Pantera Electronics LED Dome Lamp Installation Manual
This installation manual is to assist in the installation of Pantera-Electronics
LED Dome Lamp. The LED Dome Lamp is a replacement for the incan escent
bulb in the ome light mounte on the insi e roof. It replaces the festoon bulb
that melts the white plastic lense many Panteras.
It utilizes 2 high power white LEDs the pro uce a total of 120 Lumens of light,
compare to the 36 lumens of the festoon bulb.
There is minimal heat generate by the LED Dome Lamp that will not melt the
white plastic lens.
For 1973/74 Pantera’s, the LED Dome Lamp can also be use for the 2 console
lights above the gauges.
Remove the white
plastic cover by
grasping or using a
screw river to pry it
off at the chrome
base carefully.
Remove the
festoon bulb by
gently push the
bulb left or right.
The terminals are springs
that will move when pressure
is applie .

2 Pantera Electronics Rev. 06/21/17
NOTE: It’s important to keep this installation manual for future reference
since revisions to this pro uct change the contents of the installation manual.
Install the LED Dome Lamp is labele with a “-” an the letter “V”. This
terminal is connecte to the lamp socket with the VIOLET wire.
Install the LED Dome Lamp with the labele en with a “+” an the letter “W”.
This terminal is connecte to the lamp socket with the WHITE wire.
Proce ure if the wires are the same color:
If the wires connecte to the lamp socket are not violet an white you will not be
able to confirm the proper installation. A voltmeter will have to be use to
etermine the “+” an “-” terminals of the lamp socket. Connect a voltmeter with
the oor open an etermine the polarity. Mark the socket with a marker to
in icate “+” an procee with installing the LED Dome Lamp.
If a voltmeter is not available then use a temporary wire an connect to the “-” or
VIOLET terminal of the LED Dome Lamp an to chassis groun . Touch the “+”
or WHITE terminal to each of the socket terminals until the LED Dome Lamp
illuminates. The terminal that illuminates the LED Dome Lamp is the “+”
terminal. Mark the socket with a marker to in icate “+” an procee with
installing the LED Dome Lamp.

3
Pantera Electronics Rev. 06/21/2017
The polarity of the LED Dome Lamp M ST be installed
properly or permanent failure will result.
“V” = VIOLET “W” = WHITE (+)
Insert one en of the LED Dome Lamp into one of the en springs an press it
into the opposing spring. Your installation shoul look like the one below.

4 Pantera Electronics Rev. 06/21/17
Rotate the LED Dome Lamp until the 2 LED’s face outwar .
You can optimize the rotational position prior to installing the white plastic lens.
This is an installation in the console light use in 1973/74 Panteras. Note the “+”
an “-” markings on the socket.
