Panasonic TC-21PM10R User manual

Service Manual
Colour Television
TC-21PM10R
MX-7 Chassis
Specifications
Power Source : AC AUTO 110-240V, 50/60Hz Video / Audio Terminals :
FAV In : Video In 1 Vp-p 75
Power Consumption : 81W Video In Approx, 400mVrms
RAV In : Video In 1 Vp-p 75
Aerial Impedance:75 unbalanced Audio In Approx, 400mVrms
Coaxial type Monitor Out :Video Out1 Vp-p 75
Audio OutApprox, 400mVrms
Receiving System : 17 System
Receiving Channels : High Voltage : 28.0 kV ( +/- 1.0 )
VHF 2-12 (PAL/SECAM B,K1) at zero beam current
0-12 (PAL B AUST)
1-9 (PAL B N.Z) Picture Tube : XA51LSK955X-A
1-12 (PAL/SECAM D) 51cm (21 inches)
1-12 (NTSC M JAPAN) Measured diagonally, 90 deflection
2-13 (NTSC M U.S.A)
UHF 21-69 (PAL G,H,I/SECAM G,K,K1)
28-69 (PAL B AUST) Audio Output : 3.5W
13-57 (PAL D,K)
13-62 (NTSC M JAPAN)
14-69 (NTSC M U.S.A)
CATV S1-S41(OSCAR) Dimensions : Height : 470 mm
1-125 (U.S.A CATV) Width : 508 mm
C13-C41(JAPAN) Depth : 475 mm
S21-S41 (HYPER)
Z1-Z37 (CHINA) Mass : 23 kg
Intermediate Frequency :
Video 38.0 MHz Specifications are subject to change without
Sound 31.5 MHz (D,K) / 32.5MHz (B,G) notice.Mass and dimensions shown are approxi
32.0 MHz (I) / 32.5MHz (M) mate.
Colour 33.57 MHz (PAL)
33.6 MHz (SECAM)
32.5 MHz (B,G)
33.75 MHz (SECAM)
34.42 MHz (NTSC)
Panasonic
2000 Matsushita Electric Industrial Co., Ltd.
All right reserved.Unauthorized copying and
distribution is a violation of law.
ORDER NO. MTV 0006142C3
