Panasonic Na - 140vg3 Operating instructions

Read Before Using 02

SAFETY PRECAUTIONS 04

Washing Instructions 12

Optional Functions 20

Maintenance 22

Troubleshooting 25

Installation Instructions 30

Operating Instructions

& Installation Instructions

Washing Machine

(Domestic use)

Model No.

NA - 140VG3

NA - 168VG3

NA - 148VG3

Thank you for purchasing this appliance.

- For optimum performance and safety, please read these instructions

carefully.

- Before connecting, operating or adjusting this appliance, please read the

instructions completely. Please keep this manual for future reference.

NA-168VG3_English.indb 1 2011-1-24 11:24:53

2 - Read Before Using

Consider the Environment

Disposing of packaging

The packaging used to protect the

washing machine from damage during

transportation is all recyclable. For

information on recycling, contact your local

authority.

Disposing of Waste

Electrical & Electronic

Equipment

Information on disposal for users of

waste electrical & electronic equipment

(private households)

This symbol on the products and/or

accompanying documents means that

used electrical and electronic products

should not be mixed with general

household waste.

For proper treatment, recovery and

recycling, please take these products to

designated collection points, where they

will be accepted on a free of charge basis.

Alternatively, in some countries you may be

able to return your products to your local

retailer upon the purchase of an equivalent

new product.

Disposing of this product correctly will

help to save valuable resources and

prevent any potential negative effects on

human health and the environment which

could otherwise arise from inappropriate

waste handling. Please contact your local

authority for further details of your nearest

designated disposable point.

Penalties may be applicable for incorrect

disposal of this waste, in accordance with

national legislation.

Information on disposal in other

countries outside the European Union

This symbol is only valid in the European

Union.

If you wish to discard this product, please

contact your local authorities or dealer and

ask for the correct method of disposal.

Eco-friendly Laundry

Keep to the load limit of each-

programme.

The washing machine automatically-

adjusts the operating time of each

programme depending on the load.

You only need to use a preliminary wash-

if your laundry is heavily soiled.

Using the 60°C Cotton programme-

instead of the 90°C Cotton one will save

energy, and will remove ordinary stains.

For lightly soiled laundry, using the 15°C-

Wash programme instead of the 40°C

Quick 50 programme will save more

energy.

Detergent amount

Use the correct amount of detergent-

based on the detergent pack instructions

and local water hardness.

Adjust the amount of detergent-

depending on how soiled your laundry is.

When using a tumble dryer

To save energy, please select the correct

spin-dry revolution speed according to the

instruction of your tumble dryer.

This product complies with the directives

2006/95/EC and 2004/108/EC.

NA-168VG3_English.indb 2 2011-1-24 11:24:53

Read Before Using - 3

Contents

Read Before Using

Consider the Environment........2

SAFETY PRECAUTIONS ........4

Checking Your Washing Machine . . 6

Your washing machine .............6

Accessories......................6

Before You Start Washing ........7

Checking before use ...............7

Before initial use . . . . . . . . . . . . . . . . . .7

Preparing the laundry ..............7

Using the Buttons ..............8

Unlocking the door ................9

Adding Detergent and Other

Chemicals ...................10

Detergent compartment ...........10

Softener compartment.............11

Prewashing compartment ..........11

Washing Instructions

Washing.....................12

Setting washing..................12

Required time ...................13

Setting the buzzer ................13

Changing settings while washing ....13

Selecting the Programme .......14

Details of Programmes .........16

Washing Delicates.............18

Wool, Silk/Lingerie, and Delicates

programmes ....................18

Delicate laundry loads.............18

Tips for washing delicates..........18

Washing Bedding and Outdoor

Wear .......................19

Bedding programme . . . . . . . . . . . . . .19

Putting bedding into the drum .......19

Outdoor programme ..............19

Optional Functions.............20

Individual washing functions ........20

Additional functions...............20

Preset timer.....................21

Child safety lock .................21

Maintenance

Maintenance .................22

Cleaning the outside of the

appliance.......................22

Cleaning the drum................22

Cleaning the detergent drawer ......22

Cleaning the door seal and window . .23

Cleaning the drain filter ............23

Cleaning the water-supply filter......24

Preventing a frozen water-supply

hose ..........................24

Troubleshooting

Fault Checklist................25

Error Display .................29

Installation Instructions

Choosing the Right Location .....30

Carrying the appliance ............30

The right place for the appliance.....30

Installing a built-in washing machine..31

Moving and Installing...........32

Removing the anchor bolts .........32

Moving the appliance .............32

Levelling the appliance . . . . . . . . . . . .33

Connecting Hoses and Power

Supply . . . . . . . . . . . . . . . . . . . . . . 34

Hoses and cable lengths...........34

Water-supply hose ...............34

Water-drain hose.................35

Connecting to the power supply .....35

Checking After Installation.......36

Installation checklist ..............36

Test run after installation ...........37

Power and Water Consumption...38

Specifications ................39

NA-168VG3_English.indb 3 2011-1-24 11:24:54

4 - Read Before Using

SAFETY PRECAUTIONS

Please read and follow these safety

precautions.

WARNING

This describes issues which could

cause death or serious injury.

General Use

This appliance is not intended for use-

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use

of the appliance by a person responsible

for their safety.

Children should be supervised to ensure-

that they do not play with the appliance.

Do NOT place a stand or a chair close to-

the appliance.

Children may be able to reach the

control panel or climb onto or into the

appliance.

Turn off the water supply to the-

appliance if it is not going to be used

for a prolonged period, such as during

a holiday. This is especially important

if there is no drainage around the

appliance.

If the water supply is left on, the water

pressure may unnecessarily increase

and result in a leak.

Do NOT install the appliance in a damp-

location or in a location exposed to the

weather.

This may result in malfunction,

deterioration, electric shock, or fire.

Do NOT pour or spill water directly onto-

any part of the appliance.

This may result in malfunction, electric

shock, or fire.

Keep sources of ignition, such as-

candles or cigarettes, away from the

appliance.

They may cause a fire or damage to the

appliance.

Keep flammable materials away from-

the appliance, for example, gasoline,

thinner, alcohol, or clothing soaked with

these materials.

They may cause an explosion or a fire.

Power source and cable

Unplug the mains lead when cleaning-

the appliance.

Check the mains lead and mains plug for-

any damage.

If the mains lead is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified person to

aviod a hazard.

Do NOT use a mains plug adaptor or-

extension cable. There is a possibility of

overheating which may cause a fire. Use

an unused household mains socket, fully

rated at AC 220 V to 240 V. If you are

not sure, contact a qualified electrician.

ENSURE the mains plug is fully inserted-

into the household mains socket. If the

mains plug is not fully pushed in, a loose

connection may overheat and cause an

electric shock or fire.

Do NOT touch the mains lead or mains-

plug with wet hands.

Possibility of an electric shock.

Do NOT pull the mains lead but hold the-

mains plug to unplug the appliance.

Otherwise, there is possibility of damage

to the mains lead, which may lead to an

electric shock or fire.

NA-168VG3_English.indb 4 2011-1-24 11:24:54

Read Before Using - 5

SAFETY PRECAUTIONS

To Prevent Injury

The installation of the appliance should-

be done by the manufacturer’s dealer or

service agent.

If the installation, test run and inspection

of the appliance are not carried out

following the installation method outlined

in these instructions, the manufacturer

will not be liable for any accident or

damage caused.

Do NOT dismantle, repair or modify the-

appliance.

There is a possibility the appliance may

malfunction which may result in a fire or

an injury. If repairs are needed, contact

your local Customer Service Centre.

Do NOT touch the laundry inside the-

drum until it has completely stopped,

as there is a possibility of injury. Keep

children away from the rotating laundry.

CAUTION

This describes issues which could

cause injury or damage your

belongings.

General Use

Prior to use, turn on the tap and check-

the hose and connections for any leaks.

Improper connection could cause leaks.

The new hose-sets supplied with the-

appliance are to be used and that old

hose-sets should not be reused.

This appliance is only suitable for textiles-

labelled washing machine washable.

Do NOT connect to the hot water supply.-

This appliance works ONLY with cold

water.

Do NOT apply pesticide, hair spray or-

deodorant to the appliance.

Do NOT put any electrical equipment,-

for example, TVs, radios or battery

chargers, on or near the appliance.

Do NOT put too much laundry or-

detergent into the appliance.

This may cause damage to the

appliance.

REMOVE the anchor bolts before-

installing the appliance using a spanner

supplied or similar tool. The anchor bolts

are used to transport the appliance.

If the anchor bolts are not removed, the

appliance will strongly vibrate during

use.

To Prevent Injury

Do NOT climb onto the appliance.-

This may cause injury or damage to the

appliance.

Keep fingers away from the door hinge-

when opening and closing the door.

Do NOT slide your hand (or unprotected-

foot) underneath the appliance when in

use.

Check all washing and remove all-

objects such as nails, pins, coins, clips,

metal wires, etc.

They may cause damage to other

laundry or the appliance.

Do NOT use the appliance to wash-

waterproof sheets or clothing. There is

a possibility of excessive vibration or

failure during the spin-drying cycle that

may result in an injury, damage to the

appliance or a water leak.

BE CAREFUL when draining hot water-

or any detergent out of the drum.

BE CAREFUL not to get laundry caught-

in the door seal when it is closed. This

may result in a water leak or damage to

the laundry during the wash cycle.

NA-168VG3_English.indb 5 2011-1-24 11:24:54

6 - Read Before Using

Checking Your Washing Machine

Your washing machine

Caution

Do NOT bend the mains lead when the appliance is running.

Accessories

Make sure that all the accessories are

supplied with the appliance.

Elbow (see page 35)

For fixing the water-drain hose

Spanner (see pages 32-33)

End A is for adjusting the stand. End B is

for the anchor bolts.

Cover cap (x4) (see pages 32-33)

Water-supply hose (see page 34)

Either one of these hoses is supplied with

the appliance.

Detergent drawer

(see page 10)

Door

Water-drain hose

Adjustable stands

(see page 33)

Drain filter cover

(see page 23)

Mains lead/

Mains plug

Door seal

Drum

(Washing/

spin-drying tub)

Standard

Hose

Hose with

water-supply valve

(Not available for UK models)

NA-168VG3_English.indb 6 2011-1-24 11:24:56

Read Before Using - 7

Before You Start Washing

Checking before use

For the appliance’s initial operation or

after a prolonged period of non-operation,

perform the following procedures:

Secure the water-supply hose.1.

Open the tap.2.

Connect the power.3.

Make sure that the water-drain hose4.

is positioned towards a drain.

For more details, see page 35.

Before initial use

The default setting is the 40ºC Cotton

programme. For the appliance’s initial

operation, operate it WITHOUT any

detergent or clothing to rinse out residue or

moisture.

Note

There may be drops of water or

condensation in the appliance due

to the factory inspection prior to

shipment. This is not a malfunction.

Preparing the laundry

Sorting clothing

Read clothing washing labels to help-

you sort them into different loads.

Sort the laundry by colour, by type of-

fabric, and by how soiled it is. Doing

so will help you choose the correct

programme and temperature for each

wash.

Clothes that are not colour fast should-

be washed separately. Wash denim

separately.

You should put bras with metal wires,-

tights, lace clothing and small items of

clothing into a laundry net to prevent

them or the appliance from getting

damaged.

Treating stains

Apply stain remover to stained portions.

For dirt and solid stains, wash lightly by

hand first.

Checking clothing

Check that pockets on clothing do not-

contain any objects that may damage

the clothes or the appliance.

Tie up any loose strings on the clothing-

and close zippers. Turn clothing with

raised fabrics and zippers inside out.

Otherwise, the clothes may be

damaged.

Remove any hair, animal fur, sand,-

and other materials with a brush before

washing.

NA-168VG3_English.indb 7 2011-1-24 11:24:57

8 - Read Before Using

Using the Buttons

Power buttons1.

If you do not press the Start button-

within 10 minutes after the appliance

has been switched on, the appliance

automatically switches itself off.

The display below appears for 3-

seconds after the appliance has

been switched off. You cannot turn

the appliance on until this display

disappears.

Start/Pause button2.

Press this button to start or pause the

wash programme.

Programme selection dial3.

Use this dial to choose the best

programme for the laundry. (See pages

14-15.)

Additional function buttons4.

Press these buttons to add functions to

the programme to suit the laundry. (See

pages 20-21.)

Mode/Child Lock button5.

Press this button to select the function of-

processes, for example, the Rinse and

Spin function or the Drain only function.

(See page 20.)

Press and hold this button to set the-

child safety lock. The door and the

controls will be locked. (See page 21.)

Time button6.

Press this button to preset the time for

when the washing finishes. (See page

21.)

Spin speed button7.

Press this button to see the spin speed

(r/min) or to choose the spin speed for

the programme you have selected. (The

maximum spin speeds of model NA-

140VG3 and NA-148VG3 are 1400

r/min. NA-168VG3 is 1600r/min.)

Temperature button8.

Press this button to choose water

temperatures ranging from cold to 90ºC.

You can choose hotter temperatures for

whites, cottons, or soiled laundry.

Model NA-168VG3

Cotton Rinse Plus

Colours

Easy-care

Delicates

Wool

Denim

Outdoor

15ºC Wash

Quick 50

Rapid 15

Sportswear

Shirts

Bedding

Skin-care

854

Start/Pause

NA-168VG3_English.indb 8 2011-1-24 11:24:58

Read Before Using - 9

Using the Buttons

Process indicator9.

This indicator shows the current process-

of the programme. The process consists

of wash , rinse , spin , and drain

The light goes off when the wash is-

finished.

Remaining time indicator10.

This indicator shows the approximate-

time until the washing finishes. For

example, ‘1:18’ means 1 hour and 18

minutes.

The time is acquired from the weight of-

the laundry measured when washing

starts. flashes while the weight is

being measured.

Unlocking the door

The door automatically locks while in use,

and the symbol is shown while the door

is locked. A click will be heard when the

door locks or unlocks.

Note

While the door is locked, if the-

appliance is switched off, or if there

is a power interruption, the door

stays locked until the switch is turned

on again.

This is different from the child safety-

lock. (See page 21.)

Press the Start button to unlock the

door during operation.

After about 1 minute, the drum stops

spinning, and the door will automatically

unlock.

If the door doesn’t open, see page 25.

Caution

If you have to unlock the door

mid-programme, make sure that

water from the drum does not

overflow onto the floor.

Water and soap suds might come out

of the door and the door opening. You

may need a towel to soak them up.

Display on NA-168VG3

NA-168VG3_English.indb 9 2011-1-24 11:25:00

10 - Read Before Using

Adding Detergent and Other Chemicals

Detergent compartment

The following detergents and additives may

be added to this compartment:

Detergent-

Water softening agent-

Stain remover-

Tub cleaning detergent or bleach-

If you use multiple chemicals in this

compartment for washing, add them in the

following order:

1. Detergent

2. Water softening agent

3. Stain remover

Detergent

Use only detergents that are recommended

for fully-automated washing machines.

Please use low suds detergents.

Caution

If the instructions on the package

indicate that detergent should be

placed in the drum, do NOT put it

into the detergent drawer.

These detergents may not flow well

and remain in the detergent drawer.

Liquid detergent1.

Note

Do NOT use liquid detergent with the

Prewash function. It may flow away

during the prewash.

For the Wool programme, use mild liquid

detergent.

Powdered detergent2.

Detergent reaches the drum only when

water flushes through the detergent

drawer. Thus, if you forget to add

detergent, run the Drain only function using

the Mode button.

Pull out the detergent drawer and add detergent or softener to the correct

compartment. Check the packages for the appropriate recommended amounts.

Caution

Do NOT use the appliance when the detergent drawer is removed.

This may result in a water leak.

Prewashing compartment

Softener compartment

Detergent compartment

NA-168VG3_English.indb 10 2011-1-24 11:25:01

Read Before Using - 11

Adding Detergent and Other Chemicals

Then, add detergent and start washing

again.

To prevent powdered detergent from

remaining in the drawer, perform the

following:

Dry the inside of the drawer with a cloth.-

Make sure that the detergent is not-

lumpy when you add it as this may

cause a blockage over time.

Amount of Detergent

The amount of detergent you should use

depends on the following factors:

How soiled the laundry is-

The amount of the laundry-

Water hardness-

The amount of foam varies according to

the amount and type of detergent, how

soiled the laundry is, and the hardness and

temperature of the water.

Water softening agent

If you live in a hard water area (total

hardness of 1.3 mmol/L or higher), we

recommend the usage of a water softening

agent. For more details on water hardness,

contact your local water authority.

Use of a water softening agent can help

reduce the amount of detergent that is

required for each wash and help prevent

the formation of limescale deposits, which

may damage the appliance.

Softener compartment

The following additives may be added to

this compartment:

Fabric softener-

Laundry starch-

Fabric Softener

To prevent static, add softener before you

start washing. It will be automatically added

in the final rinse cycle.

Dilute concentrated softeners before you

add them. Add up to only 130 ml to the

compartment to avoid overflowing.

Rinse out the remaining softener with

a splash of water or a damp cloth after

washing. If it sticks to the compartment,

pull out the drawer and clean it out. (See

page 22.)

Laundry starch

Simply add laundry starch to the softener

compartment. It will be automatically added

to the clothing as part of the final rinsing

process. Make sure that you do not fill the

compartment over the MAX level.

If it is hard to pour, you can dilute the

starch slightly with water before adding it.

Note

After using starch, clean the detergent

drawer, especially the softener cover

(see page 22). Then, run the Rapid 15

programme WITHOUT detergent to

remove any excess starch in the drum.

Prewashing compartment

Detergent for prewashing

Whenever you use any programmes with

the Prewash function, always put detergent

for the prewash in this compartment.

Undiluted

softener Water

NA-168VG3_English.indb 11 2011-1-24 11:25:01

12 - Washing Instructions

Washing

Open the door and put the laundry1.

into the drum.

For details about preparing and sorting

the laundry, see pages 7, 14, and 15.

Caution

Make sure that no laundry gets-

caught in the door.

Do NOT overload the drum.-

This may cause excessive vibration

or damage to the appliance.

Close the door and press the On2.

button.

Turn the programme selection dial3.

either way to select the programme.

A wash time will be displayed.

Memory programme

You can design your own programme

based on the default settings of the Cotton

programme. Select Memory programme

and set other settings, then run the

programme. Later, this preset programme

can be run by simply accessing Memory

programme.

15°C Wash programme

This programme achieves the same

cleaning strength with 15°C low-

temperature washing as 40°C programme

(except for greasy filth).

When you select the 15°C wash, the

symbol flashes on the temperature display.

Cotton Rinse Pluse programme

This programme has rinse performance

better than the cotton programme.

Select optional functions.4.

Process selection (See page 20.)-

Additional functions (See page 20-21.)-

Temperature (See page 8.)-

Spin speed (See page 8.)-

For more details about available

functions and settings for each

programme, see pages 16-17.

Add detergent to the detergent5.

drawer.

(See pages 10-11.)

Press the Start button.6.

The appliance starts supplying water.

After the appliance has started, the

laundry is weighed. After about 5

seconds, a new wash time will be

displayed. If you select the Wool/Silk,

Bedding, Sportswear, Rapid 15, or

Shirt programmes, the laundry is not

weighed.

The buzzer will sound when the

programme has finnished, and the door

will unlock immediately.

Setting washing Model NA-168VG3

Cotton Rinse Plus

Colours

Easy-care

Delicates

Wool

Denim

Outdoor

15ºC Wash

Quick 50

Rapid 15

Sportswear

Shirts

Bedding

Skin-care

Start/Pause

NA-168VG3_English.indb 12 2011-1-24 11:25:02

Washing Instructions - 13

Washing

Caution

After a high temperature wash, be

careful to not burn yourself when

handling the laundry or touching

the inside of the drum.

Note

If the detergent is not completely-

removed from the laundry by using

the basic programme, use the Extra

Rinse function.

With the Eco and the Speed-

functions, if the load is big, the

laundry may stick to the inside of the

drum. This is normal.

Remove the laundry and rearrange-

where necessary. Do not leave it in

the drum too long after the programme

ends, because colours may run.

Required time

Times depend on the programmes and

temperature settings that have been

selected.

Actual times may differ slightly from-

those shown.

The displayed times include the time-

needed for the water to fill up and to

drain out, thus they vary depending on

water pressure, drainage and amount of

laundry.

If you change the functions while-

washing, the displayed times may

change.

If the laundry in the drum needs to be-

balanced, times will be extended.

Setting the buzzer

The buzzer that sounds when a

programme finishes can be turned off.

Press the Start and On buttons at the1.

same time.

Release the On button and keep2.

pressing the Start button for 3

seconds. The buzzer setting will be

turned off after a beep is heard.

If you wish to reset the setting, perform

the same steps 1 and 2. The buzzer

setting will be turned on after two beeps

are heard.

Changing settings while

washing

After washing has started, the programme,

temperature, and preset time cannot be

changed.

To change the programme or temperature-

settings, turn the appliance off and then

on again.

To change the rinse or spin settings while-

washing, press the Pause button once

the appliance is full of water.

You can change the Spin-dry revolution,-

Extra Rinse and Easy Ironing function

during the washing process.

No settings can be changed after the-

washing process has finished.

NA-168VG3_English.indb 13 2011-1-24 11:25:02

14 - Washing Instructions

Selecting the Programme

Programme Description 140VG3

Max load

148VG3

168VG3

Max load

Cotton

Daily washing for cotton, linen and

cotton blend items (For examples,

T-shirts, underwear, towels, tablecloths)

10 kg8 kg

Cotton Rinse

Plus

Washing takes longer overall but rinsing

is more thorough than the Cotton

programme.

10 kg8 kg

Easy-care Gentle washing for cotton, linen, and

synthetics. 5 kg4 kg

Delicates Gentle washing for synthetic fibres,

textiles, satin, lace, etc. 5 kg4 kg

Wool

Gentle washing for hand wash only

wool, machine washable wool, and

wool blends

2 kg2 kg

Silk/Lingerie

For lingerie and washable silk items.

Washes gentler than the Wool

programme.

2 kg―

Quick 50 Washes lightly soiled items in 50

minutes. 5 kg4 kg

Rapid 15 Washes a few lightly soiled items in 15

minutes. 2 kg2 kg

Colours For washing coloured cottons or

coloured cotton blend items separately 5 kg4 kg

NA-168VG3_English.indb 14 2011-1-24 11:25:03

Washing Instructions - 15

Selecting the Programme

Programme Description 140VG3

Max load

148VG3

168VG3

Max load

Mixed

For items with mixed fabrics, for

example, cotton, linen and synthetic

fibres

10 kg―

15°C Wash For lightly soiled cottons, and linen

blends. 5 kg4 kg

Memory

Programme based on the Cotton

programme featuring selected optional

functions and settings.

10 kg8 kg

Baby-care For babywear 5 kg―

Skin-care

For items that need to be gentle to the

skin, for example, underwear, sheets,

towels, and baby clothes. Items are

spray washed and thoroughly rinsed.

―4 kg

Shirts For shirts and blouses 2 kg2 kg

Sportswear For synthetic sportswear 3 kg3 kg

Bedding For large items, for example, blankets,

curtains, and bedspreads 3 kg3 kg

Outdoor For synthetic fabric outdoor wear and

water-repellent clothing ―3 kg

Denim The spray washing is used to prevent

jeans from fading. ―2 kg

NA-168VG3_English.indb 15 2011-1-24 11:25:04

16 - Washing Instructions

Details of Programmes

Programme

Available

programme Auto setting Manual setting Additional functions

140VG3 148VG3

168VG3 Temperature

Number

rinses

Spin-dry

revolutions

Approximate time

Temperature

Spin-dry revolutions Eco

Speed

Extra

Rinse

Prewash

Easy

Ironing

140VG3 148VG3

168VG3 168VG3 140VG3

148VG3

Cotton   40°C 2 1200 1:09 - 2:04 1:09 - 1:49 Cold - 90°C 500 - 1600 500 - 1400    

Cotton

Rinse Plus   40°C 2 1200 1:22 - 2:12 1:22 - 1:57 Cold - 90°C 500 - 1600 500 - 1400    

Easy-care   40°C 2 800 1:01 - 1:31 1:01 - 1:21 Cold - 60°C 500 - 1200 500 - 1200    

Delicates   40°C 2 800 0:55 - 1:00 0:55 - 1:00 Cold - 40°C 500 - 800 500 - 800 ―

Wool   30°C 3 500 0:40 0:40 Cold - 40°C 500 500 ―― ―

Silk/

Lingerie ―30°C 3 500 0:40 ―Cold - 40°C ―500 ―― ―

Quick 50   40°C 2 1200 0:46 - 0:49 0:46 - 0:49 Cold - 60°C 500 - 1600 500 - 1400 ―

Rapid 15   30°C 1 800 0:15 0:15 Cold - 30°C 500 - 800 500 - 800 ― ― ― ―

Colours   40°C 2 1200 0:58 - 1:23 0:58 - 1:13 Cold - 40°C 500 - 1600 500 - 1400    

Mixed ―40°C 2 1200 1:09 - 1:44 ―Cold - 40°C ―500 - 1400    

15°C Wash   2 1200 1:14 - 1:29 1:14 - 1:29 Cold 500 - 1600 500 - 1400 ―

Memory   ― ― ― ― ― Cold - 90°C 500 - 1600 500 - 1400    

Baby-care ―40°C 3 1200 1:29 - 2:04 ―Cold - 90°C ―500 - 1200    

Skin-care ―40°C 3 1200 ―1:29 - 1:49 Cold - 90°C 500 - 1200 500 - 1200    

Shirts   40°C 2 500 1:08 1:08 Cold - 60°C 500 - 800 500 - 800    

Sportswear   40°C 2 800 1:30 1:30 Cold - 40°C 500 - 1200 500 - 1200    

Bedding   30°C 2 800 1:02 1:02 Cold - 40°C 500 - 800 500 - 800 ――

Outdoor ―30°C 3 800 ―1:48 Cold - 40°C 800 800    ―

Denim ―30°C 2 800 ―0:55 Cold - 40°C 500 - 1200 500 - 1200    

NA-168VG3_English.indb 16 2011-1-24 11:25:06

Washing Instructions - 17
