Panasonic Machine Vision GP-MF130 User manual

Switch 1 Shutter Speed
2345
off off off off off
on off off off 1/100
off on off off 1/500
on on off off 1/1,000
off off on off 1/2,000
on off on off 1/4,000
off on on off 1/8,000
on on on off 1/16,000
off off off on 1/32,000
on off off on 1/64,000
off on off on 1/96,000
Other Combinations Not Specified
R
Machine Vision B/W CCD Camera
GP-MF130
Application
•Position SMT / wafer / PCB inspection
•FA / Robots
•Image Processing
Key Features
•Dimensions: 29 mm (width) x 29 mm (height) x 65 mm (length)
(w/o I/O connectors). Ultra-Compact and lightweight.
•Variable electronic shutter speed:
1/60, 1/100, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/8,000,
1/16,000, 1/32,000, 1/64,000, 1/96,000 sec.
•Long lens mount base design that allows wide range of
lens selection.
•Equipped two (2) Video output terminals.
•570 line horizontal resolution.
•Selectable field / frame integration
•1.0 lx minimum scene illumination at F1.4.
•56 dB signal-to-noise ratio.
•C-mount
•Removable IR cut filter.
•Designed to withstand strong Vibration / Shock resistant.
This lightweight, compact and high sensitive unit shows
excellent cost/performance and enables high speed electronic
shutter speed of up to 1/96,000-sec for FA applications.
The shutter speed can be set as below
1.0
0.8
0.6
0.4
0.2
400 600 800 1000 1200
0
1.0
400 600 800 12001000
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
Wave length (nm) Wave length (nm)
CCD IR FILTER
Relative Response Relative Response
Spectral Response
High speed shutters
up to 1/96,000 second.
High speed shutters
up to 1/96,000 second.

• Weights and dimensions are approximate. • Specifications are subject to change without notice. • These products may be subject to export control regulations.
Printed in Japan
[P-455]
A Division of Panasonic Broadcast & Television Systems Company
A Unit of Matsushita Electric Corporation of America
Executive Office: 50 Meddowlands Pkwy 4D-4, Secaucus, New Jersey 07094 [phone]
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada [phone]
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
San Gabriel Industrial Park 65th Infantry Ave. KM. 9.5 Carolina, P.R. 00630 [phone]
Medical & Industrial Video Company
DISTRIBUTED BY:
Pick-up Device Interline Transfer type CCD with 768 (H) x 494 (V) pixels.
Image Size 1/3” (6.00 (H) x 4.96 (V) mm)
2 : 1 interlace 1-line interlace (Frame accumulation)
2 : 1 interlace 2-line interlace (Field accumulation)
Synchronization Internal or External (Selectable Automatically)
Internal : Built-in sync generator
External : 4.0 V[p-p]/75 ohms Horizontal drive and Vertical drive pulses
for 2 : 1 interlace
Horizontal Resolution 570 lines at center
Minimum Illumination 1.0 lx (0.1 foot-candles),
(F1.4, Manual Gain Max (+6 dB), 2 : 1 interlace, without shutter)
Signal to Noise Ratio 56 dB Typical (Manual Gain Off (0 dB), 2 : 1 interlace without shutter)
Gamma 1.0
Gain Selection 0 - 6 dB, (Adjustable by Manual Gain Control on rear panel)
Electronic Shutter 10-step (1/100 s to 1/96 000 s) at normal
Lens Mount C-Mount
Vibration Resistance 10 G (10 Hz - 150 Hz) (2 hours each for three axes)
Shock Resistance 80 G (IEC 68) *IEC=International Electronical Technical Commission
Power Source DC +12 V, 170 mA
Ambient Temperature -10˚C - +50˚C (14˚F - 122˚F)
Dimensions 29 (W) x 29 (H) x 65 (D) mm [1-1/8" (W) x 1-1/8" (H) x 2-9/16" (D)]
Weight 86 g(0.19 lbs.) (Camera Only)
Lens (optional)
6-M3
1-1/8" (29)
1-1/8" (29)
3-1/16" (77.8)
2-9/16" (65)
5/16" (8)
7/16" (11.5) 1-3/4" (44.5)
13/16" (20)
SPECIFICATIONS
APPEARANCE
OPTIONAL ACCESSORIES
Camera Cable
GP-CA34 Camera Cable GP-CA33
Unit: inches (mm)
Video Monitor
Camera GP-CA34 Coaxial Cable
Coaxial Cable
HD IN
12V DC
Power Supply
VD IN
OUTIN 75Ω
Hi-Z
VIDEO
130
SYSTEM CONNECTIONS
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
Right Side View
Left Side View
Rear View
123456
SW2
SW1
Rear View
VR3
BNC
VR5 12pin Conector
SW2
1: Not used
2: Not used
3: Not used
4: Not used
5: HD 75ΩOFF/ON
6: VD 75ΩOFF/ON
SW1
1: Field / Freame
2: Electronic shutter D0
3: Electronic shutter D1
4: Electronic shutter D2
5: Electronic shutter D3
6: Not used
VR3: Pedestal Control
VR5: Manual Gain Control
BNC Conector: Video out 2
Camera Connector (12-pin)
HR10A10R12PB
Pin No. Description
1 Ground
2 +12V IN
3 Ground for Video Out
4 Video Out
5 Ground for HD
6 HD IN
7 VD IN
8 Ground
9 No connection
10 No connection
11 No connection
12 Ground for VD
Actual size Actual size
