Panasonic Viera TX-L65WT600E Reference guide

e
HELP
English
TX-L65WT600E

- 2 -
Watching
my Home Screen
•Information 12
•How to use 13
•Settings 14
Basic
•Satellite connection 16
•Basic connection 17
•Selecting channel 19
•Information banner 21
•Option Menu 23
•Subtitle 24
•Off Timer 25
•Last view 25
4K resolution
•4K compatible equipment 26
•PC 26
•Valid 4K format 27
External equipment
•External connection 28
•Watching external input 31
•Operating with TV’s remote control 32
•HDMI features 34
•Terminal information 35
•Valid input signals 37
For best picture
•Viewing Mode 38
•Ambient Sensor 39
•Auto power standby function 39
•Aspect 40
•Aspect Control Signal 41
•Advanced Settings 43
•Lock Settings 46

- 3 -
•Copy Adjustment 46
For best audio
•Sound mode 47
TV Guide
•Using TV Guide 48
•Timer Programming 50
Teletext
•Viewing Teletext 52
•Teletext mode 54
3D
•Note 55
•3D Eyewear - Functions 55
•3D Eyewear - Registration 57
•3D Eyewear - Replacing battery 58
•Viewing 3D 58
•3D Mode Selection 60
•3D Settings 61
•Source image format 63
Tuning and editing channels
•Setting menu 64
•Favourites Edit 64
•Channel List 66
•Auto Setup 67
•Manual Tuning 69
•Update Channel List 71
•New Channel Message 71
•Signal Condition 71
•Selectable satellites 72
Recording
USB HDD setup
•Preparations 73
•Setting for USB HDD 74

- 4 -
Recording current programme
•One Touch Recording 76
•REW LIVE TV 77
Timer Programming
•Setting timer programming 79
•Editing timer programming 81
•Note 82
Technical information
•USB HDD 83
Internet service
Internet content
•Information 84
•Selecting internet content 84
•Note 85
Network connections
•Internet connection 86
•Note 87
Network settings
•Network Connection 88
•Custom - Wireless 89
•Custom - Wired 91
•Network Status 92
•VIERA Name 93
•TV Remote App Settings 93
•Network Link Settings 93
•File Sharing Settings 93
•Software Update 93
•New Software Message 93
Home network
DLNA
•Information 94

- 5 -
•Using DLNA 97
Network connections
•DLNA connection 98
•Note 100
Network settings
•Network Connection 101
•Custom - Wireless 102
•Custom - Wired 104
•Custom - Wireless Access Point 105
•Network Status 106
•VIERA Name 106
•TV Remote App Settings 107
•Network Link Settings 107
•File Sharing Settings 108
•Software Update 108
•New Software Message 109
Photos
•Selecting file 110
•Viewing photo 111
•Using slideshow 111
Videos
•Selecting file 113
•Watching video 114
•Video Setup 115
•Audio output settings 116
Music
•Selecting file 117
•Playing music 118
•Music Setup 118
DIGA Recorder
•Controlling DIGA Recorder 119

- 6 -
Technical information
•Photo format 120
•Video format 120
•Music format 123
Media Player
Using Media Player
•Information 124
•Selecting device / mode 126
•Sharing file 127
Photo mode
•Selecting file 129
•Viewing photo 129
•Sorting photos 130
•Multi Shot 3D 130
•Using slideshow 131
Video mode
•Selecting file 134
•Watching video 134
•Video Setup 136
•Audio output settings 137
Recorded TV mode
•Selecting content 138
•Watching recorded TV 139
•Grouping contents 140
•Deleting content 140
•Changing device 141
•Chapter List 141
•Audio output settings 141
Music mode
•Selecting file 143
•Playing music 143
•Music Setup 144

- 7 -
Technical information
•Device handling caution 145
•SD Card 145
•USB devices 146
•Photo format 146
•Video format 147
•Music format 150
Functions
APPS List
•Information 151
•How to use 151
•Settings 152
Multi Window
•Information 153
•How to use 153
•Note 155
VIERA Link “HDAVI Control™”
•Summary of VIERA Link 156
•Preparations 160
•Easy playback 160
•Power on Link 161
•Power off Link 161
•Standby Power Save 161
•Intelligent Auto Standby 161
•VIERA Link Control 162
•Speaker Selection 163
•Note 164
Child Lock
•Using Child Lock 165
•PIN number 166
•Parental Rating 166

- 8 -
Data Service Application
•Using Data Service Application 167
•Cookie 167
•Note 168
Common Interface
•Caution 169
•Using Common Interface 169
Shipping Condition
•Shipping Condition 171
Updating the TV Software
•Information 172
•Auto update 172
•Manual update 173
Setting characters
•Using numeric buttons 174
Built-in Camera
•Using built-in Camera 175
Voice Control
•Preparations 176
•How to use 177
Bluetooth devices
•Bluetooth Setup 178
Keyboard / Gamepad
•Keyboard 179
•Gamepad 180
Settings
Setting menu
•How to use 181
•Viewing Mode 182
•Basic settings 183

- 9 -
•Ambient Sensor 184
•Noise reduction settings 184
•Resolution Remaster 184
•Caption Smoother 184
•Brilliance Enhancer 185
•Intelligent Frame Creation 185
•24p Smooth Film 185
•Advanced Settings 185
•Option Settings 185
•Screen Settings 187
•3D Settings 188
•Lock Settings 190
•Copy Adjustment 190
•Reset to Defaults 190
Sound
•Mode 190
•Basic settings 191
•Volume settings 192
•Voice Guidance Settings 193
•Advanced settings 193
•Reset to Defaults 196
Network
•Network Connection 196
•Network Status 196
•VIERA Name 196
•TV Remote App Settings 196
•Network Link Settings 197
•File Sharing Settings 197
•Other settings 197
Timer
•Off Timer 197
•Timer Programming 197
•Time Zone 197
•Auto Standby 198

- 10 -
•No signal Power off 198
Setup
•Eco Navigation 198
•Voice Control Settings 198
•USB Device Setup 198
•Recording Setup 198
•VIERA Touch Pad Controller 199
•Bluetooth Setup 199
•Child Lock 199
•Tuning Menu 199
•Language 201
•Display Settings 202
•DisplayPort Settings 204
•Common Interface 204
•VIERA Link Settings 204
•Professional Mode (isfccc) 205
•Data Service Application 205
•System Menu 206
•Other Settings 206
Support
FAQs
•Picture 208
•Digital TV 209
•Analogue TV 210
•Sound 211
•3D 211
•HDMI 213
•Network 213
•Other 214
Maintenance
•Care and Cleaning 217

- 11 -
Information
•Using Help menu 218
Optional accessories
•3D Eyewear 219
•Wall-hanging bracket 219
Licence
•Licence 220
OK Letters enclosed in a box indicate remote control buttons.
Menu Letters in cyan indicate on-screen display items.
References in this eHELP
●The images shown in this eHELP are for illustrative purposes only.

- 12 -
Watching
my Home Screen
Information
“my Home Screen” is a gateway to the TV, applications, and more.
It provides easy access to special features such as the Media Player, videos,
games, communication tools, etc. as shown below (example).
HOME
OK
OK HOME
Home Screen
Selected content screen (TV, application, etc.)
Home Screen Selection
– Your preferred Home Screen can be selected or added.

- 13 -
How to use
Home Screen provides access to special features such as the Media Player,
TV, internet content, data services, communication tools, etc.
1. Display Home Screen with HOME
(Example)
●The last viewed Home Screen is displayed when the TV is turned on.
●Press again to select or add your preferred Home Screen layout.
Watching my Home Screen Settings
2. Select a feature with / / / and press OK to access
●To watch full-screen TV
1) Select the TV viewer with / / /
(Example)
2) Press OK to watch
(Example)
●Also refer to Tutorial from the tool guide.

- 14 -
Settings
Select the setup menu from the tool guide on the top of the screen, or use
coloured button to display the setup menu.
(Example)
■Home Screen Selection
1. Display Home Screen Selection with HOME
(Example)
2. Select the screen with / and press OK to set
Full Screen TV:
Displays full-screen TV
TV Home Screen:
To make your TV experience more convenient and comfortable.
Lifestyle Screen:
Displays the TV with useful information and services for everyday life.
Info Screen:
Enjoy internet content while watching TV.
Add New Screen:
You can add a new screen to personalise.

- 15 -
■Face Recognition
By using the built-in Camera, you can select the registered Home Screen with
face recognition. Please refer to Tutorial from the tool guide.
●For details of the built-in Camera
Functions Built-in Camera Using built-in Camera
■Settings
You can customise any Home Screen. (For example, changing the wallpaper,
renaming freely, editing applications, setting the screen launched when the
TV is turned on, etc.)
1. Select Settings from the tool guide
2. Follow the on-screen instructions
■Search
You can search the content from various features.
1. Select Search from the tool guide
2. Follow the on-screen instructions
= Note =
●To use this function fully, you need a broadband network environment.
Ensure the network connections and network settings are completed.
Internet service Network connections
Internet service Network settings
●Be sure to update the software when a software update notice is displayed
on the TV screen. If the software is not updated, you will not be able to use
my Home Screen. You can update the software later manually.
Internet service Network settings Software Update

- 16 -
Basic
Satellite connection
Please ensure that the unit is disconnected from the mains socket before
attaching or disconnecting any cables.
●For DVB-S
■Dual tuner (DiSEqC)
Connect the both of satellite IN 1 / IN 2 terminals to the satellite dish with Multi
Switcher, and you can watch or record 2 DVB-S programmes simultaneously,
etc.
Satellite IN 1 / IN 2 terminals
Satellite cables with Multi Switcher
Satellite dish
■Dual tuner (Single Cable System)
Connect the satellite IN 1 terminal to the satellite dish with the Single Cable
router, and you can watch or record 2 DVB-S programmes simultaneously,
etc.
Satellite IN 1 terminal
Satellite cable with Single Cable router
Satellite dish

- 17 -
■Single tuner
Connect the satellite IN 1 terminal to the satellite dish.
●Watching or recording 2 DVB-S programmes simultaneously, etc. are not
available.
Satellite IN 1 terminal
Satellite cable
Satellite dish
= Note =
●To ensure your satellite dish is correctly installed, please consult your local
dealer. Also consult the received satellite broadcasting companies for
details.
●Selectable satellites and dish alignment to tune DVB-S channels
Watching Tuning and editing channels Selectable satellites
●External equipment and cables shown are not supplied with this TV.
●Keep the TV away from electronic equipment (video equipment, etc.) or
equipment with an infrared sensor, otherwise distortion of image / sound
may occur or operation of other equipment may be affected.
●Check the terminal type and cable plugs are correct when connecting.
Basic connection
Please ensure that the unit is disconnected from the mains socket before
attaching or disconnecting any cables.
■Aerial
Terrestrial / cable terminal
RF cable

- 18 -
Terrestrial aerial or cable
●For DVB-C, DVB-T, Analogue
■DVD Recorder / VCR
Terrestrial / cable terminal
RF cable
DVD Recorder / VCR
Terrestrial aerial or cable
AV1 (SCART) terminal
SCART cable
– AV1 (SCART) adaptor (supplied) is necessary when connecting to the
TV.
■DVD Recorder / VCR and Set top box
HDMI terminal

- 19 -
HDMI cable
Set top box
Cable
AV1 (SCART) terminal
SCART cable
– AV1 (SCART) adaptor (supplied) is necessary when connecting to the TV.
Terrestrial / cable terminal
RF cable
DVD Recorder / VCR
Terrestrial aerial
●For VIERA Link connections
Functions VIERA Link “HDAVI Control™” Summary of VIERA Link
= Note =
●External equipment and cables shown are not supplied with this TV.
●Please also read the manual of the equipment being connected.
●Keep the TV away from electronic equipment (video equipment, etc.) or
equipment with an infrared sensor, otherwise distortion of image / sound
may occur or operation of other equipment may be affected.
●When using a SCART or HDMI cable, it is recommended to use fully wired
one.
●Check the terminal type and cable plugs are correct when connecting.
Selecting channel
1. Display the TV Selection screen with TV
2. Select the mode with / and press OK to set
DVB-S / DVB-C / DVB-T / Analogue
●The selectable modes vary depending on the channels stored.
●You can also select the mode pressing TV repeatedly on the remote control
or INPUT/OK/HOLD for MENU button on the control panel of the TV.
●If the TV Selection menu is not displayed, press TV to switch the mode.
3. Select a channel with Channel Up / Down or numeric buttons
●Press the numeric buttons to select a channel position with 2 or more-
digit (e.g. 399, press ).

- 20 -
■To select a channel from the channel list
1. Display the channel list with OK
2. Select a channel from the list with / and press OK to watch
●To sort channel names in alphabetical order
(red)
●To change the category
(blue)
■To select a channel using information banner
1. Display information banner with if it is not displayed
2. Select a channel with / and press OK to watch while the banner is
displayed
Watching Basic Information banner
■To select a channel using TV Guide
1. Display TV Guide with GUIDE
2. Select the current programme or channel with / / / and press
OK to access
3. Select View with / and press OK to access (DVB)
– The current programme is displayed on the top left of the screen.
4. Press OK to exit TV Guide
Watching TV Guide Using TV Guide
●The postcode entry or update may be required depending on the country
you select. Follow the on-screen instructions.
■To watch pay-TV
●For information of the encrypted channels
Functions Common Interface Using Common Interface
●Consult the operator / broadcaster or CI module manufacturer for more
information and conditions of the services.
