Pandigital PAN7000DW User manual

Digital Photo Frame
User Guide
PAN7000DW and PAN9000DW
Effortlessly Moving Images Out of your Camera and Into your Life

2
Sign up now to enjoy the following benefits…
Qualify to win a FREE
digital photo frame!*
(valid in USA only)
Register your FREE
1-year warranty!**
*For details, go to our website: www.pandigital.net
**The online signup is for the purpose of user and product registration. Failure to register
does not in any way diminish any of your standard warranty rights, as described in the
documentation included with your product.
NOTE: If you must mail your 1-year registration, please send your name, address,
phone number, model & serial number, and when & where purchased to:
Pandigital, P.O. Box 2969, Dublin, CA 94568-2969 USA
Note: Your frame style and features may differ from those documented in this User Guide.
UG-E_PAN7000DW_PAN9000DW_V1.13_06-09
1
Year
Sign up now at…
http://www.pandigital.net

3
Table of Contents
Introduction..................................................................................................5
DPF Key Features...................................................................................................5
Overview of the DPF ....................................................................................6
Remote Control............................................................................................6
Control Buttons on DPF ..............................................................................8
Getting Started.............................................................................................9
The HOME Screen........................................................................................9
Setup Menu Overview................................................................................10
About Selecting Options ...........................................................................11
Select Media Source ..................................................................................11
PHOTOS......................................................................................................12
Photo Thumbnails..................................................................................................12
View Individual Photo during a Slideshow.............................................................13
Zoom or Rotate Photos .........................................................................................13
Adjust Screen Colors.............................................................................................14
Optimal Image Display ..........................................................................................14
Photo Import Method.............................................................................................14
Display Current Time with Photos .........................................................................15
Display Photo File Date/Time Stamp with Photos .................................................15
Import Photos into Internal Memory.......................................................................15
Delete Photos from Internal Memory.....................................................................16
PHOTO SLIDESHOWS ...............................................................................17
Slideshow of Photos in Internal Memory ...............................................................17
Slideshow of Photos on your Media Source..........................................................17
Pause a Slideshow................................................................................................17
Slideshow Folders.................................................................................................18
Slideshow Background Music................................................................................19
Set Slideshow Music Mode ...................................................................................19
Set Slideshow Interval...........................................................................................20
Set Slideshow Transition.......................................................................................20
Set Slideshow Shuffle............................................................................................21
MUSIC .........................................................................................................21
Select Media Source for Music..............................................................................21
Playing Music Only................................................................................................21
Music Repeat Mode...............................................................................................22
Import Music Files into Internal Memory................................................................22
Delete Music Files from the Internal Memory ........................................................23

4
VIDEOS .......................................................................................................23
Select Media Source for Videos ............................................................................23
Watch a Video.......................................................................................................24
Video Repeat Mode...............................................................................................24
Import Video Files into Internal Memory................................................................24
Delete Videos from the Internal Memory ...............................................................25
CALENDAR/CLOCK ...................................................................................26
Select Media Source for Calendar Slideshow........................................................26
Set Schedule.........................................................................................................26
Disable Schedule...................................................................................................27
Run the Schedule..................................................................................................27
Run Schedule from Slideshow..........................................................................28
Run Schedule from CALENDAR/CLOCK Screen.............................................28
Set Date and Time.................................................................................................28
Set Alarm...............................................................................................................28
Wi-Fi............................................................................................................29
Set up DPF to connect to Photo Sharing Websites...............................................30
The Virtual Keyboard.............................................................................................30
Set up Wireless Network .......................................................................................31
Windows Live FrameIt...........................................................................................33
Photo Sharing Websites........................................................................................36
DPF to PC – Wireless Connection ............................................................38
DPF to PC – USB Connection....................................................................39
USB Flash Drive to DPF Connection ........................................................42
Bluetooth Connection ...........................................................................43
Set Sleep Mode...........................................................................................44
Set Language .............................................................................................44
Reset to Factory Defaults..........................................................................44
Connect Speakers or Headphones to DPF...............................................45
Frequently Asked Questions.....................................................................45
Important Safety Precautions ...................................................................47
Technical Specifications ...........................................................................48
Limited Warranty........................................................................................49
FCC Statement ...........................................................................................50

5
Introduction
Welcome to the Pandigital Multimedia Digital Photo Frame (DPF). Now
you can display your digital photos directly from your memory card, no
computer is necessary.
DPF Key Features
Simple Plug & Play
Displays digital Photo files (JPEG up to 16 mega pixels)
Plays digital Music files (MP3)
Plays digital Video files (AVI)
Displays Calendar/Clock with photo slideshow and Alarm function
Wi-Fi connect to photo sharing websites and DPF-PC file
transfer
Does not require a computer
Infrared Remote Control and control buttons on the frame
1GB Internal Memory
2 USB2.0 ports (Device & Host)
Compatible Memory Cards
Compatible memory cards include: Secure Digital™ (SD), Compact
Flash (select models), MultiMedia Card™(MMC), xD Card, Memory
Stick™(MS), MemoryStick Pro™, and Memory Stick Pro Duo™*
*The Memory Stick Pro Duo™ requires an
additional adaptor to fit properly into the DPF
(not included). You can purchase the adaptor at
retail outlet stores that sell memory cards.
What’s in the Box
Digital Photo Frame (DPF)
AC Power Cord and Adapter
Infrared Remote Control
White and Charcoal Decorative Paper Mats
USB Cable
Quick Start Guide, User Guide

6
Overview of the DPF
(The memory card slots, ports, and jacks in your DPF may be different than those pictured here.)
Remote Control
You can access all of the DPF’s features, and perform all of the functions
by using the remote control. You will be able to perform several functions
with the remote control that are not possible with the top-back panel
control buttons.
Note: Before first time use, pull the plastic tab sticking
out of the remote control. It protects the battery
and the remote control will not work unless it is
removed.
USB Host
Memory cards
slot
MENU EXIT ENTER
Right arrow Left arrow
Magnetized area
for storing
Remote Control
Mini USB Device
Brightness
control
Power ON/OFF
DC
power jack
Audio-out jack
A
djustable
stand

7
Overview of Remote Control
Safely Store Remote Control
You can avoid misplacing the remote control by safely storing it on
the back of the DPF when not in use.
The top back of the remote control has a built-in magnet and the
back of the DPF has a ‘magnetic area’ so you can simply attach the
remote control to the back of the DPF for safe keeping.
TIP: Remove sticker before use.
Exit or go back
Scroll Up
Scroll Previous
Play/Pause/Select object
Volume - adjust lower
or De-select object Enlarge image
Access Setup screens
Scroll Forward
Scroll Down
Volume adjust higher
or Select object Rotate image
Start Slideshow

8
Replace the Remote Control Battery
1. Hold the remote control with the buttons facing down.
2. Push and hold the small release tab while pulling the
battery tray out.
3. Replace the “CR2025” Lithium battery on the tray with
the positive (+) side facing up.
4. Push the tray back in until it clicks into place.
Control Buttons on DPF
You can perform many (but not all) of the DPF functions by using the
control buttons located on the top-back panel of the DPF. Their basic
functions are the same no matter when you use them.
TIP: The instructions throughout this User Guide only reference
the use of the remote control. However, you can use the
frame control buttons when the , ENTER, EXIT, and
MENU buttons are referenced when desired.
Button Action
Scroll left
ENTER Select the highlighted option, start a Slideshow, Play and Pause
Scroll right
EXIT Exit the current display, or go back a screen
MENU Displays function setup screens
Release tab

9
Getting Started
1. Plug the AC Power Adapter into the DPF’s DC power jack and an
electrical wall outlet.
2. Slide the power button on the left side of the DPF up to the ON
position.
3. If prompted, select the desired language for the user interface
display (varies by model).
4. After the initial start up screen is displayed, a slideshow will
automatically begin displaying the photos that are stored in the
internal memory.
5. To view your own photos, insert a memory card or USB flash drive
containing your photos into the appropriate slot/port on the DPF.
Press ENTER on Start Slideshow.
CAUTION:The cards and USB flash drive will only fit in one direction; do not
force them as this will damage the card reader or USB port.
The HOME Screen
The five main DPF features, PHOTOS, MUSIC, VIDEO, CLOCK, and
Wi-Fi are accessed from the HOME screen.
To access the HOME screen while a slideshow is playing, press MENU.

10
PHOTOS
Display your photo files (.JPG or .JPEG) individually or as
slideshows. PHOTOS-Manage: set viewing preferences,
assign photos to category folders, import and delete photo
files (page 12)
MUSIC Play your MP3 music files. MUSIC-Manage: set listening
preferences, import and delete music files (page 21)
VIDEO Play your AVI video files. VIDEO-Manage: set viewing
preferences, import and delete video files (page 23)
Clock View clock and calendar with photo slideshow, and manage
the calendar, clock, and alarm settings (page 26)
Wi-Fi With the Pandigital Wi-Fi USB adapter (sold separately) you
can connect wirelessly for access to on-line photo sites
(page 29) and to your PC for file transfer (page 38)
Edit Quick access to single photo manage mode for Zooming,
Rotating, or Deleting currently displayed photo.
Setup Menu Overview
Use the Setup Menu for DPF functions to optimize your viewing
preferences.
On the HOME screen press MENU to display the Setup Menu screen.

11
Select Media
Source Select the media source for current viewing or
listening (page 11)
Wi-Fi Network
Setup Set up wireless network to which you want to
connect (page 31)
Slideshow Setup Set multiple slideshow functions to optimize your
viewing preferences (page 17)
Adjust Screen
Colors Adjust LCD screen settings as desired (page 14)
Optimal Image
Display Set photos to display as actual photo size, or
optimized to best fit the screen (page 14)
Photo Import
Method Set photos to be imported compressed or
original resolution and file size (page 15)
Set Sleep Mode Power saving function (page 44)
Reset to Factory
Defaults Returns all function settings to the factory
defaults (page 44)
Set Language Select desired DPF display language (page 44)
System Upgrade For firmware upgrades
About Selecting Options
Throughout this User Guide, when you are instructed to ‘select’ a function
option or button, unless otherwise instructed, use to highlight [the
referenced option], and then press ENTER to select.
Select Media Source
If you have inserted one or more external media sources (i.e., memory
card, USB flash drive), you can use the Select Media Source function to
switch between the internal memory and your external media source for
viewing your photos, videos, or listening to music.

12
You will also use this function to view the contents of the Slideshow
Folders after you assign photos to these folders (page 18).
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Select Media Source, and then select the desired media source
(sources not present will not be available).
Internal Memory = Built-in flash memory
SD/MMC = Secure DigitalTM / Multi MediaTM card
MS = Memory StickTM (Standard, Pro, and Duo)
xD = Standard flash memory card
CF = Compact Flash (not available in this model)
USB = Standard USB flash drive
Slideshow Folders = View photos after assigning to folders (page 18)
3. The Photo Thumbnails or Slideshow Folders selection screen will
be displayed.
PHOTOS
The PHOTOS feature includes many functions for optimizing and
customizing your viewing preferences. You can view your photos
individually or as slideshows with or without background music. Other
optional functions allow you to display the current time with your images,
adjust the screen colors, choose slideshow transitions, and even
schedule slideshows according to your weekly schedule.
Photo Thumbnails
1. On the HOME screen, select the PHOTOS-Manage button.

13
2. Use to scroll through individual photos, or use the
Page Up/Page Down arrows to scroll full pages.
3. To view an individual photo full screen, press ENTER on the
highlighted photo.
4. While the photo is displayed, you can use to view the
next/previous photos.
5. Press
EXIT to return to the previous screen.
View Individual Photo during a Slideshow
1. With the desired photo displayed, press EXIT to pause the
slideshow.
2. The photo will be displayed approximately 15 seconds and then
the slideshow will automatically resume, or you can press ENTER
or SLIDESHOW to resume the slideshow.
Zoom or Rotate Photos
You can temporarily magnify or rotate photos while viewing them in
single photo view. The rotation of a photo will be saved only for
photos in the internal memory.
Zoom or Rotate a photo during a slideshow
1. With the photo displayed that needs rotating, press ZOOM
or ROTATE, multiple times if necessary, to achieve the
desired view.
2. Press
SLIDESHOW to resume the slideshow.
Zoom or Rotate a photo from the Photo Thumbnails screen
1. On the HOME screen, select the PHOTOS-Manage button.
2. On the
Photo Thumbnails screen, press ENTER to select
the desired photo to be magnified or rotated, and then press
ZOOM or ROTATE multiple times if necessary to achieve the
desired view.
3. Press
EXIT to return to the Photo Thumbnails screen.

14
TIP: When a photo is zoomed, you can pan around the photo by
using to view portions of the photo that are not
currently visible.
Adjust Screen Colors
You can adjust the four LCD color levels for optimal image viewing.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Adjust Screen Colors.
3. Use to scroll through the LCD options, and use to
adjust the setting until the desired view is achieved.
4. Use to select Done.
5. Press
EXIT to return to the previous screen.
TIP: You can also adjust the brightness with the dial on the left side of
the DPF.
Optimal Image Display
You can choose the desired display mode for displaying your photos
on the DPF as follows:
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Optimal Image Display, and then select the desired
setting.
Original = Displays photos in actual photo size
Optimal (default) = Optimizes the size and resolution to best fit the screen,
which may result in part of a photo not being visible on the screen.
3. Press EXIT to return to the previous screen.
Photo Import Method
When importing files into the internal memory from an external media
source, the file can be optimized or left as the original file size and
resolution.
1. On the
HOME screen, press MENU to display the Setup Menu.

15
2. Select Photo Import Method, and then select the desired
setting.
Optimized (default) = The photo file is downscaled in size and compressed
into a smaller sized JPEG, allowing more photos to be stored in the internal
memory.
Original = The photo file is stored keeping its original size and resolution
3. Press EXIT to return to the previous screen.
Display Current Time with Photos
You can have the current time displayed with your photos if desired.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Slideshow Setup, and then select Yes or No under
‘Display current time with photos?’.
3. Select
Done.
4. Press
EXIT to return to the previous screen.
TIP: If the time is incorrect, refer to Set Date and Time on page 28
to set the clock.
Display Photo File Date/Time Stamp with Photos
Most digital cameras typically include a Date/Time stamp when
saving photo files. If your photo files contain this Date/Time
information, you can have it displayed with your photos if desired.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Slideshow Setup, and then select Yes or No under
‘Display photo file date/time stamp?’.
3. Select
Done.
4. Press
EXIT to return to the previous screen.
Import Photos into Internal Memory
You can import your photo files from external media sources (i.e.,
memory card, USB flash drive) into the DPF’s internal memory. The
number of photo files you can import depends on file size and
available memory.

16
TIP: After starting an import, you can press EXIT to cancel the
import operation.
Import All Photos into Internal Memory
1. Insert your media source into the DPF. The memory card
option screen will be displayed.
2. Select
Import All Photos.
3. When import is complete, press EXIT to return to the
previous screen.
Import Individual Photos into Internal Memory
1. Insert your media source into the DPF. The memory card
option screen will be displayed.
2. Select
Select Photos to Import.
3. Use to scroll through the photos, and then press
‘+’ to select the desired photos to import (‘-‘ will deselect).
4. Press
MENU, and then select Import Selected Photos.
5. Press
EXIT to return to Photo Thumbnails screen.
Delete Photos from Internal Memory
You can delete photo files from the DPF’s internal memory, but not
from an external media source (i.e., memory card, USB flash drive).
Be sure you have Internal Memory as your selected media source.
TIP: It is recommended to make backup copies of the photos
before you delete them from the DPF.
1. On the
HOME screen, select the PHOTOS-Manage button.
2. To delete all photos, press MENU, and then select Delete All.
To delete individual photos, use to highlight the
photos you want to delete, press ‘+’ to select (‘-‘ will deselect),
press MENU, and then select Delete Selected.
3. A confirmation message appears; select Yes to delete the
photos, or No to keep the photos in the internal memory.
4. Press
EXIT to return to Photo Thumbnails screen.

17
TIP: If you select Yes by mistake, press EXIT to cancel the delete
operation. Photos already deleted will not be automatically
restored.
PHOTO SLIDESHOWS
The DPF can display all of the photos on the selected media source as a
slideshow, or you can select specific photos for a custom slideshow. You
can also have background music with your slideshows simply by storing
music MP3 files on your selected media source.
Slideshow of Photos in Internal Memory
You can play a slideshow of the photos stored in the DPF’s internal
memory by simply powering on the DPF (with no external media
source or wireless Wi-Fi adapter inserted*)and then wait for the
slideshow to automatically begin.
Slideshow of Photos on your Media Source
Insert an external media source and then power on the DPF; the
slideshow will begin displaying your photos (with no wireless Wi-Fi
adapter inserted*).
If you insert a media source after power on, a memory card option
screen is displayed; select Start Slideshow.
*If you have a Wireless Wi-Fi Adapter inserted in the DPF, and you
have previously connected with a wireless network, a message will
be displayed asking if you want to connect to the wireless network
at this time. If you select Yes, the DPF will connect to the network
and the Network options screen will be displayed. If you select No,
the HOME screen will be displayed; press Slideshow or wait
approximately 15 seconds for the slideshow to begin. (If no photos
exist on media source, the HOME screen will remain displayed.)
Pause a Slideshow
To pause a slideshow press EXIT. The slideshow will pause for
approximately 15 seconds, and then the slideshow will automatically
resume. To resume immediately, press ENTER or SLIDESHOW.

18
Slideshow Folders
There are five category folders in the internal memory into which you
can assign photo files for personalized organization and slideshows
(these folder names cannot be changed):
Family – Friends – Vacation – Events – Others
Only photos stored in the internal memory can be assigned to the
slideshow folders. Assigned photos are not physically moved or
copied into the folders, rather, a link is assigned to the photo so it
appears to be located in the folder. If you delete the actual photo file
from internal memory, the link to the folder will also be deleted.
Assign Photos to Slideshow Folder
1. On the HOME screen, select the PHOTOS-Manage button.
2. On the
Photo Thumbnails screen, use to scroll
through your photos.
3. To assign an individual photo: With the desired photo
displayed, press MENU.
To assign multiple photos: Press ‘+’ to select desired photos
(‘-‘ will deselect), and then press MENU.
4. Select
Assign to Folder, and then select the desired
folder to assign the photo.
5. Press
EXIT to return to the previous screen.
Play Slideshow from Slideshow Folder
1. On the HOME screen, press MENU.
2. Select
Select Media Source.
3. Select
Slideshow Folders.
4. Select the desired folder containing the photos you want to
view in your slideshow.
5. On the
Folders Thumbnails screen, press Slideshow.
Copy or Reassign Photos to Different Folders
After assigning photos to folders you can copy those photos to
other folders, or you can reassign photos to appear in a different
folder.

19
1. With the slideshow folders slideshow playing (per above
instructions), press EXIT twice to display the Folder
Thumbnails screen.
2. To copy or reassign an individual photo, highlight the desired
photo and then press MENU.
To copy or reassign multiple photos, use to
scroll through the photos, use ‘+’ to select those that you
want to copy or reassign (‘-‘ will deselect), and then press
MENU.
3. Select
Copy to Folder or Reassign to Folder, and then
select the desired folder into which you want to reassign or
copy the photos.
Slideshow Background Music
To play background music during a slideshow, simply copy at least
one music MP3 file onto the same media source as your photos. The
music will automatically play as the slideshow is displayed.
If you have multiple MP3 files on your media source, each music file
will play in succession until all have been played, and then will repeat
according to the Music Repeat Mode setting (page 22).
Adjust the Volume
While the music is playing, press ‘+’ or ‘-‘ to adjust the volume.
Mute Slideshow Background Music
While the slideshow is playing, press ENTER to mute the
background music. The slideshow will continue to display without
the music until you press ENTER again.
Set Slideshow Music Mode
You can set the DPF to not play background music with your
slideshows, even if MP3 files are saved on your media source.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Slideshow Setup.

20
3. Use to select Slideshow Music, and then use to
select your desired setting.
ON (default) = Play background music with slideshow
OFF = Do not play music with slideshow, even if MP3 files are stored on
selected media source
4. Select Done.
5. Press
EXIT to return to the previous screen.
Set Slideshow Interval
You can set the speed at which the slideshow photos transition from
one to another.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Slideshow Setup,
3. Use to select Slideshow Interval, and then use to
select your desired setting.
5 (default), 10, 30, 60 seconds, 1 hour, or 24 hours
4. Select Done.
5. Press
EXIT to return to the previous screen.
Set Slideshow Transition
You can set the transition ‘special effects’ as photos transition from
one to another during a slideshow.
1. On the
HOME screen, press MENU to display the Setup Menu.
2. Select
Slideshow Setup.
3. Use to select Slideshow Transition, and use to
select your desired setting.
Off = Photos transition from one photo to the next without special effects.
Random (default) = Photos will transition using all special effects randomly
throughout a slideshow.
Remaining special effects = Choose individual transition effect as desired
4. Select Done.
5. Press
EXIT to return to the previous screen.
