
When using a chemical cloth for cleaning, read
the caution provided with the chemical cloth
product.
When the dirt is hard to remove, use a
mild detergent and wipe gently.
When the dirt is hard to remove, use a mild
detergent and wipe gently. Then, wipe off the
remaining detergent with a dry cloth.
Transmission interval
Image transmission interval may become slow
depending on the network environment, PC
performance, shooting subject, access num-
ber, etc.
About SDHC/SD memory card
 • Before inserting the SDHC/SD memory
card, turn off the power of this product
first. Otherwise, it may cause malfunction
or damage data recorded on the SDHC/
SD memory card. Refer to page 20 for
descriptions of how to insert/remove an
SDHC/SD memory card.
 • When using an unformatted SDHC/SD
memory card, format it using this camera.
Recorded data on the SDHC/SD memory
card will be deleted when formatted.
If an unformatted SDHC/SD memory card
or an SDHC/SD memory card formatted
with other devices is used, this product
may not work properly or performance
deterioration may be caused. Refer to the
Operating Instructions (PDF) for how to for-
mat a SDHC/SD memory card.

13
 • When some SDHC/SD memory cards are
used with this product, the product may
not work properly or performance deterio-
ration may be caused.Use the SDHC/SD
memory cards recommended in page 34.
Code label
The code labels (accessory) are required at
inquiry for trouble. Use caution not to lose
these labels. It is recommended to paste one
of the labels onto the CD-ROM case.
Discoloration on the color filter of the
MOS image sensor
When continuously shooting a bright light
source such as a spotlight, the color filter of the
MOS image sensor may have deteriorated and
it may cause discoloration. Even when chang-
ing the fixed shooting direction after continu-
ously shooting a spotlight for a certain period,
the discoloration may remain.
MPEG-4 Visual Patent Portfolio License
This product is licensed under the MPEG-4
Visual Patent Portfolio License for the personal
and non-commercial use of a consumer for (i)
encoding video in compliance with the MPEG-
4 Visual Standard ("MPEG-4 Video") and/or (ii)
decoding MPEG-4 Video that was encoded by
a consumer engaged in a personal and non-
commercial activity and/or was obtained from a
video provider licensed by MPEG LA to provide
MPEG-4 Video. No license is granted or shall
be implied for any other use. Additional infor-
mation including that relating to promotional,
internal and commercial uses and licensing
may be obtained from MPEG LA, LLC. See
http://www.mpegla.com.
AVC Patent Portfolio License
This product is licensed under the AVC Patent
Portfolio License for the personal and non-
commercial use of a consumer to (i) encode
video in compliance with the AVC Standard
("AVC Video") and/or (ii) decode AVC Video that
was encoded by a consumer engaged in a per-
sonal and non-commercial activity and/or was
obtained from a video provider licensed to pro-
vide AVC Video. No license is granted or shall
be implied for any other use. Additional infor-
mation may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.

14
Precautions for Installation
This camera is designed to be used
indoors.
This camera is not operable outdoors.
Do not expose this camera to direct sunlight for
hours and do not install the product near a
heater or an air conditioner. Otherwise, it may
cause deformation, discoloration and malfunc-
tion. Keep this camera away from water and
moisture.
Installation place
Do not place the unit in the following places:
 • Locations where it may get wet from rain
or water splash
 • Locationswhereachemicalagentisused
such as a swimming pool
 • Locationssubjecttohumidity,dust,steam
and oil smoke
 • Locations in a specificenvironment where
a solvent or a flammable atmosphere
exists
 • Locations where a radiation, an X-ray, a
strong radio wave or a strong magnetic
field is generated
 • Locations where corrosive gas is pro-
duced, Locations where it may be dam-
aged by briny air such as seashores
 • Locations where the temperature is not
within –10 °C to +50 °C {14 °F to 122 °F}.
 • Locations subjecttovibrations(Thisprod-
uct is not designed for on-vehicle use.)
 • Locations subject to condensation as the
result of severe changes in temperature
Be sure to remove this product if it is not
in use.
Shielded (STP) LAN cables must be used
with this unit to ensure compliance with
EMC standards. *
* PAL models only
Before installation
 • The camera mount bracket described on
page 23 shall be used to mount the cam-
era.
 • When this camera and camera mount
bracket are mounted on a ceiling or a wall,
use the screws described on page 23. The
screws to be used are not provided.
Prepare the screws according to the mate-
rial, structure, strength and other factors of
the mounting area and the total weight of
objects to be mounted.
 • Ensure that the mounting surface, anchor
and screws are sufficiently strong.
 • Do not mount this product on a plaster
board or a wooden section because they
are too weak. If this product is unavoidably
mounted on such a section, the section
shall be sufficiently reinforced.
Screw tightening
 • The screws and bolts must be tightened
with an appropriate tightening torque
according to the material and strength of
the installation area.
 • Do not use an impact driver. Use of an
impact driver may damage the screws or
cause tightening excessively.
 • When a screw is tightened, make the
screw at a right angle to the surface. After
tightening the screws or bolts, perform
visual check to ensure tightening is enough
and there is no backlash.
Fall prevention measures
When the external safety wire is connected,
select a connection point resulting in that noth-
ing will hit people after the mount bracket is
damaged. The wire length shall be adjusted to
remove slack.

15
Angle adjustment
Be sure to loosen the screw of this product
mount bracket when the camera angle is
adjusted. If the camera angle is changed when
the screw is tight, excessive force is applied to
the camera mount bracket and camera, and
accordingly they may be damaged. Be sure to
tighten the screw securely after camera angle
adjustment.
Radio disturbance
When this product is used near TV/radio anten-
na, strong electric field or magnetic field (near a
motor, a transformer or a power line), images
may be distorted and noise sound may be pro-
duced.
PoE (Power over Ethernet)
Use a PoE hub/device that is compliant with
IEEE802.3af standard.
Router
When connecting this product to the Internet,
use a broadband router with the port forward-
ing function (NAT, IP masquerade).
Refer to the Operating Instructions (PDF) for
further information about the port forwarding
function.
Time & date setting
It is necessary to set the time & date before
putting this product into operation. Refer to the
"Operating Instructions (PDF)" on the provided
CD-ROM for descriptions of how to perform
the settings.

16
Major operating controls
<Side view>
<Rear view>
About the [INITIAL SET] button
After turning off the power of the camera, turn on the power of the camera while holding down this
button, and wait for around 5 seconds or more without releasing this button. Wait around 2 minutes
after releasing the button. The camera will start up and the settings including the network settings
will be initialized. Before initializing the settings, it is recommended to write down the settings in
advance.
W
ABF
SDCARD LOCK
W
Lens (option)
ALC lens connector
Tripod mount base
Auto back focus button
Slide cover
Clamp for SDHC/SD memory card
SP306
F.A.
SDCARD LOCK
Focus assist button SP305 SP302
POWER
10BASE T/100BASE-TX
AUDIO OUT MIC/LINE IN
EXT I/O
SD CARD/FOCUS ASSIST(F.A.)
MONITOR OUT
ACT LINK
12V = IN
GND 4 3 2 1
INITIAL
SET
ALARM IN
AUX OUT ALARM OUT
POWER
10BASE T/100BASE-TX
AUDIO OUT MIC/LINE IN
EXT I/O
SD CARD/ABF
MONITOR OUT
ACT LINK
12V = IN
GND 4 3 2 1
INITIAL
SET
ALARM IN / DAY/NIGHT IN
AUX OUT ALARM OUT
12 V DC power supply terminal
Monitor for adjustment
Output connector
Power indicator
Access indicator
(blinking at accessing)
Link indicator (lighting at linking)
Network connector
Audio output connector
EXT I/O terminals
INITIAL SET button
Microphone/line input connector
SDHC/SD memory card error indicator/
ABF indicator (Blinks when ABF is being
activated)
SP305 SP302
SDHC/SD memory card error indicator/
F.A. indicator
(Lights when the focus assist function
is activated or when the focus ring is
positioned near the best focus position.)
SP306

17
Lens mounting
Slowly rotate the lens clockwise to mount the lens and connect the lens cable to the ALC lens con-
nector of the camera.
Important:
SP305
SP302
 • Itisimpossibletouselenseswithoutthefocusadjustmentfunctionorzoomlenses.
Optional dedicated lens
Product name Model number
ALC lens for 1/3 inch CCD cameras WV-LZA62/2
2x vari-focal (High resolution)
* If a lens for 1/3 inch video camera other than the above is mounted and the camera is used at
resolution of 1 280 x 720 or higher, the camera cannot achieve full performance of high resolu-
tion. It is recommended to use a dedicated high-resolution lens especially when the illuminance
level of the photographic subject is low and the camera is used with the lens iris open.
How to adjust the focus
SP306
zBefore adjustment, reset the back focus position by holding down the auto back focus button
for 5 seconds or more when the power is on. (This operation can also be performed on the
setup menu. Refer to the Operating Instructions (PDF).)
xAdjust the view angle and focus coarsely by adjusting the zoom and focus of the lens to center
a subject in the screen, and then press the auto back focus button on the side of the camera
(☞page 16) or perform the auto back focus function from the setup menu.
Refer to the Operating Instructions (PDF) for how to perform the auto back focus function from
the setup menu.
T
W
CS-mount lens
(option)
Zoom lock knob
Focus ring
ALC lens connector
Protruded portion
from mount face:
ø20 mm {25/32"}
or less
Protruded portion from flange face:
4.5 mm {5/32"} or less
1 3
2 4
Pin No.
1 Dump @
2 Dump !
3 Drive !
4 Drive @

18
Note:
 • Themostcommonuseofavarifocallensandazoomlens
Note that the adjustment method is different depending on the type. For further information,
refer to the operating instructions for the lens to be used.
Adjust the back focus after positioning the zoom ring at the "T" end and positioning the focus
ring at a step short of the "F" end.
 • Depending on the lens to be used, if the zoom ring is fully rotated in the "W" direction, the
periphery may become dark. In such a case, rotate the zoom ring in the "T" direction for read-
justment.
 • Whenimagesinthenear-infraredlightareachangefromthecolormodetotheblack&white
mode, out-of-focus may be occurred according to the nature of optical property. In this case,
the focus can be corrected by selecting "Auto" or "Preset" for "Adjusting method" on the setup
menu (The focus will not automatically be adjusted according to the illumination level change
once the focus is corrected.) Refer to the Operating Instructions (PDF) for how to configure the
"Adjusting method" setting on the setup menu.
 • Whenshootingin the following place or the following subjects, it may have difficulty adjusting
the back focus position automatically.
In this case, adjust the back focus position manually from the setup menu.
Refer to the Operating Instructions (PDF) for how to perform the auto back focus function from
the setup menu.
• Placetherethelenseasilybecomesdirty
 • Subj.movingfrequently
 • Subj.withlargeilluminancechange
 • Subj.withlowilluminance
 • Subj.withreflectionorextrabrightness
 • Subj.throughawindow
 • Subj.withlesscontrastsuchaswhitewall
 • Subj.withheavyflicker
How to adjust the focus
SP305
SP302
The focus is adjusted using the focus assist function.
The angle of view and focus can be adjusted in accordance with the distance between the camera
lens and a photographic subject. These adjustments shall be performed together with the camera
angle adjustment.
zLoosen the zoom lock knob, and adjust the angle of view
(angular field of view) in accordance with the photographic
subject by moving the zoom lock knob and focus ring.
xFasten the zoom lock knob.
cPress the focus assist button.
→"FOCUS ADJUSTMENT" menu will be displayed.
The focus assist function will be activated to perform the
optimum adjustment.
FOCUS ADJUSTMENT
LOW HIGH
............|.......
INDICATOR 620 BEST
PEAK HOLD 635 FOCUS

19
vWhen the focus ring is positioned near the best focus position, the position will automatically
be memorized as the "PEAK HOLD" position.
bWhen the focus ring is moved, the current focus position will be indicated on "INDICATOR"
Adjust the focus position so that the indicator value goes close to the "PEAK HOLD" position.
nWhen the indicator value goes to the best focus position, "BEST FOCUS" will be displayed in
reverse at the lower right corner of the screen.
mPress the focus assist button again to close the "FOCUS ADJUSTMENT" menu. (No operation
for 3 seconds also closes the menu.)
Note:
 • Themostcommonuseofavarifocal lens
Note that the adjustment method is different depending on the type. For further information,
refer to the operating instructions for the lens to be used.
When positioning the zoom ring at a step short of the "T" (or "W") end, the focus adjustment
will be easier.
 • Depending on the lens to be used, if the zoom ring is fully rotated in the "W" direction, the
periphery may become dark. In such a case, rotate the zoom ring in the "T" direction for read-
justment.
 • When shooting the following subjects, close the "FOCUS ADJUSTMENT" menu by pressing
the focus assist (F.A.) button again, and adjust the focus to obtain the best focus position while
monitoring images from the camera.
 • Placewherethelenseasilybecomesdirty
 • Subj.movingfrequentlyorhavinglargeilluminancechange
 • Subj.withlowilluminance
 • Subj.withreflectionorextrabrightness
 • Subj.throughawindow
 • Subj.withlesscontrastsuchaswhitewall
 • Subj.withheavyflicker
 • In case the angular field of view has changed during adjustment, close the "FOCUS
ADJUSTMENT" menu once by pressing the focus assist (F.A.) button. (When the angular field
of view changes, the indicator values of "PEAK HOLD" and "INDICATOR" also change.) After
fixing the angular field of view, retry Step 3.

20
Insert/remove an SDHC/SD memory card
Important:
 • BeforeinsertinganSDHC/SDmemorycard,turnoffthepowerofthecamerafirst.
 • WheninsertinganSDHC/SDmemorycard,makesurethedirection.
 • BeforeremovingtheSDHC/SDmemorycard,select"Notuse"for"AboutSDmemorycard"on
the [SD memory card] tab of "Basic" on the setup menu first. Turn off the power after "Not use"
selection, and then unload the SDHC/SD memory card. When the SDHC/SD memory card is
inserted or removed with the power on, data in the SDHC/SD memory card may be damaged.
(☞Operating Instructions)
zOpen the slide cover on the side of the camera, and then insert an SDHC/SD memory card into
the SDHC/SD memory card slot.
xIf necessary, loosen the screw of the clamp for SDHC/SD memory card and tighten the screw
after rotating the clamp 90° clockwise.
(Recommended tightening torque: 0.19 N·m {0.14 lbf·ft})
cClose the slide cover on the side of the camera.
vTo remove the SDHC/SD memory card, rotate the clamp for SDHC/SD memory card 90
degrees counterclockwise, push the memory card to unlock it, and remove the memory card
from the SDHC/SD memory card slot.
ABF
SDCARD LOCK
ABF
SDCARD LOCK
ABF
SDCARD LOCK
T
W
T
W
T
W
Label face downward
Screw of the clamp for
SDHC/SD memory card
ABF
SDCARD LOCK
ABF
SDCARD LOCK
ABF
SDCARD LOCK
ABF
SDCARD LOCK
T
W
T
W
T
W
Label face downward
Screw of the clamp for
SDHC/SD memory card
ABF
SDCARD LOCK
(This illustration
represents WV-SP306.)
