BitStorm™6051 POTS Splitter
Installation Instructions
Document Number 6051-A2-GZ40-00
April 2002
About the BitStorm 6051 POTS Splitter
The BitStorm™ system enables simultaneous high-speed digital data access and
analog voice service over the same twisted-pair telephone line. The BitStorm 6051
POTS (plain old telephone service) splitter card separates the DSL (Digital
Subscriber Line) and POTS frequencies. It provides service to up to 24 DSL ports.
POTS Splitter Chassis
The BitStorm POTS splitter card is mounted in a POTS splitter chassis. Two
chassis models are available:

Chassis Model 5011 – 1-slot chassis which can be placed on a tabletop or
installed in a rack.

Chassis Model 5016 – 6-slot chassis which must be installed in a commercial
EIA-standard 19″or 23″rack or cabinet.
DSL Interface
Loop Interface
PSTN Interface
02-17152
POTS
Splitter Card

2April 2002 6051-A2-GZ40-00
Product-Related Documents
Refer to the following documents for information about the BitStorm 4800 IP
access concentrator.
Contact your sales or service representative to order additional product
documentation.
Paradyne documents are also available on the World Wide Web at
www.paradyne.com. Select
Library
→
Technical Manuals
→
BitStorm DSL
Products.
Installation Overview
Installation of the POTS splitter card requires the following steps:
❑Determining the cables you need
❑Preparing the installation location and checking the package contents
❑Installing the POTS splitter chassis
❑Inserting the POTS splitter card(s) into the chassis
❑Connecting the cabling from the POTS splitter card connectors to the
BitStorm 4800, local loop, and in-building wiring
❑Securing the cables
Be sure to register your warranty at www.paradyne.com/warranty.
Document Number Document Title
4800-A2-GB20
BitStorm 4800 User’s Guide
4800-A2-GN10
BitStorm 4800 Management Module Installation
Instructions
4821-A2-GN20
BitStorm 4800 Installation Guide

6051-A2-GZ40-00 April 2002 3
Cables You Need
The POTS splitter card has three interfaces and each of the three POTS Splitter
card connectors requires a 50-conductor cable with a 50-pin Telco connector. Use
a minimum of 24 AWG.
Each DSL port at the BitStorm 4800 uses one pair of copper wires out of the
25 pairs on each 50-position connector. To use all 48 ports, two POTS splitter
cards and six cables are required.
Preparation
The installation location should be well ventilated, clean, and free of environmental
extremes. Allow clearance at the front of the POTS splitter chassis to provide
access to the cables.
Read the
Important Safety Instructions
on page 17.
Tools Required

A small #1 or #2 Phillips screwdriver to tighten the POTS splitter card
fasteners.

A large #3 or #4 Phillips screwdriver to install the chassis into a rack.

A flat-blade screwdriver to install the chassis grounding wire.
POTS Splitter Card Package Checklist
Verify that your POTS splitter card package contains the following:
❑BitStorm 6051 POTS splitter card
❑Plastic bag with three of each item:
—Plastic tie-wrap anchors
—#4-40 x 1/4″screws
—#4-40 x 1/4″jack screws
—8″cable tie wraps

4April 2002 6051-A2-GZ40-00
1-Slot 5011 POTS Splitter Chassis Package Checklist
Verify that your 1-slot POTS splitter chassis package contains the following:
❑1-slot POTS splitter chassis
❑Two brackets for 19″racks and two brackets for 23″racks
❑Small plastic bag with:
—Six #10-32 x 1/4″Phillips flat-head mounting screws
—Four #10-32 x 1/2″Phillips-head mounting screws
—Four #12-24 x 1/2″Phillips-head mounting screws
—Four #12-24 self-retaining nuts
—Four black rubber feet
NOTE:
If your 1-slot 5011 POTS splitter chassis is being placed on a tabletop, install
the rubber feet as shown above. Discard the rubber feet for a rack-mounted
chassis.
02-17153
POTS Splitter
1-Slot Chassis
Placement of
Rubber
Feet

6051-A2-GZ40-00 April 2002 5
6-Slot 5016 POTS Splitter Chassis Package Checklist
Verify that your 6-slot POTS splitter chassis package contains the following:
❑6-slot POTS splitter chassis with five filler panels. Each filler panel is attached
to the chassis with two 1/4-turn fasteners. Keep filler panels installed in all
unused slots.
❑Two brackets for 483 mm (19″)racks and two brackets for 584 mm (23″)racks
❑Small plastic bag with:
—Six #10-32 x 1/4″Phillips flat-head mounting screws
—Four #10-32 x 1/2″Phillips-head mounting screws
—Four #12-24 x 1/2″Phillips-head mounting screws
—Four #12-24 self-retaining nuts
—Four black rubber feet (discard)
02-17154
POTS Splitter
6-Slot Chassis
Filler
Panels
TM

6April 2002 6051-A2-GZ40-00
POTS Splitter Chassis Installation
Both the POTS splitter chassis and the BitStorm 4800 are shipped with mounting
brackets that allow them to be mounted in a 483 mm (19″)or 584 mm (23″)
cabinet or rack.
In preparation for bracket and chassis installation, determine:

Whether the BitStorm 4800 will be rack-mounted.

Width of the rack: 483 mm (19″)or 584 mm (23″).

Chassis position in the rack: center-mounted or front-mounted.
Center-mounting is recommended for convenient access to cables.

Whether the rack has mounting rails with threaded or non-threaded screw
holes.
NOTE:
Install chassis in the rack from the bottom up to maintain stability.
02-17158
DSLPORTS1-24
DSL PORTS 25-48
UPLINK
GigE DOWNLINK
GigE
STACKPOSITION
Front
Rear
POTS Splitter
Card in 1-Slot
Chassis
BitStorm 4800

6051-A2-GZ40-00 April 2002 7
Installing the Brackets
The brackets can be installed in the chassis in a center-mounted or front-mounted
configuration. Mounting holes are provided in the chassis for either configuration.
Install the appropriate 483 mm (19″) or 584 mm (23″)brackets on the 1-slot or
6-slot chassis.
Select one of the next two procedures for chassis installation in a rack.
19-Inch Rack
23-Inch Rack
99-15486-02
1-Slot Chassis
19-Inch Rack
23-Inch Rack
99-15434-02
Front Mount
Center Mount
6-Slot Chassis

8April 2002 6051-A2-GZ40-00
Installation into a Rack without Threaded Screw Holes
Procedure
After installing the appropriate brackets on the chassis:
1. Determine where the chassis will be placed in the rack. Mark the front rail
where the four holes in the mounting brackets will be.
2. Slide a self-retaining nut onto each marked rail hole and align the hole of the
nut with the hole in the rail.
3. Line up the chassis mounting brackets with the self-retaining nuts.
4. Loosely install the bottom screws first and then the top screws.
5. Tighten all screws firmly using a Phillips screwdriver.
Repeat the process for each POTS splitter chassis. POTS splitter chassis can be
mounted directly on top of each other.
Front Rail
00-15436-02
Screw
Self-Retaining
Nut

6051-A2-GZ40-00 April 2002 9
Installation into a Rack with Threaded Screw Holes
Procedure
After installing the appropriate brackets on the chassis:
1. Determine where the chassis will be placed in the rack.
2. Line up the chassis mounting brackets with the front rail holes.
3. Loosely install the bottom screws first and then the top screws.
4. Tighten all screws firmly with a Phillips screwdriver.
Repeat the process for each POTS splitter chassis. POTS splitter chassis can be
mounted directly on top of each other.
Front Rail
99-15435-01
Screw

10 April 2002 6051-A2-GZ40-00
Installing the Ground Wire
To comply with Network Equipment Building System (NEBS) requirements, the
ground wire must be installed.
Procedure
1. Obtain copper wire of appropriate wire gauge:
2. Strip back the insulation approximately 6 mm (1/4″) on the copper wire.
3. Locate the grounding lug on the chassis:
4. Loosen the screw on the
grounding lug.
5. Insert the stripped end of the
wire into the open end of the
grounding lug and tighten the
lug’s screw. Make sure that
the screw is making contact
with the stripped portion of
the wire.
If you have a . . . Then the ground wire gauge must be . . .
1-slot 5011 chassis 10–14 AWG.
6-slot 5016 chassis 6–14 AWG.
If you have a . . . Then the grounding lug is . . .
1-slot chassis On the rear of the chassis on the left.
6-slot chassis On the front of the chassis on the top right.
POTS Splitter
1-Slot Chassis
TM
02-17155
POTS Splitter
6-Slot Chassis
98-15879-01
