Panduit MA002 User manual

Customer Service: [e-mail] 800.777.3300-TechnicalSupport:[e-mail]866.405.6654page 1
IM037 REV 00
iNC Network Controller Module – Vertical PDU’s (MA002)
The iNC Network Controller Module is a hot-swappable network management card that works with the Panduit
SmartZone G5 iPDU series of intelligent power distribution units. It is the “brain” of the PDU that contains the most
complicated and sensitive electronic sub-systems. It is designed for safe removal without disrupting the PDU
hardware operation.
Note: The iNC Network Control Modules are designed to connect to a SmartZone G5 iPDU only. Connecting it to
another device may result in damage.
INVENTORY:
INSTALLATION INSTRUCTIONS:
1.
Using a T10 screwdriver, loosen the (2) screws securing the iNC
Network Control Module in place
2. Remove the iNC Network Control Module from the PDU chassis
3. Press the release button on the iNC Network Control module cable that
plugs into the PDU and disconnect
4. Remove all connections from the front of the existing iNC Network
Control module (Ethernet, Serial, Sensor, etc.) and plug them into the
front of the replacement iNC Network Control module
NOTE: It is recommended to disconnect and reconnect ports
immediately to insure the cables are plugged into the same ports as
before
NETWORK CONTROLLER
USB
DRIVE
CABLE

Customer Service: [e-mail] 800.777.3300-TechnicalSupport:[e-mail]866.405.6654page 2
IM037 REV 00
5. Plug the Cable into the iNC Network Controller module
6. Plug the iNC Network Controller module cable into the PDU
7. Install the iNC Network Control Module into the PDU chassis
8.
Using a T10 screwdriver, tighten the (2) screws securing the iNC
Network Control Module in place
Recommended tightening torque = 1.25 N-m [11.1Lb-in]
UPDATING THE FIRMWARE:
1. Go to http://www.panduit.com/pdu-support and download the most recent firmware version. Save
this file to the USB Drive
2. Insert the USB Drive into the USB port of the iNC Network Controller
3. Enter USB mode on the PDU: Press Select / Go to Setup > USB > Yes. Select Yes to confirm
entering USB mode.
4. Select F/W Up > Yes to upload new firmware
5. The OLED will show the firmware update progress
6. When the upload is complete, remove the USB Drive
7. From the USB Menu, Select Quit to exit USB mode. Select Yes to confirm exit.
8. The PDU will automatically reboot
9. To confirm that the firmware was uploaded successfully, go to Setup > Device > Firmware
For alternate means to update the firmware, please reference Appendix C: Firmware Update
Procedure of the Panduit SmartZone G5 User manual.
The Panduit iPDU iNC Network Controller Module is installed, updated, and ready for usage. For more
information, please contact www.panduit.com
