Panasonic WV-CF504 User manual

Super Dynamic 5 Fixed Dome Camera with ABS (Adaptive Black Stretch),
i-VMD (intelligent-Video Motion Detection) and ABF (Auto Back Focus)
Key Features
Optional Accessories
Smoke Dome Cover
WV-CW4S
Standard Accessories
• CD-ROM *1 .................................. 1 pc.
• Installation Guide ......................... 1 pc.
• Warranty Card *2 .......................... 1 pc.
*1 The CD-ROM contains the operating instructions (PDF).
*2 NTSC models only
The followings are for installation.
• Camera Attachment ..................... 1 pc.
• Super Dynamic 5 delivers Superior image by fusion of Super
Dynamic, ABS (Adaptive Black Stretch) and i-VMD (intelligent-
Video Motion Detection) technology.
• High resolution: 650 TV lines typical (Color mode), 700 TV lines
minimum (B/W mode)
• High sensitivity with Day/Night function: 0.1 lx (Color), 0.01 lx (B/W)
at F1.4 (Wide). IR cut filter switches on/off to enhance the
sensitivity in B/W mode.
• i-VMD (intelligent-Video Motion Detection) including video motion
detection, object detection (removal and left behind), scene
change detection when lens is covered, spray painted, removed or
defocused
• ABF (Auto Back Focus) ensures easy installation and stable focus
in both color and B/W modes.
• 3-dimensional color conversion function for natural color
reproduction even in lower color temperature situation
• Adaptive Digital Noise Reduction: Integration of 2D-DNR and
3D-DNR ensures noise reduction in various conditions.
• Electronic sensitivity enhancement: Auto (Up to 32x) / Manual (Up
to 32x)
• Electronic shutter from 1/100 (NTSC), 1/120 (PAL) to 1/10,000 s.
• 3.8 ~ 8.0 mm, 2x Varifocal Auto Iris lens with 2x digital zoom
• Auto Image Stabilizer for applications where vibration or wind is a
concern
• Internal / Line-lock / Multiplexed Vertical Drive (VD2) synchronization
• Over the coaxial cable data communication
• 16 alphanumerics camera title display
• Multi language: English, French, Italian, Spanish, German, Russian
• Monitor output for easier installation
• 3-way hinge (horizontal, vertical and swivel rotation) for easy
installation
• Various mounting options: Surface mount and Embedded ceiling
mount
Super Dynamic 5 Fixed Dome Camera
WV-CF504
WV-CF504 (24 V AC or 12 V DC) WV-CF504 (24 V AC or 12 V DC)
Embedded Ceiling Mount Bracket
WV-Q175

http://panasonic.net/security/
Printed in Japan (2A-070L)
• All TV pictures are simulated.
• Masses and dimensions are approximate.
• Specifications are subject to change without notice.
• These products may be subject to export control regulations.
• All product pictures are NTSC models.
Specifications Part Names and Functions
Appearance
DISTRIBUTED BY:
Unit: mm (inches)
Attachment plate
assembly
Trademarks and registered trademarks
– "Super Dynamic", "SDII", "SDIII", "SD5", "SD5Link" and "i-Pro" logos are trademarks or registered trademarks of Panasonic Corporation.
Important
– Safety Precaution: carefully read the operating instructions and installation manual before using this product.
SR 52.5
129(5-1/8") 0.5
73.8(2-7/8") 46
(1-3/4")
170(6-3/4")140(5-1/2")
ø151(6")
83.5(3-1/4")
Focus Lock Knob
Zoom Lock Knob
Panning Lock Screw
Camera Fixing Screw
Panning Table
Monitor Output Connector
Tilting Lock Screw
Tilt Adjusting Table
ABF Operation Indicator
Setting Button [(SET), ABF2/MENU]
TV System NTSC PAL
Camera Image Sensor 1/3 type interline transfer CCD
Effective Pixels 976 (H) x 494 (V) 976 (H) x 582 (V)
Scanning Mode 2:1 interlace scan
Scanning Area 4.8 (H) x 3.6 (V) mm
Scanning Frequency Horizontal: 15.734 kHz Horizontal: 15.625 kHz
Vertical: 59.94 Hz Vertical: 50 Hz
Horizontal Resolution 650 TV lines typical at color mode, 700 TV lines at B/W mode
Minimum Illumination*1 Color: 0.1 lx (0.01 lx)(SENS UP: OFF),
0.003 lx (0.0003 lx)(SENS UP: 32x) at F1.4 *2
B/W: 0.01 lx (0.001 lx)(SENS UP: OFF),
0.0003 lx (0.00003 lx)(SENS UP: 32x) at F1.4 *2
Signal-to-Noise Ratio 50 dB (AGC Off)
White Balance ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K),
or AWC (2,000 ~ 10,000 K)
Light Control ALC / ALC+
AGC ON (HIGH / MID / LOW) / OFF
Super Dynamic 5 ON / ON (i-VMD) / OFF (with BLC masking 8 x 6 areas)
Dynamic Range
52 dB typical (Super Dynamic 5 ON) 54 dB typical (Super Dynamic 5 ON)
Electronic Shutter OFF (1/60), 1/100, 1/250, OFF (1/50), 1/120, 1/250,
1/500, 1/1,000, 1/2,000, 1/500, 1/1,000, 1/2,000,
1/4,000, 1/10,000 s 1/4,000, 1/10,000 s
Electronic Sensitivity UP OFF / AUTO (2x, 4x, 6x, 10x, 16x, 32x) /
FIX (2x, 4x, 6x, 10x, 16x, 32x)
Digital Noise Reduction High / Low
Black and White Mode Mode: AUTO1 / AUTO2 / ON / OFF
Digital Zoom ON (up to 2x) / OFF
Scene File 2 patterns
i-VMD (intelligent-Video Video Motion Detection, Object Detection (Removal and Left
Motion Detection) Behind), Scene Change Detection
Privacy Zone ON (Gray / Mosaic) or OFF
Image Stabilizer ON / OFF
Camera Title Up to 16 characters
Lens Mount CS-mount
Back Focus Adjustment ABF (AUTO / PRESET / FIX), MANUAL-ADJ
Synchronization
Internal (INT), Multiplexed Vertical Drive (VD2), Line-Lock (LL) *3
Lens Focal Length 3.8 ~ 8.0 mm, 2x varifocal
Angular Field of View H: 35.6° (Tele) ~ 73.6° (Wide) V: 26.6° (Tele) ~ 53.4° (Wide)
Maximum Aperture Ratio 1 : 1.4 (Wide) ~ 1 : 1.8 (Tele)
Focusing Range 1.2 m (3.9 ft.) ~ ∞
ALC Drive DC
Pan and Panning range ±170°
Tilt Tilting Range ±75°
Azimuth Range ±100°
Input/ Video Output 1.0 V [P-P] / NTSC composite 1.0 V [P-P] / PAL composite
Output Output 75 Ω / BNC Connector 75 Ω / BNC Connector
Multiplexed VD2 and control Multiplexed VD2 and control
data capable data capable
Monitor Output 1.0 V [P-P] / NTSC composite 1.0 V [P-P] / PAL composite
75 Ω / RCA Jack 75 Ω / RCA Jack
General Safety/EMC Standard
UL (UL60065), FCC (Part15, ClassA) CE
C-UL (CAN/CSA C22.2 No.60065), (EN60065, EN55022 ClassB, EN55024),
DOC (ICES003 ClassA) GOST (R 51558)
Language English, Russian (For setup menu and camera title), German,
French, Italian, Spanish (For setup menu)
Power Source and 24 V AC 60 Hz, 3.4 W, 24 V AC 50 Hz, 3.4 W,
Power Consumption 12 V DC, 280 mA 12 V DC, 280 mA
Ambient Operating Temperature –10 °C ~ +50 °C (14 °F ~ 122 °F)
Ambient Operating Humidity Less than 90 % (no condensation)
Dimensions ø151 mm x 129 mm (H) (ø5-15/16" x 5-1/16" (H))
Mass (approx.) Main Body: 0.9 kg (2.0 Ibs),
(including camera attachment 60 g (0.13 Ibs)
Down Button [(DOWN), ABF1]
Up Button [(UP)]
Left Button [(LEFT), NEAR]
Right Button [(RIGHT), FAR]
Video Output Cable
Power Cord
Inner Dome
Enclosure
*1 With Standard Clear Dome Cover
*2 Estimated figure
*3 Phase adjustable
