INSTALLATION INSTRUCTIONS PN420E
© Panduit Corp. 2008
For Technical Support: www.panduit.com/resources/install_maintain.asp
Page 1 of 2
DPoE Compact 8 Midspan
Part Number: DPOE8S2XG
DPOE8S2XG
1.
The PANDUIT DPoE Compact 8 Midspan may be installed in a standard 19" rack with the DPoE 1RU Shelf (PANDUIT part no. DPOESHELF),
on a wall with the DPoE Wall Mount Bracket (PANDUIT part no. DPOEWM8B) or directly on a tabletop with the rubber feet included in the
DPoE Compact 8 Midspan Kit.
Rack-Mount Installation Tabletop Installation Wall-Mount Installation
2.
Connect patch cords from an Ethernet switch to the bottom row of RJ45 connectors on the DPoE Compact 8 Midspan. Complete the data path
by connecting the top row of RJ45 connectors to powered devices either directly or through a patch panel. The upper set of LED’s indicate the
status of ports 1-4. The center LED indicates the status of the power midspan. The lower set of LED’s indicate the status of ports 5-8. Label
ports using the blank PANDUIT ULTIMATE ID labels and covers and record this information, along with unit specific information, on the DPoE
Installation Worksheet (PANDUIT part no. PN377*).
* Denotes revision letter.
To Powered Ethernet Device
From Ethernet Switch
(Data Only)
(Data + Power) INSTALLATION ADVISORY:
- Ensure that cabling to powered devices is
protected from inductive coupling from nearby
power cables and other sources.
- Ensure that powered devices are properly installed
and grounded (according to manufacturer’s
recommendations), and all the cabling and
connections are isolated from external surges.
NOTE:
When installing cabling and making connections to
the DPOE8S2XG, follow all local standards as well as
the applicable TIA-942 standards and IEEE 802.3
(Ethernet) standards.

E-mail:
[email protected]
Fax:
[phone]
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
INSTALLATION INSTRUCTIONS PN420E
Page 2 of 2
3. (Optional)
To use the optional remote management interface, install the DPoE
Element Manager software, included on the enclosed CD, on a
computer that supports network communication to the DPoE Compact
8 Midspan. Using a patch cord, connect the management port on the
rear of the power midspan to an Ethernet switch. A DHCP server must
be on the network.
The latest version of software products may be downloaded at
www.panduit.com/managednetworksolutions
4.
To supply power to the DPoE Compact 8 Midspan using a DPoE
Power Supply (PANDUIT part no. DPOEPWRB120Y), simply mate the
attached power connector to the power midspan and then connect AC
power to the DPoE Power Supply. To supply power using the rack
mounted DPoE Power System (PANDUIT part no. DPOEPWRCU
with a DPOEPWRR500 or DPOEPWRR1250), remove power from
the port on the DPoE Power System (remove the fuse for the port).
Insert the provided 10' power harness into the panel power connector.
Connect the other end of the harness to the appropriate port on the
DPoE Power System. Butt splices are provided to extend the power
harness (refer to user guide for maximum length). Then apply power
to the port by inserting the appropriate fuse in the DPoE Power
System.
From Network
Notes:
1. DPoE Compact 8 Midspan cannot be used for analog or non-Ethernet devices.
2. PANDUIT STRUCTUREDGROUND Kits for Data Center Rack Grounding can be used to properly ground PANDUIT NETRACK Rack Systems and racks from most other manufacturers.
3. Never touch uninsulated communications wiring or terminals unless the communication line has been disconnected at the network interface.
4. Only trained and qualified service personnel should service DPoE Compact 8 Midspans.
5. Before installing or servicing the DPoE Compact 8 Midspan or communication wiring, be aware of the hazards with the associated electrical circuitry.
ATTENTION:
Observe precautions for handling electrostatic sensitive electronic devices
when installing this product. Ensure that you are properly grounded with a
wrist strap or equivalent while making connections to the product. Never
make any connections to the product when power is being applied.
DPoE European (EMC) Warning:
Product is not intended for use in a residential environment. Use of this
product in residential areas may cause electromagnetic interference.
