SC-TMAX10E

2
TABLE OF CONTENTS
PAGE
1 Safety Precautions ------------------------------------------------3
1.1. General Guidelines ------------------------------------------3
1.2. Leakage Current Cold Check ------------------------------3
1.3. Leakage Current Hot Check (See Figure 1.) ----------3
1.4. Protection Circuitry -------------------------------------------3
2 Warning ---------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ------------4
2.2. Caution for AC Cord (For EB) -----------------------------5
2.3. Service Caution Based on Legal Restrictions ---------6
2.4. Precaution of Laser Diode ----------------------------------7
2.5. Static Electricity Protection Measures -------------------8
2.6. Ground for Electrostatic Breakdown Prevention ------8
3 Service Navigation ------------------------------------------------9
3.1. Service Information ------------------------------------------9
3.2. Software Version Confirmation ---------------------------9
3.3. Software Update ---------------------------------------------9
4 Specifications ----------------------------------------------------- 10
5 Location of Controls and Components ------------------- 12
6 Service Mode ------------------------------------------------------ 14
6.1. Self-Diagnostic Mode ------------------------------------ 14
6.2. Self-Diagnostic Error Code Table ---------------------- 15
6.3. Sales Demonstration Lock Function ------------------ 15
7 Troubleshooting Guide ---------------------------------------- 16
7.1. No Power ----------------------------------------------------- 16
7.2. Bluetooth® Pairing Failure ------------------------------- 16
7.3. No Light from the Illuminator ---------------------------- 16
7.4. No Sound ---------------------------------------------------- 17
7.5. Check Points ------------------------------------------------ 19
8 Disassembly and Assembly Instructions ---------------- 20
8.1. Disassembly Flow Chart ---------------------------------- 20
8.2. Types of Screws--------------------------------------------- 20
8.3. Main Component and P.C.B. Position ----------------- 21
8.4. Disassembly of Top Cabinet Unit ----------------------- 22
8.5. Disassembly of USB P.C.B. Unit ----------------------- 22
8.6. Disassembly of VFD P.C.B. Unit
and Key P.C.B. Unit ---------------------------------------- 22
8.7. Disassembly of Power P.C.B. Unit---------------------- 23
8.8. Disassembly of Main P.C.B. Unit----------------------- 23
8.9. Disassembly of Speakers--------------------------------- 23
8.10. Disassembly of CD Mecha ----------------------------- 24
9 Voltage Measurement ------------------------------------------- 25
10 Wiring Connection Diagram--------------------------------- 27
11 Exploded View and Replacement Parts List ---------- 28
11.1. Cabinet Parts Location 1 -------------------------------- 28
11.2. Cabinet Parts Location 2 -------------------------------- 29
11.3. Packing Parts & Accessories Section ---------------- 30
11.4. Replacement Parts List ---------------------------------- 31

3
1 Safety Precautions
1.1. General Guidelines
1. IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by in the
Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s
specified parts to prevent X-RADIATION, shock, fire, or other hazards. Do not modify the original design without permission
of manufacturer.
2. An Isolation Transformer should always be used during the servicing of AC Adaptor whose chassis is not isolated from
the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in
personal injury from electrical shocks. It will also protect AC Adaptor from being damaged by accidental shorting that may
occur during servicing.
3. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
4. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
5. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.2. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on the
equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the chassis,
the reading should be between 1MΩ and 5.2MΩ. When the exposed metal does not have a return path to the chassis, the
reading must be infinity.
1.3. Leakage Current Hot Check (See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kΩ, 10W resistor, in parallel with a 0.15μF capacitor, between each exposed metallic part on the set and a
good earth ground, as shown in Figure 1.
3. Use an AC voltmeter, with 1 kΩ/V or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75V RMS. A leakage current tester (Simpson Model 229 or equivalent) may
be used to make the hot checks, leakage current must not exceed 1/2 mA. In case a measurement is outside of the limits
specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned
to the customer.
1.4. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• No sound is heard when the power is turned on.
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires
are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
Figure. 1

4
2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices.
Examples of typical ES devices are IC(integrated circuits)and some field-effect transistors and
semiconductor “chip” components.
The following techniques should be used to help reduce the incidence of component damage caused by electrostatic
discharge(ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD
on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging
ESD wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an antistatic solder removal device. Some solder removal devices not classified as "antistatic (ESD protected)"
can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
CAUTION :
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD)
sufficient to damage an ES device).

5
2.2. Caution for AC Cord (For E)
2.2.1. Information for Your Safety
IMPORTANT
Your attention is drawn to the fact that recording of
prerecorded tapes or discs or other published or broadcast
material may infringe copyright laws.
WARNING
To reduce the risk of fire or shock hazard, do not expose
this equipment to rain or moisture.
CAUTION
To reduce the risk of fire or shock hazard and annoying
interference, use the recommended accessories only.
FOR YOUR SAFETY
DO NOT REMOVE THE OUTER COVER
To prevent electric shock, do not remove the cover. No
user serviceable parts inside. Refer servicing to qualified
service personnel.
2.2.2. Caution for AC Mains Lead
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three-pin mains
plug for your safety and convenience.
A 3-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 3 amperes and it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the
fuse.
If the plug contains a removable fuse cover you must ensure
that it is refitted after the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
Panasonic Dealer.
If the fitted moulded plug is unsuitable for the socket outlet in
your home then the fuse should be removed and the plug cut
off and disposed of safety.
There is a danger of severe electrical shock if the cut off plug
is inserted into any 13-ampere socket.
If a new plug is to be fitted please observe the wiring code as
shown below.
If in any doubt, please consult a qualified electrician.
2.2.2.1. Important
The wires in this mains lead are coloured in accordance with
the following code:
Blue Neutral
Brown Live
As the colours of the wires in the mains lead of this
appliancemay not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to
the terminal in the plug which is marked with the letter N or
coloured BLACK.
The wire which is coloured BROWN must be connected to
the terminal in the plug which is marked with the letter L or
coloured RED.
Under no circumstances should either of these wires be
connected to the earth terminal of the three pin plug, marked
with the letter E or the Earth Symbol.
Earth Symbol
2.2.2.2. Before Use
Remove the Connector Cover as follows:
2.2.2.3. How to Replace the Fuse
1. Remove the Fuse Cover with a screwdriver.
2. Replace the Fuse and attach the Fuse cover.

6
2.3. Service Caution Based on Legal Restrictions
2.3.1. General Description About Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for
thisequipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of
tin(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that
of thenormal solder.
Distinction of P.C.B. Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the P.C.B. using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the P.C.B. cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to
melt the lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature
at 350±30°C(662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
SVKZ000001-----------(0.3mm 100g Reel)
SVKZ000002-----------(0.6mm 100g Reel)
SVKZ000003-----------(1.0mm 100g Reel)
Note
* Ingredient: Tin (Sn) 96.5%, Silver (Ag) 3.0%, Copper (Cu) 0.5%. (Flux cored)
The letter of " PbF" is printed either foil side or components side
on the P.C.B.using the lead free solder.(See right figure) PbF

7
The letter of " PbF" is printed either foil side or components side
on the P.C.B.using the lead free solder.(See right figure) PbF
2.4. Precaution of Laser Diode
CAUTION :
This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pick-up lens. Wave
length:770 to 800 nm (CDs)/645 to 660 nm (DVDs) Maximum output radiation power from pick-up:100 μW/VDE Laser
radiation from the pick-up lens is safety level, but be sure the followings:
1. Do not disassemble the optical pick-up unit, since radiation from exposed laser diode is dangerous.
2. Do not adjust the variable resistor on the pick-up unit, it was already adjusted.
3. Do not look at the focus lens using optical instruments.
4. Recommend not to look at pick-up lens for a long time.
Caution !
This unit utilizes a laser. Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
CAUTION INVISIBLE LASER RADIATION WHEN OPEN
DO NOT STARE INTO BEAM.
DANGER INVISIBLE LASER RADIATION WHEN OPEN
AVOID DIRECT EXPOSURE TO THE BEAM.

74%-

8
2.5. Static Electricity Protection Measures
• The laser diode in the traverse unit (optical pick-up) may break down due to potential difference caused by static electricity
of clothes or human body.
So, be careful of electrostatic breakdown during repair of the traverse unit (optical pick-up).
2.6. Ground for Electrostatic Breakdown Prevention
• As for parts that use optical pick-up (laser diode), the optical pick-up is destroyed by the static electricity of the working
environment.
Repair in the working environment that is grounded.
2.6.1. Work table grounding
• Put a conductive material (sheet) or steel sheet on the area where the traverse unit (optical pick-up) is placed, and ground
the sheet.
2.6.2. Human body grounding
• Use the anti-static wrist strap to discharge the static electricity from your body.
2.6.3. When exchanging the Drive
• Before remove the ESD prevention bag, make sure to use the anti-static wrist strap to discharge the static electricity when
replace the Drive.
Note:
The ESD prevention bag is used to replace the original short-circuit point.
It can be removed while placing the Drive.

9
3 Service Navigation
3.1. Service Information
This service manual contains technical information, which allow service personnels to understand and service this model.
Please place orders with the part numbers in the parts list, not the numbers in the exploded views. If the circuit is changed or
modified, the information will be followed by supplement to be filed with original service manual.
In case of repair of parts, please refer as follow:
Detective Parts Repair Method
1. LED P.C.B. Change by
Speaker Wooden Box Unit
2. AC Inlet Change by
Power P.C.B. Unit
3. Bluetooth P.C.B. Change by
VFD P.C.B. Unit
3.2. Software Version Confirmation
1. Turn on the unit.
2. Press [SETUP] repeatedly to select "SW VER" and then press [OK].
The software version is shown.
3. Press [OK] again to exit.
3.3. Software Update
Panasonic may release updated software for this system that may add or improve the way a feature operates.
For more details, refer to the following website.
http://panasonic.jp/support/global/cs/
CD Software Version
37 35 18
Operation Software
Version
Bluetooth Software
Version
Example:

10
4 Specications
Confidential
Until:
26 Apr 2019
21
TQBJ2182
Specifications
█ General
Battery life in use (Bluetooth® : SBC mode) [TMAX20]
Illumination ON (Vol. Max.) Approx. 3 hours
Power save mode (Vol. Max.) Approx. 7 hours
Power save mode (Vol. 19) Approx. 10 hours
The battery life may vary with external devices and
signal sources used.
Battery charging time (25°C) [TMAX20]
Unit is OFF Approx. 3 hours
Dimensions (W x H x D) 285 mm x 585 mm x 303 mm
Mass 10.2 kg
Operating temperature range 0°C to +40°C
Charging temperature range [TMAX20] +10°C to +35°C
Operating humidity range
35% to 80% RH (no condensation)
█ Amplifier section
RMS output power (Built-in battery) [TMAX20]
Front Ch (both ch driven)
37.5 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS power 75 W
RMS output power (AC Power supply)
Front Ch (both ch driven)
150 W per channel (3 Ω), 1 kHz, 30% THD
Total RMS power 300 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
█ Disc section
[TMAX10]
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
USB recording
Bit rate 128 kbps
USB recording speed
[TMAX20] 1x
[TMAX10] 1x, 3x (CD only)
Recording file format MP3 (*.mp3)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Audio format PCM
Microphone
Terminal Mono, 6.3 mm jack (2 system)
Analog audio input
Audio input Pin jack (1 system)
DC IN [TMAX10]
Terminal type USB Micro-B, 5 V, 2 A
█ Bluetooth
®
section
Version Bluetooth® Ver. 5.0
Class Class 1
Supported profiles
A2DP, AVRCP, SPP
Frequency band 2.4 GHz band FH-SS
Operation distance 30 m line of sight
Supported codec SBC
█ Speaker section
Speaker unit(s)
Woofer 20 cm cone type x 1
Tweeter 6 cm cone type x 2
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum
analyzer.
• The dry battery charge retention time may be shorter under
some operating conditions.
Power supply AC 110 V to 240 V, 50/60 Hz
Built-in battery [TMAX20] 14.4 V (Li-ion 2200mAh)
Power consumption
[TMAX20] 58 W
[TMAX10] 47 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.5 W
With “BLUETOOTH STANDBY” set to “ON” 0.6 W
For Mexico
Power consumption per day
[TMAX20] 58 Wh per day (58 W, 1 hour)
[TMAX10] 47 Wh per day (47 W, 1 hour)
Power consumption per day (in standby mode)
11.5 Wh per day (0.5 W, 23 hours)
SC-TMAX10.20PU_TQBJ2182 En.fm Page 21 Thursday, April 25, 2019 3:55 PM
offset printing
SC-TMAX10 PU/PR
Confidential
Until:
26 Apr 2019
21
TQBJ2182
Specifications
█ General
Battery life in use (Bluetooth® : SBC mode) [TMAX20]
Illumination ON (Vol. Max.) Approx. 3 hours
Power save mode (Vol. Max.) Approx. 7 hours
Power save mode (Vol. 19) Approx. 10 hours
The battery life may vary with external devices and
signal sources used.
Battery charging time (25°C) [TMAX20]
Unit is OFF Approx. 3 hours
Dimensions (W x H x D) 285 mm x 585 mm x 303 mm
Mass 10.2 kg
Operating temperature range 0°C to +40°C
Charging temperature range [TMAX20] +10°C to +35°C
Operating humidity range
35% to 80% RH (no condensation)
█ Amplifier section
RMS output power (Built-in battery) [TMAX20]
Front Ch (both ch driven)
37.5 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS power 75 W
RMS output power (AC Power supply)
Front Ch (both ch driven)
150 W per channel (3 Ω), 1 kHz, 30% THD
Total RMS power 300 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
█ Disc section
[TMAX10]
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
USB recording
Bit rate 128 kbps
USB recording speed
[TMAX20] 1x
[TMAX10] 1x, 3x (CD only)
Recording file format MP3 (*.mp3)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Audio format PCM
Microphone
Terminal Mono, 6.3 mm jack (2 system)
Analog audio input
Audio input Pin jack (1 system)
DC IN [TMAX10]
Terminal type USB Micro-B, 5 V, 2 A
█ Bluetooth
®
section
Version Bluetooth® Ver. 5.0
Class Class 1
Supported profiles A2DP, AVRCP, SPP
Frequency band 2.4 GHz band FH-SS
Operation distance 30 m line of sight
Supported codec SBC
█ Speaker section
Speaker unit(s)
Woofer 20 cm cone type x 1
Tweeter 6 cm cone type x 2
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum
analyzer.
• The dry battery charge retention time may be shorter under
some operating conditions.
Power supply AC 110 V to 240 V, 50/60 Hz
Built-in battery [TMAX20] 14.4 V (Li-ion 2200mAh)
Power consumption
[TMAX20] 58 W
[TMAX10] 47 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.5 W
With “BLUETOOTH STANDBY” set to “ON” 0.6 W
For Mexico
Power consumption per day
[TMAX20] 58 Wh per day (58 W, 1 hour)
[TMAX10] 47 Wh per day (47 W, 1 hour)
Power consumption per day (in standby mode)
11.5 Wh per day (0.5 W, 23 hours)
SC-TMAX10.20PU_TQBJ2182 En.fm Page 21 Thursday, April 25, 2019 3:55 PM
offset printing
Confidential
Until:
26 Apr 2019
21
TQBJ2182
Specifications
█ General
Battery life in use (Bluetooth® : SBC mode) [TMAX20]
Illumination ON (Vol. Max.) Approx. 3 hours
Power save mode (Vol. Max.) Approx. 7 hours
Power save mode (Vol. 19) Approx. 10 hours
The battery life may vary with external devices and
signal sources used.
Battery charging time (25°C) [TMAX20]
Unit is OFF Approx. 3 hours
Dimensions (W x H x D) 285 mm x 585 mm x 303 mm
Mass 10.2 kg
Operating temperature range 0°C to +40°C
Charging temperature range [TMAX20] +10°C to +35°C
Operating humidity range
35% to 80% RH (no condensation)
█ Amplifier section
RMS output power (Built-in battery) [TMAX20]
Front Ch (both ch driven)
37.5 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS power 75 W
RMS output power (AC Power supply)
Front Ch (both ch driven)
150 W per channel (3 Ω), 1 kHz, 30% THD
Total RMS power 300 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
█ Disc section
[TMAX10]
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
USB recording
Bit rate 128 kbps
USB recording speed
[TMAX20] 1x
[TMAX10] 1x, 3x (CD only)
Recording file format MP3 (*.mp3)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Audio format PCM
Microphone
Terminal Mono, 6.3 mm jack (2 system)
Analog audio input
Audio input Pin jack (1 system)
DC IN [TMAX10]
Terminal type USB Micro-B, 5 V, 2 A
█ Bluetooth
®
section
Version Bluetooth® Ver. 5.0
Class Class 1
Supported profiles A2DP, AVRCP, SPP
Frequency band 2.4 GHz band FH-SS
Operation distance 30 m line of sight
Supported codec SBC
█ Speaker section
Speaker unit(s)
Woofer 20 cm cone type x 1
Tweeter 6 cm cone type x 2
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum
analyzer.
• The dry battery charge retention time may be shorter under
some operating conditions.
Power supply AC 110 V to 240 V, 50/60 Hz
Built-in battery [TMAX20] 14.4 V (Li-ion 2200mAh)
Power consumption
[TMAX20] 58 W
[TMAX10] 47 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.5 W
With “BLUETOOTH STANDBY” set to “ON” 0.6 W
For Mexico
Power consumption per day
[TMAX20] 58 Wh per day (58 W, 1 hour)
[TMAX10] 47 Wh per day (47 W, 1 hour)
Power consumption per day (in standby mode)
11.5 Wh per day (0.5 W, 23 hours)
SC-TMAX10.20PU_TQBJ2182 En.fm Page 21 Thursday, April 25, 2019 3:55 PM
offset printing
Frequency range (For Argentina)
87.9 MHz to 107.9 MHz (200 kHz step)
87.5 MHz to 108.0 MHz (100 kHz step)
Confidential
Until:
26 Apr 2019
21
TQBJ2182
Specifications
█ General
Battery life in use (Bluetooth® : SBC mode) [TMAX20]
Illumination ON (Vol. Max.) Approx. 3 hours
Power save mode (Vol. Max.) Approx. 7 hours
Power save mode (Vol. 19) Approx. 10 hours
The battery life may vary with external devices and
signal sources used.
Battery charging time (25°C) [TMAX20]
Unit is OFF Approx. 3 hours
Dimensions (W x H x D) 285 mm x 585 mm x 303 mm
Mass 10.2 kg
Operating temperature range 0°C to +40°C
Charging temperature range [TMAX20] +10°C to +35°C
Operating humidity range
35% to 80% RH (no condensation)
█ Amplifier section
RMS output power (Built-in battery) [TMAX20]
Front Ch (both ch driven)
37.5 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS power 75 W
RMS output power (AC Power supply)
Front Ch (both ch driven)
150 W per channel (3 Ω), 1 kHz, 30% THD
Total RMS power 300 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
█ Disc section
[TMAX10]
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
USB recording
Bit rate 128 kbps
USB recording speed
[TMAX20] 1x
[TMAX10] 1x, 3x (CD only)
Recording file format MP3 (*.mp3)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Audio format PCM
Microphone
Terminal Mono, 6.3 mm jack (2 system)
Analog audio input
Audio input Pin jack (1 system)
DC IN [TMAX10]
Terminal type USB Micro-B, 5 V, 2 A
█ Bluetooth
®
section
Version Bluetooth® Ver. 5.0
Class Class 1
Supported profiles A2DP, AVRCP, SPP
Frequency band 2.4 GHz band FH-SS
Operation distance 30 m line of sight
Supported codec SBC
█ Speaker section
Speaker unit(s)
Woofer 20 cm cone type x 1
Tweeter 6 cm cone type x 2
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum
analyzer.
• The dry battery charge retention time may be shorter under
some operating conditions.
Power supply AC 110 V to 240 V, 50/60 Hz
Built-in battery [TMAX20] 14.4 V (Li-ion 2200mAh)
Power consumption
[TMAX20] 58 W
[TMAX10] 47 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF” 0.5 W
With “BLUETOOTH STANDBY” set to “ON” 0.6 W
For Mexico
Power consumption per day
[TMAX20] 58 Wh per day (58 W, 1 hour)
[TMAX10] 47 Wh per day (47 W, 1 hour)
Power consumption per day (in standby mode)
11.5 Wh per day (0.5 W, 23 hours)
SC-TMAX10.20PU_TQBJ2182 En.fm Page 21 Thursday, April 25, 2019 3:55 PM
offset printing
Frequency range (For other countries)
47 W

11
SC-TMAX10 E
Confidential
Until:
07 May 2019

74%-

Specifications
Ű General
'LPHQVLRQV:[+[' PP[PP[PP
0DVV NJ
2SHUDWLQJWHPSHUDWXUHUDQJH &WR&
2SHUDWLQJKXPLGLW\UDQJH
WR5+QRFRQGHQVDWLRQ
Ű Amplifier section
506RXWSXWSRZHU$&3RZHUVXSSO\
)URQW&KERWKFKGULYHQ
:SHUFKDQQHOȍN+]7+'
7RWDO506SRZHU :
Ű Tuner section
)UHTXHQF\PRGXODWLRQ)0
3UHVHWPHPRU\ VWDWLRQV
)UHTXHQF\UDQJH
0+]WR0+]N+]VWHS
$QWHQQDWHUPLQDOV ȍXQEDODQFHG
Ű Disc section
'LVFSOD\HGFPRUFP
&'&'55:&''$03 
03(*/D\HU
3LFNXS
:DYHOHQJWK QP&'
NORSK
%¡OJHOHQJGH QP&'
/DVHUVW\UNH ,QJHQIDUOLJVWUnOLQJVHQGHVXW
Ű Terminal section
86%SRUW
86%VWDQGDUG 86%IXOOVSHHG
0HGLDILOHIRUPDWVXSSRUW 03PS
86%GHYLFHILOHV\VWHP )$7)$7)$7
'LJLWDODXGLRLQSXW
2SWLFDOGLJLWDOLQSXW 2SWLFDOWHUPLQDO
6DPSOLQJIUHTXHQF\  N+] N+] N+]N+]
$XGLRIRUPDW 3&0
0LFURSKRQH
7HUPLQDO 0RQRPPMDFNV\VWHP
$QDORJDXGLRLQSXW
$XGLRLQSXW 3LQMDFNV\VWHP
'&,1
7HUPLQDOW\SH 86%0LFUR%9$
Ű Bluetooth

section
9HUVLRQ %OXHWRRWK9HU
&ODVV &ODVV
6XSSRUWHGSURILOHV $'3$95&3633
)UHTXHQF\EDQG *+]EDQG)+66
2SHUDWLQJIUHTXHQF\ 0+]WR0+]
0D[LPXPSRZHU(,53 G%P
2SHUDWLRQGLVWDQFH POLQHRIVLJKW
6XSSRUWHGFRGHF 6%&
Ű Speaker section
6SHDNHUXQLWV
:RRIHU FPFRQHW\SH[
7ZHHWHU FPFRQHW\SH[
Note:
 6SHFLILFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH
0DVVDQGGLPHQVLRQVDUHDSSUR[LPDWH
 7RWDOKDUPRQLFGLVWRUWLRQLVPHDVXUHGE\WKHGLJLWDOVSHFWUXP
DQDO\VHU
3RZHUVXSSO\ $&9WR9+]
3RZHUFRQVXPSWLRQ :
3RZHUFRQVXPSWLRQLQVWDQGE\PRGHDSSUR[LPDWH
:LWK³%/8(7227+67$1'%<´VHWWR³2))´ :
:LWK³%/8(7227+67$1'%<´VHWWR³21´ :
(1*/,6+
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing

12
5 Location of Controls and Components
Confidential
Until:
26 Apr 2019

74%-
Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLWVSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
$&RXWOHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H5HFRUGLQJRSHUDWLRQFRQWURO
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
M6HOHFW'-HIIHFWRU'-VDPSOHU
N6HOHFWWKHLOOXPLQDWLRQHIIHFWV
O6HOHFW03DOEXPRUWUDFN
3UHVV>$/%8075$&.@WRVHOHFWDOEXPRUWUDFN
%URZVHWUDFNVRUDOEXPV
3UHVV>RT@RUWXUQ>92/80(08/7,&21752/@WR
EURZVH
7RVWDUWSOD\EDFNIURPWKHVHOHFWLRQSUHVV>49@
P6HOHFWWKH.DUDRNHHIIHFWV
7RFDQFHOSUHVVDQGKROG>±2))@XQWLO³2))())(&7´
LVVKRZQ
USB
AUXBLUETOOTH
CD FM
D-IN
6&70$;38B74%-(QIP3DJH7KXUVGD\$SULO30
offset printing
SC-TMAX10 PU/PR
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
SC-TMAX10 E

13
Confidential
Until:
07 May 2019

74%-

M6HOHFW'-HIIHFWRU'-VDPSOHU
N6HOHFWWKHLOOXPLQDWLRQHIIHFWV
O6HOHFW03DOEXPRUWUDFN
3UHVV>$/%8075$&.@WRVHOHFWDOEXPRUWUDFN
%URZVHWUDFNVRUDOEXPV
3UHVV>RT@RUWXUQ>92/80(08/7,&21752/@WR
EURZVH
7RVWDUWSOD\EDFNIURPWKHVHOHFWLRQSUHVV>49@
P6HOHFWWKH.DUDRNHHIIHFWV
7RFDQFHOSUHVVDQGKROG>±2))@XQWLO³2))())(&7´
LVVKRZQ
Q9ROXPHRUPXOWLFRQWURONQRE
'RQRWWXUQNQREIDVWWRSUHYHQWLUUHJXODURIYROXPH
RSHUDWLRQ
R6HOHFW'-MXNHER[
6HOHFW'(02SOD\
3UHVVDQGKROG>±'(02@IRUPRUHWKDQVHFRQGVWKH
EXLOWLQGHPRQVWUDWLRQVRQJZLOOEHSOD\HG
3UHVV>8@WRVWRSWKHGHPRQVWUDWLRQ
S2SHQRUFORVHWKHGLVFWUD\
T'-IXQFWLRQGLUHFWEXWWRQV
3UHVV>'-@WRVZLWFKRQWKH'-IXQFWLRQ
3UHVV>'-@WR>'-@WRVHOHFWWKHGHVLUHGIXQFWLRQ
7RFDQFHOSUHVVWKHVHOHFWHG>'-@WR>'-@DJDLQ
U0LFURSKRQHMDFN
V86%SRUW 
3OD\03WUDFNV
W5HPRWHFRQWUROVHQVRU
3RLQWWKHUHPRWHFRQWURODWWKHUHPRWHFRQWURO
VHQVRUDZD\IURPREVWDFOHVDQGZLWKLQWKH
RSHUDWLRQUDQJH
'LVWDQFH:LWKLQDSSUR[LPDWHO\P
$QJOH$SSUR[LPDWHO\XSDQGGRZQOHIW
DQGULJKW
X'LVSOD\SDQHO
Y'LVFWUD\
SELECT
VOL
DJ6
DJ5
DJ4
DJ3
DJ2
DJ1
SOUND
JUKEBOX
KARAOKE
ALBUM/
TRACK
ILLUMINATION
7RSSDQHO
(1*/,6+
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
Record sound or music tracks.(For PU/PR)
Confidential
Until:
07 May 2019

74%-

M6HOHFW'-HIIHFWRU'-VDPSOHU
N6HOHFWWKHLOOXPLQDWLRQHIIHFWV
O6HOHFW03DOEXPRUWUDFN
3UHVV>$/%8075$&.@WRVHOHFWDOEXPRUWUDFN
%URZVHWUDFNVRUDOEXPV
3UHVV>RT@RUWXUQ>92/80(08/7,&21752/@WR
EURZVH
7RVWDUWSOD\EDFNIURPWKHVHOHFWLRQSUHVV>49@
P6HOHFWWKH.DUDRNHHIIHFWV
7RFDQFHOSUHVVDQGKROG>±2))@XQWLO³2))())(&7´
LVVKRZQ
Q9ROXPHRUPXOWLFRQWURONQRE
'RQRWWXUQNQREIDVWWRSUHYHQWLUUHJXODURIYROXPH
RSHUDWLRQ
R6HOHFW'-MXNHER[
6HOHFW'(02SOD\
3UHVVDQGKROG>±'(02@IRUPRUHWKDQVHFRQGVWKH
EXLOWLQGHPRQVWUDWLRQVRQJZLOOEHSOD\HG
3UHVV>8@WRVWRSWKHGHPRQVWUDWLRQ
S2SHQRUFORVHWKHGLVFWUD\
T'-IXQFWLRQGLUHFWEXWWRQV
3UHVV>'-@WRVZLWFKRQWKH'-IXQFWLRQ
3UHVV>'-@WR>'-@WRVHOHFWWKHGHVLUHGIXQFWLRQ
7RFDQFHOSUHVVWKHVHOHFWHG>'-@WR>'-@DJDLQ
U0LFURSKRQHMDFN
V86%SRUW 
3OD\03WUDFNV
W5HPRWHFRQWUROVHQVRU
3RLQWWKHUHPRWHFRQWURODWWKHUHPRWHFRQWURO
VHQVRUDZD\IURPREVWDFOHVDQGZLWKLQWKH
RSHUDWLRQUDQJH
'LVWDQFH:LWKLQDSSUR[LPDWHO\P
$QJOH$SSUR[LPDWHO\XSDQGGRZQOHIW
DQGULJKW
X'LVSOD\SDQHO
Y'LVFWUD\
SELECT
VOL
DJ6
DJ5
DJ4
DJ3
DJ2
DJ1
SOUND
JUKEBOX
KARAOKE
ALBUM/
TRACK
ILLUMINATION
7RSSDQHO
(1*/,6+
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing

14
6 Service Mode
6.1. Self-Diagnostic Mode
Item
FL Display Key Operation
Mode Name Description
Service Mode Enter into Service Mode. In CD mode:
Step 1: Set volume at [0].
Step 2: Press [n] and [g] on
main set for more than 2
seconds.
To exit, press [
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
] on main unit.
Error Code
Information
System will perform a check on
any unusual/error code from the
memory.
It can display up to 5 latest
error codes. To view the each
of the error codes press [n] key
repeatedly.
Please refer to below table for
the ERROR code description.
Example:
If there is no error code it will
display “≡” .
In Service Mode:
Step 1: Press [n] button on the main
set.
To exit, press [
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
] on main unit.
(Error code is still memorized.)
Clear Error Codes To clear the stored Error Codes
in memory.
In Service Mode:
Step 1: Press [OK] on remote control
for more than 5 seconds
during error code display
mode.
To exit, press [
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
] on main unit.
Accumulation Time
(for set turn on)
To check the total turn-on hours.
Time accumulation increases by
hours.
Example: In Service Mode:
Step 1: Press [i].
To clear accumulation time, long
press [OK] on remote control until
“CLEAR” displayed.
To exit, press [
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
] on main unit.
Cold Start To carry out cold-start or initialize
to shipping mode.
(“Error Code Information” and
“Accumulation Time” is not
reset.)
In Service Mode:
Step 1:Press [SETUP] on remote
control.
To exit, press [
Confidential
Until:
07 May 2019

74%-

Overview of controls
'RWKHSURFHGXUHVZLWKWKHUHPRWHFRQWURO<RXFDQDOVRXVHWKHEXWWRQVRQWKHXQLWLIWKH\DUHWKHVDPH
A6WDQGE\RQVZLWFK>`@>1@
3UHVVWRVZLWFKWKHXQLWIURPRQWRVWDQGE\PRGHRU
YLFHYHUVD,QVWDQGE\PRGHWKHXQLWLVVWLOOFRQVXPLQJ
DVPDOODPRXQWRISRZHU
:KHQWKHXQLW¶VSRZHUVRXUFHLVRWKHUWKDQKRXVHKROG
PDLQVVRFNHWSUHVV>1@RQWKHXQLWWRVZLWFKLWRQ
B'HFUHDVHWKHEULJKWQHVVRIWKHGLVSOD\SDQHO
7KHLOOXPLQDWLRQLVDOVRVZLWFKHGRII
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
C6HOHFWWKHDXGLRVRXUFH
3UHVV>6(/(&7 !@XQLW>6(/(&7@UHSHDWHGO\WR
VHOHFWWKHVRXUFH
2QWKHXQLW
7RVWDUW%OXHWRRWKSDLULQJSUHVVDQGKROG> @
D%DVLFSOD\EDFNFRQWURO
E9LHZWKHVHWXSPHQX
F9LHZWKHFRQWHQWLQIRUPDWLRQ
G6HOHFWRUFRQILUPWKHRSWLRQ
H6HWWKHVOHHSWLPHU
I$GMXVWWKHYROXPHOHYHO
2QWKHXQLW
3UHVV>92/@DQGWKHQWXUQ>92/80(08/7,
&21752/@WRDGMXVWWKHYROXPH
$GMXVWWKHPLFURSKRQHYROXPHOHYHO
3UHVVDQGKROG>±0,&92/@XQWLO³0,&92/´LVVKRZQ
7XUQ>92/80(08/7,&21752/@WRDGMXVWWKH
YROXPH
J0XWHWKHVRXQG
7RFDQFHOSUHVVWKHEXWWRQDJDLQ
³087(´LVDOVRFDQFHOOHGZKHQ\RXDGMXVWWKHYROXPH
RUZKHQ\RXVZLWFKRIIWKHV\VWHP
K9LHZWKHSOD\PHQX
L6HOHFWWKHVRXQGHIIHFWV
USB
AUXBLUETOOTH
CD FM
D-IN
70$;(B74%-B(Q6Z'D)L3R&]ERRN3DJH0RQGD\0D\$0
offset printing
] on main unit.
SERVICE
0H
≡
CLEAR
- - - - - - -
“CLEAR” will display for 1s
followed by “≡” display.
F61
≡

15
6.2. Self-Diagnostic Error Code Table
Self-Diagnostic Mode provides information on any problems occurring for the unit and its respective components by displaying
the error codes.
Error Code Description Solution
F61 DAMP output abnormal. Check following:
1. Speaker wires short,
2. Speaker connection.
F76 Power supply abnormal. Check supply voltages on Main
P.C.B.
F703 Bluetooth Communication
abnormal.
Communication between module
and micro-p abnormal
Check Bluetooth P.C.B. on VFD
P.C.B. Unit.
F77 Bluetooth address error
If there is no valid Bluetooth
address in EEPROM.
Check EEPROM IC on Main
P.C.B.
6.3. Sales Demonstration Lock Function
Item
FL Display Key Operation
Mode Name Description
Entering into Sales
Demonstration Lock
Function
To enter into the sales
demonstration lock mode.
Lock function mode will
maintain after Power ON/
OFF or AC In/Out.
The display will show upon
entering into this mode for 2 sec.
In CD mode:
Step 1: Set volume at [0].
Step 2: Press and hold [q] and
[SELECT] buttons on main
set for more than 2 seconds.
Note:
[q] button is invalid and the main
unit displays "LOCK" while the lock
function mode is entered.
To cancel the sales
demonstration lock mode.
The display will show upon
entering into this mode for 2 sec.
In CD mode:
Step 1: Set volume at [0].
Step 2: Press and hold [q] and
[SELECT] buttons on main
set for more than 2 seconds.
- - LOCK - -
Cancellation of Sales
Demonstration Lock
Mode
- UNLOCK -
“Cold Start” will release the
lock function mode.

16
7 Troubleshooting Guide
7.1. No Power
7.2. Bluetooth® Pairing Failure
Can`t power on
Connect the AC cord.
Press the Power
button on the unit to
turn on the unit.
Change
Power P.C.B. unit
OK
NG
Check the Main P.C.B.
XP5 Pin 6/7/8/9 power
output at 28V
[Refer to check point ①]
VFD Panel
doesn’t light up.
Check the cable is
connected correctly
(Main P.C.B. XP5 to
Power P.C.B. XP1)
Reconnect correctly
or change the cable
NG
OK
NG
Press [z] on the
remote control to
Power on the unit.
Check the cable is
connected correctly
(Main P.C.B. XP9 to
Key P.C.B. XP9)
NG
Change
Main P.C.B. Unit
Reconnect correctly or
change the cable
Change
VFD P.C.B. Unit
NG
Change
Key P.C.B. Unit
OK
Change
Key P.C.B. Unit
NG
OK
Bluetooth® Pairing failure
Press [z/I] on the
unit to turn on the
unit.
Press [SELECT <, >]
to select
“BLUETOOTH”.
NG
OK
Press [z/I] on
the unit to turn
on the unit.
The light ring
doesn’t light up.
The light ring is not bright
Change
Key P.C.B. Unit
Press and hold
[ ] on the unit to
start “PAIRING”.
Change
VFD P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B. XP9 to
Key P.C.B. XP9)
Reconnect correctly
or change the cable
NG
Check the cable is
connected correctly
at Main P.C.B. XP6.
Reconnect
correctly
NG
OK
Change
Speaker Wooden
Box Unit
NG
OK
OK Change
Main P.C.B. Unit
23
74%-
ラジオ
Bluetooth
お知らせ
p登録できる Bluetooth機器は最大 8台です。最大登録
数を超えて登録すると、登録の古いものから上書き登
録されます。
準備する
p本機と他の Bluetooth機器がすでに接続さ
れている場合、その機器の接続を解除して
ください。(>右記 )
[ ] を押して音源を
「Bluetooth」に切り換える
表示部に「接続待ち」と表示されます。
Bluetooth機器側で Bluetooth
の接続画面などを開き、
「RX-D70BT」を選んで接続する
表示部に「接続」と表示されます。
Bluetooth機器で音楽などを再生
する
お知らせ
p同時に接続できる Bluetooth機器の台数は 1 台です。
p音源を Bluetoothに切り換えると、本機は最後に接続
していた Bluetooth機器に接続しようとします。
pBluetooth機器と接続中に操作します。
[ 学習モード / 再生モード ] を押す
[][] を押して「接続解除」
を選び、[/] を押す
[][] を押して「YES」を
選び、[/] を押す
お知らせ
p「ペアリング」が表示されるまで [ ] を押したままに
することで、接続を解除することもできます。
pBluetooth以外の音源が選ばれると、Bluetooth機
器の接続が解除されます。
登録されている機器を接続・
再生する
接続を解除する
5;'%774%-BMSQERRN࣮࣌ࢪ㸰㸮㸯㸷ᖺ㸱᭶㸶᪥ࠉ㔠᭙᪥ࠉ༗ᚋ㸳󰪍㸲㸴ศ
7.3. No Light from the Illuminator
Bluetooth® Pairing failure
Press [z/I] on the
unit to turn on the
unit.
Press [SELECT <, >]
to select
“BLUETOOTH”.
NG
OK
Press [z/I] on
the unit to turn
on the unit.
The light ring
doesn’t light up.
The light ring is not bright
Change
Key P.C.B. Unit
Press and hold
[ ] on the unit to
start “PAIRING”.
Change
VFD P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B. XP9 to
Key P.C.B. XP9)
Reconnect correctly
or change the cable
NG
Check the cable is
connected correctly
at Main P.C.B. XP6.
Reconnect
correctly
NG
OK
Change
Speaker Wooden
Box Unit
NG
OK
OK Change
Main P.C.B. Unit

17
Bluetooth® Pairing failure
Press [z/I] on the
unit to turn on the
unit.
Press [SELECT <, >]
to select
“BLUETOOTH”.
NG
OK
Press [z/I] on
the unit to turn
on the unit.
The light ring
doesn’t light up.
The light ring is not bright
Change
Key P.C.B. Unit
Press and hold
[ ] on the unit to
start “PAIRING”.
Change
VFD P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B. XP9 to
Key P.C.B. XP9)
Reconnect correctly
or change the cable
NG
Check the cable is
connected correctly
at Main P.C.B. XP6.
Reconnect
correctly
NG
OK
Change
Speaker Wooden
Box Unit
NG
OK
OK Change
Main P.C.B. Unit
23
74%-
ラジオ
Bluetooth
お知らせ
p登録できる Bluetooth機器は最大 8台です。最大登録
数を超えて登録すると、登録の古いものから上書き登
録されます。
準備する
p本機と他の Bluetooth機器がすでに接続さ
れている場合、その機器の接続を解除して
ください。(>右記 )
[ ] を押して音源を
「Bluetooth」に切り換える
表示部に「接続待ち」と表示されます。
Bluetooth機器側で Bluetooth
の接続画面などを開き、
「RX-D70BT」を選んで接続する
表示部に「接続」と表示されます。
Bluetooth機器で音楽などを再生
する
お知らせ
p同時に接続できる Bluetooth機器の台数は 1 台です。
p音源を Bluetoothに切り換えると、本機は最後に接続
していた Bluetooth機器に接続しようとします。
pBluetooth機器と接続中に操作します。
[ 学習モード / 再生モード ] を押す
[][] を押して「接続解除」
を選び、[/] を押す
[][] を押して「YES」を
選び、[/] を押す
お知らせ
p「ペアリング」が表示されるまで [ ] を押したままに
することで、接続を解除することもできます。
pBluetooth以外の音源が選ばれると、Bluetooth機
器の接続が解除されます。
登録されている機器を接続・
再生する
接続を解除する
5;'%774%-BMSQERRN࣮࣌ࢪ㸰㸮㸯㸷ᖺ㸱᭶㸶᪥ࠉ㔠᭙᪥ࠉ༗ᚋ㸳󰪍㸲㸴ศ
7.4. No Sound
7.4.1. No Sound (CD)
No Sound (CD)
No Sound (Bluetooth®)
Press the Power
button to turn on
the unit.
Select “BLUETOOTH”
source and connect
Bluetooth® device
Go to
“Bluetooth® Pairing failure”
NG
OK Change
Main P.C.B. Unit
Press the
power button to
turn on the unit.
NG
Select “CD”source
and load CD disc.
No sound output
Change
Key P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B.
XP12,XP14,XP18 to Loader)
Connect correctly
NG
OK Change
Main P.C.B. Unit
No sound output
OK
7.4.2. No Sound (Bluetooth®)
No Sound (CD)
No Sound (Bluetooth®)
Press the Power
button to turn on
the unit.
Select “BLUETOOTH”
source and connect
Bluetooth® device
Go to
“Bluetooth® Pairing failure”
NG
OK Change
Main P.C.B. Unit
Press the
power button to
turn on the unit.
NG
Select “CD”source
and load CD disc.
No sound output
Change
Key P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B.
XP12,XP14,XP18 to Loader)
Connect correctly
NG
OK Change
Main P.C.B. Unit
No sound output
OK
7.4.3. No Sound (USB)
No Sound (USB)
Press [z/I] to
turn on the unit
After display
“READING”,
press [i] button.
No Sound (Optical Input)
Select “USB”
source and insert
USB device
Press the [z/I] to
turn on the unit
No Sound
output
Connect external device.
Press [SELECT <,>]
repeatedly to select “D-IN”
Change
Main P.C.B. Unit
No Sound output
Yes
Change
OPTICAL cable
Yes
Change
Main P.C.B. Unit
Display
“NO DEVICE”
No
Change
USB P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B. XP10
to USB P.C.B. XP10)
Reconnect correctly
or change the cable
NG
Yes
Yes
OK
NG
Change
Main P.C.B. Unit
NG

18
7.4.4. No Sound (Optical Input)
No Sound (USB)
Press [z/I] to
turn on the unit
After display
“READING”,
press [i] button.
No Sound (Optical Input)
Select “USB”
source and insert
USB device
Press the [z/I] to
turn on the unit
No Sound
output
Connect external device.
Press [SELECT <,>]
repeatedly to select “D-IN”
Change
Main P.C.B. Unit
No Sound output
Yes
Change
OPTICAL cable
Yes
Change
Main P.C.B. Unit
Display
“NO DEVICE”
No
Change
USB P.C.B. Unit
Check the cable is
connected correctly
(Main P.C.B. XP10
to USB P.C.B. XP10)
Reconnect correctly
or change the cable
NG
Yes
Yes
OK
NG
Change
Main P.C.B. Unit
NG
7.4.5. No Sound (AUX)
No Sound(AUX)
No Sound (FM)
Press [z/I] to
turn on the unit No Sound output
Select “AUX ”source
and connect external
device.
Change
Audio cable
Yes
Change
Main P.C.B. Unit
Press [z/I] to
turn on the unit
Select “FM ”source
and connect the
antenna.
Yes
Change
Main P.C.B. Unit
Search for the right
FM radio station
NG
No Sound output
NG
7.4.6. No Sound (FM)
No Sound(AUX)
No Sound (FM)
Press [z/I] to
turn on the unit No Sound output
Select “AUX ”source
and connect external
device.
Change
Audio cable
Yes
Change
Main P.C.B. Unit
Press [z/I] to
turn on the unit
Select “FM ”source
and connect the
antenna.
Yes
Change
Main P.C.B. Unit
Search for the right
FM radio station
NG
No Sound output
NG

19
7.5. Check Points
CheckPoints
MainBoard
>3,1@RI;39
Main P.C.B.
1

20
8.4. Top Cabinet
8 Disassembly and Assembly Instructions
8.1. Disassembly Flow Chart
The following chart is the procedure of disassembling the casing and inside parts for internal inspection when
carrying out the servicing.
To assemble the unit, reverse the steps shown in the chart below.
8.2. Types of Screws
CAUTION NOTE:
Please use origianl screws and at correct locations.
Below shown is part no. of different screw types used:
8.6. VFD P.C.B. & Key P.C.B. 8.5. USB P.C.B.
8.7. Power P.C.B. 8.8. Main P.C.B. 8.9. Speaker
8.10. CD Mecha
aTHMA001N
b THMA002N
cTHMA003N
dTHMA004N
eTHMA006H
f THMA007H
