Panasonic AV-HS6000 User manual

2ME Live Switcher
AV-HS6000 Series
ENGLISH
VQT5J51A-4(E)
W0214HM4066 -YI
Main Frame
Model No. AV-HS60U1P/AV-HS60U2P
Model No. AV-HS60U1E/AV-HS60U2E
Menu Panel
Model No. AV-HS60C3G
Control Panel
Model No. AV-HS60C1P/AV-HS60C2P
Model No. AV-HS60C1E/AV-HS60C2E
Control Panel
Model No. AV-HS60C4P
Model No. AV-HS60C4E
(Included Installation Instructions)
Operating Guide

– 2 –
Information on software for this product
Included with this product is software licensed under the GNU General Public License (GPL) and GNU Lesser General Public License (LGPL), and
users are hereby informed that they have the right to obtain, change, and redistribute the source codes of this software.
Included with this product is software which is licensed under MIT-License.
To obtain the source codes, visit the following website.
http://pro-av.panasonic.net/
The manufacturer asks users to refrain from directing inquiries concerning the source codes they have obtained and other details to its representatives.
Trademarks and registered trademarks
fMicrosoft®, Windows®7, and Internet Explorer®are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
fIntel®and Intel®CoreTM are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and/or other countries.
fAdobe®and Reader®are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
fSDHC Logo is a trademark of SD-3C, LLC.
fPrimatte®is a registered trademark of IMAGICA DIGIX Inc.
fThe copyrights of Primatte®belong to IMAGICA DIGIX Inc.
fThe patents for Primatte®belong to IMAGICA DIGIX Inc.
fOther names of companies and products contained in this document may be trademarks or registered trademarks of their respective owners.
Copyright and license
Distributing, copying, disassembling, reverse compiling, reverse engineering, and also exporting in violation of export laws of the software provided with
this unit are expressly prohibited.
How to read this document
rAbbreviations
The following abbreviations are used in this document.
fMicrosoft®Windows®7 Professional SP1 32/64-bit is abbreviated to Windows 7.
fWindows®Internet Explorer®8.0, Windows®Internet Explorer®9.0, and Windows®Internet Explorer®11.0 are abbreviated as Internet Explorer.
fThe model numbers of the Main Frames AV-HS60U1P/AV-HS60U2P, AV-HS60U1E/AV-HS60U2E are described as “AV-HS60U1”/“AV-HS60U2”.
fThe model numbers of the Control Panels AV-HS60C1P/AV-HS60C2P, AV-HS60C1E/AV-HS60C2E are described as “AV-HS60C1”/“AV-HS60C2”.
fThe model numbers of the Control Panels AV-HS60C4P and AV-HS60C4E are described as “AV-HS60C4”.
fThe model number of the Menu Panel AV-HS60C3G is described as “AV-HS60C3”.
fThe model number of the optional Storage Module AV-HS60D1G is described as “AV-HS60D1”.
fThe model number of the optional Chromakey Software AV-SFU60G is described as “AV-SFU60”.
fBoth SD memory cards and SDHC memory cards are described as “memory cards”.
When individual descriptions are provided, they are featured individually.
fPersonal computers are described as “computers”.
rIllustrations and screen displays featured in this document
fWhat is shown in this document’s illustrations and screen displays may differ from how it is actually appears.
rConventions used in this document
fWords and phrases in [ ] brackets indicate descriptions displayed in the Menu Panel AV-HS60C3 or the multi-selection menu panel, source name
display panel, status display area of the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4.
fWords and phrases in < > brackets indicate design text used on this unit, such as button names.
rReference pages
fIn this document, reference pages are described as (page 00).

Contents
– 3 –
Contents
Chapter 1 Overview 5
Before use 6
Features 7
Conguration of the AV‑HS6000 series 8
Conguration list of the AV‑HS6000 series 8
Accessories of the AV-HS6000 series 8
Required computer environment 9
Precautions for use 10
Chapter 2 Installation and Connection (To
installation personnel) 11
Installation (To installation personnel) 12
Installing the Main Frame AV-HS60U1/AV-HS60U2 12
Installing the Control Panel AV-HS60C1/AV-HS60C2/
AV-HS60C4 13
Installing the Menu Panel AV-HS60C3 13
Attaching the Storage Module AV-HS60D1 (SSD) 13
Installing the Chromakey Software AV-SFU60 14
Connection (To installation personnel) 15
Connecting the imaging systems 15
Connecting the control systems 15
Chapter 3 Part Names and Functions 19
Main Frame AV‑HS60U1/AV‑HS60U2 20
Front panel 20
Rear panel 20
Control Panel AV‑HS60C1/AV‑HS60C2/AV‑HS60C4 22
Operation panel 22
Front panel 27
Rear panel 28
Side (right) 29
Menu Panel AV‑HS60C3 30
Operation panel 30
Rear panel 31
Chapter 4 Preparations 32
Turning power on/off 33
Turning power on 33
Turning power off 34
Basic menu operations 35
Menu conguration and operations 35
Numeric entry item operations 36
Text entry item operations 37
Color settings menu operations 38
Other buttons 39
Basic operations for the multi‑selection panel area 40
Background wipe preset menu 40
Shot memory menu 41
Event memory menu 42
Video memory menu 43
Plug-in menu 44
Menu delegation function 45
Enabling/disabling the menu delegation function 45
Menu delegation function list 45
Various settings 47
Network settings 47
Setting signal formats 49
Setting sync signals 49
Setting input signals 49
Button settings 50
Setting output signals 50
Setting MultiView displays 50
Setting a tally 50
Setting date and time 51
Chapter 5 Basic Operations 52
Background transition 53
Selecting a bus 53
Selecting a bus using the SHIFT function 53
Selecting the bus mode 53
Transition operations 53
Wipe 55
Selecting the wipe pattern for background transition 55
Selecting the wipe direction 55
Wipe decorations (border, soft effect) 55
Modifying wipe 56
KEY 61
Selecting the key type 61
Selecting the key source 62
Key transitions 62
Key wipe transition 63
Key output 65
Adjusting the luminance key/linear key 65
Adjusting the chroma key 65
Key decorations 70
Masking the key signals 71
Setting box matte 71
PinP (Picture in Picture) 71
Setting the priority 75
Setting [Key On Link] 75
On/off of the key by the menu operation 75
DSK (Downstream key) 76
Selecting the DSK type 76
Selecting the source type 76
Selecting the ll type 76
Selecting the DSK source 76
DSK transition 77
DSK output 77
Adjusting the luminance key/linear key 77
DSK decorations 78
Masking the DSK 79
Setting the priority 79
Setting [DSK On Link] 80
On/off of the DSK by the menu operation 80
USK (Upstream key) 81
Selecting the USK type 81
Selecting the source type 81
Selecting the ll type 82
Selecting the USK source 82
Setting the USK insert 82
Adjusting the luminance key/linear key 83
Masking the USK 83
IMAGE 85
Setting image effects 85
Executing image effects 85
Color corrector 86
Setting the color corrector 86
Initializing the color corrector 86
Copying the setting 86
Process control 86
Tone curve 87
Adjusting the gain of color matrix 87
Internal color signals 88
Setting the color background 88
Setting the gradation 88
Switching the AUX output 89
Selecting the AUX output sources 89
Transitions of AUX1 to AUX4 buses 89
Linking AUX buses 89
Memory 90
Shot memory 90
Event memory 92
Macro memory 99
Key preset 102
Video memory 103
Recording still images (Still) 103
Recording moving images (Clip) 104
Operating the register memory 105
Using image les created on a computer 106
Playing back moving images (Clip) 108
Layout of display icons 110
Operating in the multi-selection panel area 112
Project management 113
Saving data on a memory card or storage module 113
Loading data from a memory card or the storage module 113
Editing data in a memory card or the storage module 114
Saving and loading data in/from the local computer 114
Storage 115
Memory card 115
Storage Module 116
Saving and loading data in/from the local computer 117

Contents
– 4 –
Chapter 6 Input/Output Signal Settings 118
Setting input signals 119
Setting the frame synchronizer 119
Setting the input mode 119
Setting the delay amount 120
Freezing input signals 120
Setting the source name 120
Setting the up-converter 120
Setting DVI input signals 121
Displaying video input signal information 124
Setting output signals 125
Assigning output signals 125
Setting the down-converter 125
Setting MultiView displays 127
Setting the screen layout 127
Setting the split frame and characters 127
Setting the tally display 128
Other display settings 128
Chapter 7 CONFIG Menu 129
Disabling button operations 130
Assigning signals to buttons 131
Setting the source name 132
Setting the source name display panel 132
Setting the MultiView display 132
Setting the source link 134
Setting the key coupling 134
Linking the AUX bus 134
Setting the operation mode 135
Setting the operation mode for the crosspoint buttons 135
Setting the transition operation mode 136
Switching the ME area in the Control Panel AV-HS60C1/
AV-HS60C2/AV-HS60C4 137
Key source preset settings 138
Locking the menu operation 139
Chapter 8 System Menu 140
System settings 141
Setting the video format function 141
Setting the output phase 141
Setting the sync signal 144
Other video signal settings 144
Network settings 146
Setting the image and the WFM/VECT to display on the Menu
Panel AV-HS60C3 147
Setting the Main Frame AV‑HS60U1/AV‑HS60U2 148
Setting the ME output and DSK output 148
Setting the Control Panel AV‑HS60C1/AV‑HS60C2/
AV‑HS60C4 151
Settings for the main control panel and sub control panel 151
Setting the button color 151
Setting the external connection 153
Setting a serial port 153
Setting a tally
153
Setting the GPI input/output 154
Maintenance settings 156
Software and hardware version 156
Alarm 156
Initialization 157
Installation condition of the Storage Module 158
Maintenance 159
Setting the date and time 159
Locking the menu operation 161
Chapter 9 3G mode/4K mode 162
Switcher mode 163
Selecting the switcher mode 163
Difference of function for each mode 164
Comparison of function for each mode 164
Considerations for 4K mode 166
Chapter 10 External Interfaces 168
GPI input/output settings and alarm output 169
GPI input/output ports of the Main Frame AV-HS60U1/
AV-HS60U2 169
GPI input/output ports of the Control Panel AV-HS60C1/
AV-HS60C2/AV-HS60C4 170
Serial ports 171
Serial ports of the Main Frame AV-HS60U1/AV-HS60U2 171
Serial ports of the Control Panel AV-HS60C1/AV-HS60C2/
AV-HS60C4 171
Plug‑in software 172
Chapter 11 Specications 173
Dimensions 174
Dimensions of the Main Frame AV-HS60U1/AV-HS60U2 174
Dimensions of the Control Panel AV-HS60C1/AV-HS60C2 175
Dimensions of the Control Panel AV-HS60C4 176
Dimensions of the Menu Panel AV-HS60C3 177
Specications 178
Main Frame AV-HS60U1/AV-HS60U2 178
Control Panel AV-HS60C1/AV-HS60C2 181
Control Panel AV-HS60C4 181
Menu Panel AV-HS60C3 182
Storage Module 183
Chapter 12 Appendix 184
Setting menu table 185
<ME1>/<ME2> button (top menu) 185
<DSK MISC> button (top menu) 190
<MEM> button (top menu) 191
<SYS> button (top menu) 194
<IN OUT> button (top menu) 198
<MV> button (top menu) 199
<PLUG IN> button (top menu) 200
<PRJ> button (top menu) 200
<CONF> button (top menu) 200
Glossary 202
Index 204

Please read this chapter, and check the accessories before use.
Chapter 1 Overview

– 6 –
Chapter 1 Overview — Before use
Before use
rOverview
Live Switcher AV-HS6000 employs a newly designed, easy-to-use UI graphical Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 to support accurate
switching.
And even with a 3U size compact design, it is equipped with abundant inputs and outputs for great system integration as seen by its 32 SDI and 2 DVI
inputs plus 16 SDI outputs.
To top it all off, situations where creative video production is demanded alongside fast response are handled by providing 4 DVEs per ME to enable
diverse transitions.
rPrecautions
fBe sure to perform validation of the unit before use.
fShould displaying or recording of the video fail due to a malfunction of the unit or memory cards used, we will not assume liability for such failure.
rNetwork security
The unit also has functions which are used when it is connected to a network. Using the unit when it has been connected to a network may possibly give
rise to the following issues.
fLeakage or theft of information through this unit
fUse of this unit for illegal operations by persons with malicious intent
fInterference with or stoppage of this unit by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself against the above network security risks.
fUse this unit in a network secured by a rewall, etc.
fIf this unit is connected to a network that includes computers, make sure that the system is not infected by computer viruses or other malicious entities
(using a regularly updated antivirus program, anti-spyware program, etc.).
The following points should be borne in mind as well.
fUse with the same segment is recommended for the devices which are connected to the unit. If the unit is connected to the devices whose segments
are different, events dependent upon the settings inherent to the network equipment, for instance, may occur. Thoroughly check the connections with
the devices to which the unit will be connected prior to the start of operation.
fDo not choose an installation location where the unit, cables and other parts will be easily damaged.
rConcerning differences in the system versions
This document describes the functions of the models with system version 4.00-00-0.00 or later.
Some functions cannot be operated in the models with system version earlier than 4.00-00-0.00.
To check the system version of this unit, select the <SYS> button on the top menu →[MAINTENANCE] →[Status] tab →[System Version] in the
[System Version] column. (page 156)
For the latest information, visit the following website.
http://pro-av.panasonic.net/ (English only)
rConcerning the switcher mode
There are three operation modes of Standard mode, 3G mode, and 4K mode for this unit. The video formats that can be selected are different for each
mode.
fThe HD format and the SD format can be selected for the Standard mode.
-HD format: [1080/59.94i], [1080/50i], [1080/29.97PsF], [1080/25PsF], [1080/24PsF], [1080/23.98PsF], [720/59.94p], [720/50p].
-SD format: [480/59.94i], [576/50i].
fFollowing formats can be selected for the 3G mode.
[1080/59.94p], [1080/50p]
fFollowing formats can be selected for the 4K mode.
[2160/59.94p], [2160/50p]
This document describes the operation of the Standard mode unless it is specically noted. For details on operation of the 3G mode or the 4K mode,
refer to “Difference of function for each mode” (page 164).

– 7 –
Chapter 1 Overview — Features
Features
rGraphical Control Panel AV‑HS60C1/AV‑HS60C2/AV‑HS60C4
fThe multi-selection panel is set up for each ME for quick access to various functions such as wipe patterns, shot memory, and event memory.
fTactile color LCD switch: The multi-selection panel employs switch so that you can make sure keys being pressed, supporting reliable operation.
fCrosspoint buttons: Crosspoint buttons can be grouped by buttons lights with multiple color.
fSource name display panel: The monochrome source name display panel is set up for each ME so that graphics can be displayed on the crosspoint
buttons.
rRich array of inputs/outputs with standard 34 inputs
fThe unit is equipped with SDI×32 inputs/DVI×2 inputs and SDI×16 outputs.
fAll inputs have built-in frame synchronizers.
fColor correctors are installed in 8 inputs and 4 outputs.
fUp-converters are installed in 4 inputs and down-converters are installed in 2 outputs.
rDiverse transitions and a full array of keyers
fThe unit is equipped with 4 DVE and 2 DVE (2D) per ME to handle backgrounds and keys.
fAUX1 to AUX4 buses are equipped with MIX transitions.
fThe unit is equipped with real-time high-quality chroma keying that employs Primatte®* algorithms. Standard 1 channel per ME is expandable up to 4
channels per ME.
fThe unit is equipped with 4 channels per ME (total 8 channels) of keyer which is capable of PinP.
fThe unit is equipped with 4 channels of downstream keyers.
fThe unit is equipped with 4 channels of upstream keyers.
* Primatte®is a registered trademark of IMAGICA DIGIX Inc. The copyrights of Primatte®belong to IMAGICA DIGIX Inc. The patents for Primatte®belong to
IMAGICA DIGIX Inc.
rMultiViewer output
fThe unit is equipped with 4 independent MultiViewer displays.
fSingle MultiViewer can display a maximum of 16 video sources.
fSource names, tallies, audio level meters, and safety markers are displayable.
rNetwork function
fWeb server function: Enables menu operation from a Web browser of a computer which is connected to the <LAN> terminal of the Main Frame
AV-HS60U1/AV-HS60U2.
rRedundant operation system for peace of mind
fThe Main Frame AV-HS60U2 and the Control Panel AV-HS60C2/AV-HS60C4 have separate power sources. (The single power supply model is also
available.)
fOperation with two additional panels is possible by IP connection.
rWide range of functions to increase operability
fShot memory, event memory, and macro memory allow you to preset and recall frequently used effects easily.
fVideo clips and still images can be registered up to 4ch each, allowing them to be easily used for CG wipes.
fThe switcher can be set by the 10.1-inch touch-operated Menu Panel AV-HS60C3 (optional) or by a PC monitor and USB mouse.
fWith plug‑in software, external device control capability can be added in accordance with the operation workow.

– 8 –
Chapter 1 Overview — Conguration of the AV‑HS6000 series
Conguration of the AV‑HS6000 series
Conguration list of the AV‑HS6000 series
Series product name AV-HS6000 series
Main Frame Single Power Supply model AV-HS60U1
Redundant Power Supply model AV-HS60U2
Control Panel (24XPT) Single Power Supply model AV-HS60C1
Redundant Power Supply model AV-HS60C2
Control Panel (16XPT) Redundant Power Supply model AV-HS60C4
Menu Panel AV-HS60C3
Storage Module AV-HS60D1
Chromakey Software AV-SFU60
Accessories of the AV‑HS6000 series
rMain Frame AV‑HS60U1/AV‑HS60U2
fAC cable
-AV-HS60U1P: 1 cable, AV-HS60U2P: 2 cables
-AV-HS60U1E: 2 cables, AV-HS60U2E: 4 cables
fRack-mounted rear panel support bracket
fScrews for the rack-mounted rear panel support bracket: 8 screws
fOperating Guide of the AV-HS6000 series (Excerpted Version)
fAV-HS60U1/AV-HS60U2 Operating Instructions (Excerpted Version)
rControl Panel AV‑HS60C1/AV‑HS60C2
fAC cable
-AV-HS60C1P: 1 cable, AV-HS60C2P: 2 cables
-AV-HS60C1E: 2 cables, AV-HS60C2E: 4 cables
fLAN cable: 1 cable (used to connect with the Main Frame AV-HS60U1/AV-HS60U2)
fSwitch blank cap (large): 24 caps
fSwitch blank cap (small): 12 caps
fAV-HS60C1/AV-HS60C2 Operating Instructions
rControl Panel AV‑HS60C4
fAC cable
-AV-HS60C4P: 2 cables
-AV-HS60C4E: 4 cables
fLAN cable: 1 cable (used to connect with the Main Frame AV-HS60U1/AV-HS60U2)
fSwitch blank cap (large): 16 caps
fSwitch blank cap (small): 8 caps
fAV-HS60C4 Operating Instructions (Excerpted Version)
rMenu Panel AV‑HS60C3
fControl Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 connection cable (with ferrite core): 1 cable
fControl Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 mounting bracket
fScrew for the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 mounting bracket: 6 screws
fAV-HS60C3 Operating Instructions (Excerpted Version)
rStorage Module (AV‑HS60D1)
fAV-HS60D1 Installation Guide
rChromakey Software (AV‑SFU60)
fRead before use
fSoftware Licensing Agreement
fPouch containing the key code
@@NOTE
tAfter removing the product from its container, dispose of the AC cable cap and packing materials in an appropriate manner.

– 9 –
Chapter 1 Overview — Required computer environment
Required computer environment
@@NOTE
tFor the host computer to be connected to the <LAN> terminal of the Main Frame AV-HS60U1/AV-HS60U2, use a computer which meets the following
conditions:
CPU Intel®CoreTM 2 DUO 2.4 GHz or more recommended
Memory 2 GB or more recommended
Network function 100Base-TX
Image display function
Resolution:
1024×768 pixels or more
Color generation:
True Color (24 bits or more)
Compatible OS Microsoft
Windows 7:
Internet Explorer 9.0, Internet Explorer 11.0
fInternet Explorer 8.0 cannot be used.
Hard disk drive 50 MB or more free memory
Other Adobe®Reader®
(For viewing the Operating Guide)

– 10 –
Chapter 1 Overview — Precautions for use
Precautions for use
rHandle carefully.
Do not drop the product, or subject it to strong impact or vibration. Do not carry or move the product by the fader lever. This is important to prevent
malfunction or accidents.
rUse the product at a temperature of 0 °C to 40 °C (32 °F to 104 °F).
Avoid using the product at a cold place below 0 °C (32 °F) or at a hot place above 40 °C (104 °F), because extremely low or high temperature may
adversely affect the parts inside.
rTurn off the power before connecting or disconnecting cables.
Before connecting or disconnecting the cables, be sure to turn off the power.
rAvoid humidity and dust.
Avoid using the product at a humid, dusty place because much humidity and dust will cause damage to the parts inside.
rMaintenance
Turn off the power and wipe the product using a dry cloth. To remove stubborn dirt, dip a cloth into a diluted solution of kitchen detergent (neutral), wring
it out well, and wipe the product gently. Then, after wiping the product with a moist cloth, wipe it again with a dry cloth.
@@NOTE
tAvoid using benzine, paint thinners and other volatile uids.
tIf a chemical cleaning cloth is to be used, carefully read through the precautions for its use.
rPrecaution to be observed during production
Video switching and video effect functions of this unit can be used to produce videos which icker rapidly or videos which change rapidly.
However, bear in mind when using these functions in production that the kinds of videos produced may have an adverse effect on the viewer’s physical
well-being.
rBuilt‑in display
Leaving the organic EL panel of the source display panel, multi-selection menu panel, and LCD panel of the Menu Panel AV-HS60C3 on with the same
image over a long period of time may result in afterimage (burn‑in). Use after conguring the screensaver settings.
The liquid crystal parts are highly precise with more than 99.99% of the pixels effective. This leaves less than 0.01% of pixels that may not light or may
remain on all the time.
These phenomena are normal and will have no effect on the images you shoot.
Condensation may form on the LCD panel if you use the unit where temperatures uctuate. Wipe it with a soft, dry cloth.
When the unit has completely cooled down, the display on the LCD monitor appears slightly darker than usual immediately after the power has been
turned on. Once the internal temperature of the unit rises, the display returns to the normal brightness.
rTouch screen
Operate with your ngers on the touch screen of the Menu Panel AV‑HS60C3. Do not touch the panel with sharp‑pointed, hard object such as a ballpoint
pen.
rWhen the product is to be discarded
When the product is to be discarded at the end of its service life, ask a specialized contractor to dispose of it properly in order to protect the
environment.
rConsumable parts
fCooling fan:
This is a consumable part.
As a general rule, replace it every 5 years or so (when the unit has been operated for 15 hours a day).
fPower supply unit:
This is a consumable part.
As a general rule, replace it every 5 years or so (when the unit has been operated for 15 hours a day).
The period when the consumable parts need to be replaced will differ depending on the operating conditions.
When the time comes to replace one of these parts, be sure to ask your dealer to do the job.

This chapter describes installation and connection.
Chapter 2 Installation and Connection (To
installation personnel)

– 12 –
Chapter 2 Installation and Connection (To installation personnel) — Installation (To installation personnel)
Installation (To installation personnel)
CAUTION:
These servicing instructions are for use by qualied service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualied to do so.
indicates safety information.
Installing the Main Frame AV‑HS60U1/AV‑HS60U2
When installing or connecting the unit, be sure to ask your dealer. When you want to add the redundant power supply on the Main Frame
AV‑HS60U1, consult your dealer.
rConnecting the power supply
fConnect the <SIGNAL GND> terminal on the rear panel of the unit to the ground of the system.
fUse the Main Frame AV-HS60U2 with both the power supply 1 and the power supply 2.
An alarm is displayed when there is no AC power input to the power supply 1 and the power supply 2 or when the power switch is set to <OFF>.
(An alarm will not be displayed on the Main Frame AV-HS60U1, because it has only the power supply 1.)
rHandle carefully.
fDropping the unit or subjecting it to strong impact or vibration may cause trouble and/or malfunctioning.
rDo not allow any foreign objects to enter inside the unit.
fAllowing water, metal items, scraps of food or other foreign objects inside the unit may cause a re and/or electric shocks.
rChoosing the best installation location
fThis unit is a device for indoor use only.
fSecurely mount the unit on the 19-inch standard rack that complies with the EIA standards (overall depth: 600 mm (23-5/8 inches) or more).
fSecurely afxed with screws that match an appropriately sized rack.
fBe sure to attach the rack-mounted rear panel support bracket (accessory) that supports the back part of the Main Frame AV-HS60U1/AV-HS60U2.
(Prepare a support bracket appropriate for the rack if the supplied bracket cannot be attached.)
fSecure sufcient space around the ventilation holes at the front and side of the front cover.

– 13 –
Chapter 2 Installation and Connection (To installation personnel) — Installation (To installation personnel)
fDo not install the unit in a manner in which the unit or cables can be easily damaged.
fAvoid installing the unit where it will be exposed to direct sunlight or to the hot air that is blown out from other products.
fInstalling the unit in a very humid, dusty, or vibration-prone location may cause malfunction.
Installing the Control Panel AV‑HS60C1/AV‑HS60C2/AV‑HS60C4
When installing or connecting the unit, be sure to ask your dealer. When you want to add the redundant power supply on the Control Panel
AV‑HS60C1, consult your dealer.
rConnecting the power supply
fConnect the <SIGNAL GND> terminal on the rear panel of the unit to the ground of the system.
fUse the Control Panel AV-HS60C2/AV-HS60C4 with both the power supply 1 and the power supply 2.
An alarm is displayed when there is no AC power input to the power supply 1 and the power supply 2 or when the power switch is set to <OFF>.
(An alarm will not be displayed on the Control Panel AV-HS60C1, because it has only the power supply 1.)
rHandle carefully.
fDropping the unit or subjecting it to strong impact or vibration may cause trouble and/or malfunctioning.
rDo not allow any foreign objects to enter inside the unit.
fAllowing water, metal items, scraps of food or other foreign objects inside the unit may cause a re and/or electric shocks.
rChoosing the best installation location
fThis unit is a device for indoor use only.
fInstall the unit on a sufciently strong, stable, and level surface for use.
fSecure a space surrounding the ventilation holes on the front panel of the power supply unit and on the rear panel of the Control Panel AV-HS60C1/
AV-HS60C2/AV-HS60C4 so that air circulation is not impeded.
In particular, ensure sufcient space between ventilation and wiring when using mounted in a panel or table.
fAvoid installing the unit where it will be exposed to direct sunlight or to the hot air that is blown out from other products.
fInstalling the unit in a very humid, dusty or vibration-prone location may cause malfunction.
Installing the Menu Panel AV‑HS60C3
Attach the panel using 4 mounting holes (M4 screw ×4, 75 mm (2-15/16 inches) pitch) on the rear panel of the Menu Panel AV-HS60C3.
For details, refer to “Dimensions of the Menu Panel AV-HS60C3” (page 177).
Attaching the Storage Module AV‑HS60D1 (SSD)
If attached inside the Main Frame AV-HS60U1/AV-HS60U2, register memories of Still and Clip, and project data can be saved in the Main Frame
AV-HS60U1/AV-HS60U2.
For details, refer to the “Installation Guide” of the Storage Module AV-HS60D1 (optional).
@@NOTE
tWhen attaching or removing the module, be sure to ask your dealer.
tBefore attaching or removing the module, turn off the power, and disconnect the power plug.
tBefore coming into physical contact with the Storage Module AV-HS60D1 (optional), touch a grounded metal object with your hand to discharge the
static electricity in your body. A safe way to proceed is to wear an anti-static wrist strap. Touching the option board with static still in your body may
cause malfunction.
tDo not drop the Storage Module AV-HS60D1 (optional) or subject it to strong impact or vibration.
tWhen attaching or removing the Storage Module AV-HS60D1 (optional), take care not to hurt yourself on the edges or metal parts of the Main Frame
AV-HS60U1/AV-HS60U2.

– 14 –
Chapter 2 Installation and Connection (To installation personnel) — Installation (To installation personnel)
Installing the Chromakey Software AV‑SFU60
If the activation operation is performed using the key code attached to the Chromakey Software AV-SFU60 (optional), chroma key functions of KEY2,
KEY3, and KEY4 can be added. One package contains a single keyer for ME1 and ME2, so three packages are required when adding chroma key
functions to all keyers.
For details, refer to “Expansion of the chroma key function” (page 158).

– 15 –
Chapter 2 Installation and Connection (To installation personnel) — Connection (To installation personnel)
Connection (To installation personnel)
Connecting the imaging systems
<SDI IN 1> to <SDI IN 32>/<DVI‑D IN1>/<DVI‑D IN2> terminals
Connect cameras, VTR, and other external sources.
The SDI input of the Main Frame AV-HS60U1/AV-HS60U2 has a frame synchronizer function, and a non-synchronized SDI signal can be input. To
reduce image delay, set the frame synchronizer function to [Off], send a sync signal to the unit and the input device, and congure a synchronized
system.
Computer
Camera
<SDI OUT 1> to <SDI OUT 16> terminals
Connect the switcher output signal to monitors and other external devices.
HD-SDI monitor
<REF> terminal
Connect the system sync signal from the sync signal generator.
The loop-through output is performed in the external sync mode. If the loop-through output is not going to be used, provide a 75 Ωtermination.
Black burst signals are output from both terminals in the internal sync mode.
Internal sync mode
Internal signal
generator
INT
Sync signal
External sync mode
Connecting the control systems
Connect the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4, computer for menu operation, or external devices to the Main Frame AV-HS60U1/
AV-HS60U2.
The connection of the main control panel and the sub control panel is described here using the illustration of AV-HS60C1/AV-HS60C2.
AV-HS60C4 can also be connected in the same manner.

– 16 –
Chapter 2 Installation and Connection (To installation personnel) — Connection (To installation personnel)
@@NOTE
tPrepare a cable in the following cases.
- When connecting a computer for menu operation or external devices to the <LAN> terminal of the Main Frame AV-HS60U1/AV-HS60U2.
- When installing in a location out of reach of the supplied LAN cable (CAT5E) length (10 m (32.8 ft)).
- Recommended cable: LAN cable (CAT5E), straight or crossover cable, STP (Shielded Twisted Pair), max. 100 m (328 ft)
Connecting the Main Frame AV‑HS60U1/AV‑HS60U2 and the Control Panel AV‑HS60C1/AV‑HS60C2/AV‑HS60C4
Connect the <PANEL> terminal of the Main Frame AV-HS60U1/AV-HS60U2 and the <MAIN FRAME> terminal of the Control Panel AV-HS60C1/
AV-HS60C2/AV-HS60C4 using the supplied LAN cable (CAT5E).
Supplied cable: LAN cable (CAT5E), straight cable, STP (Shielded Twisted Pair), 10 m (32.8 ft)
rConnecting the sub control panel
The second and the third sub control panels (sub control panel 1, sub control panel 2) can be connected to the <LAN> terminal of the Main Frame
AV-HS60U1/AV-HS60U2.
CHR LIN LUM FULL
4
SDI
IN3
3
SDI
IN2
2
SDI
IN1
1
Black
24
23
22
2120
19
18171615
14
13121110
SDI
IN9
9
SDI
IN8
SDI
IN11
SDI
IN12
Still
1V
Still
2V
Still
3V
Still
4V
Clip
1V
Clip
2V
Clip
3V
Clip
4V
CBGD
1
ME1
PGM
ME2
PGM
SDI
IN10
8
SDI
IN7
7
SDI
IN6
6
SDI
IN5
5
SDI
IN4
RECALL
STORE
DEL
RECALL
CBGD
STORE
DEL
MIX
02s01f
MIX
01s00f
MIX
01s00f
WIPE
01s00f
CHR LIN FULL FULL
WIPE
01s00f
MIX
01s00f
MIX
01s00f
MIX
CG5V CG6V CAM1 CAM2
CG5V CG6V CAM1 CAM2
CG1V CG2V CG3V CG4V
01s00f
MIX ME2
01s00f
MIX ME1
01s00f
BUS
SHFT
BUS
SHFT
1-7
4-1
1-8 1-9
SHOT000
1-1
SHOT001
1-2
SHOT002
1-3
SHOT003
1-4 1-5 1-6
PLAY
SEL
AUKDSK
ME2
XPT
ME1
4
SDI
IN3
3
SDI
IN2
2
SDI
IN1
1
Black
24
23
22
2120
19
18171615
14
13121110
SDI
IN9
9
SDI
IN8
SDI
IN11
SDI
IN12
Still
1V
Still
2V
Still
3V
Still
4V
Clip
1V
Clip
2V
Clip
3V
Clip
4V
CBGD
1
ME1
