Panasonic NA-FS16X3 User manual

Order No. PAPTH160201AE
Service Manual
Fully Automatic Washing Machine
Destination
UAE (Export),
Kuwait, Saudi Arabia
NA-FS16X3
NA-F150A3
Simplified
Product Colour
Stainless Colour (L)
White (W)
The service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt within this service information by anyone
else could result in serious injury or death.
WARNING
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do
not modify the original design without permission of manufacturer.
© Panasonic Appliances (Thailand) Co., Ltd. 2016.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
Please use this Manual together with the Service Manual Order No. PAPTH141101CE
Service NA-FS16X3,NA-F150A3.indd 1Service NA-FS16X3,NA-F150A3.indd 1 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Accessories
PARTS IDENTIFICATION
Drain hose
Pulsator
Lint filter
Lid
Tub
Operation Panel
Leveller
Softener case
Power cord and plug
Detergent inlet
Adjustable leg
●COLD
●HOT
Water supply valve
Water supply valve
For Middle East For Saudi Arabia
●Water supply hose
• Length: 1.0 m
●Water tap adaptor
●Drain hose
●Hose band
●Hose holder
●Screw
●Bottom cover
●Screw
- 2 -
Service NA-FS16X3,NA-F150A3.indd 2Service NA-FS16X3,NA-F150A3.indd 2 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

SPECIFICATIONS
Countries UAE (Export) KUWAIT SAUDI ARABIA
Model F150A3 F150A3 FS16X3 F150A3
(SRW) (WRU) (SRY) (WRY)
Model Code W9VY W9VY W9VW W9VX
Body Colour White White Stainless White
Code W W L W
Power cord unit S3 S3 S3
Rate voltage and Frequency 220 ~ 240V/50Hz 220V/60Hz
Rate Power Consumption Wash 540 W 540 W 530 W 470 W
Spin 310 W 310 W 200 W 360 W
Power Consumption 170 Wh (220V/50Hz)
180 Wh (240V/50Hz) 150Wh 180Wh
Standard Capacity Wash 15.0 Kg 15.0 Kg 16.0 Kg 15.0 Kg
Spin 15.0 Kg 15.0 Kg 16.0 Kg 15.0 Kg
Standard Consumption Water 96 Liter 96 Liter 99 Liter 96 Liter
Product Weight Accessories 48 Kg 48 Kg 49 Kg 48 Kg
Packing 53 Kg 53 Kg 54 Kg 53 Kg
Outer Dimention (mm.)
(WxDxH) Body 640X680X1074 640X680X1074 640X680X1074 640X680X1074
Installation 643X709X1074 643X709X1074 643X709X1074 643X709X1074
Pulsator with rated load (r.p.m.) 95 r / min
Spin Tub with rated load (r.p.m.) 630 r / min
Water Supply Pressure 0.01 to 1 MPa (0.1 to 10 Kgf / cm2) / 1.2 ~ 18 liter / min.
Motor Single-phase induction motor 135°C Three - phase induction motor
135 °C
Single - phase
induction motor
135 °C
Safety Switch Checking Unbalance
MR sensor Openlid detection during operation
Buzzer Rings when finishing washing or unusual
Detergent Case Dispenser Usable
Fabric Softener Dispenser Usable
Filter Unit Usable
Child Safety Usable
Auto Restart Usable
Auto Power Off Usable
- 3 -
Service NA-FS16X3,NA-F150A3.indd 3Service NA-FS16X3,NA-F150A3.indd 3 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

TECHNICAL INFORMATION
Standard Wash Capacity
PROGRAM MAXIMUM CAPACITY
NA-F150A3 NA-FS16X3
NORMAL 15.0 kg 16.0 kg
ENERGY SAVE (SPEEDY) 15.0 kg 16.0 kg
WETER SAVE 15.0 kg 16.0 kg
BABY-CARE (FOR MID-EAST) 15.0 kg -
FRAGRANCE 15.0 kg 16.0 kg
COMFORTER 4.2 kg 4.2 kg
POWER WASH + SOAK 15.0 kg 16.0 kg
TUB HYGIENE - -
GENTLE HAND WASH 2.5 kg 2.5 kg
AIR DRY 3.0 kg 3.0 kg
Note : -Normal course and Water Save course are recommended for a normally soiled load at the rated capacity of this
washing machine.
Standard Water Supply : Middle East
FOR NA-F150A3
PROGRAM TOTAL TIME WASH RINSE SPIN
(APPROX.)
NORMAL 60 min 12 min Refill 2 times 5 min
ENERGY SAVE (SPEEDY) 55 min 9 min Refill 2 times 5 min
WATER SAVE 80 min 12 min 3 times 5 min
BABY-CARE
75 min 12 min Refill 2 times 7 min
FRAGRANCE 85 min 12 min 2 times 5 min
BLANKET 75 min 12 min Refill 2 times 3 min
POWER WASH + SOAK 120 min
(Soak 60min)+12 min Refill 2 times 5 min
GENTLE HAND WASH 45 min 12 min Refill 2 times 1 min
TUB HYGIENE 150 min
(Soak 60min)+12 min Refill 2 times 7 min
Standard Water Supply : Saudi Arabia
FOR NA-FS16X3
PROGRAM TOTAL TIME WASH RINSE SPIN
(APPROX.)
NORMAL 60 min 12 min Refill 2 times 5 min
ENERGY SAVE (SPEEDY) 55 min 9 min Refill 2 times 5 min
GENTLE HAND WASH 45 min 12 min Refill 2 times 1 min
FRAGRANCE 85 min 12 min 2 times 5 min
BLANKET 80 min 12 min Refill 2 times 3 min
POWER WASH + SOAK 130 min
(Soak 70min)+12 min Refill 2 times 5 min
WATER SAVE 80 min 12 min 3 times 5 min
TUB HYGIENE 150 min
(Soak 60min)+12 min Refill 2 times 7 min
PROGRAM TOTAL TIME WASH RINSE SPIN
(APPROX.)
NORMAL 60 min 12 min Refill 2 times 5 min
ENERGY SAVE (SPEEDY) 55 min 9 min Refill 2 times 5 min
GENTLE HAND WASH 45 min 12 min Refill 2 times 1 min
FRAGRANCE 85 min 12 min 2 times 5 min
BLANKET 75 min 12 min Refill 2 times 3 min
POWER WASH + SOAK 130 min
(Soak 70min)+12 min Refill 2 times 5 min
WATER SAVE 80 min 12 min 3 times 5 min
TUB HYGIENE 150 min
(Soak 60min)+12 min Refill 2 times 7 min
Note : -Total time is approximate (When the standard water supply rate is 15 L / min).
-Total time may increase depending on low water pressure, bad draining conditions, and the amount and type of clothes.
FOR NA-FS16X3
- 4 -
Service NA-FS16X3,NA-F150A3.indd 4Service NA-FS16X3,NA-F150A3.indd 4 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

INSTALLATION
Connect.
Insert all the way.
Slide the hose band in the
arrow direction.
●Slide all the way until it stops.
Hose band
1. Check the location.
■Avoid the following locations for installation.
• Locations with a possibility of freezing
• Damp locations or locations where it may be
exposed to rain, etc.
(To prevent electric shock or fire)
• Locations exposed to direct sunlight
(To prevent malfunction or deformation)
• Uneven or unstable locations (on blocks,
timbers, a table with wheels, etc.)
2. Attach the bottom cover.
Insert the bottom
cover along the
guides.
Fix with 2 screws.
Screw
3. Attach the external drain water hose.
B
A
Water supply hose
Water tap adaptor
Bottom cover Drain hose
Elbow
Holes for the hose
holder
Water supply
valve screw
COLD
HOT
COLD HOT
AB
Water supply hose
Water tap adaptor Water supply valve screw
Bottom cover Drain hose
Elbow
Holes for the hose
holder
Hook the elbow of the drain hose
to the basin.
CAUTION
Make sure the drain hose is
securely hooked so that it does
not come off by water pressure
during drainage.
NOTE
●Do not twist, pull out or bend
the drain hose.
●Do not put the hose tip under
water.
●Do not direct the drain hose
downwards.
80 - 120 cm
Middle East Model
Saudi Arabia Model
- 5 -
Service NA-FS16X3,NA-F150A3.indd 5Service NA-FS16X3,NA-F150A3.indd 5 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

5. Connect the power plug and grounding wire.
●Ask a service person to do the grounding work.
●In case of a 2-pin power cord, establish a ground.
6. Check the washing machine is level.
The bubble should be at the
centre of the mark.
Leveller
Mark
Bubble
■If the bubble is out of the mark
3Turn to the right to
tighten.
1Turn the adjustable leg knob to
the left to loosen.
2Turn the adjustable
leg to eliminate
wobble.
To lowerTo raise
Perform a trial operation.
●Check that there is no water leakage, abnormal sounds or error display.
Connect the water tap adaptor to
the water faucet.
1Turn part A to the left until approx.
4 mm of the thread becomes
visible.
2Loosen the 4 screws.
3Connect to the faucet and tighten
the screws.
4Turn part A to the right and tighten
securely. (To prevent water
leakage)
Connect the water supply hose to
the water tap adaptor.
Insert the hose into the adaptor while
pushing down the lever, and hook
the claw of the lever on the flange of
the adaptor.
Connect the water supply hose to
the water supply valve screw.
1
Hold the elbow and tighten the nut.
2Check that the elbow is not loose.
Water faucet
Water supply hose
Water tap adaptor
CAUTION
●Tighten the nut firmly.
●Do not twist, squash, modify
or cut the hose.
Part A
Flange
Thread
Lever
Claw
Screw
Elbow
Water supply
valve screw
Nut
Water supply hose
For Saudi Arabia
For Middle East
4. Connect the water tap adaptor and water supply hose.
Water supply valve screw
Nut
Elbow
Water supply hose
COLD HOT CAUTION
●Do not make wrong connection
for the HOT and COLD water
supply faucets.
●Tighten the nut firmly.
●Do not twist, squash, modify or
cut the hose.
- 6 -
Service NA-FS16X3,NA-F150A3.indd 6Service NA-FS16X3,NA-F150A3.indd 6 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

OPERATION PANEL / MIDDLE EAST
NA-F150A3
Power Off/OnAir Dry Start/Pause
Program selection
Child Lock lamp
NOTE
●In case of a power failure during
operation, operation will resume from
the point where it was stopped when the
power is recovered (Auto Restart).
●The power turns off automatically if you
do not press “Start/Pause” within 10
minutes after power-on.
Change water
level
During the wash
process, press “Water
Level” to change the
water level.
●Some water levels
cannot be selected
depending on the
program.
●When the remaining
time is displayed,
press “Water Level”
to check the water
level.
Water level/water amounts
Level High
10-8
Mid
7-5
Low
4-2
Extra
Low
1
Detergent *
Water amount
(L) 96 88 81 74 66 59 52 46 38 33
* : 1 scoop of detergent
●Each water level, except “Extra Low”, has
three water amount options that can be
switched while the level is lit by pressing
“Water Level”.
Water level/remaining
time
After starting operation, indicates
the water level according to the
amount of laundry.
After approx. 5 seconds, indicates
the approximate remaining time
(min).
Change process
settings
Change the combination
of wash, rinse and spin
processes, and the time
length or number of times for
individual processes.
Flashing (in progress)
Lighted
●After starting operation,
you can change settings
only during wash process
by pressing “Start/Pause”.
Preset
Set the time to finish washing
(in hours). ( lights.)
e.g.) 8 hours later
●Setting range: 2 - 24
hours later, in one-hour
increments. (3 - 24 hours
later for the Power wash +
Soak program)
●Not available for the
following programs:
Gentle Hand Wash,
Fragrance, Blanket, Tub
Hygiene, Air Dry
- 7 -
Service NA-FS16X3,NA-F150A3.indd 7Service NA-FS16X3,NA-F150A3.indd 7 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

OPERATIONS PANEL / SAUDI ARABIA
Power Off/On
Air Dry Start/Pause Program selection
Child Lock lamp
Change water
level
During the wash
process, press “Water
Level” to change the
water level.
●Some water levels
cannot be selected
depending on the
program.
●Only during the wash
process, press “Water
Level” to check the
water level.
Water level/water amounts
Level High
10-8
Mid
7-5
Low
4-2
Extra
Low
1
Detergent *
Water amount
(L) 99 88 81 74 66 59 52 46 38 33
* : 1 scoop of detergent
●Each water level, except “Extra Low”, has
three water amount options that can be
switched while the level is lit by pressing
“Water Level”.
Water level/remaining time
After starting operation, indicates the
water level according to the amount
of laundry.
After approx. 5 seconds, indicates the
approximate remaining time (min).
ECONAVI lamp (P. 12)
NOTE
●In case of a power failure during operation, operation will resume from the point where it was stopped when the
power is recovered (Auto Restart).
●The power turns off automatically if you do not press “Start/Pause” within 10 minutes after power-on.
■Touch operation
●Operation buttons are capacitive (Except for the power Off/On and Start/Pause buttons). Touch the buttons
directly with your bare fingers.
●When a towel containing water or detergent touches an operation button, the appliance may malfunction.
Change process
settings
Change the combination
of wash, rinse and spin
processes, and the time
length or number of times
for individual processes.
Flashing (in progress)
Lighted
●After starting operation,
you can change settings
only during wash
process by pressing
“Start/Pause”.
Preset
Set the time to finish washing
(in hours). ( lights.)
e.g.) 8 hours later
●Setting range: 2 - 24
hours later, in one-hour
increments. (3 - 24 hours
later for the Power wash +
Soak program)
●Not available for the
following programs:
Gentle Hand Wash,
Fragrance, Blanket, Tub
Hygiene, Air Dry
Temp Setting
For washing, cold water can be mixed
with hot water. Press the button to select
Hot/Warm/Cold.
Do not use water hotter than 60 ºC.
● The estimated water temperature in
the tub during wash process (when
hot water is 50 ºC, and normal water
is 20 ºC):
Hot approx. 40 ºC
Warm approx. 30 ºC
● Lamp indications
Lighted: Hot/Warm/Cold is set.
Flashing: Hot water is being supplied.
● Not available for the following
programs: Gentle Hand Wash, Tub
Hygiene, Air Dry
NA-FS16X3
- 8 -
Service NA-FS16X3,NA-F150A3.indd 8Service NA-FS16X3,NA-F150A3.indd 8 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

NA-F150A3
Power Off/OnAir Dry Start/Pause Program selectionChild Lock lamp
NOTE
●In case of a power failure during operation, operation will resume from the point where it was stopped when the
power is recovered (Auto Restart).
●The power turns off automatically if you do not press “Start/Pause” within 10 minutes after power-on.
Change water
level
During the wash
process, press “Water
Level” to change the
water level.
●Some water levels
cannot be selected
depending on the
program.
●When the remaining
time is displayed,
press “Water Level”
to check the water
level.
Water level/water amounts
Level High
10-8
Mid
7-5
Low
4-2
Extra
Low
1
Detergent *
Water amount
(L) 96 88 81 74 66 59 52 46 38 33
* : 1 scoop of detergent
●Each water level, except “Extra Low”, has
three water amount options that can be
switched while the level is lit by pressing
“Water Level”.
Water level/remaining
time
After starting operation, indicates
the water level according to the
amount of laundry.
After approx. 5 seconds, indicates
the approximate remaining time
(min).
Change process
settings
Change the combination
of wash, rinse and spin
processes, and the time
length or number of times for
individual processes.
Flashing (in progress)
Lighted
●After starting operation,
you can change settings
only during wash process
by pressing “Start/Pause”.
Preset
Set the time to finish washing
(in hours). ( lights.)
e.g.) 8 hours later
●Setting range: 2 - 24
hours later, in one-hour
increments. (3 - 24 hours
later for the Power wash +
Soak program)
●Not available for the
following programs:
Gentle Hand Wash,
Fragrance, Blanket, Tub
Hygiene, Air Dry
Temp Setting
For washing, cold water can be mixed
with hot water. Press the button to select
Hot/Warm/Cold.
Do not use water hotter than 60 ºC.
● The estimated water temperature in
the tub during wash process (when
hot water is 50 ºC, and normal water
is 20 ºC):
Hot approx. 40 ºC
Warm approx. 30 ºC
● Lamp indications
Lighted: Hot/Warm/Cold is set.
Flashing: Hot water is being supplied.
● Not available for the following
programs: Gentle Hand Wash, Tub
Hygiene, Air Dry
- 9 -
Service NA-FS16X3,NA-F150A3.indd 9Service NA-FS16X3,NA-F150A3.indd 9 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

WASHING / MIDDLE EAST
Preparation:
●Check if the washing machine is properly installed.
●Turn on the water faucet.
1After loading laundry
Turn the power on.
●The Normal program is selected when the
power is turned on.
2Select a program.
■Timer preset
3Start.
The pulsator moves without
water and measures the amount
of laundry (approx. 5 seconds).
Water level indication
(approx. 5 seconds)
Remaining time indication
●To check the water level
Press “Water Level”.
4According to the water level indication
Put in detergent.
●Approx. 20 seconds after the water level is
displayed, water supply begins.
5Close the lid.
Operation ends with beeps.
Set how many hours later to finish
operation.
●2 minutes after start-up, all indications except
turn off.
●To confirm after the timer has been set, press
.
●To cancel or change, press .
●The hours that can be set differ depending on
the program.
When the Fragrance program is selected
The buzzer sounds before the final rinse and
operation is paused. Put the desired amount
of softener which has been diluted with water
directly into the tub.
5 beeps
●The Fragrance program cannot be selected
when Child Lock is set.
●Operation will resume if the lid is left closed for
more than 1 hour.
■After pressing “Start”
●You can change the water level until the end of
the wash process.
●You can change each of the “Wash”, “Rinse”
and “Spin” operation contents until the end of
the wash process. Press “Pause” beforehand.
●You cannot change the program.
2
3
Timer preset 1
- 10 -
Service NA-FS16X3,NA-F150A3.indd 10Service NA-FS16X3,NA-F150A3.indd 10 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

WASHING / SAUDI ARABIA
Preparation:
●Check if the washing machine is properly installed.
●Turn on the water faucet.
●When using Temp Setting, turn on both hot and cold water faucets.
1After loading laundry
Turn the power on.
●The Normal program is selected when the
power is turned on.
2Select a program.
■Temp Setting
■Timer preset
3Start.
The pulsator moves without
water and measures the
amount of laundry
(approx. 10 seconds).
Water level indication
(approx. 5 seconds)
Remaining time indication
●To check the water level
→Press “Water Level”.
4According to the water level indication
Put in detergent.
●Approx. 20 seconds after the water level is
displayed, water supply begins.
5Close the lid.
Operation ends with beeps.
Set how many hours later to finish
operation.
●2 minutes after start-up, all indications except
turn off.
●To confirm after the timer has been set, press
.
●To cancel or change, press .
●The hours that can be set differ depending on
the program.
When the Fragrance program is selected
The buzzer sounds before the final rinse and
operation is paused. Put the desired amount
of softener which has been diluted with water
directly into the tub.
5 beeps
●The Fragrance program cannot be selected
when Child Lock is set.
●Operation will resume if the lid is left closed for
more than 1 hour.
■After pressing “Start”
●You can change the water level until the end of
the wash process.
●You can change each of the “Wash”, “Rinse”
and “Spin” operation contents until the end of
the wash process. Press “Pause” beforehand.
●You cannot change the program.
Press to select Hot/Warm/Cold for
washing.
Hot ←Warm ←Cold
23
Timer preset
Temp setting
1
- 11 -
Service NA-FS16X3,NA-F150A3.indd 11Service NA-FS16X3,NA-F150A3.indd 11 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

WIRING OPTIONS
ECONAVI
Available in the Normal program, this function
automatically adjusts the operation time and water
level according to the detected amount of laundry
and water temperature.
ECONAVI will not work if you change the water
level or process settings.
■Lamp indications
• Flashing: Detecting
• Lighted: ECONAVI enabled
• Unlit: ECONAVI disabled
■Switch on/off
1
2
3Press and hold for 3 seconds
4to select (On) or (Off)
56 beeps
* Test conditions:
• Normal program
• Comparison between ECONAVI-enabled operation (amount
of laundry: 4.0 kg, water temperature: above 35 ºC) and
ECONAVI-disabled operation (amount of laundry: 16.0 kg
(rated capacity), water temperature: below 15 ºC)
• Test was conducted based on IEC60456 except for water
temperature.
Gentle Hand Wash
Use this program to gently wash delicate clothes and
stylish garments.
Attach the washing board.
Load the laundry.
Load laundry evenly.
●Load lighter items first and press
them from above.
●Use laundry nets for delicate
underwear only.
●Amount that can be washed at
one time:
Water Level Capacity
46 L 2.5 kg
38 L 1.2 kg
NOTE
●Do not use bleach.
●Use liquid delicate detergent.
●After operation ends, take out clothes immediately.
(To prevent wrinkles and colour staining)
1) Double up the
board and put it
in the base.
2) Align the
position
and open
the board.
Blanket
■Washable blankets
• Material: 100 % synthetic fibre or 100 % cotton
• Weight: 4.2 kgor less
• Blankets with a machine-washable tag attached
●Put a blanket in the net and load it in the tub.
Roll
●The zipper part
should face up.
(To prevent
damage to the
net)
NOTE
●Use liquid detergent.
●The water level indication shows the maximum and
cannot be changed.
●Set the claws (4 places) securely.
3) Press the board circumference and fix it.
- 12 -
Service NA-FS16X3,NA-F150A3.indd 12Service NA-FS16X3,NA-F150A3.indd 12 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

WIRING DIAGRAM
1$)6;
1$)$
- 13 -
Service NA-FS16X3,NA-F150A3.indd 13Service NA-FS16X3,NA-F150A3.indd 13 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

PARTS EXPLODED VIEW AND REPLACEMENT PARTS LIST
Parts Explode View : A
A3
A4
A5
A4
A2.1
A17
A18
A19
A11
A14
A12
A13
A10
A10
A16
A15
A20
A21
A24
A22
A23
A5.1
A6
A6
A7
A7
A8 A9
A2
A1
- 14 -
Service NA-FS16X3,NA-F150A3.indd 14Service NA-FS16X3,NA-F150A3.indd 14 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Replacement Parts List
Part List - Part A
Safety Ref.
No. Part Name Part No.
UAE(EXP) Kuwait Saudi Arabia
Remark
F150A3 F150A3 FS16X3 F150A3
A1 BODY B AXW01028XT0W 11 WHITE
AXW01029PN0L 1WHITE/HOT WATER
AXW01029PN0W 1STAINLESS COLOUR/HOT WATER
A2 PANEL FACE B AXW01469VY00 11 ENGLISH/ARABIC
AXW01469VW00 1ENGLISH/ARABIC
AXW01469VX00 1ENGLISH/ARABIC
A2.1 PANEL FACE F AXW01509MG00 1
A3 PANEL FACE D AXW01488XT10 11 1
A4 PANEL FACE E AXW01498XT10 11 1
AXW01499MG10 1
A5 PANEL FACE A UNIT AXW001J9VW00 1FOR X3 SERIES
A5.1 PANEL FACE C AXW01478XT00 11 1 FOR A3 SERIES
A6 CONTROLLER UNIT AXW024C9VY06 11
AXW024C9VW04 1ECONAVI
AXW024C9VX04 1
A7 INSULATION SPACER A AXW04868XT00 11 1
AXW04869MG00 1
A8 PANEL A AXW01308XT0W 11 1 WHITE
AXW01309MG0L 1STAINLESS COLOUR
A9 LOCATING INSTRUCTION D AXW99629VY00 11 ARABIC
AXW99629VW00 11 ARABIC/HOT WATER
A10 LID HINGE SPRING AXW11168XT00 1111 RIGHT
AXW11168XT50 1111 LEFT
A11 LEVELLER AXW03536NA10 1111
A12 SOAP CASE B AXW21518XT1W 11 1 WHITE
AXW21518XT1L 1STAINLESS COLOUR
A13 ANTIFREEZE INSTRUCTION B AXW99599CR0W 11 1 ARABIC/WHITE
AXW99599CR0L 1ARABIC/STAINLESS COLOUR
A14 SOAP CASE LID AXW21928XT0W 11 1 WHITE
AXW21928XT0L 1STAINLESS COLOUR
A15 PANEL A BACK COVER AXW01388XT10 11
AXW01389PN00 11
A16 SOAP CASE PACKING AXW21647EC00 2222 COLD WATER
AXW21647EC00 11 HOT WATER
A17 PRESSURE SENSOR UNIT AXW024T04400 1111
A18 SUB DRAIN HOSE UNIT AXW002Q9MG00 1111
A19 SAFETY SWITCH A AXW166125000 1111
A20 FEEDING VALVE AXW292126716 1111
COLD WATER
A21 CONNECTOR LEAD WIRE
UNIT
AXW014A9PG10 11 A3 SERIES
AXW014A9VW00 1A3 SERIES/HOT WATER
AXW014A9PP10 1X3 SERIES/HOT WATER
A22 LID UNIT AXW001G8XT0W 11 1 WHITE
AXW001G8XT0L 1STAINLESS COLOUR
A23 LID HINGE SHAFT AXW01937JS00 2222
A24 SENSOR UNIT AXW024N09410 1111 BODY B
A25 FEEDING VALVE AXW292126606 11 HOT WATER
Screws
Safety Ref.
No. Part Name Part No.
UAE(EXP) Kuwait Saudi Arabia
Remark
F150A3 F150A3 FS16X3 F150A3
SPECIAL TAPPING SCREW XTWAXW469J 4444 BODY B~BODY AU
BINDING TAPPING SCREW XTB4+12CFJ 4444
LID UNIT
XTB4+15CFJ 6676 CONTROLLER HOLDER~PANEL A
XTB4+15CFJ 2222
PANEL A BACK COVER~SAFETY SW.
XTB4+15CFJ 4444 PANEL A~BODY B
XTB4+15CFJ 6666 PANEL A BACK COVER~BODY B
XTB4+15CFJ 2222
PANEL A BACK COVER~FEEDING VALVE
XTWAXW435 22 FEEDING VALVE HOT WATER
- 15 -
Service NA-FS16X3,NA-F150A3.indd 15Service NA-FS16X3,NA-F150A3.indd 15 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Parts Explode View : Part B
Accessories
B7B6 B25
B16
B24 B15
B26
B3
B5
B4
B4
B4
B20
B18
B17
B2
B22
B9
B12
B11
B10
B13
B2
B19
B21
B24
B23 B21
B19
B1
B20
B14
B8
(FOR NA-FS16X3)
(FOR NA-F150A3)
- 16 -
Service NA-FS16X3,NA-F150A3.indd 16Service NA-FS16X3,NA-F150A3.indd 16 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Replacement Parts List
Part List - Part B
Safety Ref.
No. Part Name Part No. UAE(EXP) Kuwait Saudi Arabia Remark
F150A3 F150A3 FS16X3 F150A3
B1 BODY A UNIT AXW001A8XT2W 1 1 1 WHITE
AXW001A8XT2L 1 STAINLESS COLOUR
B2 GRIP AXW01107JP1W 1 1 1 WHITE
AXW01107JP1L 1 STAINLESS COLOUR
B3 BASE A AX’W03019VY00 1 1 1 1
B4 LEG COVERING AXW03397JS00 1 1 1 1
B5 ADJUSTABLE LEG UNIT AXW003D8XT00 1 1 1 1
B6
SERVICE PRESSURE HOSE UNIT AXW012D8AR00 1 1 1 1 SAUDI ADD HOT WATER
B7 BOTTOM COVER AXW21588XT00 1 1 1 1
B8 BACK PANEL AXW01568XT20 1 1 1 1
B9 POWER CORD UNIT -S3 AXW004A772E4 1 1 1 1
B10 COIL BOX AXW45519MG00 1
B11 COIL UNIT AXW034L9MG06 1
B12 NOISE REDUCER AXW243004900 1
B13 COIL BOX PLATE AXW45529MG00 1
B14 CHEMICAL COVER AXW04487EC10 1 1 1
W0448-9MG00 2
B15 FLEXIBLE HOSE A UNIT AXW002D6RJ00 1 1 1 1
B16 HOSE BAND AXW02456RJ10 1 1 1 1
B17 CAPACITOR AXW04037V807 1 1 14F
AXW04037P957 1 12.5F
B18 NAME PLATE AXW01539VY00 1 1
AXW01539VW00 1
AXW01539VX00 1
B19 BODY A PROTECTION AXW90468AR10 4 4 4 4 t30x50x50/HARD TYPE
B20 BODY A PROTECTION AXW90468XT50 2 2 3 2 t20x50x50/SOFT TYPE
B21 BODY A PROTECTION AXW90467JP50 1 1 1 1 t1x70x240
B22 BODY A PROTECTION AXW90466AA6M 2 2 2 2 t1x70x120
B23 SPINNER LID LABEL AXW11179CR0W 1 1 ENGLISH/ARABIC
AXW11179PN0L 1 ENGLISH/ARABIC
AXW11179PN0W 1 ENGLISH/ARABIC
B24 PUMP UNIT AXW008C9CR56 1 1 50Hz
AXW008C9CR06 1 1 60Hz
B25 HOSE SUPPORTER AXW02796RJ10 1 1 1 1
B26 OVER FLOW FILTER A AXW02769VY00 1 1 1 1
Screws
Safety Ref.
No. Part Name Part No. UAE(EXP) Kuwait Saudi Arabia Remark
F150A3 F150A3 FS16X3 F150A3
SPECIAL TAPPING SCREW XTTAXW444J 11 11 11 11 BASE A
XTTAXW444J 4 4 4 4 BACK PANEL
XTTAXW444J 1 1 1 1 HOSE SUPPORTER
XTTAXW444J 1 1 1 1 BOTTOM COVER
XTWAXW471 3 3 3 3 PUMP UNIT
PAN HEAD TAPPING SCREW XTN4+8HFJ 1 1 1 1 EARTH U~BODY A
XSN4-W10FJ 1 1 1 CAPACITOR
- 17 -
Service NA-FS16X3,NA-F150A3.indd 17Service NA-FS16X3,NA-F150A3.indd 17 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Parts Explode View : Part C
C1
C7
C32
C15
C29
C28
C30
C26
C26
C15
C18
C31
C8
C21
C23
C27
C6
C25
C24
C19
C20
C15
BLACK
BLACK
GREEN
GRAY
C22
C15
C16
C3
C2
C5
C4
(For X3)
(For A3)
C12
C13
C17
C14
C9
C11
C10
- 18 -
Service NA-FS16X3,NA-F150A3.indd 18Service NA-FS16X3,NA-F150A3.indd 18 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Replacement Parts List
Part List - Part C
Safety Ref.
No. Part Name Part No. UAE(EXP) Kuwait Saudi Arabia Remark
F150A3 F150A3 FS16X3 F150A3
C1 OUTER TUB COVER AXW32248XT10 1 1 1 1
C2 O-RING AXW02577BK00 1 1 1 1
C3 PULSATOR UNIT AXW05018XW00 1 1 1 A3 SERIES+F115X1P/WHITE
PULSATOR AXW005D8XT00 1 X3 SERIES/STAINLESS COVER
C4 SCREW CAP AXW21118XW00 1 1 1 A3 SERIES/WHITE
AXW21118XT00 1 X3 SERIES/STAINLESS COVER
C5 SHAFT BUSHING AXW05046ZR00 1 1 1 1
C6 SPINNER SHAFT FLANGE NUT AXW15176RU20 1 1 1 1
C7 SPINNER FLANGE WASHER B AXW151980200 1 1 1 1
C8 BALANCER UNIT AXW035A8XT30 1 1 1 1
C9 TUB B AXW02029MG00 1 1 1 1
C10 FILTER UNIT AXW022A8AR1W 1 1 1 1
C11 TUB E UNIT AXW012V9MG00 2 2 2 2
C12 TUB C UNIT AXW012U9MG00 1 1 1 1
C13 SLOT AXW11988XT00 1 1 1 1
C14 TUB UNIT AXW002A9MG00 1 1 1 1
C15 SUSPENSION UNIT AXW034U9MG00 1 1 1 1 FRONT/LEFT,GRAY
AXW034U9MG50 2 2 2 2 FRONT/RIGHT,REAR/LEFT,BLACK
AXW034U9MGA0 1 1 1 1 REAR/RIGHT,GREEN
C16 OUTER TUB A AXW12019MG00 1 1 1 1
C17 OUTER TUB B AXW12028XT00 1 1 1 1
C18 MOTOR WASHER A AXW04207JS10 2 2 2
AXW04209MG00 2
C19 MOTOR AXW04015B506 1 1 1
AXW04015C108 1
C20 MOTOR WASHER B AXW04217BK20 1 1 1
AXW04219MG00 1
C21 MOTOR PULLEY UNIT AXW004G9MG00 1 1 1 1
C22 V-BELT AXW041219860 1 1 1 M-19.8”/50HZ
AXW04129PN50 1 M-21.0”/60HZ
C23 SPINNER PLATE B AXW32328XT00 1 1 1 1
C24 HOSE A AXW02479CR00 1 1 1 1
C25 EARTH WIRE UNIT AXW003F9MJ00 1 1 1 INTERNAL EARTH
AXW003F9MG00 1 INTERNAL EARTH
C26 HOSE BAND AXW024552410 2 2 2 2 DRAIN PIPE-HOSE A/HOSE A-PUMP
C27 MACHA-CASE UNIT AXW020A9MG00 1 1 1
AXW020A9VW00 1
C28 VALVE ROD A AXW093259U5M 1 1 1 1
C29 VALVE SPRING A AXW092259U0A 1 1 1 1
C30 DRAIN PIPE AXW32229CR00 1 1 1 1
C31 GEARED MOTOR AXW348204506 1 1 1 1
C32 LEAD WIRE UNIT AXW014B9MJ00 1 1 1 GEARED MOTOR
AXW014B-9MG00 1 GEARED MOTOR
Screws
Safety Ref.
No. Part Name Part No. UAE(EXP) Kuwait Saudi Arabia Remark
F150A3 F150A3 FS16X3 F150A3
SPECIAL TAPPING SCREW XTWAXW523 8 8 8 8 TUB A-TUD
PAN HEAD TAPPING SCREW XTN4+8HFJ 1 1 1 1 EARTH U~OUTER TUB B
SPECIAL SMALL SCREW XSSAXW682 1 1 1 1 PULSATOR UNIT
SPECIAL BOLT XVGAXW703J 1 1 1 1 MOTOR PULLEY
XVGAXW839J 2 2 2 2 MOTOR
XVGAXW840J 4 4 4 4 MECHA CASE~OUTER TUB B
SPECIAL TAPPING SCREW XTWAXW6517J 7 7 7 7 OUTER TUB A~B
XTWAXW6517J 4 4 4 4 SPINNER PLATE B
XTWAXW6518J 3 3 3 3 GEARED MOTOR (CLUTCH)
XTWAXW531 4 4 4 4 BALANCER U~TUB
- 19 -
Service NA-FS16X3,NA-F150A3.indd 19Service NA-FS16X3,NA-F150A3.indd 19 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM

Parts Explode View : Packing
Accessories
7
9
8
11
4
2
5
Fully Automatic
Washing Machine
Fully Automatic
Washing Machine
THIS PART USE FOR PACKING,
NOT PART OF PRODUCT.
1
10
6
3
- 20 -
Service NA-FS16X3,NA-F150A3.indd 20Service NA-FS16X3,NA-F150A3.indd 20 3/17/2559 BE 10:23 AM3/17/2559 BE 10:23 AM
