Panasonic MC-UG589-00 User manual

© 2008 PANASONIC HOME APPLIANCES
COMPANY, DIVISION OF PANSONIC
CORPORATION OF NORTH AMERICA. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
MC-UG589-00
Vacuum Cleaner
Specifications are subject to change without notice for further improvement.
Order Number MAC0803006CE

1 WIRING DIAGRAM AND DRAWING 3
1.1. Wiring Diagram 3
1.2. PICTORIAL DIAGRAM 4
2 EXPLODED VIEW AND PARTS LIST 5
2.1. Body 5
2.2. Nozzle Housing 7
2.3. Packing Materials 9
3 REPLACEMENT INSTRUCTIONS 10
3.1. Lower Plate Replacement 10
3.2. Belt Replacement 10
3.3. Agitator Assembly Replacement 11
3.4. Carpet/Bare Floor and Handle Release Assembly 11
3.5. BRUSH REPLACEMENT 11
3.6. Headlight Bulb Replacement 12
3.7. Power Cord / On-Off Switch Replacement 13
3.8. Motor Replacement 13
CONTENTS
Page Page
2
MC-UG589-00

1 WIRING DIAGRAM AND DRAWING
1.1. Wiring Diagram
3
MC-UG589-00

1.2. PICTORIAL DIAGRAM
NOTE:
For general servicing, it is necessary to eliminate pinching of any wire during reassembly. After servicing any electrical
component or electrical enclosure, the unit should be reassembled and checked for dielectric breakdown or current leakage.
Use part number AC79FCWZZ000 (FIBERGLASS CLOTH TAPE) whenever original tape is removed.
4
MC-UG589-00

2 EXPLODED VIEW AND PARTS LIST
2.1. Body
2.1.1. Exploded View
5
MC-UG589-00

2.1.2. Parts List (Body)
Ref. No. Part No. Part Name & Description Quantity Remarks
1 AC78KDABZV07 DUST COMPARTMENT 1 INCLUDES ITEMS
2 AC70PJPZV07 WAND HOLDER 1 INCLUDES ITEM 3
3 AXTN4+16BFY SCREW (WAND HOLDER) 3 SHIPPED 10 PER PACKAGE
4 AMC98E-V010U SWITCH 1 INCLUDES
5 AMC62E-J20 CORD STOPPER 1
6 AXTN4+16BFY SCREW (CORD STOPPER) 2 SHIPPED 10 PER PACKAGE
7 AC97EAACZV06 POWER CORD 1
8AMC-1CTCE23 WIRE CONNECTOR 3
9 AC66KV01V06 DUST CONTAINER PACKING 2
10 AC03EDEVZV07 SWITCH COVER 1
11 AC73KV0ZV06 SWITCH COVER PACKING 1
12 AXTN4+16BFY SCREW (SWITCH COVER) 2 SHIPPED 10 PER PACKAGE
13 AMC73B-V00 HANDLE SCREW 1
14 AMP21B-170 NUT 1 SHIPPED 10 PER PACKAGE
15 AC61LAGMZ00 PACKING 1
16 AMC596-702 CABLE TIE 1
17 AMC32K-V00 FILTER SUPPORTER 1
18 AC37KAAEZ00 HEPA FILTER 1
19 AC99CBSAZV06 WHEEL 2
20 AC16CUSZ00 SHAFT (WHEEL) 1 INCLUDES ITEM 21
21 AC74SUSZ00 STOPPER (WHEEL) 2
22 AXWG6E115FY WASHER (WHEEL) 2
23 AC16KDDWZ000 DUST BAG (Type U12) 1
24 AC09FBFTZS00 MOTOR CASE 1
25 AMC02L-V00 REAR COVER PACKING 1
26 AC19FJPZV06 MOTOR CASE PACKING 1
27 AXTN4+20BFY SCREW (MOTOR CASE) 4 SHIPPED 10 PER PACKAGE
28 AC84PJPZV06 HOSE ASSEMBLY 1
29 AC02HYUZV06 COVER 1
30 AC53RJPZV06 HOSE RING 1
31 AXTN4+16BFY SCREW (HOSE) 2 SHIPPED 10 PER PACKAGE
32 AC92FDDWZ000 MOTOR 1
33 AC99WDACZ000 LEAD WIRE (FUSE) 1
34 AC26FDDWZU01 MOTOR CAP 1
35 AC99GAMMZ00 NOISE SUPPRESSOR 1
36 AC02FJPZ00 MOTOR SUPPORT (FRONT) 1
37 AMC03F-V00 MOTOR SUPPORT (REAR) 1
38 AC25SCWZZ000 FLANGE (UK) 1
39 AXTN4+8JFY SCREW TAPTITE 2 SHIPPED 10 PER PACKAGE
40 AC83DDAAZU00 LOCKING CAM 1
41 AXTS3+12KFYY SCREW (LOCKING CAM) 1
42 AMC37G-V200U WIRE CORD 1
43 AMC-1CTCE23 WIRE CONNECTOR 3
44 AC39AARSZV00 PACKING (RIGHT) 1
45 AC40AARSZV00 PACKING (LEFT) 1
46 AC64BCZZZV07 HANDLE ASSEMBLY 1
47 AC23PJP1V07 HOSE HOLDER 1
48 AC53EV0ZV07 UPPER CORD STORAGE HOOK 1
49 AMC76N-F70 SPRING (CORD HOOK) 1
50 AMC58B-F70 WASHER (CORD HOOK) 1 SHIPPED 10 PER PACKAGE
51 AC54EV0ZV07 LOWER CORD STORAGE HOOK 1
52 AXTN4+30BFY SCREW (CORD HOOK) 2 SHIPPED 10 PER PACKAGE
53 AC60KDEXZSU0 DUST COVER 1
54 AC01DDEVZV07 LATCH 1
55 AC23DDEVZ000 SPRING 1
56 AC15MVZ00 BODY (INDICATOR) 1
57 AMC17M-V20 INDICATOR CAP 1
58 AXTN4+10BFY SCREW INDICATOR 2 SHIPPED 10 PER PACKAGE
59 AMC03M-68ZR0 INDICATOR LEAD 1
60 AC04MRFZ00 INDICATOR SPRING 1
61 AMC09M-L30 INDICATOR PACKING 2
62 AC88RYUZV06 DUSTING BRUSH 1
63 AC60RZFZVU6 CREVICE TOOL 1
64 AC40PJPZV06 WAND (WITH TABS) 1
65 AC40PZG1V06 WAND (EXTENSION) 1
6
MC-UG589-00

2.2. Nozzle Housing
2.2.1. Exploded View
7
MC-UG589-00

2.2.2. Parts List (Nozzle Housing)
Ref. No Part No. Part Name & Description Quantity Remarks
1 AC01ADEYZSU0 Nozzle Housing 1 Includes item 7
2 AC10ACRSZV07 Furniture Guard 1
3 AC21HCRSZ000 Window 1
4 AMC25S-V00 Plastic Shaft 1
5 AC34PAJDZV06 Nozzle Hose 1
6 AC42AAFYZV06 Pedal 1
7 AC04RANPZV06 Nozzle Packing 1
8 AC92BAMAZ000 Handle Release Assembly 1 Includes items 9, 10 and 11
9 AC81HAGZZ00 Spring 1
10 AC43AAFY200 Bracket Assembly 1
11 AC57AAFWZ00 Spring (Foot Gear Pedal) 1
12 AXTN4+16BFY Screw 4 Shipped 10 per package
13 AC84HBZTZ000 Reflector 1
14 AC47ADAAZM0E Pedal 1
15 AC58AAFVZ00 Spring (Pedal) 1
16 AMC51A-V30 Shaft (Pedal) 1
17 AC11S2VZW00 Belt Cover Assembly 1
18 AC93HURZ00 Bulb Socket 1
19 AC28GADFZ00 Bulb 1
20 AC28SCZPZ000 Belt 1
21 AC02ACRS1W0H Body (Upper) 1
22 AC12ACRSZW0H Cap (Body) 1
23 AMC68A-V30 Screws 2 Shipped 10 per package
24 AC93QAGZZV06 Wheel 2
25 AC16CNXZ00 Shaft (Wheel) 2
26 AC91ACRS1000 Lower Plate Assembly 1 Includes items 27, 28, 29, 30, 31, 37 and 38
27 AMC68N-V30K Latch (Lower Plate) 2
28 AC70NYUZ00 Spring (Stop Latch) 2
29 AC74ACRSZ000 Packing (Lower Plate) 1
30 AC74ACRRZ000 Packing (Lower Plate) 1
31 AMC39A-2V0 Packing (Lower Plate) 2
32 AC92SBVNZ000 Agitator Assembly 1
33 AC85RBFT1000 Brush Unit 1
34 AXTN4+10BFY Screw 1 Shipped 10 per package
35 AC82ACRRZV07 Agitator Holder Assembly 1
36 AC62FAVGZ00 Washer 4 Shipped 10 per package
37 AC75ACRSZ000 Packing (Lower Plate) 2
38 AC75AAWRZV00 Packing (Lower Plate) 1
8
MC-UG589-00

2.3. Packing Materials
2.3.1. Exploded View
2.3.2. Parts List (Packing Materials)
Ref. No. Part No. Part Name & Description Quantity Remarks
1 AC61ZCRJZ000 Packing Assembly 1 Includes 1 and items a thru f
2 AC01ZDEYZ000 Operating Instructions 1
9
MC-UG589-00

3.1. Lower Plate Replacement
3.1.1. Removal
1. Before servicing any parts, disconnect vacuum from
electrical outlet.
2. Place paper under nozzle whenever lower plate is removed
to protect floor.
3. Place handle in upright position and turn vacuum over to
expose lower plate.
4. Release lower plate by pressing two (2) latches inward.
5. Remove lower plate and remove any residue that may exist
in belt area.
3.1.2. Installation
1. Close the rear belt cover.
2. Hook the front of the lower plate into the slots on the front
of the nozzle housing. Press the lower plate down into
place.
3. Fasten the lower plate by pushing the two (2) latches
outward.
NOTE: For general servicing, it is necessary to eliminate
pinching of any wire during reassembly. After servicing
any electrical component or electrical enclosure, the unit
should be reassembled and checked for dielectric
breakdown or current leakage.
3.2. Belt Replacement
3.2.1. Removal
1. Remove lower plate.
2. Lift rear belt cover.
3. Remove agitator by carefully lifting out.
4. Remove worn or broken belt.
5. Clean agitator.
3.2.2. Installation
1. Loop new belt (Panasonic Type UB8 only) around motor
shaft and agitator pulley; see illustration for correct belt
routing.
2. Reinstall agitator back into nozzle housing grooves.
3. Close rear belt cover.
4. After reinstalling the agitator, turn it by hand to make sure
that belt is not twisted or pinched and that all rotating parts
turn freely.
5. Reinstall lower plate.
3 REPLACEMENT INSTRUCTIONS
10
MC-UG589-00

3.3. Agitator Assembly
Replacement
3.3.1. Removal
1. The brushes are replaceable separately. When the brushes
need replacing, the agitator assembly will have to be
removed.
2. Remove the lower plate as outlined in the LOWER PLATE
REPLACEMENT section.
3. Remove the agitator assembly as outlined in the BELT
REPLACEMENT section. .
3.3.2. Installation
1. Place the belt around the motor shaft.
2. Start the new agitator assembly back into the nozzle
housing by placing the side opposite the belt partially into
the slot. The small tabs should be aligned with the nozzle
and the other against the lower plate. This will hold the
agitator in place and leave both hands free to place enough
tension on the belt to allow that side of the agitator to return
to the nozzle housing slot.
3. Place the belt around the agitator pulley on the agitator
assembly.
4. Use both hands to pull the belt tight, slide the agitator
assembly firmly into the slots on each end of the nozzle
housing.
5. Rotate the agitator assembly by hand to insure nothing
rubs and to check for correct assembly.
6. Replace the lower plate as outlined in the LOWER PLATE
REMOVAL/INSTALLATION section.
3.4. Carpet/Bare Floor and Handle
Release Assembly
3.4.1. Removal
1. Place the carpet/bare floor pedal in the carpet position.
Insert a screwdriver under the back of the pedal cover and
pry up to remove it from the pedal assembly. Take care not
to scratch the nozzle housing.
NOTE: Every time the pedal cover is removed for any
reason, it should be replaced with a new one. See Nozzle
Exploded View and Parts List for correct replacement part
number.
2. Turn the vacuum over and remove the lower plate, belt and
agitator as outlined in their respective removal sections.
3. Remove the nozzle housing.
4. Remove the three (3) screws that secure the carpet/bare
floor & handle release assembly to the nozzle housing.
5. Remove the pedal/frame assembly by sliding it out through
the bottom of the nozzle housing.
6. Once the carpet/bare floor & handle release assembly is
out it can be disassembled for parts replacement as shown
in the Exploded View diagram.
NOTE: For general servicing, it is necessary to eliminate
pinching of any wire during reassembly. After servicing
any electrical component or electrical enclosure, the unit
should be reassembled and checked for dielectric
breakdown or current leakage.
3.4.2. Installation
1. Slide the carpet/bare floor & handle release assembly back
into the slot in the nozzle housing.
2. Replace the three screws that hold the frame and pedal
shaft onto the nozzle housing.
3. Install the new pedal cover by pushing it onto the pedal
assembly until the tab snaps into place.
4. Replace the nozzle housing.
5. Install the belt, agitator assembly, and the lower plate
according to the respective instructions.
3.5. BRUSH REPLACEMENT
1. The agitator brushes should be replaced when the brushes
are worn. Brushes should be checked by holding a card
11
MC-UG589-00

across the lower plate. If the bristles on the agitator
assembly do not touch the card you should replace all the
brushes for best cleaning results.
3.5.1. Removal
1. Remove the lower plate as outlined in the LOWER PLATE
REPLACEMENT section.
2. Remove the agitator assembly as outlined in the agitator
assembly section.
3. The agitator assembly may now be disassembled and the
brushes replaced.
4. Carefully remove the E-clip from the agitator shaft, do not
misplace. Remove the right brush support. Pull the agitator
shaft out of the opposite end of the.
5. Pull or pry out the agitator pulley and agitator holder.
6. Push each brush out of the agitator.
7. Install new brushes by reversing procedure.
8. Reinstall agitator holder and agitator pulley completely.
9. Reinstall the agitator shaft, end cap and E-clip.
10. Position belt over agitator pulley on the agitator.
11. Reinstall agitator and lower plate.
3.6. Headlight Bulb Replacement
1. Pry up window at slots.
2. Remove old bulb from the socket by pushing in while
turning counter-clockwise.
12
MC-UG589-00

3.7. Power Cord / On-Off Switch
Replacement
3.7.1. Removal
1. Remove the dust cover and switch cover to expose the
electrical connections of the power cord, on-off switch and
wire cord.
2. Pull the power cord into the dust compartment in order to
remove the strain relief (for power cord replacement) by
prying or cutting, remove the wire connections, and wire tie,
if present.
3. Remove the on-off switch (for on-off switch replacement) by
depressing the retaining tabs while pushing up and out of
the dust compartment at the same time.
4. Pull the power cord out of the dust compartment (for power
cord replacement).
3.7.2. Installation
1. Insert the new power cord (power cord replacement only)
into the dust compartment as far as necessary in order to
place a new cord retainer in proper location on power cord.
The proper location is approximately one and one eighth
inches/thirty millimeters (1 1/8”/30 MM.) of new power cord
outer jacket extending past the cord retainer and washer.
The washer goes between the cord retainer and the dust
compartment. Attach wires with wire connectors according
to the wiring diagram in the front of this manual. ONLY USE
A NEW CORD RETAINER, DO NOT REUSE A CORD
RETAINER.
2. For switch replacement only, insert the new ON/OFF switch
with the numbers 1,2,3, facing toward you, into the dust
compartment until secured by the retaining tabs. Use a wire
tie in the location illustrated taking care not to overtighten it.
Tuck the wire connectors back into the dust compartment
as illustrated in the close-up view.
3. Ensure that the insulator packing is installed correctly.
4. Replace the switch cover, the two (2) switch cover screws,
and the dust cover. Care should be taken not to pinch wires
and make sure that the switch cover goes on easily and
stays flat. If there is resistance to the switch cover lying flat
and in place, stop, remove the cover and make sure that no
wires are being pinched. DO NOT USE A POWER
SCREWDRIVER TO SECURE THE COVER.
NOTE: For general servicing, it is necessary to eliminate
pinching of any wire during reassembly. After servicing
any electrical component or electrical enclosure, the unit
should be reassembled and checked for dielectric
breakdown or current leakage.
3.8. Motor Replacement
3.8.1. Removal
1. Remove the dust cover by grasping the top near the on-off
switch and pulling sharply out toward you.
2. Remove the lower plate, agitator assembly, belt, light bulb
assembly, plastic shaft, and the nozzle housing as
13
MC-UG589-00

instructed in the respective removal sections.
3. Turn the vacuum over to the front side.
4. Remove the four (4) screws from the motor case and then
remove the motor case.
5. Disconnect the motor leads and remove the motor. Remove
the motor support rubber (rear), noise suppressor, cooling
guide, motor flange, and the motor support rubber (front).
Place these items on the new motor.
3.8.2. Installation
1. Place the motor back into the dust compartment with
brushes aligned parallel to the front edge of the dust
compartment.
2. Rewire per the Pictorial Diagram.
3. Replace the motor case and the four (4) screws.
4. Turn the vacuum back over and replace the plastic shaft,
light bulb assembly, nozzle housing, belt, agitator
assembly, and lower plate according to the respective
installation instructions.
14
MC-UG589-00
