Panasonic EBL512 G3 5000 User manual

User manual
MEW01603
Revision -
Fire alarm system
EBL512 G3
EBL512 G3 version 2.0.x
Daily user's manual
Author: Jan Pettersson
Date of issue: 2013-01-10
Date of rev:

This page has deliberately been left blank.

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
1
Table of contents
1Introduction________________________________ 2
2Front______________________________________ 3
3Log on to the Control Unit (c.i.e.) ______________ 4
4Perform monthly test (H1) ___________________ 6
5Disable or re-enable (H2) ____________________ 7
5.1 Zone or Zone / Address (B1) _________________________ 8
5.2 Output (B2) ______________________________________ 9
5.3 Output type (B3) __________________________________ 10
5.4 Alarm devices (B4) _______________________________ 11
5.5 Routing equipment (B5)____________________________ 12
5.6 Alert Annunciation function (B6) ____________________ 13
6Set calendar and clock (H3) _________________ 14
7Present system status (H4) __________________ 15
7.1 Disablement (U1)_________________________________ 16
7.2 Disablement by time channel (U2)____________________ 16
7.3 Open doors (U3)__________________________________ 17
7.4 Sensor values (U4)________________________________ 17
7.5 Sensors activating SERVICE signal (U5) ______________ 18
7.6 Technical warning (U6) ____________________________ 18
7.7 Event log (U7) ___________________________________ 19
7.8 Information (U8) _________________________________ 19
8FAULT Acknowledge (H6)__________________ 20
9Perform ZONE TEST (Test mode) (H7)_______ 21
10 Interlocking outputs and inputs (H9) _________ 23
10.1 Activated interlocking outputs / inputs (C1) ____________ 24
10.2 Activate / deactivate interlocking output (C2)___________ 24
10.3 Disable / re-enable interlocking output (C3) ____________ 25
11 Change password (H10) ____________________ 26
12 Revision history____________________________ 27

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
2
1 Introduction
This document is intended to be used for the daily duties like
disablements / re-enablements, zone tests, etc. in the EBL512 G3
system.
Due to continual development and improvement different S/W
versions can be found. This document is valid for EBL512 G3 S/W
version 2.0.x. (x=0 at the "Date of issue" or "Date of revision".)
The document describes the main menus (incl. the sub menus) valid
for access level / type "Building officer".
This document is less detailed and shorter than the Operating
Instruction, MEW01552.
NOTE! In the left margin are pictures of the buttons / soft keys used
in the menu respectively. Each picture is only shown one time in each
menu –not each time the button / soft key should be used.
A User name and a Password is required to Log on to the control
unit, i.e. for access to the menu system.
1
The PC program EBLWin is used for commissioning, etc. User
names and Passwords can be added and edited via this program.
EBLWin require an EBLWin key (hardware) to log on to the control
unit in order to download Site Specific Data, e.g. User names and
Passwords.
1
The menus available are depending on the access level / type for the user
respectively, see chapter "Log on to the Control Unit (c.i.e.)", page 4.

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
3
2 Front
Front, upper (light grey) part. Fire Brigade Panel (FBP).
Front, lower (dark grey) part. LEDs and keypad.
Soft keys. Information will be visible above the
key respectively when it has a function.

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
4
3 Log on to the Control Unit (c.i.e.)
User name
Up to ten (10) User names (0, 1, 2 - - 9) might be programmed.
Default are normally three User names available (0, 1 and 2) but they
might have been changed and/or User names 3 –9 might have been
added during the commissioning of the system. User name examples:
0Information only
1 Building officer
2 Service personnel
3 Mr. Xxxxxxxxx
4 Miss Yyyyyyyyy
etc.
Password
Each User name has a Password for an access level / type, i.e.
"Information only", "Building officer" or "Service personnel".
Access levels (access types):
Information only will give access to the menus H4, H6, H9 and H10.
Building officer will give access to the menus H1, H2, H3, H4, H6,
H7, H9 and H10. (Described in this document.)
Service personnel will give access to the menus H1, H2, H3, H4, H5,
H6, H7, H8, H9 and H10.
How to log on
Press the Soft key "Menu".
With the keypad select 0, 1, 2 - - 8 or 9 for a User name.
Type the Password for that user name. (Six digits. * * * * * *)
After typing a correct Password a main menu list with the available
menus will be displayed. (For "0", i.e. Information only, is by default
no Password required.)
Information only
H4 Present system status
H6 Display FAULTS (No possibility to Acknowledge the faults.)
H9 Interlocking outputs and inputs
H10 Change password (Password for the User name that was used for
log on to the control unit.)
Menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
5
Building officer (Described in this document.)
H1 Perform monthly test
H2 Disable or re-enable
H3 Set calendar and clock
H4 Present system status
H6 FAULT Acknowledge
H7 Perform ZONE TEST
H9 Interlocking outputs and inputs
H10 Change password (Password for the User name that was used for
log on to the control unit.)
Service personnel
H1 Perform monthly test
H2 Disable or re-enable
H3 Set calendar and clock
H4 Present system status
H5 Service
H6 FAULT Acknowledge
H7 Perform ZONE TEST
H8 Maintenance
H9 Interlocking outputs and inputs
H10 Change password (Password for the User name that was used for
log on to the control unit.)
Keypad
Use the arrow keys ( , , , ) to step in the
menu lists and in the selected menu respectively.
Press Return / Enter () to accept / select.
A quick jump to a menu can be done by pressing the
corresponding digit key, e.g. "6" for menu H6.
Press ESC to stop the enting of data and to jump one
step upwards in the menu system, e.g. from a sub menu
to a main menu.

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
6
4 Perform monthly test (H1)
Not possible for access level / type "Information only".
Press the Soft key "Menu".
With the keypad select 0, 1, 2 - - 8 or 9 for a User name.
Type the Password for that user name. (Six digits. * * * * * *)
H1 Perform monthly test
Press ().
Press ().The c.i.e. buzzer sounds, all the dots in the display are
shown and all LEDs on the front are turned on. If the c.i.e. has a
printer it has made a print out: ABC..........Z abc.........z.
Press ().Up to four zones can be set in test mode. Use the keypad
to type the zone numbers.
Press ().Perform the test. To end the test, press ().
If the routing equipment shall not be tested press () and see 
below.
If the routing equipment shall be tested press ( ) to highlight
Yes and press (). Started test is indicated by LED "Fault tx
activated" and after 30 seconds also LED "Fire brigade tx". After 60
seconds (in total) the routing equipment test is ended and the LEDs
are turned off.
Press ().
Monthly test is completed. Press ().
To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Menu
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
7
5 Disable or re-enable (H2)
Not possible for access level / type "Information only".
NOTE! One or more disablements in the system are indicated by the
LED "General disablements" on the c.i.e. front. Depending on the
type of disablements, also the LED "Alarm devices" and/or "Fire
brigade tx".
Press the Soft key "Menu".
With the keypad select 0, 1, 2 - - 8 or 9 for a User name.
Type the Password for that user name. (Six digits. * * * * * *)
H1 Perform monthly test
Press ( ) to highlight menu H2.
H2 Disable or re-enable
Press ().A sub menu list (B1 –B6) will be displayed. B1
Disable zone
B1 Zone or Zone / Address
B2 Output
B3 Output type
B4 Alarm devices
B5 Routing equipment
B6 Alert annunciation function
To open the sub menu respectively, see the following chapters.
Menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
8
5.1 Zone or Zone / Address (B1)
Up to 512 whole zones can be disabled via menu B1. Normally all
alarm points within the zone will be disabled except the addressable
manual call points.
Up to 200 alarm points (Zone / Address) can be disabled via menu B1.
Disabled Zones and/or Zone / Addresses can also be Re-enabled via
menu B1.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ().
Disable
NOTE! To Re-enable, see ➓below.
By default is Zone 000 selected. Press the Soft key "Change type
of disablement" to toggle between:
Zone 000
Zone 000 address 00.
Use the keypad to type the Zone or Zone / Address. Press ().
If "Automatically re-enablement" shall be used, press ( and ) to
highlight Yes , accept the suggested time or use the keypad to type
another time (hh:mm). Press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Re-enable list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable
Re-enable list.
Press ( ) to highlight the Zone or Zone / Address that shall be Re-
enabled.
⓫Press (). A successful Re-enablement is indicated by a beep and it
will also disappear from the Re-enable list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
9
5.2 Output (B2)
Up to 200 outputs can be individually disabled via menu B2.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ( ).
B2 Output
Press ().
Disable output
NOTE! To Re-enable, see ➓below.
By default is Loop unit 000000 output 0 selected. Press the Soft
key "Change type of disablement" to toggle between:
Loop unit 000000 output 0
Control unit 00 S0
Control unit 00 R0
Control unit 00 expansion board output 0.
Use the keypad to type the required data. Press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Re-enable list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable output
Re-enable list.
Press ( ) to highlight the output that shall be Re-enabled.
⓫Press (). A successful Re-enablement is indicated by a beep and it
will also disappear from the Re-enable list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
10
5.3 Output type (B3)
Outputs of the same type can be collectively disabled via menu B3.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ( ) two times.
B3 Output type
Press ().
Disable output type
NOTE! To Re-enable, see ➓below.
By default is type Control outputs in control unit 00 All selected.
Press the Soft key "Change type of disablement" to toggle
between:
Control outputs
Ventilation outputs
Extinguishing outputs
Interlocking outputs
Press () and type the control unit number if not All outputs shall
be disabled. Press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Re-enable list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable output type
Re-enable list.
Press ( ) to highlight the output type that shall be Re-enabled.
⓫Press (). A successful Re-enablement is indicated by a beep and it
will also disappear from the Re-enable list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
11
5.4 Alarm devices (B4)
Outputs of the type "Alarm devices" can be collectively disabled via
menu B4.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ( ) three times.
B4 Alarm devices
Press ().
Disable
NOTE! To Re-enable, see ➓below.
By default is All alarm devices selected.
Press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Re-enable list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable
Re-enable list
⓫Press (). A successful Re-enablement is indicated by a beep and it
will also disappear from the Re-enable list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
12
5.5 Routing equipment (B5)
Outputs for routing equipment (fire alarm and fault condition
respectively) can be disabled via menu B5.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ( ) four times.
B5 Routing equipment
Press ().
Disable routing equipment
NOTE! To Re-enable, see ➓below.
By default is Fire selected. Press ( ) to highlight Fault .
After "Fire" or "Fault" is selected, press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Disabled routing equipment list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable routing equipment
Disabled routing equipment list
⓫Highlight the output. Press ( ) if required.
Press (). A successful Re-enablement is indicated by a beep
and it will also disappear from the Disabled routing equipment list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
13
5.6 Alert Annunciation function (B6)
The Alert Annunciation function can be permanently turned off via
menu B6 –until turned on again via menu B6.
The LED "Fire brigade tx delay" on the front is indicating when the
alert annunciation function is turned on, i.e. when the transmission to
the fire brigade will be delayed.
Cont. from , page 7.
B1 Zone or Zone / Address
Press ( ) five times.
B6 Alert annunciation function
Press ().
Disable
NOTE! To Re-enable, see ➓below.
By default is Alert annunciation selected.
Press ().
A successful disablement is indicated by a beep and a "√". It will also be
shown in the Re-enable list.
A not successful disablement is indicated by another beep and a "X".
Re-enable
➓Press the Soft key " ⇥" to toggle between:
Disable
Re-enable list
⓫Press (). A successful Re-enablement is indicated by a beep and it
will also disappear from the Re-enable list.
⓬To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
14
6 Set calendar and clock (H3)
The time, date and day set via this menu will be valid for the whole
system.
NOTE! If you don't want to change anything in menu H3, press ESC to
leave the menu.
Press the Soft key "Menu".
With the keypad select 0, 1, 2 - - 8 or 9 for a User name.
Type the Password for that user name. (Six digits. * * * * * *)
H1 Perform monthly test
Press ( ) two times to highlight menu H3.
H3 Set calendar and clock
Press ().
Depending on if it is the date, time and/or the day that shall be set,
press ( and ) to highlight it.
➏Use the keypad to enter new values.
➐Press ().
➑To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu
Menu

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
15
7 Present system status (H4)
If the c.i.e. has a printer it is possible to get a print-out from some of
the sub menus U1-U8.
If it is possible to get a print-out, the Soft key "Print" is shown and
shall be used to start the print-out.
During printing the same Soft key might change to "Abort printing".
NOTE! After pressing the Soft key "Abort printing" it will change
back to "Print" but the printing might continue for a few seconds.
If the list in the selected menu is empty, "- - - List is empty - - -" will
be shown.
Press the Soft key "Menu".
With the keypad select 0, 1, 2 - - 8 or 9 for a User name.
Type the Password for that user name. (Six digits. * * * * * *)
H1 Perform monthly test
Press ( ) three times to highlight menu H4.
H4 Present system status
Press ().A sub menu list (U1 –U8) will be displayed. B1
Disable zone
U1 Disablement
U2 Disablement by time channel
U3 Open doors
U4 Sensor values
U5 Sensors activating SERVICE signal
U6 Technical warning
U7 Event log
U8 Information
➏To open the sub menu respectively, see the following chapters.
Menu
Print

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
16
7.1 Disablement (U1)
Disablements, except disablements by time channel, will be displayed
via menu U1, also alarm points that have been automatically disabled
in conjunction with fire alarm reset.
Disablements and Re-enablements are done via menu H2/B1-B6.
Cont. from , page 15.
The LED "General disablements" is indicating one or more
disablements in the system. Depending on the type of disablements,
also the LED "Alarm devices" and/or "Fire brigade tx".
Press ().
The list is dynamic, i.e. you can scroll in the list with ( ) or ( ).
If a printer is available the Soft key "Print" is shown and can be used
to start a print-out.
➑To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
7.2 Disablement by time channel (U2)
Only disablements by time channel, will be displayed via menu U2.
The LED "General disablements" is indicating one or more
disablements in the system.
Cont. from , page 15.
U1 Disablement
Press ( ).
U2 Disablement by time channel
Press ().
The list is static (max. four items per page). You can scroll (also to
the next page) with ( ) or ( ).
➒To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu
Escape
menu
Print

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
17
7.3 Open doors (U3)
If any door in the system is open, the open door symbol is shown
up to the right in the display's symbol area.
Cont. from , page 15.
U1 Disablement
Press ( ) two times.
U3 Open doors
Press ().
The list is dynamic, i.e. you can scroll in the list with ( ) or ( ).
If a printer is available the Soft key "Print" is shown and can be used
to start a print-out.
➒To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
7.4 Sensor values (U4)
Cont. from , page 15.
U1 Disablement
Press ( ) three times.
U4 Sensor values
Press ().
Use the keypad to enter the technical number and/or press ().
This is a list, i.e. you can scroll in the list with ( ) or ( ).
Depending on if it is a heat, smoke or multi detector the information
looks different.
If a printer is available the Soft key "Print" is shown and can be used
to start a print-out.
❿To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
NOTE! The Performance factor and the Min. and Max values are
updated at midnight, i.e. the values are from the previous day.
If the week average sensor value ("Weekly") is 00.0%/m, leave menu
U4 and open it again after approx. 2 minutes.
Escape
menu
Escape
menu
Print
Print

Panasonic Eco Solutions Nordic AB
MEW01603 Rev: - EBL512 G3 version 2.0.x, Daily user's manual
18
7.5 Sensors activating SERVICE signal (U5)
If any smoke detector in the system is activating SERVICE signal, the
SERVICE signal symbol is shown up to the right in the display's
symbol area.
NOTE! SERVICE signal is acknowledged via menu H8/S2, which
require log on with a password for access level / type "Service
personnel".
Cont. from , page 15.
U1 Disablement
Press ( ) four times.
U5 Sensors activating SERVICE signal
Press ().
This is a list, i.e. you can scroll in the list with ( ) or ( ).
If a printer is available the Soft key "Print" is shown and can be used
to start a print-out.
❿To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
NOTE! Sensors activating SERVICE signal have to be replaced.
Call for service personnel.
7.6 Technical warning (U6)
If one or more technical warnings are activated in the system, the
technical warning symbol is shown up to the right in the display's
symbol area.
Cont. from , page 15.
U1 Disablement
Press ( ) five times.
U6 Technical warning
Press ().
This is a list, i.e. you can scroll in the list with ( ) or ( ).
If a printer is available the Soft key "Print" is shown and can be used
to start a print-out.
To leave a menu press ESC.
To leave the menu system press the Soft key "Escape menu".
Escape
menu
Print
Print
Escape
menu
