Paradox Digiplex DGP2PS17-EI01 User manual
Power Supply Module V1.0
(DGP2-PS17)
Instructions
DGP2PS17-EI01
I
NTRODUCTION
The Power Supply Module (DGP2-PS17) is a fully supervised 1.7A switching
power supply that is connected to the communication network of the Digiplex
(DGP-48) or DigiplexNE (DGP-NE96) control panel.
I
NSTALLATION
The DGP2-PS17 is connected to the control panel's communication
network in a star and/or daisy chain configuration. This 4-wire
communication network provides power and two-way communication
between the control panel and all modules connected to it. Connect the four
terminals labeled red, black, green and yellow of the DGP2-PS17 to the
corresponding terminals on the control panel as shown in Figure 1 (refer to
reverse side). Connect the 5A PGM output of the DGP2-PS17 as shown in
Figure 1, Inset 2 (refer to reverse side).
A
UXILIARY
O
UTPUT
The DGP2-PS17’s auxiliary output provides up to 12Vdc. Connect devices
to the auxiliary terminals as shown in Figure 1 (refer to reverse side). A
fuseless circuit protects the auxiliary output against current overload and
autimatically shuts down if the current exceeds 1.1A.
P
ROGRAMMING
M
ETHOD
To program the DGP2-PS17, you must enter the “Module Programming
Mode” using any keypad in the system:
1) Press and hold the [0] key.
2) Key in the [INSTALLER CODE].
3) Key in section [953] (DGP-48) / [4003] (DGP-NE96).
4) Key in the DGP2-PS17’s 8-digit [SERIAL NUMBER].
5) Key in the 3-digit [SECTION]you wish to program.
6) Turn the desired option ON/OFF or key in the required data.
Please note that the serial number is located on the DGP2-PS17’s PC
board. The DGP2-PS17 can also be programmed using the control panel’s
Module Broadcast feature as well as through the WinLoad Software (V2.0
or higher). Refer to the Digiplex or DigiplexNE Reference & Installation
Manual for more information on the Module Broadcast feature and to
WinLoad’s Online Help for information on programming with WinLoad.
The DGP2-PS17 does not come equipped with a tamper switch. If your
installation requires tamper recognition, enable this feature and connect a
tamper switch as shown in Figure 1, Inset 1 (refer to reverse side). When a
tamper is detected on the module, it will send a tamper report to the control
panel via the communication network. Default: Option [1] is OFF.
Turning option [2] ON will set the battery charging current at 700mA.
Turning option [2] OFF will set the battery charging current at 350mA. A
battery charging current of 350mA will require more time to charge the
battery compared to 700mA but will consume less power from the module
itself. Default: Option [2] is OFF.
When the PGM Activation Event occurs, this option determines when the
PGM will return to its normal state (deactivate). When option [3] is ON, the
PGM will deactivate when the PGM Timer programmed in section [003] has
elapsed. When option [3] is OFF, the PGM will deactivate when the PGM
Deactivation Event programmed in sections [008] to [011] occurs.
Default: Option [3] is OFF.
If the PGM Deactivation Option (section [001] option [3]) is set to follow the
PGM Timer,you must define whether the PGM Timer programmed in
section [003] is in minutes or seconds. If option [4] is ON, the PGM Timer
will be in minutes. If option [4] is OFF, the PGM Timer will be in seconds.
Default: Option [4] is OFF.
If the PGM Deactivation Option (section [001] option [3]) is set to follow the
PGM Timer, the value programmed in section [003] represents how long
the PGM will remain in its opposite state after being activated. To program
the timer, enter a 3-digit decimal value (001-255) into section [003], where
this value is multiplied by the PGM Base Time Selection (section [001]
option [4]) of 1 second or 1 minute. Default: 005.
The PGM Activation Event determines which event will activate the DGP2-
PS17’s on-board PGM output. The Event Group specifies the event, the
Feature Group identifies the source, and the Start # and End # sets the
range within the Feature Group. Use the PGM Programming Table in the
Digiplex/DigiplexNE Modules Programming Guide to program the DGP2-
PS17 PGM Activation Event. Enter the sections that correspond to the
Event Group, Feature Group, Start # and End # of the PGM and enter the
required data.
Only Event Groups 000 to 055 can be used to program the
DGP2-PS17’s PGM Activation Event.
If the PGM Deactivation Option is set to follow the PGM Deactivation Event
(Section [001] option [3]), the PGM will return to its normal state when the
event programmed in sections [008] to [011] occurs. The Event Group
specifies the event, the Feature Group identifies the source, and the Start #
and End # sets the range within the Feature Group. Use the PGM
Programming Table in the Digiplex/DigiplexNE Modules Programming
Guide to program the DGP2-PS17 PGM Deactivation Event. Enter the
sections that correspond to the Event Group, Feature Group, Start # and
End # of the PGM and enter the required data.
Only Event Groups 000 to 055 can be used to program the
DGP2-PS17’s PGM Deactivation Event.
Section [001] - Option [1]
Tamper Recognition
Section [001] - Option [2]
Battery Charging Current
Section [001] - Option [3]
PGM Deactivation Option
Section [001] - Option [4]
PGM Base Time Selection
Section [003]
PGM Timer
Sections [004] to [007]
PGM Activation Event
Event Group Feature Group Start # End #
PGM [004] [005] [006] [007]
Sections [008] to [011]
PGM Deactivation Event
Event Group Feature Group Start # End #
PGM [008] [009] [010] [011]
Entering section [020] will activate the PGM for 8 seconds to verify if the
PGM is functioning properly.
The value programmed in section [002] represents how long the Power
Supply Module will wait before reporting an AC power failure to the control
panel. To program the timer, enter a 3-digit decimal value (000 to 255
minutes) into section [002]. Default: Instant reporting (000).
S
PECIFICATIONS
AC Power: 16Vac, 20/40VA, 50 - 60Hz
Aux. Power: 12Vdc, typical 600mA, 700mA max.
Battery: 12Vdc, 4Ah minimum
Number of Outputs: 1 form “C” relay rated @ 125V, 5A receptive load
Control Panel
Compatibility: Any Digiplex (DGP-48) or DigiplexNE (DGP-NE96)
Specifications may change without prior notice.
Section [020]
PGM Test Mode
Section [002]
AC Failure Report Delay
Figure 1: Connecting the DGP2-PS17
PRINTED IN CANADA - 04/2002
