Panasonic KH-B90FBC1 User manual

OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
BEDIENINGSINSTRUCTIES
ISTRUZIONI D’USO
INSTRUCCIONES DE USO
BRUGSVEJLEDNING
ANVÄNDARINSTRUKTIONER
BRUKSANVISNING ZY02-C68
Fa1212K0
KH-B90FBW1
Cooker Hood
Dunstabzugshaube
Hotte
Dampkap
Cappa da cucina
Campana Extractora
Emhætte
Spiskåpa
Kjøkkenventilator
Model No.
KH-B90FBC1
KH-B90FBW1

Thank you for purchasing this Panasonic appliance. Please read this instructions carefully before
using the appliance. Keep Operating Instructions and Guarantee Certificate for future use. This
appliance is intended for domestic use.
* Installation Instructions is included.
Vielen Dank für den Kauf dieses Panasonic Elektrogeräts. Bitte lesen Sie vor Gebrauch des Geräts
diese Anleitung aufmerksam durch. Bewahren Sie die Bedienungsanleitung und den Garantieschein
für späteren Gebrauch auf. Dieses Gerät ist nur für den Gebrauch im Haushalt bestimmt.
* Die Installationsanleitung ist inbegriffen.
Nous vous remercions d’avoir acheté cet appareil Panasonic. Veuillez lire attentivement ces
instructions avant d’utiliser l’appareil. Conservez le Mode d’emploi et le Certificat de garantie pour
toute référence future. Cet appareil est destiné à un usage domestique.
* Instructions de montage incluses.
Bedankt voor uw aankoop van dit Panasonic toestel. Gelieve deze instructies grondig te lezen
vooraleer het toestel te gebruiken. Bewaar de bedieningsinstructies en het garantiecertificaat om
die later te kunnen raadplegen. Het toestel is bedoeld voor huishoudelijk gebruik.
* Installatie-instructies inbegrepen.
Grazie per aver acquistato il presente apparecchio Panasonic. Vi preghiamo di leggere attentamente
le presenti istruzioni prima di utilizzare l’apparecchio. Conservare le istruzioni d’uso e il certificato di
garanzia per l’uso futuro. Questo apparecchio è destinato all’uso domestico.
* Le istruzioni di installazione sono incluse.
Gracias por comprar este aparato electrodoméstico Panasonic. Por favor, lea atentamente las
instrucciones antes de utilizar el dispositivo. Conserve las Instrucciones de uso y el Certificado de
Garantía para usos futuros. Este aparato está diseñado para uso doméstico.
* Las instrucciones de instalación están incluidas.
Tak fordi De har valgt at købe dette Panasonic apparat. Læs venligst denne vejledning omhyggeligt
før De anvender apparatet. Gem Brugsvejledningen og Garantibeviset til fremtidig brug. Dette
apparat er beregnet til privat brug.
* Installationsvejledning er inkluderet.
Tack för att du valt en Panasonic-apparat. Läs noggrant dessa instruktioner innan du börjar använda
apparaten. Förvara användarinstruktionerna och garantibeviset för framtida bruk. Denna apparat är
avsedd för hemmabruk.
* Installationsanvisningar medföljer.
Takk for at du har valgt å kjøpte dette Panasonic apparatet. Vennligst les instruksjonene nøye
før apparatet tas i bruk. Ta vare på Bruksanvisningen og Garantibeviset for fremtidig bruk. Dette
apparatet er kun ment for privat bruk.
* Installasjonsveiledning medfølger.

1
A
Min. 65 cm
SUCTION MODE
RECIRCULATION MODE
Min. 65 cm
X = Min. 65 cm
Y
H32 cm
S
1
2
3
4
V1
ø 8 mm
C
B
2
B
1
V2
3

2
C
V5
V2
V5
L
3
H
L
V7
2
4
5
6
ø 6 mm
1
H
G
1
V6
ø 6 mm

3
Y
H1
H
X=Min. 65 cm
A1
B1
1
2
C
C1 3
4
ø 8 mm
ø 8 mm
x8
V1
C
V2
D
E
C
2
CEILING
x4
V3
1

4
B2
B3
V3
1
2
CEILING
FALSE
CEILING
A
C
A
V3
V3
CEILING
C1
D
A
1
2
CEILING
FALSE
CEILING
C
C1
E
D
3
4
C
F
E
D
CEILING
FALSE
CEILING

5
C1
CEILING
FALSE
CEILING
C
x4
x4
3
2
4
V4

6
D1
CEILING
FALSE
CEILING
1
x4
V3
2
3
6
4
x4
V3
7

7

8
N
H3
3
4
5
2
1
H2
M

9
Contents
A: WARNINGS ..................................................................................................................... 12
B: TECHNICAL SPECIFICATIONS ...................................................................................... 13
C: INSTALLATION ............................................................................................................... 13
D: ELECTRICAL CONNECTIONS ........................................................................................ 14
E: HOOD VERSION WITH EXTERNAL EXHAUST ............................................................ 14
F: HOOD VERSION WITH INTERNAL RECIRCULATION (filtering) ................................ 15
G: ELECTRONIC PUSH BUTTON CONTROL PANEL FUNCTIONING ............................. 15
H: FILTERS removing and replacing’s instructions ......................................................... 16
I: LED SPOTLIGHT ILLUMINATION ................................................................................. 17
J: MAINTENANCE AND CLEANING ................................................................................. 17
K: MOUNTING HOOD INSTRUCTIONS ............................................................................ 17
Inhalt
A: WARNHINWEISE ............................................................................................................ 20
B: TECHNISCHE DATEN ..................................................................................................... 21
C: INSTALLATION ............................................................................................................... 21
D: ELEKTRISCHE ANSCHLÜSSE ....................................................................................... 22
E: HAUBENVERSION FÜR ABLUFTBETRIEB ................................................................... 22
F: HAUBENVERSION FÜR UMLUFTBETRIEB (Filterung) ............................................... 23
G: FUNKTIONEN DER ELEKTRONISCHEN BEDIENTASTEN .......................................... 23
H: FILTER
anweisungen zu entnahme und austausch ............................................................ 24
I: BELEUCHTUNG MIT LED-STRAHLERN ....................................................................... 25
J: WARTUNG UND REINIGUNG ....................................................................................... 25
K: ANWEISUNGEN ZUR MONTAGE DER ABZUGSHAUBE ........................................... 26
Contenu
A: AVERTISSEMENTS...........................................................................................................29
B: CARACTÉRISTIQUES TECHNIQUES..............................................................................30
C: INSTALLATION .................................................................................................................31
D: BRANCHEMENTS ÉLECTRIQUES...................................................................................31
E: VERSION HOTTE AVEC ASPIRATION EXTÉRIEURE.....................................................32
F: VERSION HOTTE AVEC RECYCLAGE INTÉRIEUR (filtrage).........................................32
G: PANNEAU DE COMMANDE DE FONCTIONNEMENT ÉLECTRONIQUE
À BOUTONS .....................................................................................................................32
H: INSTRUCTIONS DE RETRAIT ET DE REMPLACEMENT DES FILTRES .......................34
I: ÉCLAIRAGE AVEC PROJECTEURS LED.........................................................................34
J: ENTRETIEN ET NETTOYAGE ..........................................................................................34
K: INSTRUCTIONS DE MONTAGE DE LA HOTTE .............................................................35

10
Inhoudsopgave
A: WAARSCHUWINGEN .....................................................................................................38
B: TECHNISCHE SPECIFICATIES ........................................................................................40
C: INSTALLATIE ....................................................................................................................40
D: ELEKTRISCHE AANSLUITINGEN ...................................................................................40
E: DAMPKAP VERSIE MET EXTERNE UITLAAT ...............................................................41
F: DAMPKAP VERIS MET INTERNE RECIRCULATIE (gefilterd) ......................................41
G: ELEKTRISCHE DRUKKNOP WERKING BEDIENINGSPANEEL ....................................41
H: INSTRUCTIES OM FILTERS TE VERWIJDEREN EN TE VERVANGEN ........................42
I: LED SPOTLAMPVERLICHTING ......................................................................................43
J: ONDERHOUD EN SCHOONMAAK ................................................................................43
K: INSTRUCTIES VOOR MONTAGE VAN DE DAMPKAP .................................................44
Indice
A: AVVERTENZE ...................................................................................................................47
B: SPECIFICHE TECNICHE....................................................................................................48
C: INSTALLAZIONE ..............................................................................................................49
D: COLLEGAMENTI ELETTRICI ...........................................................................................49
E: CAPPA IN VERSIONE AD EVACUAZIONE ESTERNA (aspirante) ...............................50
F: CAPPA IN VERSIONE A RICICLO INTERNO (filtrante) .................................................50
G: FUNZIONAMENTO CON PULSANTIERA ELETTRONICA ............................................50
H: FILTRI istruzioni per l’estrazione e la sostituzione ........................................................51
I: ILLUMINAZIONE CON FARETTI LED .............................................................................52
J: MANUTENZIONE E PULIZIA ..........................................................................................52
K: ISTRUZIONI DI MONTAGGIO CAPPA ............................................................................53
Contenidos
A: ADVERTENCIAS ..............................................................................................................56
B: DATOS TÉCNICOS ..........................................................................................................57
C: INSTALACIÓN ..................................................................................................................58
D: CONEXIONES ELÉCTRICAS ...........................................................................................58
E: VERSIÓN DE LA CAMPANA CON EVACUACIÓN EXTERNA ......................................59
F: VERSIÓN DE LA CAMPANA CON RECIRCULACIÓN INTERNA (filtrado) ..................59
G: PANEL DE CONTROL CON PULSADORES ELECTRÓNICOS.......................................59
H: INSTRUCCIONES PARA EL DESMONTAJE Y LA SUSTITUCIÓN
DE LOS FILTROS...............................................................................................................60
I: ILUMINACIÓN LED...........................................................................................................61
J: MANTENIMIENTO Y LIMPIEZA .....................................................................................61
K: INSTRUCCIONES DE MONTAJE DE LA CAMPANA EXTRACTORA ...........................62

11
Indholdsfortegnelse
A: ADVARSLER......................................................................................................................65
B: TEKNISKE SPECIFIKATIONER.........................................................................................66
C: INSTALLATION .................................................................................................................66
D: ELTILSLUTNINGER ..........................................................................................................67
E: EMHÆTTE VERSION MED EKSTERN UDLEDNING .....................................................67
F: EMHÆTTE VERSION MED INTERN RECIRKULATION (filtrering)...............................68
G: SÅDAN FUNGERER DET ELEKTRONISKE TRYKKNAP KONTROLPANEL .................68
H: FILTRE anvisninger for fjernelse og udskiftning ...........................................................69
I: LED SPOT BELYSNING....................................................................................................70
J: VEDLIGEHOLDELSE OG RENGØRING...........................................................................70
K: VEJLEDNING I MONTERING AF EMHÆTTEN ..............................................................70
Innehåll
A: VARNINGAR .....................................................................................................................73
B: TEKNISKA SPECIFIKATIONER .......................................................................................74
C: INSTALLATION ................................................................................................................74
D: ANSLUTNING TILL EL ....................................................................................................75
E: SPISKÅPSMODELL MED FRÅNLUFT ............................................................................75
F: SPISKÅPSMODELL MED INTERN ÅTERCIRKULERING (filtrerande) .........................75
G: FUNKTION PÅ ELEKTRONISK TRYCKKNAPPSPANEL ................................................76
H: FILTER instruktioner för borttagning och byte .............................................................77
I: LED-BELYSNING SPOTLIGHTS ......................................................................................77
J: UNDERHÅLL OCH RENGÖRING ....................................................................................78
K: SPISKÅPANS MONTERINGSINSTRUKTIONER ...........................................................78
Innhold
A: ADVARSLER .....................................................................................................................81
B: TEKNISKE SPESIFIKASJONER .......................................................................................82
C: INSTALLASJON................................................................................................................82
D: ELEKTRISKE KOBLINGER................................................................................................83
E: KJØKKENVENTILATOR I VERSJON UTLUFTING ........................................................83
F: KJØKKENVENTILATOR I VERSJON OMLUFT (filtrering) ...........................................83
G: SLIK VIRKER DET ELEKTRONISKE TRYKKNAPPANELET............................................84
H: FILTER instruksjoner for fjerning og utskiftning ...........................................................85
I: LED SPOTLIGHT BELYSNING .........................................................................................85
J: VEDLIKEHOLD OG RENGJØRING ..................................................................................85
K: MONTERINGSANVISNING FOR KJØKKENVENTILATOR............................................86

12
GB OPERATING
INSTRUCTIONS
WARNINGS
A
This instruction booklet must be kept together with the appliance for future reference. If the
appliance is sold or consigned to other parties, check that the booklet is supplied with it,
to ensure that the new user has the correct information on the operation of the cooker hood
and is aware of the warnings. These warnings have been provided for the your safety and the
safety of others. As a result, please read them carefully before installing and operating the
appliance.
This appliance is not intended for use by young children or infirm persons unless they have
been adequately supervised by a responsible person to ensure that they can use the appliance
safely. Young children should be supervised to ensure they do not play with the appliance.
The appliance must be installed by qualified personnel, in accordance with the standards in
force. In case of malfunction or breakdown, immediately stop using the appliance. Turn off the
circuit breaker, and then contact the service centre. Failure to do this may cause smoke, burns,
and electric shock.
Breakdown examples:
- Burning smell comes from the appliance.
- Can feel electricity when touching the appliance.
If the supply cord is damaged, it must be re-placed by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard. Any modifications that may be required
to the electrical system for the installation of the cooker hood must only be made by qualified
electricians.
It is dangerous to modify or attempt to modify the characteristics of this system. In the event of
malfunctions or if repairs are required to the appliance, do not attempt to solve the problems
directly.
Repairs performed by unqualified persons may cause damage. For all repair and other work on
the appliance, contact the service centre.
Always check that all the electrical parts (lights, exhaust device), are off when the appliance
is not being used. Turn off the circuit breaker when the appliance will not being used for a long
period of time. Read the entire instruction booklet before performing any operations on the
cooker hood.
The cooker hood must only be used for the exhaust of cooking fumes in home kitchens. The
manufacturer disclaims all liability for any other use of the appliance.
The maximum weight of any object placed above the hood, or hung to it (if possible) must
not exceed 1.5 kilos. After installing the stainless steel hood, clean it in order to remove any
residue of the protective glue, and stains of grease or oil. The manufacturer recommends its
cleaning cloth available for purchase. The manufacturer accepts no liability in case of dam-
age caused by the use of different detergent types.
SAFETY WARNINGS
The electrical system features an earth connection in compliance with international safety
standards; furthermore, it is compliant with the European standard for electromagnetic
compatibility. This appliance must be properly earthed following the electric laws. Earth line
must not be connected to gas pipe, water pipe, earth of lightning rod and telephone. Install
dedicated single-phase circuit with the adequate rated circuit breaker for the power supply.
Do not connect the appliance to flues (from boilers, fireplaces, etc.). Make sure the mains volt-

13
age corresponds to the values on the rating plate located inside the cooker hood. The minimum
safety distance between the cooktop and the cooker hood must be at least 65 cm.
Never cook on “open” flames under the cooker hood.
Check deep-fryers during use: superheated oil may be flammable.
- Ensure there is adequate ventilation of the room when the cooker hood is used at the same
time as appliances burning gas or other fuels.
- Do not flambe under the cooker hood.
- The exhaust air must not be discharged into a flue which is used for exhausting fumes from
appliances burning gas or other fuels.
- Ensure that all regulations concerning the discharge of exhaust air have been fulfilled before
you use the appliance.
Accessible parts may become hot when used with cooking appliance. Wear work gloves
for all installation and maintenance operations. Before performing any cleaning or mainte-
nance operations, disconnect the appliance by unplugging it or using the main switch. The
manufacturer disclaims all liability for any damage that may be directly or indirectly caused
to people, things and animals due to the failure to follow all the instructions provided in this
booklet and above all the warnings relating to the installation, operation and maintenance of
the appliance.
DISPOSAL OF WASTE PRODUCTS
Information on disposal for users of waste electrical & electronic equipment (private house-
holds) This symbol on the products and/or accompanying documents means that
used electrical and electronic products should not be mixed with general
household waste.
For proper treatment, recovery and recycling, please take these products to
designated collection points, where they will be accepted on a free of charge
basis. Alternatively, in some countries you may be able to return your products
to your local retailer upon the purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources and
prevent any potential negative effects on human health and the environment which could oth-
erwise arise from inappropriate waste handling. Please contact your local authority for further
details of your nearest designated disposable point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
Information on disposal in other countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for
the correct method of disposal.
TECHNICAL SPECIFICATIONS
B
The technical specifications of the appliance are shown on the rating plates located inside the
cooker hood.
INSTALLATION
C
(Section reserved for qualified installers of the cooker hood)
The distance between the hob and the lowest part of the kitchen cooker hood cannot be small-
er than X=65 cm. Should the instructions of the gas hob specify a greater distance, take this

14
into consideration.
In the outside suction version, the diameter of the fume discharge duct must be no smaller than
the cooker hood connection. We recommend using pipes with 150 mm diameter.
If using pipes with 120 mm diameter, install attached “reducer (150-120 mm)” to the discharge
hole of the cooker hood.
When screwing or installing the metallic duct to the wall which metal lath, wire lath or metal
plate is lined, do not let them come in contact with metal part. Otherwise, it may cause electric
leakages or fires.
In the horizontal sections, the duct must slope slightly (around 10%) upwards, so at to better
convey the air outside of the room. The duct must be installed not to bend it in the immediate
vicinity of the discharge hole. Otherwise, the return valve will get stuck with the duct, and will
not work for the exhaust properly. Reduce curves to the bare minimum, and check that the
length of the ducts is also the bare minimum.
Comply with the current regulations on air discharge into the atmosphere.
If other appliances that use gas or other fuels are being used at the same time (boiler, stove,
fireplaces, etc.), make sure the room where the fumes are extracted is well ventilated, in com-
pliance with the current regulations.
Assembly instructions: see section “K” of the booklet.
ELECTRICAL CONNECTIONS
D
(Section reserved for qualified installers)
WARNING!
Before doing any work inside the cooker hood, disconnect the appliance from the mains
power supply.
Check that the wires inside the cooker hood are not disconnected or cut; if this is the case,
contact your nearest service centre. The electrical connections must be performed by quali-
fied personnel.
The connections must be performed in compliance with the legal standards in force. Check
that the relief valve and the electrical system are able to support the load of the appliance (see
the technical specifications in point B).
This appliance is supplied with a cable without plug. Standardized plugs must be used, keeping
in mind that:
- the yellow-green wire must be used for the earth,
- the blue wire must be used for the neutral,
- the brown wire must be used for the phase; the cable must not come into contact with hot
parts (over 70°C).
- fit a plug that is suitable for the load to the power cable, and connect it to a suitable power
outlet.
Please refer to a qualifed person. (See technical specifications in point B).
WARNING!
The supply cord must be set properly not to be damaged. The manufacturer declines all li-
ability if the safety standards are not observed.
EHOOD VERSION WITH EXTERNAL EXHAUST
In this version the kitchen fumes and vapours are conveyed outside through an exhaust pipe.
The exhaust conveyor that protrudes from the upper part of the hood must be connected with
the pipe that conducts the fumes and vapours in an external output.
In this version, charcoal filters supplied on the hoods must not be used.
When the kitchen hood is used simultaneously with other appliances that use gas or other
fuels, the room must have sufficient ventilation according to the standards in force.

15
Deviation for Germany:
When the cooker hood and appliances supplied with energy other than electricity are si-
multaneously in operation, the negative pressure in the room must not exceed 4 Pa (4x10
E-5 bar).
FHOOD VERSION WITH INTERNAL
RECIRCULATION (filtering)
In this model, the area passes through the charcoal filters to be purified and is then introduced
into the kitchen environment. To mount the filters, refer to section H2.
For maximum efficiency, the third speed should be used when there are strong odours or a lot
of steam, the second speed in normal conditions, and the first speed for keeping the air clean
with minimum energy consumption. The cooker hood should be switched on when starting to
cook, and left on until the odours disappear.
GELECTRONIC PUSH BUTTON CONTROL PANEL
FUNCTIONING
24 h
Key 1: Timer/Filter alarm
The BLUE fix light indicates that the grease filter alarm is active (after 30 hours); to deactivate
this alarm and reset the hour meter, press the button for 3 seconds.
BLUE flashing light indicates that the timer function is active. This function can be activated
only if the motor is already active with any speed when the key is pressed (prolonged pressure
or not). This function activates the auto power off function of the cooker hood after 15 minutes
with the active Timer function, the cooker hood can be turned off by the user and the function
will be disabled. The Timer function remains associated to a speed. The speed change with the
active timer function determines its deactivation.
Key 2: 1st Speed +On/Off motor
A slight pressure of the key activates the hood at the first speed and the relative LED.
When the LED is on and the key is pressed, both the LED and MOTOR will turn off.
When the LED is off, if the key is pressed for at least 3sec, the recirculation function activates.
During the recirculation function (which lasts 24 hours), the LED flashes.
From the activation of this function, the cooker hood will remain active for 1 hour at 1st speed,
then it will stop for 3 hours and reactivate for another hour. These cycles are repeated until
timeout. With activation of this function, other speeds may not be selected. To deactivate this
function, keep key 2 pressed for at least 3 seconds.
Key 3: 2nd Speed
If the LED is off and another speed is active, press the key (slightly or prolonged) to select the
2nd speed, turn the relative LED on and turn the LED associated to the previously selected
speed off.
If the LED is off and no speed is active, the key is disabled.
When the LED is on, key 3 is disabled.
To turn off the cooker hood, select the first speed and press that key again.

16
Key 4: 3rd Speed
If the LED is off and another speed is active, press the key (slightly or prolonged) to select
the 3rd speed, turn the relative LED on and turn the LED associated to the previously selected
speed off.
If the LED is off and no speed is active, the key is disabled.
When the LED is on, key 4 is disabled.
To turn off the cooker hood, select the first speed and press that key again.
Key 5: 4th Speed
If the LED is off and another speed is active, press the key (slightly or prolonged) to select
the 4th speed, turn the relative LED on and turn the LED associated to the previously selected
speed off.
If the LED is off and no speed is active, the key is disabled.
When the LED is on, key 5 is disabled.
The fourth speed lasts 14 minutes, then the cooker hood returns to the third speed.
To turn off the cooker hood, select the first speed and press that key again.
Key 6: Light
Light: Briefly pressing key T6 will turn the light on and off. The T6 key lights on if the light is on.
Key pressure management
Prolonged pressure = finger pressed on key for at least 3 seconds, the function activates dur-
ing pressure.
Non-prolonged pressure = finger pressed on key for less than 3 seconds, the function activates
upon its release.
FILTERS REMOVING AND REPLACING’S INSTRUCTIONS
H
1. METAL FILTERS
Open the panel (see fig. H1). To remove the grease-trapping metallic filters pull on the
handles. To place the grease-trapping metallic filters, insert the tabs into the holes as il-
lustrated in the lower left figure.
2. CARBON FILTERS
To replace the charcoal filters, proceed as follows: remove the metal filters as described
above. Now the motor compartment can be accessed and it is possible to proceed with
the assembly/disassembly of the carbon filters as illustrated in the lower right figure.
To order new charcoal filters, contact your distributor/dealer.

17
LED SPOTLIGHT ILLUMINATION
I
The cooker hood is equipped with high efficiency, low consumption LED spotlights with ex-
tremely long duration under normal use conditions. LED spotlight replacement must be carried
out only by qualified technicians using only original spare parts.
MAINTENANCE AND CLEANING
J
Constant maintenance ensures the correct operation and efficiency of the appliance over
time. Special attention should be paid to the metal grease-trapping filters and the charcoal
filters. Frequent cleaning of the filters and their supports will ensure that fats and grease do
not accumulate on the cooker hood, with the consequent risk of fire.
1. METAL GREASE-TRAPPING FILTERS
These trap the fat and grease particles suspended in the air, and therefore should be
washed every month in hot water and detergent, without bending them. Wait until they
are completely dry before repositioning them. To remove and replace these filters, see the
instructions in point H1. This operation should be performed at regular intervals.
2. CHARCOAL FILTERS
These trap the odours present in the stream of air that passes through them. The air is puri-
fied by passing a number of times through the filters and being recirculated into the kitchen.
The charcoal filters cannot be cleaned, and should be replaced on average every 3-4 months
(according to use). To replace the charcoal filters, see the instructions in point H2.
3. CLEANING THE OUTSIDE OF THE APPLIANCE
It is advised to clean the external hood surfaces at least every 15 days in order to avoid that
oily or greasy substances affect the steel surfaces.
The outside of the cooker hood should be cleaned using a damp cloth and neutral liquid
detergent or denatured alcohol.
In case of fingerprint-less finish (fasteel) clean only with water and neutral soap using
clean with a soft cloth, rinse and wipe dry thoroughly. Do not use products that contain
abrasive substances or cloths NOT specifically designed for cleaning steel. Using abrasive
substances or rough cloths will inevitably damage the finish of steel. The steel surface
will be irrevocably damaged if the instructions above are not complied with. Keep these
instructions together with the instructions for use of your hood.
The manufacturer accepts no liability for any damage caused by non-compliance with the
instructions above.
4. CLEANING THE INSIDE OF THE APPLIANCE
The electrical parts or parts of the motor assembly inside the cooker hood must not be
cleaned using liquids or solvents.
Do not use abrasive products. All the above operations must be performed after having dis-
connected the appliance from the mains power supply. There is a fire risk if cleaning is not
carried out in accordance with the instructions.
KMOUNTING HOOD INSTRUCTIONS
Before performing the installation, definitely turn off the circuit breaker.
The ceiling must be flat, horizontal and adequately load bearing. The wall plugs must have
a secure grip. The enclosed screws and wall plugs are suitable for solid brickwork or solid

18
concrete. Suitable fasteners must be used for other structures (e.g. plasterboard, porous con-
crete, porous bricks)
K1 WALL COOKER HOOD ASSEMBLY INSTRUCTIONS
Phase 1
(Fig. A)
1) Place the support bar (S) on the wall at a height H from hob resulting from the sum of the
quotas:
- X + Y + 320 mm, where X=650 mm and Y is the height of the cooker hood cone.
2) With a spirit level, verify the horizontal alignment;
3) mark 2 drilling points at the ends of support bar.
4) Drill, insert 2 ø 8mm wall plugs and fasten the support bar (S) with the relative screws (V1).
(Fig. B)
1) Hook the hood on the support bar (S).
2) Adjust the alignment of the hood, using the fixing screws.
- The upper screw (B) adjusts the distance from the wall, the lower one (C) the vertical scroll-
ing.
3) To prevent the hood from falling due to a pressure below, fasten it to the wall with 2 ø 6mm
wall plugs and relative screws (V2) using the appropriate holes on the back of the hood.
Phase 2
- Remove the perimeter suction panel and metallic filters as described in sec. H.
- Suction version (SUCTION MODE): install the return valve (M) as described in Fig. H2, and
then, connect the outlet fitting of the fan to the external discharge through suitable piping.
- Filtering version (RECIRCULATION MODE): assemble the charcoal filters as described in
sec. H.
- Carry out the electric connection only after having disconnected the electric power supply
of the hood as described in sec. D.
Phase 3
(Fig. C)
1) Insert the extension (H) in the chimney (G).
2) Fasten it all (G+H) to the hood body using the screws (V5).
3) Slide the extension (H) until it reaches the desired height.
4) Place the bracket (L) on the wall, verify the horizontal alignment with a spirit level and mark
2 drilling points at the ends.
5) Drill, insert 2 ø 6mm wall plugs and fasten the bracket (L) with the relative screws (V6).
6) Screw the extension (H) to the bracket (L) using the two screws (V7).
- Reassemble the perimeter suction panel and metallic filters as described in sec. H.
- Power the hood complying with the regulations in force (see sec. D of the booklet).
K2 ISLAND COOKER HOOD ASSEMBLY INSTRUCTIONS
Phase 1
(Fig. A1)
1) Identify the height H of the hob resulting from the sum of the quotas:
X + Y + H1 (X normally is equal to 65cm)
2) Scroll trellises (C) and (C1) until reaching the desired height (H),
3) Then block them using 8 self-threading screws (V1).
4) Fasten the trellis (C) to the ceiling with 4 Ø 8mm wall plugs and relative screws (V2) using the
appropriate holes on the ceiling.
Phase 2
(Fig. B1)
1) Introduce the extension (E) onto the chimney (D) and block them together using the adhe-
