Panasonic MC-E3001-WP47 User manual

© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
Order No.VCB0608004S2
Vacuum Cleaner
MC-E3001-WP47
MC-E3003-AP47
MC-E3003-AE49
Destination : Europe
Subject : We herewith inform you of the new part number that represents the three
components to be supplied as a set.
(Reason: To improved the repair efficiency.)
Please file and use this supplement manual together with the service manual for Model No.MC-
E3001,E3003, Order No.ECD0504007C2

2
TABLE OF CONTENTS
PAGE PAGE
1 Specifications ------------------------------------------------------2
2 Exploded View and Replacement Parts List -------------2
2.1. New part number -------------------------------------------2
2.2. Configurafion of the new component------------------2
2.3. Exploded view (Body unit)...(MC-
E3003,E3001) ---------------------------------------------- 3
2.4. Parts list (Body unit)...(MC-E3003,E3001) ---------- 4
1 Specifications
2 Exploded View and Replacement Parts List
2.1. New part number
2.2. Configurafion of the new component

3
2.3. Exploded view (Body unit)...(MC-E3003,E3001)
7
5
6
3
2
4
8
10
9
11
1
12
13
14
15
16
17
17
17
18
19
20
27
25
26
23
23
22
24
28
30
29
31
21
32
33
34
35
35
37
38
39
40
47
45
46
43
43
42 44
44
48
50
49
51
41
52
53
54
55
56
57 58
80
59
60
67
66
63
62
64
68
68 70
65
69
69
71
61 61
72
72
73 74
75
76
77
78
MC-E3001
36
79
79
79
79
79
79
79
79
79

4
2.4. Parts list (Body unit)...(MC-E3003,E3001)
safety Ref. No. Part No. RePart Name & Descriptionarks Remarks
1 AMC95B-XB0WE Handle unit MC-E3001 UK (AMC95B-XB0W)
1 AMC95B-XB0AE Handle unit MC-E3003 UK (AMC95B-XB0A)
1 AMC95B-XB0AQ Handle unit MC-E3003 Germany,Italy,Spain
2 AMC33Z-XD008 Warning label MC-E3001,E3003 UK
2 AMC33Z-XB00Q Warning label MC-E3003 Germany,Italy,Spain
3 AMC73B-XD00E Handle screw (AMC73B-XD0)
4 AMC93E-XB0K8 Mains lead (Power cord) MC-E3001,E3003 UK
4 AMC91E-XB0KQ Mains lead (Power cord) MC-E3003 Germany,Italy,Spain
5 AMC84P-XA00E Hose unit MC-E3001 UK
5 AMC84P-XB008 Hose unit MC-E3003 UK
5 AMC84P-XB00Q Hose unit MC-E3003 Germany,Italy,Spain
6 AMC07Z-XB00E Caution label A MC-E3001,E3003 UK
6 AMC07Z-XB00Q Caution label A MC-E3003 Germany,Italy,Spain
7 AMC35P-XB00Q Hose label MC-E3003 Germany,Italy,Spain
8 AMC19P-XB04E Hose cover
9 AMC98M-XA00E Indicator unit MC-E3001 UK
9 AMC98M-XB00E Indicator unit MC-E3003 UK,Germany,Italy,Spain
10 AMC15M-XB00E Indicator pipe
11 AMC03M-XB0UE Indicator needle
12 AMC04M-XA00E Indicator spring MC-E3001 UK
12 AMC04M-XB00E Indicator spring MC-E3003 UK,Germany,Italy,Spain
13 AMC27M-XB00E Indicator tube
14 AMC91F-XB00C PC BOARD W/Component
15 AMC99W-XB00E Fuse Unit 250V 12A
16 AMC21A-XB0WE Rear body MC-E3001 UK
16 AMC21A-XB0AE Rear body MC-E3003 UK,Germany,Italy,Spain
17 XTN4+12BFJ Tapping screw
18 AMC27H-XB04E Connection wand
19 AMC55P-XB04E Extension wand holder
20 AMC01E-XD0KE ON/OFF Switch
21 AMC0AE-XB00E Seal Packing A
22 AMC24Z-XB00E Label A
23 AMC66K-XB00E Dust cover packing
24 AMC61R-XB04E Crevice nozzle (AMC61R-XB04)
25 AMC40P-XB04E Extension wand (AMC40P-XB04)
26 AMC88R-XD04E Dusting brush unit (AMC88R-XD04)
27 AMC18M-XB0WE Protector Supporter MC-E3001 UK
27 AMC18M-XB0AE Protector Supporter MC-E3003 UK,Germany,Italy,Spain
28 AMC70K-XA00E Protector Spring MC-E3001 UK
28 AMC70K-XB00E Protector Spring MC-E3003 UK,Germany,Italy,Spain
29 AMC03M-XL00E Indicator needle
30 AMC68K-XB0WE Protector case MC-E3001 UK
30 AMC68K-XB0AE Protector case MC-E3003 UK,Germany,Italy,Spain
31 AMC85E-XA0WE Switch cover unit MC-E3001 UK
31 AMC85E-XB0AE Switch cover unit MC-E3003 UK,Germany,Italy,Spain
32 AMC81A-XB00E Tight packing
33 AMC61L-XB00E Packing
34 AMC32K-XB0KE Filter supporter
35 AMC85L-XB0WE HEPA filter MC-E3003 UK,Germany,Italy,Spain (AMC85L-XB0W)
35 AMC42K-XA0WE Filter case MC-E3001 UK
36 AMC38K-XA00E Exhaust filter MC-E3001 UK (AMC38K-XA0)
37 AMC92L-XA0WE Dust box lid unit MC-E3001 UK
37 AMC92L-XB0AE Dust box lid unit MC-E3003 UK,Germany,Italy,Spain
38 AMC8F96W2000 Dust bag(Type U-20E) (pack of 5 bags)
39 AMC19F-XB00E Motor case rubber
40 AMC09F-XB0WE Motor case MC-E3001 UK
40 AMC09F-XB0AE Motor case MC-E3003 UK,Germany,Italy,Spain
41 AMC30L-XB00E Outlet filter
42 AMC16C-XB00E Roller shaft
43 AMC01C-XD04E Wheel
44 XUB7FP Fixing washer
45 AMC64H-XB00E Suction inlet packing (AMC64H-XB0)
46 AMC10G-XB00E Noise absorber
47 AMC92F-XB00C Fan motor unit
48 AMC27F-XL00E Carbon brush
49 AMC75Z-XB00E Cushion plate
50 AMC03F-XB00E Motor support rubber(rear)
51 AMC02F-XB00E Motor support rubber(front)
52 AMC67V-XB00E Lead wire A unit
53 AMC98R-XA0WE Floor nozzle upper unit MC-E3001 UK
53 AMC98R-XB0AE Floor nozzle upper unit MC-E3003 UK,Germany,Italy,Spain

5
54 AMC31A-XB04E Furniture guard
55 AMC25S-XD00E Plastic holder
56 AMC90S-XB00E Idler pulley
57 AMC68A-XD00E Screw
58 AMC47A-XB04E Pedal left/handle release
59 AMC51A-XB00E Pedal shaft
60 AMC58A-XB00E Pedal spring right
61 AMC54R-XB04E End plate
62 AMC06R-XD00E Pipe felt
63 AMC79A-XD00E Body packing
64 AMC52P-XB00E Connector pipe
65 AMC97R-XB04E Floor nozzle lower unit MC-E3001,E3003 UK
65 AMC97R-XB04Q Floor nozzle lower unit MC-E3003 Germany,Italy,Spain
66 XTN4+27BFJ Tapping screw
67 AMC06Q-XB00E Pipe cover
68 AMC50R-XD00E Floor nozzle roller shaft
69 AMC90Q-XD00E Nozzle roller
70 AMC08Z-XB00Q Caution label B MC-E3003 Germany,Italy,Spain
71 AMC21Z-XB00Q Caution label MC-E3003 Germany,Italy,Spain
72 XWG7F135FJ Plain washer
73 AMC95S-XD00E Belt unit kit 2belts (AMC95S-XD0)
74 AMC28S-XD00E Belt
75 AMC39S-XD00E Belt B
76 AMC92S-XD00E Beater bar unit (AMC92S-XD0)
77 AMC28H-XB00E Elbow packing
78 AMC04Z-XD00E Sticker
79 XTN4+18BFJ Tapping screw
80 AMC80A-XB04E Pedal Unit
safety Ref. No. Part No. RePart Name & Descriptionarks Remarks
