Para systems MinuteMan EXR Series User manual

Para Systems, Inc.
1455 LeMay Dr.
Carrollton, TX 75007
Phone: [phone]
Fax: [phone]
Internet: minutemanups.com
UPS Sizing: sizemyups.com
PN: 34000537 R2
User's Manual

1
Table of Contents
1. Introduction ..................................................................... 2
2. Controls and Indicators .................................................. 6
3. Installation ....................................................................... 11
4. Operation ......................................................................... 17
5. Configurable Parameters & Settings ............................. 21
6. Obtaining Service............................................................ 22
7. Troubleshooting .............................................................. 23
8. Replacing the Battery ..................................................... 24
9. Specifications.................................................................. 27
10. Limited product Warranty............................................. 29
A1. Declaration of Conformity............................................ 30

2
Chapter 1: Introduction
Thank you for purchasing this power protection product. It has been
designed and manufactured to provide many years of trouble-free service.
Please read this manual before installing your EXR UPS Series, models
EXR750RT2U, EXR1000RT2U, EXR1500RT2U, EXR2000RT2U,
EXR3000RT2U, EXR1500RTHV, EXR3000RTHV as it provides important
information that should be followed during the installation and the
maintenance of the UPS system allowing you to correctly set up your system
for the maximum safety and performance. Included is information on
customer support and factory service if it is required. If you experience a
problem with the UPS system, please refer to the Troubleshooting guide in
this manual to correct the problem or collect enough information so that the
Technical Support Department can assist you.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
CONSIGNES DE SÉCURITÉ IMPORTANTES
SAUVEGARDEZ CES CONSIGNES!
Veuillez lire ce manuel avant l'installation de l'onduleur modèles
EXR750RT2U, EXR1000RT2U, EXR1500RT2U, EXR2000RT2U,
EXR3000RT2U, EXR1500RTHV, EXR3000RTHV. Il contient de l'information
importante qui doit être respectée au cours de l'installation et de l'entretien
de l'onduleur et des batteries. Cette information vous permettra de
correctement installer le système pour atteindre son rendement maximum
en toute sécurité.
CAUTION! The maximum ambient operating temperature for this UPS
series is 40°C (“0 ~ 40°C” for Ambient Operation).
The external vents and openings on the UPS are provided for ventilation.
To ensure reliable operation of the UPS and to protect the UPS from
over-heating, these vents and openings must not be blocked or covered.
Do not insert any object into any of the vents or openings that may
hinder the ventilation.
Install the UPS system in a well-ventilated area, away from excess
moisture, heat, dust, flammable gas, or explosives.
Leave adequate space (at least 20cm) around all sides of the UPS
system for proper ventilation.
Do not mount the UPS system with its front or rear panel facing down at
any angle.
Before usage, you must allow the UPS system to adjust to room
temperature (20°C~25°C or 68°F~77°F) for at least one hour to avoid
moisture condensing inside the UPS.
3
CAUTION! This UPS series is ONLY intended to be installed in an
indoor temperature-controlled environment that is free of conductive
contaminants. This UPS series is not intended for use in a computer room
as defined in the Standard for the Protection of Electronic Computer/Data
Processing Equipment ANSI/NFPA 75.
CAUTION! Connect the UPS to a two pole, three wire, grounded, utility
power AC wall outlet. The receptacle must be connected to the appropriate
branch protection (circuit breaker or fuse). Connection to any other type of
receptacle may result in a shock hazard and violate local electrical codes.
Do not use extension cords, adapter plugs, or surge strips.
CAUTION! To reduce the risk of fire, connect only to a utility power
circuit provided with 20 / 30 amperes maximum branch circuit over-current
protection in accordance with the National Electric Code, ANSI/NFPA 70.
CAUTION! To reduce the risk of electrical shock with the installation of
this UPS equipment and the connected equipment, the user must ensure
that the combined sum of the AC leakage current does not exceed 3.5mA.
CAUTION! To reduce the risk of electrical shock in conditions where the
load equipment grounding cannot be verified, disconnect the UPS from the
AC wall outlet before installing a computer interface cable. Reconnect the
power cord only after all signaling connections are made.
WARNING: This Uninterruptible Power Supply contains potentially
hazardous voltages. Do not attempt to disassemble the UPS beyond the
battery replacement procedure. This UPS contains no user serviceable
parts. Repairs and battery replacement must be performed by QUALIFIED
SERVICE PERSONNEL ONLY.
WARNING: Qualified Service Personnel ONLY must perform the
Installation and Servicing of these UPS systems. MINUTEMAN accepts no
liabilities and is not limited to injury to the Service Personnel, or damages to;
the UPS, or the connected equipment caused by the incorrect installation or
servicing of the UPS system.
WARNING: Risk of Electrical Shock. Hazardous live parts inside these
power supplies are energized from the battery even when the AC input is
disconnected.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE
UPS. The mounting brackets are ONLY for securing the UPS to the rack.

4
CAUTION! To de-energize the outputs of the UPS:
1. If the UPS is on press and release the On/Off/Test button. NOTE: Turn the
input circuit breaker (on the rear panel) off for the 208V models.
2. Disconnect the UPS from the AC wall outlet.
3. To de-energize the UPS completely, disconnect the battery.
ON / OFF / TEST BUTTON: Press and release the On/Off/Test
button during the audible alarm's first beep to turn the UPS On.
Once the UPS successfully passes the twenty second self-test the
load will be powered. NOTE: The input circuit breaker (on the rear
panel) MUST be in the on position for the 208V models.
Press and release the On/Off/Test button during the audible alarm's
first beep to turn the UPS Off. The UPS will continue to charge the
batteries whenever it is plugged into a wall outlet and there is an
acceptable AC voltage present.
To perform a ten second battery test: With the UPS in the AC
normal mode, press and hold the On/Off/Test button until the audible
alarm sounds four beeps, and then release. During the test, the
UPS will switch to the Battery mode, the On-Battery icon will
illuminate, and the alarm will sound.
NOTICE: This equipment has been tested and found to comply with the limits for a
Class B computing device in accordance with the specifications in Subpart J of Part
15 of FCC Rules and the Class B limits for radio noise emissions from digital
apparatus set out in the Radio Interference of the Canadian Department of
Communications. These limits are designed to provide reasonable protection
against such interference in a residential installation. This equipment generates and
uses radio frequency and if not installed and used properly, that is, in strict
accordance with the manufacturer's instructions, this equipment may cause
interference to radio and television reception. If this equipment does cause
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient the receiving antenna.
Relocate the computer with respect to the receiver.
Move the computer away from the receiver.
Plug the computer into a different outlet so that the computer and receiver are on
different branch circuits.
Shielded communications interface cables must be used with this product.
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: These UPSs are shipped with the batteries disconnected. The batteries
must be connected before putting these UPSs into service. Refer to Section 3
"Installation" for connecting the batteries.
5
Receiving Inspection
After removing your UPS from its carton, it should be inspected for damage
that may have occurred in shipping. Immediately notify the carrier and
place of purchase if any damage is found. Warranty claims for damage
caused by the carrier will not be honored. The packing materials that your
UPS was shipped in are carefully designed to minimize any shipping
damage. In the unlikely case that the UPS needs to be returned to the
manufacturer, please use the original packing material. Since the
manufacturer is not responsible for shipping damage incurred when the
system is returned, the original packing material is inexpensive insurance.
PLEASE SAVE THE PACKING MATERIALS!
Life Support Policy
As a general policy, we do not recommend the use of any of our products in
life support applications where failure or malfunction of the product can be
reasonably expected to cause failure of the life support device or to
significantly affect its safety or effectiveness. We do not recommend the
use of any of our products in direct patient care. We will not knowingly sell
our products for use in such applications unless Para Systems receives, in
writing, assurances satisfactory to us that (a) the risks of injury or damage
have been minimized, (b) the customer assumes all such risks, and (c) our
liability is adequately protected under the circumstances.
© COPYRIGHT 2020 BY PARA SYSTEMS, INC.
All Rights Reserved. All rights of this User Manual (“Manual”), including but
not limited to the content, information, and figures are solely owned and
reserved by Para Systems, Inc. (“Para Systems”). The Manual can only be
applied to the operation or the use of this product. Any disposition,
duplication, dissemination, reproduction, modification, translation, extraction,
or usage of this Manual in whole or in part is prohibited without the prior
written permission of Para Systems. Given that Para Systems will
continuously improve and develop the product, changes may be made to the
information in this Manual at any time without obligation to notify any person
of such revision or changes. Para Systems will make all possible efforts to
secure the accuracy and the integrity of this Manual. Para Systems
disclaims any kinds or forms of warranty, guarantee, or undertaking, either
expressly or implicitly, including but not limited to the completeness,
faultlessness, accuracy, non-infringement, merchantability, or fitness for a
particular purpose of the Manual.

6
Chapter 2: Controls and Indicators
CONTROL PANEL
1. Pressing the Enter button saves the changes made to the UPS settings.
2. The Escape button will exit the current screen.
3. The LCD screen provides useful information about the UPS.
4. The AC normal icon illuminates when the UPS is on and operating in the
AC normal mode. The AC normal icon will extinguish when operating
in the Battery mode. The AC normal icon will blink when the UPS is
operating in the Boost and/or the Buck mode.
5. The On-Battery icon illuminates when the UPS is operating in the
Battery mode. The On-Battery icon will extinguish when operating in
the AC normal, Boost and Buck modes.
6. The Multi-function On/Off/Test button is used to turn the UPS on or off or
to perform a self-test.
7. The Fault icon illuminates when the UPS detects an internal fault. The
Fault icon is extinguished when the UPS is operating properly.
8. The Weak/Bad/Disconnected Battery icon illuminates when the UPS
detects a weak battery, bad battery or if the battery is disconnected.
The Weak/Bad/Disconnected Battery icon is extinguished when the
battery's condition is good.
9. The Scroll up button allows the user to scroll through the UPS
parameters that are available on the LCD screen.
10. The Scroll down button allows the user to scroll through the UPS
parameters that are available on the LCD screen.
7
LCD FLOWCHART
The following information is available on the LCD screen:

8
The LCD screen's Home Page has four sections:
Status
Configuration
Event Log
About
Status Page:
1. Operating Mode:
Standby mode (the UPS is connected to utility power, but is not turned
on)
AC Normal mode
AVR mode Boost 1
AVR mode Boost 2
AVR mode Buck 1
AVR mode Buck 2
Battery mode
Fault mode
2. Load T (Combined total of the load on all three output banks), 1 (Load
on output bank 1), 2 (Load on output bank 2), 3 (Load on output bank 3).
3. Battery: Voltage and Capacity.
4. Input: Voltage and Frequency.
5. Output: Voltage and Frequency.
6. Last UPS Test Results.
7. Load Bank Status: ON / OFF.
8. Estimated Runtime: The amount of estimated time the UPS will
operate in the Battery mode.
9. Battery Aging Coefficient: Using the battery install date and periodic
monitoring of the batteries to get early warning alarms for battery
replacement.
Configuration Page:
1. Audible Alarm: Turn On/Off the audible alarm (for the Battery mode
Only). NOTE: With the exception of the On-Battery alarm all the other
Warning/Fault alarms cannot be silenced. Once the Warning/Fault
condition has been corrected the alarm will reset to default.
2. Load Bank On/Off Setting: Enable or Disable the Load Shedding
function.
3. Battery Install Date: Set the date the batteries were replaced.
4. Reset Battery Aging Coefficient: Reset the Battery Aging Coefficient
once the batteries have been replaced.
5. External Battery Pack Number: Set the number of External Battery
Packs that are connected to the UPS.
6. Reset to Default: Resets the changes to the Configuration back to the
factory default settings (Must be in the Standby mode).
7. Service Mode (The UPS must be in the Standby mode to enter the
Service mode): Enter the password (default 0000) and then hit the
enter key.
9
Output Voltage: Set the Battery mode output voltage 120V (Default) /
125V. Once set hit the enter key to save the changes.
Load Shedding: Turn off Load Bank 1 and/or Load Bank 2. Once set
hit the enter key to save the changes.
Password Setup: Change the password. Enter the old password first
and then hit the enter key. Enter the new password and then hit the
enter key to save the changes.
Sensitivity: Set the input sensitivity level to L1 or L2. Once set hit the
enter key to save the changes.
Event Log Page:
1. Fault Log 1,2,3: View the current or previous faults.
2. Warning Log 1,2,3: View the current or previous warnings.
About Page:
1. UPS Model: Displays the model name of the UPS.
2. UPS Serial No.: Displays the serial number of the UPS.
3. Battery Part No.: Displays the battery module part number.
4. Battery Install Date: Displays the date the battery module was
installed.
5. UPS Firmware: Displays the UPS's firmware version.
Selecting the 'Reset to Default' will reset the following items to the factory
default settings:
Confi
g
urable Settin
g
s Factor
y
Default Settin
g
s
A
udible Alarm ON
Load Bank 1 ON
Load Bank 2 ON
Batter
y
Install Date Jan-20
Batter
y
A
g
in
g
Coefficient 1.0
External batter
y
Packs No.
A
uto
Output Volta
g
e 120V
Load Sheddin
g
Enabled
Password Setup ‘0000’
Sensitivit
y
L1 OFF
Sensitivit
y
L2 OFF
A
uto Restar
t
Enabled
Power On Dela
y
Time 0
–
Seconds
Fault Lo
g
s 1,2,3 Empt
y
, no faults listed
Warnin
g
Lo
g
s 1,2,3 Empt
y
, no warnin
g
s listed

10
REAR PANEL
1. The R-J11/R-J45 modular connectors are used for 10/100/1000 Base-T
Network/single line Phone/Fax/Modem protection.
2. The External Battery Pack detect port (EXB) is for the UPS to automatically
detect the External Battery Pack so that the UPS can calculate the estimated
runtime.
3. The RS232 Communications Port is for UPS monitoring and control.
4. The REPO (Remote Emergency Power Off) Port is for UPS control. This
connection is not for telecommunication use.
5. The option slot is for option cards.
6. The fan is for ventilation.
7. The External Battery Connector is for connecting an External Battery Pack.
8. The Battery Backup output receptacles. The output receptacles are electrically
wired into two segments to support the "Load Shedding Function" (Labeled Load
1 & Load 2). The locking and Always On receptacles (Labeled Load 3) do not
support the "Load Shedding Function". NOTE: The locking receptacle is not on
all models.
9. The input circuit breaker will trip in the event the load exceeds the UPS’s power
rating.
10. The rackmount brackets are for attaching the UPS to rack.
11. The input power cord (120V models). The AC Power Inlet IEC320 (208V
models).
12. The External Ground Stud is for connecting an external ground wire.
13. The USB Communications Port is for UPS monitoring and control.
Model Input Power Plug
(All power cords are 10ft)
Output Power Receptacles
EXR750RT2U
EXR1000RT2U
EXR1500RT2U
NEMA 5-15P 6-NEMA 5-15R (Controllable)
2-NEMA 5-15R (Always On)
EXR2000RT2U NEMA 5-20P
8-NEMA 5-15/20R (Controllable)
1-NEMA L5-20R (Always On)
EXR3000RT2U NEMA L5-30P
6-NEMA 5-15/20R (Controllable)
1-NEMA L5-30R (Always On)
EXR1500RTHV NEMA 6-15P
4-NEMA 6-15R (Controllable)
2-NEMA 6-15R (Always On)
EXR3000RTHV NEMA L6-30P
6-NEMA 6-15/20R (Controllable)
1-NEMA L6-30R (Always On)
11
Chapter 3: Installation
INSTALLATION PLACEMENT
This UPS series is ONLY intended to be installed in an indoor temperature-
controlled environment that is free of conductive contaminants. DO NOT
operate the UPS in extremely dusty and/or unclean areas, locations near
heating devices, water, or excessive humidity, or where the UPS is exposed
to direct sunlight. Select a location, which will always provide good air
circulation for the UPS. Route power cords so they cannot be walked on
or damaged. This UPS series is not intended for use in a computer room
as defined in the Standard for the Protection of Electronic Computer/Data
Processing Equipment ANSI/NFPA 75. Typical battery life is 3 to 5 years.
Environmental factors do affect battery life. High temperatures, poor utility
power, and frequent, short duration discharges have a negative impact on
battery life.
Operating Temperature (Maximum): 0 to 40C (+32 to +104F)
Operating Elevation: 0 to 3,000m (0 to +10,000 ft)
Operating and Storage Relative Humidity: 5 ~ 95%, non-condensing
Storage Temperature: -15 to +45°C (+5 to +113°F)
Storage Elevation: 0 to 15,000m (0 to +50,000 ft)
INSTALLATION
Be sure to read the installation placement and all the cautions before
installing the UPS. Place the UPS in the final desired location and
complete the rest of the installation procedure. These UPSs are shipped
with the internal batteries disconnected. The batteries must be connected
before putting these UPSs into service. See the "Connecting the Batteries"
procedure to connect the batteries and then the "Rackmount Configuration"
to install the UPS into the rack. USE CAUTION: The UPS is heavy. Use
the appropriate number of personnel when installing the UPS.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE
UPS. The mounting brackets are ONLY for securing the UPS to the rack.
NOTE: If you are using an External Battery Pack with this EXR UPS
series, the UPS must be configured so that the UPS will report the
correct estimated runtime on the LCD screen and in the Power
Monitoring software and/or the SNMP card. See the UPS's, or the
Power Monitoring software or the SNMP card’s User's Manual to
configure the UPS.

12
CONNECTING THE BATTERY
(QUALIFIED SERVICE PERSONNEL ONLY)
Please read all the WARNINGS and CAUTIONS before attempting to connect
the battery.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE UPS.
The mounting brackets are ONLY for securing the UPS to the rack.
WARNING: Use two or more people when installing the UPS, the UPS is
extremely heavy.
1. Remove the UPS from the shipping box.
2. Place the UPS on a flat surface.
3. Remove the battery door and set aside (FIG. 1).
4. Verify proper polarity. Connect the red battery connectors together (FIG. 2).
NOTE: Some sparking may occur this is normal.
5. Reinstall the battery door onto the UPS.
6. Connecting the batteries is complete. See the Rackmount Configuration.
FIG. 1
FIG. 2
13
RACKMOUNT CONFIGURATION
This UPS series comes with mounting brackets for the standard 19"
(46.5cm) rack pre-installed on the UPS. The mounting brackets to fit a 23"
(59.2cm) rack and Rail Kits for 4-post racks and cabinets are also available.
NOTE: The Rail Kits for a 4-post rack and/or cabinet are included with the
EXR2000RT2U, EXR3000RT2U and the EXR3000RTHV.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE
UPS. The mounting brackets are ONLY for securing the UPS to the rack.
NOTE: The mounting brackets can be mounted in the middle of the UPS.
1. Mount the UPS into the rack and secure with the retaining screws.
WARNING: Use two or more people when installing the UPS, the UPS
is extremely heavy. Do not move the rack after the units have been
installed. The rack may become unstable due to the weight distribution.
2. The Rackmount Configuration is complete. See Connecting your
Equipment.

14
TOWER CONFIGURATION
The tower configuration allows the user to install the UPS in the upright
position next to a tower computer. The tower brackets are provided with
the UPS. WARNING: Use two or more people when installing the UPS, the
UPS is extremely heavy.
1. Once the location of the UPS has been determined, place the UPS on a
flat surface, remove the rackmount brackets from the UPS and then
place the tower brackets in the desired location.
2. The LCD panel can be rotated to read in the upright position. Use a
small flat blade screwdriver on the right-hand side of the LCD panel and
gently pop out the LCD panel. Rotate the LCD panel so that it reads in
the upright position and then reinstall it back into the front panel.
WARNING: The UPS must be installed in the proper upright position. If
the UPS is not installed in the proper upright position the batteries will be
damaged. Once the UPS is placed in the tower brackets, looking at the
front panel the YELLOW Battery Disconnected label on the top cover of the
UPS MUST be on your left-hand side.
3. Slide the UPS into the tower brackets. Make sure that the UPS is stable.
4. The Tower Configuration is complete. See Connecting your Equipment.
WALLMOUNT CONFIGURATION
The wallmount configuration allows the user to mount the UPS on the wall.
There is a wallmount bracket kit available for the UPS. The kit includes two
wall mounting brackets, ten retaining screws, and the wallmount template.
WARNING: Use two or more people when installing the UPS, the UPS is
extremely heavy. The UPS's side panels have mounting bracket screw
holes for attaching the wall mounting brackets.
1. Once the location of the UPS has been determined, place the UPS on a
flat surface and remove the rackmount brackets from the UPS.
15
2. The LCD panel can be rotated to read in the upright position. Use a small
flat blade screwdriver on the right-hand side of the LCD panel and gently
pop out the LCD panel. Rotate the LCD panel so that it reads in the upright
position and then reinstall it back into the front panel.
WARNING: The UPS must be installed in the proper upright position. If the
UPS is not installed in the proper upright position the batteries will be damaged.
Once the UPS is placed on the wall, looking at the front panel the YELLOW
Battery Disconnected label on the top cover of the UPS MUST be on your left-
hand side.
3. Align the mounting brackets with the mounting bracket screw holes on the
side panels of the UPS and attach with the six retaining screws.
4. Attach a sheet of ¾” plywood into structural material (wood or metal wall
studs). WARNING: The plywood must be a minimum of ¾” thick and the
wall studs must be a minimum of 1.5” wide and 3.5” thick.
5. Use the template to mark the screw hole position on the sheet of plywood.
CAUTION, you should always wear protective gear for your hands and eyes
when operating power tools.
6. Attach the four retaining screws to the sheet of plywood and make sure that
all the retaining screws are secure. Then clean the area of any loose
material. Do not tighten the retaining screws all the way; leave
approximately 3/8" of the retaining screws sticking out.
7. Use CAUTION, the UPS is extremely heavy. Position the UPS, so that
the mounting bracket keyed holes line up with the four retaining screws.
Slide the UPS down until its resting securely on the four retaining screws.
8. Tighten the four retaining screws to secure the UPS to the plywood.
9. The Wallmount Configuration is complete. See Connecting your Equipment.

16
CONNECTING YOUR EQUIPMENT
Plug the equipment into the output receptacles on the rear panel of the UPS.
Ensure that you do not exceed the maximum output rating of the UPS (refer to the
information label or the Electrical Specifications in this manual). DO NOT PLUG
EXTENSION CORDS, ADAPTER PLUGS OR SURGE STRIPS INTO THE OUTPUT
RECEPTACLES OF THE UPS.
CAUTION! DO NOT connect a laser printer to the output receptacles on the UPS
unless the UPS is rated 2000VA or greater. A laser printer draws significantly more
power when printing than at idle and may overload the UPS.
CONNECTING THE UPS TO AN AC SOURCE
Plug the UPS into a two pole, three wire, grounded AC wall outlet. The AC wall
outlet shall be near the UPS and shall be easily accessible. The plug on the input
power cord on this UPS series is intended to serve as a disconnect device. DO
NOT PLUG THE UPS INTO EXTENSION CORDS, ADAPTER PLUGS OR SURGE
STRIPS. DO NOT CUT THE INPUT PLUG OFF AND ATTEMPT TO HARDWIRE
THIS UPS; DOING SO WILL VOID THE WARRANTY.
CHECKING THE SITE WIRING FAULT (120V Models)
After plugging the UPS into the AC wall outlet, check for the Site Wiring Fault error
message on the LCD screen. If there is a SWF error message, the UPS is plugged
into an improperly wired AC wall outlet. Have a qualified Electrician correct the
problem.
CHARGING THE BATTERY
The UPS will charge the internal batteries whenever the UPS is connected to an AC
source and there is an acceptable AC voltage present. NOTE: The input circuit
breaker MUST be in the on position for the 208V models. It is recommended that
the UPS's batteries be charged for a minimum of 4 hours before use. The UPS may
be used immediately; however, the “On-Battery” runtime may be less than normally
expected. NOTE: If the UPS is going to be out of service or stored for a prolonged
period, the batteries must be recharged for at least twenty-four hours every ninety
days.
NETWORK/PHONE/FAX/MODEM PROTECTION CONNECTION (OPTIONAL)
Connect a 10/100/1000 Base-T network, Single line phone, Fax, or Modem line to
the RJ11/45 modular connectors on the rear panel of the UPS. This connection will
require another length of telephone or network cable. The cable coming from the
telephone service or network system is connected to the port marked “IN”. The
equipment to be protected is connected to the port marked "OUT". NOTE:
Connecting to the Network/Phone/Fax/Modem modular connectors is optional. The
UPS works properly without this connection.
COMMUNICATIONS PORT CONNECTION (OPTIONAL)
The Power Monitoring Software and interface cables can be used with the UPS.
Use only the interface cables that come with these UPSs. Connect the interface
cable (Serial or USB) to the appropriate communications port on the rear panel of the
UPS. Connect the other end of the cable to the device that will be
monitoring/controlling the UPS. NOTE: Connecting to the Communications Port is
optional. The UPS works properly without this connection.
17
POWER MONITORING SOFTWARE
This UPS series supports Minuteman's SentryHD power monitoring software.
Please go to our website at www.minutemanups.com/minuteman-software-
download-center/ to download (Free of Charge) the latest version of the Minuteman
SentryHD power monitoring software.
REPO (Remote Emergency Power Off) PORT (OPTIONAL)
Connect one end of a two-wire cable to the REPO port (two pin terminal block) and
the other end of the two-wire cable to the EPO switch. Short pin1 to pin2 for
approximately 0.5-seconds in the AC or the Battery mode to shutdown the UPS.
The UPS must be turned off and then back on again to restart the UPS. NOTE:
Connecting to the REPO port is optional. The UPS works properly without this
connection.
EXTERNAL BATTERY PACK DETECTION PORT (OPTIONAL)
Connecting the External Battery Detection cable from the UPS to the Battery Pack
allows the UPS to automatically detect the External Battery Pack. Once the UPS
detects that there is an External Battery Pack connected it will automatically
recalculate the estimated runtime based on the number of External Battery Packs
detected and the attached load on the UPS. NOTE: The External Battery Pack
can also be set through the LCD screen, the Power Monitoring Software, or the
SNMP card. NOTE: Connecting to the External Battery Pack Detection port is
optional. The UPS works properly without this connection.
Chapter 4: Operation
SYSTEM OVERVIEW
This Line-Interactive UPS protects computers, network, and telecommunications
equipment from blackouts, brownouts, overvoltages, and surges. The AVR
(Automatic Voltage Regulator) function continuously corrects the voltages, in-
between the brownout and overvoltage transfer points (80 - 164VAC/150 - 271VAC),
to a safe usable level without using the batteries. When the UPS is operating in the
AVR mode the audible alarm will remain silent and the AC Normal icon will flash.
During normal AC operation, the UPS will quietly and confidently protect your system
from power anomalies. The UPS will charge the batteries with the UPS in the on or
off position if the UPS is plugged into the wall outlet and there is an acceptable AC
voltage present (80 - 164VAC/150 - 271VAC).
Block Diagram of the Basic Wiring and Internal Circuit Configuration

18
NOTE: The input circuit breaker MUST be in the on position for the 208V models.
When a blackout, brownout, or an overvoltage condition occurs; the UPS will transfer
to the battery mode, the On-Battery icon will illuminate, and the audible alarm will
sound once every ten seconds indicating that the commercial power is lost or
unacceptable. When the commercial power returns or is at an acceptable level, the
UPS will automatically transfer back to the AC normal mode and start recharging the
batteries. During an extended outage when there is approximately two minutes of
backup time remaining the audible alarm will sound twice every five seconds. This
Low Battery Warning is letting the user know that they should save all open files and
turn off their computer. When the batteries reach the predetermined level, the UPS
will automatically shutdown protecting the batteries from over discharging. Once the
commercial power returns the UPS will automatically restart, providing safe usable
power to the connected equipment and start recharging the batteries.
TURNING THE UPS ON / OFF
ON / OFF / TEST BUTTON
Press and release the On/Off/Test Button after one beep to turn the UPS on and
supply power to the load. NOTE: The input circuit breaker on the rear panel
MUST be on for the 208V models. The load is immediately powered while the UPS
runs a five second self-test. Press and release the On/Off/Test Button after one
beep to turn the UPS off. NOTE: Turn the input circuit breaker (on the rear panel)
off for the 208V models. The UPS will continue to charge the batteries whenever it
is plugged into a wall outlet and there is acceptable AC voltage present. NOTE:
The input circuit breaker (on the rear panel) MUST be on for the 208V models.
SELF-TEST
The self-test feature is useful to verify the correct operation of the UPS and the
condition of the batteries. With the UPS in the AC normal mode, press and hold the
On/Off/Test Button for four beeps, then release the button. The UPS will perform a
ten second self-test. During the self-test, the UPS will switch to the battery mode
and the On-Battery icon will illuminate and the audible alarm will sound. The UPS
will automatically perform a five second inverter test on start-up to verify the correct
operation of the UPS and the condition of the batteries. If the UPS fails a self-test,
there will be an error message on the LCD screen indicating the type of problem.
ALARM SILENCER BUTTON
When the UPS is operating in battery mode, the audible alarm can be silenced.
Press the Enter button on the front panel for three seconds. Once the UPS reaches a
Low Battery Warning alarm the audible alarm will turn back on and cannot be
silenced. The UPS audible alarm will be reset to default once the utility power returns.
The alarm cannot be silenced during a general fault alarm.
SERVICE MODE
The UPS has a Service mode function activated through the LCD screen. The
Service mode items are:
Output Voltage Adjustment
Load Shedding Function
Password Setup
Input Voltage Sensitivity Adjustment
19
INVERTER (ON-BATTERY) OUTPUT VOLTAGE ADJUSTMENT
The Inverter (On-Battery) output voltage setting can be either 120VAC (208VAC)
default or 125VAC (240VAC). Changing the Inverter (On-Battery) output voltage to
125VAC will also change the Buck set point. Changing the Inverter (On-Battery)
output voltage to 240VAC, will also change the Brownout, Boost, Buck, and
Overvoltage set points. The UPS must be in the off position and connected to the
AC outlet. Use the scroll buttons on the LCD screen scroll to the Service Mode
screen and then press the Enter key. Then scroll to the Output Voltage Setting
screen and press the Enter Key. Then scroll to the desired output voltage setting
and press the Enter Key. Then press the Escape key to exit the Configuration
screen. Now the UPS is ready for Normal operation. Press the On/Off/Test button
to turn the UPS on.
LOAD SHEDDING FUNCTION
The output receptacles are electrically wired into two segments to support the "Load
Shedding Function" (Labeled Load 1 & Load 2). The user can control the two
segments individually or both at the same time. The Load Shedding Function is
controllable by the LCD screen (look under the Service Mode screen), the Power
Monitoring Software or the SNMP card. NOTE: The output segment labeled Load
3 does not support the "Load Shedding Function" it is Always ON.
PASSWORD SETUP
Changing the password: Enter the old password first and then hit the enter key. Enter
the new password and then hit the enter key to save the changes.
INPUT VOLTAGE SENSITIVITY ADJUSTMENT
The input voltage sensitivity can be adjusted through the LCD screen. The when
the input waveform distortion is causing the UPS to transfer to the Battery mode too
often, adjusting the sensitivity will allow the UPS to remain in the AC mode without
depleting the battery reserves. The following chart shows the adjustments for Level
1 and Level 2.
Mode Level 1 Level 2
Brownout Transfer Point (120V model) 76VAC +2 / -4V 74VAC +2 / -4V
Brownout Reset Point (120V model) 80VAC ±4V 78VAC ±4V
Brownout Transfer Point (208V model) 138VAC ±4V 135VAC ±4V
Brownout Reset Point (208V model) 148VAC ±4V 145VAC ±4V
Brownout Transfer Point (240V model) 172VAC ±4V 168VAC ±4V
Brownout Reset Point (240V model) 182VAC ±4V 178VAC ±4V
Input Frequency Range (all models) 60Hz: 53.4~66.6Hz
50Hz: 43.5~56.5Hz
60Hz: 52.8~67.2Hz
50Hz: 43.0~57.0Hz
BATTERY AGING COEFFICIENT
Use the battery install date and periodic monitoring of the batteries to get early
warning alarms for battery replacement. After replacing the batteries reset the
Battery Aging Coefficient through the LCD screen.
OPTION SLOT
The option slot on the rear panel of the UPS is for option cards. Contact your local
dealer for the available option cards or visit our web site at www.minutemanups.com.

20
EXTERNAL BATTERY PACK DETECTION PORT
Connecting the External Battery Detection cable from the UPS to the Battery
Pack allows the UPS to automatically detect the External Battery Pack. Once
the UPS detects that there is an External Battery Pack connected it will
automatically recalculate the estimated runtime based on the number of External
Battery Packs detected and the attached load on the UPS. NOTE: The
External Battery Pack can also be set through the LCD screen, the Power
Monitoring Software, or the SNMP card.
REPO (Remote Emergency Power Off) PORT
Connect one end of a two-wire cable to the REPO port (two pin terminal block)
and the other end of the two-wire cable to the EPO switch. Short pin1 to pin2
for approximately 0.5-seconds in the AC or the Battery mode to shutdown the
UPS. The UPS must be turned off and then back on again to restart the UPS.
The LCD screen will display EPo for this function.
ALARMS
ON BATTERY
When the UPS is operating on the Battery mode, the On-Battery icon will
illuminate, and the audible alarm will sound once every ten seconds. The alarm
will stop once the UPS returns to the AC normal mode.
LOW BATTERY WARNING
The audible alarm will sound two beeps every five seconds when the battery
reserve runs low. This condition will continue until AC returns or the UPS shuts
down from battery exhaustion.
WEAK/BAD/DISCONNECTED BATTERY
The UPS automatically tests the battery’s condition. If the battery is weak, bad,
or disconnected, the Weak/Bad/Disconnected Battery icon will illuminate, and
the audible alarm will beep three times every five minutes until the battery is
reconnected or replaced. This alarm will be repeated until the batteries pass a
self-test. It is recommended that the UPS be allowed to charge overnight
before performing a battery test to confirm a Weak/Bad Battery condition.
OVERLOAD
When the amount of load attached to the UPS exceeds 110% of its power rating;
the audible alarm will sound a constant alarm and the LCD screen will display
the error message 'UPS is overloaded - UPS will shutdown'. This alarm and
error message will remain on until the excess load is removed, or the UPS’s self-
protection circuit shuts the UPS down. If the UPS shuts down because of an
Overload condition, the UPS must perform an Inverter function and/or a Self-
Test to clear the Overload Alarm.
UPS FAULT
When the UPS detects a hardware fault, the Fault icon will illuminate, and the
audible alarm will sound a constant alarm and the LCD screen will display an
error message identifying the fault. The fault condition, in some instances, may
be reset by turning the UPS off and then on.
21
Chapter 5: Configurable Parameters
and Settings
(These items may require optional software or hardware)
Function Factory
Default
User Choices Description
UPS ID EXR Series Up to 64
characters to
define the UPS
Use this function to uniquely
identify the UPS in your network
environment
Battery
Install
Date
Date of
manufacture
Date of battery
replacement –
month/day/year
Enter the current date of when
the batteries were replaced
Battery
life in
days
1826 Up to 5
characters
At first battery replacement, reset
to reflect actual number of days
experienced in your environment
or leave at factory default
Enable /
Disable
Auto
Restart
Enabled Enable
or
Disable
When enabled, the UPS will
automatically restart from a low
battery shutdown when normal
AC returns
Set
audible
alarm
state
Enabled Enabled,
at Low Battery,
Disabled
Enabled – the UPS will emit a
short beep when in the battery
mode.
At Low Battery - the UPS will
emit two beeps from low battery
warning until shutdown.
Disabled - Use only when
software is controlling the UPS or
to silence the alarm
Shut-
down
type
Entire UPS Entire UPS
or
UPS output
Entire UPS - Turns off the entire
UPS.
UPS Output - Turns off the
UPS's output
r
eceptacles only.
Set
inverter
output
voltage
120VAC
(208VAC)
120, 125VAC
(208, 240VAC)
Changes the output voltage for
battery mode operation only.
Enable/
Disable
REPO
Disabled Enable
or
Disable
Enabled - the UPS will be
powered off and remain off until
the UPS is reset.
Set
External
Battery
Pack
0 0 - 10 Configures the UPS so that it will
report the correct estimated
runtime on the LCD screen and
in the Power Monitoring software
and/or the SNMP card.

22
Chapter 6: Obtaining Service
IF THE UPS REQUIRES SERVICE
1. Use the Troubleshooting section to eliminate obvious causes.
2. Verify there are no tripped circuit breakers and that the batteries are good.
A tripped circuit breaker and defective batteries are the most common
issues.
3. Call your dealer for assistance. If you cannot reach your dealer or if they
cannot resolve the issue, call our Technical Support department at: (972)
446-7363 or send an email to [email protected] or visit our
Web site at www.minutemanups.com the "Discussion Board". Before
calling the Technical Support, Department have the following information
available:
a) Contact name and address.
b) Where and when the unit was purchased.
c) All of the model information about your unit.
d) The serial number of your unit.
e) Any information on the failure, including LEDs that may be illuminated
or error messages displayed.
f) A description of the protected equipment including model numbers, if
possible.
g) A technician will ask you for the above information and if possible,
help solve the issue over the phone. If unit requires factory service,
the Technical Support Representative will issue you a Return Material
Authorization Number (RMA #). NOTE: We must have the model
number and the serial number of the product to issue an RMA #.
h) If the unit is under warranty, the repairs will be done at no charge. If
the unit is not under warranty, there will be a charge for the repair.
4. Pack the unit in its original packaging. If the original packaging is no longer
available, ask the Technical Support Representative about obtaining a new
set. It is important to pack the unit properly to avoid damage in transit.
Never use Styrofoam beads for a packing material.
a) Include a letter with your name, address, daytime phone number,
RMA number, a copy of your original sales receipt, and a brief
description of the problem.
5. Mark the RMA # on the outside of all packages. The factory cannot accept
any package without the RMA # marked on the outside of the package.
6. Return the unit by insured prepaid carrier to:
Para Systems Inc.
MINUTEMAN UPS
1809 W. Frankford Road, Suite 150
Carrollton, TX 75007
ATTN: RMA # _______
23
Chapter 7: Troubleshooting
Symptom / Error Message Cause / What to do
UPS will not turn on. Press the On/Off button and release after one
beep.
UPS operates in battery
mode only, even though
there is AC present.
Reset the input circuit breaker. If it trips after the
UPS restarts, reduce the load on the UPS.
Bad Battery -
PLS replace battery
Check the battery connections, charge the
batteries for 8-hours and retest, or replace the
batteries.
Battery Depleted -
UPS has shutdown
The UPS's batteries have been depleted. The
UPS has shutdown due to battery exhaustion.
Charge the batteries for 24-hours.
Charger Failure -
UPS has shutdown
The charger has failed, call for service.
Fan Failure -
PLS replace fan
The fan has either failed or has stopped due to
excessive dirt. If the fan has failed, call for
service. If the fan is dirty, use a can of "Canned
Air" to clean the fan.
High Input Current -
PLS Reduce Load
The input voltage is very low, and the UPS is
heavily loaded. Reduce the load.
High Internal Temperature -
UPS has shutdown
The internal or ambient temperature has
exceeded the temperature ratings. Check the
specifications.
Internal Bus Fault -
UPS has shutdown
The UPS has an internal problem, call for
service.
Inverter / Output Failure -
UPS has shutdown
The UPS has an internal problem, call for
service.
Low Battery -
Shutdown imminent
The UPS's battery reserve is low. This condition
will continue until AC returns or the UPS shuts
down from battery exhaustion.
Low Internal Temperature -
UPS has shutdown
The internal or ambient temperature has
exceeded the temperature ratings. Check the
specifications.
Output Short Circuit -
UPS has shutdown
Disconnect the attached equipment. If, the error
does not clear the UPS has an internal problem.
Call for service.
Site Wiring Fault -
PLS check input connection
Have a qualified electrician correct the service
wiring.
UPS is overloaded -
UPS will shutdown
Check the specifications and remove part of the
load. If, the UPS shuts down because of an
Overload, the UPS must perform an Inverter
function or a Self-Test to clear the Overload
Alarm.

24
Chapter 8: Replacing the Battery
QUALIFIED SERVICE PERSONNEL ONLY
Please read all the WARNINGS and CAUTIONS before attempting to service
the batteries. Typical battery life is 3 to 5 years. Environmental factors do
affect battery life. High temperatures, poor utility power, and frequent, short
duration discharges have a negative impact on battery life.
WARNING! This UPS contains potentially hazardous voltages. Do not
attempt to disassemble the UPS beyond the battery replacement procedure.
This UPS contains no user serviceable parts. Repairs and battery replacement
must be performed by QUALIFIED SERVICE PERSONNEL ONLY.
CAUTION: Do not open or mutilate batteries. Released electrolyte is harmful
to the skin and eyes and may be toxic.
CAUTION: Do not dispose of batteries in a fire. The batteries may explode.
The batteries in this UPS are recyclable. Dispose of the batteries properly.
The batteries contain lead and pose a hazard to the environment and human
health if not disposed of properly. Refer to local codes for proper disposal
requirements or return the battery to the supplier.
CAUTION: The battery system can present a risk of electrical shock. These
batteries produce enough current to burn wire or tools very rapidly, producing
molten metal. Observe these precautions when replacing the batteries:
1. Remove watches, rings, or other metal objects.
2. Use hand tools with insulated handles.
3. Wear protective eye gear (goggles), rubber gloves and boots.
4. Do not lay tools or other metal parts on top of batteries.
5. Disconnect the charging source prior to connecting or disconnecting the
battery terminals.
6. Determine if the battery is inadvertently grounded. If the battery is,
remove the source of the grounding. Contact with any part of a grounded
battery can result in an electrical shock. The likelihood of such shock will
be reduced if such grounds are removed during installation and
maintenance.
CAUTION: Replace the batteries with the same number and type as originally
installed in the UPS. These batteries have pressure operated vents. These
UPSs contain sealed non-spillable maintenance-free lead acid batteries.
Model # EXR750RT2U
EXR1000RT2U
EXR1500RT2U
EXR1500RTHV EXR2000RT2U EXR3000RT2U EXR3000RTHV
Battery
Module
Part #
BM0086 BM0087 BM0088 BM0089
25
BATTERY REPLACEMENT PROCEDURE
(QUALIFIED SERVICE PERSONNEL ONLY)
PLEASE READ THE CAUTIONS AND WARNINGS BEFORE
ATTEMPTING TO REPLACE THE BATTERY MODULE
Hot-swappable batteries mean that the battery modules can be replaced
without powering down the whole UPS system.
NOTE: If there is a power interruption while replacing the hot-swappable
battery module, with the UPS on, the load will not be backed up. To hot
swap the battery module, start with step number 6.
1. Turn off the equipment that is plugged into the output receptacles of the
UPS.
2. Press and release the On/Off/Test button on the front panel to turn the
UPS OFF.
NOTE: For the 208V models turn the input circuit breaker on the rear panel
off.
3. Unplug the UPS's AC power cord from the AC wall outlet.
4. Unplug the equipment from the output receptacles of the UPS.
5. Unplug the computer interface cable from the rear panel of the UPS.
6. Remove the battery door and set aside. (FIG. 2)
7. Disconnect the red battery connectors. (FIG. 3)
8. Remove the retaining screw for the battery retaining bracket. (FIG. 3)
9. Remove the battery retaining bracket. (FIG. 4)
FIG. 1
FIG. 2

26
10. Grasp the battery pull tab and gently pull the battery module out of the UPS and
set aside. (FIG. 5)
NOTE: Use Caution, the battery module is heavy.
11. Slide the new battery module into the UPS.
12. Reinstall the battery retaining bracket.
13. Reinstall the retaining screw for the battery retaining bracket.
14. Verify proper polarity. Reconnect the red battery connectors together.
NOTE: Some sparking may occur this is normal.
15. Reinstall the battery door on the UPS.
16. The UPS is now ready for the normal operation.
17. Properly dispose of the old battery module at an appropriate recycling facility or
return them to the supplier in the packing material that the new battery module
came in.
NOTE: If the UPS has a Weak/Bad Battery Alarm after replacing the battery
module, the user must initiate a self-test to clear the Weak/Bad Battery Alarm. To
initiate a self-test, see section 4 "SELF-TEST".
FIG. 3
FIG. 4
FIG. 5
27
Chapter 9: Specifications
SYSTEM SPECIFICATIONS
Model Number EXR750RT2U EXR1000RT2U EXR1500RT2U
EXR1500RTHV EXR2000RT2U EXR3000RT2U
EXR3000RTHV
Topology Line-Interactive, Sine Wave
Maximum Power Capacity 750VA
675W
1000VA
900W
1500VA
1350W
2000VA
1800W
3000VA
2700W
INPUT
Number of Phase Single (1Ø 2W +G)
Nominal Voltage 120VAC (208VAC)
Acceptable Input voltage 0 - 165VAC (0 – 300VAC)
Voltage Range 80 - 164VAC (150 – 271VAC)
Frequency Limits 50 or 60 Hz, ±6Hz, autosensing
Low Voltage Transfer Point 80V (150V) resets to Utility Power at 85V (157V) or higher
High Voltage Transfer Point 164V (271V) resets to Utility Power at 159V (264V) or lower
Input Protection Resettable Circuit Breaker
OUTPUT NON-BATTERY OPERATION
Voltage Range 120VAC: 101 – 136VAC (208VAC: 186 – 236VAC)
Voltage Regulation 120VAC: -15.8% - +11.7% (208VAC: -10.6% - +13.5%)
Frequency Range 60Hz: 54 - 66Hz or 50Hz: 44 – 56Hz
Efficiency (Line Mode) >93% (Full Load)
OUTPUT BATTERY OPERATION
Waveform Type Sine Wave
Nominal Voltage Default: 120VAC (208VAC), User selectable: 125VAC (240VAC)
Voltage Regulation Nominal ±5% (until Low Battery Warning)
Frequency 50/60Hz, ±0.1Hz (unless synchronized to utility)
Voltage T.H.D. <5% (Linear Load)
Dynamic Response ±10% @ 100% Load change in 30 ms
Transfer Time 6 ms Typical
Slew Rate <1Hz / second
Overload Capacity 110% for 20-sec, 125% for 10-sec, 150%Shutdown Immediately
Protection Over-Current, Short-Circuit Protected, Latching Shutdown
BATTERY SYSTEM
Battery Type Sealed, Non-Spillable, Maintenance Free, Value Regulated, Lead Acid
Typical Recharge Time 8-hours to 90% capacity from a full load discharge
Typical Battery Life 3 to 5 years, depending on discharge cycles and ambient temp
System Voltage 36VDC 72VDC
Battery Module Part # BM0086 BM0086 BM0087 BM0088 BM0089
Runtime: Full Load (min) 7 4 2.5 4.5 2.5
Runtime: Half Load (min) 19 13 9 13 10

28
SURGE PROTECTION AND FILTERING
Surge Energy Rating 1000 J (800 J)
Surge Current Capability 6500 Amps total
Surge Response Time 0 ns (instantaneous) normal mode; <5 ns common mode
Surge voltage let through
(as a percentage of an
applied ANSI C62.41 Cat.
A +/-2 kV)
<5%
10/100/1000 Base-T
surge protection let-
through (as a percentage
of an applied +/-2 kV
1.2/50 us, 500A 8/20 uS
test)
<5%
Telephone line surge
protection let-through (as
a percentage of an
applied +/-2 kV 1.2/50 us,
500
A
8/20 uS test)
<1%
Noise Filter >45db normal and common mode EMI/RFI suppression
Audible Noise at 1 m (3 ft) <45 dBA <60 dBA
ENVIRONMENTAL
Operating Temperature
(max) 0 to 40°C (+32 to +104°F)
Storage Temperature -15 to +45°C (+5 to +113°F)
Operating/Storage
Humidity 0 - 95% Non-Condensing
Operating Elevation 0 to 3000m (0 to +10,000 ft)
Storage Elevation 0 to 15,000m (0 to +50,000 ft)
PHYSICAL
Size – Net L X W X H
(
rackmount brackets installed
)
17.32 x 18.96 x 3.48"
440 x 481.6 x 88.5 mm
23.62 x 18.96 x 3.48"
600 x 481.6 x 88.5 mm
Weight - Net 41.7 lbs
18.9 Kgs
41.7 lbs
18.9 Kgs
43.0 lbs
19.5 Kgs
71.9 lbs
32.6 Kgs
77.6 lbs
35.2 Kgs
Size - Shipping
L X W X H
23.67 x 21.89 x 9.76"
601 x 556 x 248 mm
31.50 x 23.46 x 9.37"
800 x 596 x 238 mm
Weight - Shipping 51.4 lbs
23.3 Kgs
51.4 lbs
23.3 Kgs
52.7 lbs
23.9 Kgs
91.1 lbs
41.3 Kgs
96.8 lbs
43.9 Kgs
REGULATORY COMPLIANCE
Safety and Approvals
cULus (UL1778 5th Edition & CSA 22.2 no. 107.3-14 / R: 2014), FCC
Class B, CE & NOM certified, EnergyStar, RoHS2 (EU Directive
2011/65/EU & 2015/863/EU)
Specifications are subject to change without prior notice.
29
Chapter 10: Limited Product Warranty
Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and
operated within specified conditions, against faulty materials or workmanship for a period
of three years from the date of purchase. For equipment sites within the United States
and Canada, this warranty covers depot repair or replacement of defective equipment at
the discretion of Para Systems. Depot repair will be from the nearest authorized service
center. The customer pays for shipping the product to Para Systems. Para Systems
pays ground freight to ship the product back to the customer. Replacement parts and
warranty labor will be borne by Para Systems. For equipment located outside of the
United States and Canada, Para Systems only covers faulty parts. Para Systems
products that are depot repaired or replaced pursuant to this warranty shall only be
warranted for the unexpired portion of the warranty applying to the original product. This
warranty applies only to the original purchaser who must have properly registered the
product within 10 days of purchase.
The warranty shall be void if (a) the equipment is damaged by the customer, is improperly
used, is subjected to an adverse operating environment, or is operated outside the limits
of its electrical specifications; (b) the equipment is repaired or modified by anyone other
than Para Systems or Para Systems approved personnel; or (c) has been used in a
manner contrary to the product’s User's Manual or other written instructions.
Any technical advice furnished before or after delivery in regard to use or application of
Para Systems’ equipment is furnished without charge and on the basis that it represents
Para Systems’ best judgment under the circumstances, but it is used at the recipient’s
sole risk.
EXCEPT AS PROVIDED HEREIN, PARA SYSTEMS MAKES NO WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation of
implied warranties; therefore, the aforesaid limitation(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL PARA SYSTEMS BE LIABLE
FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE. Specifically, Para Systems is not liable for any
costs, such as; labor for on-site installation, on-site maintenance or on-site service, lost
profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of
data, cost of substitutes, claims by third parties, or otherwise. The sole and exclusive
remedy for breach of any warranty, expressed or implied, concerning Para Systems’
products and the only obligation of Para Systems hereunder, shall be depot repair or
replacement of defective equipment, components, or parts; or, at Para Systems’ option,
refund of the purchase price or substitution with an equivalent replacement product. This
warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
No employee, salesman, or agent of Para Systems is authorized to add to or vary the
terms of this warranty.
Please go to our website at www.minutemanups.com/warranty/ to fill out the Warranty
Registration.

30
A1. Declaration of Conformity
Application of Council Directive(s): 2014/30/EU
Standard(s) to which Conformity is declared: EN61000-3-2, EN61000-3-3,
EN62040-2, IEC61000-2-2 IEC61000-4-2, IEC61000-4-3, IEC61000-4-4,
IEC61000-4-5, IEC61000-4-6, IEC61000-4-8, IEEE C62.41 Category A1,
UL1778, CSA 22.2 no. 107.3-14, FCC Class B
Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS)
Manufacturer’s Address: 1455 LeMay Drive, Carrollton, Texas 75007 (USA)
Type of Equipment: Uninterruptible Power Supplies (UPS)
Model No: EXR750RT2U (Y), EXR1000RT2U (Y), EXR1500RT2U (Y),
EXR2000RT2U (Y), EXR3000RT2U (Y), EXR1500RTHV (Y),
EXR3000RTHV (Y)
Year of Manufacture: Beginning October 2020
I hereby declare that the equipment specified above conforms to the above
Directive(s).
Robert Calhoun Manager Engineering
(Name) (Position)
Place: Carrollton, Texas, USA Date: October 1, 2020
31
Notes:
