Paradyne Hotwire 7995 User manual

HotwireTDM SHDSL Endpoints
Models 7995 and 7996
User’s Guide
Document No. 7990-A2-GB20-00
May 2002

AMay 2002 7990-A2-GB20-00
Copyright © 2002 Paradyne Corporation.
All rights reserved.
Printed in U.S.A.
Notice
This publication is protected by federal copyright law. No part of this publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form or
by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the express
written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773.
Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation
reserves the right to revise this publication and to make changes from time to time in the contents hereof without
obligation of Paradyne Corporation to notify any person of such revision or changes.
Changes and enhancements to the product and to the information herein will be documented and issued as a new
release to this manual.
Warranty, Sales, Service, and Training Information
Contact your local sales representative, service representative, or distributor directly for any help needed. For additional
information concerning warranty, sales, service, repair, installation, documentation, training, distributor locations, or
Paradyne worldwide office locations, use one of the following methods:

Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at
www.paradyne.com/warranty.)

Telephone: Call our automated system to receive current information by fax or to speak with a company
representative.
— Within the U.S.A., call 1-800-870-2221
— Outside the U.S.A., call 1-727-530-2340
Document Feedback
We welcome your comments and suggestions about this document. Please mail them to Technical Publications,
Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to [e-mail]. Include the
number and title of this document in your correspondence. Please include your name and phone number if you are
willing to provide additional clarification.
Trademarks
ACCULINK, COMSPHERE, FrameSaver, Hotwire, MVL, NextEDGE, OpenLane, and Performance Wizard are
registered trademarks of Paradyne Corporation. GranDSLAM, ReachDSL, and TruePut are trademarks of Paradyne
Corporation. All other products and services mentioned herein are the trademarks, service marks, registered
trademarks, or registered service marks of their respective owners.

7990-A2-GB20-00 May 2002 i
Contents
About This Guide

Document Purpose and Intended Audience . . . . . . . . . . . . . . . . . . . . v

Document Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v

Product-Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
1 About the TDM SHDSL Endpoint

TDM SHDSL Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

TDM SHDSL Endpoint Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Front Panel LED Status Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Rear Panel Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

SNMP Management Capabilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Management Information Base (MIB) Support . . . . . . . . . . . . . . . 1-6
SNMP Trap Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
2 Using the Asynchronous Terminal Interface

User Interface Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Communication Port Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Initiating an ATI Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Menu Hierarchy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Screen Work Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Navigating the Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Keyboard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Switching Between Screen Work Areas . . . . . . . . . . . . . . . . . . . . 2-8

Ending an ATI Session. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Contents
ii May 2002 7990-A2-GB20-00
3 Initial Startup and Configuration

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Connecting Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Connecting to an Optional External DC Power Source. . . . . . . . . 3-2

Connecting to the Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Connecting to a DTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Connecting to a System Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Entering Identity Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Choosing a Configuration Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Configuring the Unit Using Configuration Menus. . . . . . . . . . . . . . . . . 3-7

Accessing and Displaying Configuration Options . . . . . . . . . . . . . . . . 3-8
Current and Default Factory Configurations . . . . . . . . . . . . . . . . . 3-9
Configuration Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11

Saving Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

Resetting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14

Adaptive Rate Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Setting the DSL Line Rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

Downloading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
4 Configuring the Unit Using the Internal Switches

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Configuring the Unit Using Internal Switches. . . . . . . . . . . . . . . . . . . . 4-2
Switchpack Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Model 7995 Switchpack Definitions. . . . . . . . . . . . . . . . . . . . . . . . 4-4
Model 7996 Switchpack Definitions. . . . . . . . . . . . . . . . . . . . . . . . 4-6
5Security

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

ATI Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Creating a Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Deleting a Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Resetting the Unit's COM Port or Factory Defaults . . . . . . . . . . . . . . . 5-5

Controlling SNMP Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Assigning SNMP Community Names and Access Types . . . . . . . 5-6
Limiting SNMP Access through the IP Addresses of the
Managers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Contents
7990-A2-GB20-00 May 2002 iii
6 Monitoring and Troubleshooting

What to Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Viewing System and Test Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Health and Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Self-Test Results Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Test Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Entry Response Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Viewing DSL Error Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

Viewing DSL Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

Viewing G.703 Performance Statistics (Model 7996). . . . . . . . . . . . . . 6-14

Viewing Current DSL Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16

Using the Display LEDs Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18

Front Panel LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19

Viewing Identity Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21
7Testing

Accessing the Test Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Running DSL Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
DSL Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
G.703 Repeater Loopback (Model 7996) . . . . . . . . . . . . . . . . . . . 7-4
G.703 DTE Loopback (Model 7996) . . . . . . . . . . . . . . . . . . . . . . . 7-5
Remote Send Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6

SYNC Data Port Tests (Model 7995). . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Data Terminal Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Data Channel Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Repeater Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Send Remote Data Channel Loopback. . . . . . . . . . . . . . . . . . . . . 7-11

Device Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Lamp Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

Ending an Active Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
A Configuration Options

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

DSL Interface Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

DSL Port Threshold Trap Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

Synchronous Data Port Options for Model 7995 . . . . . . . . . . . . . . . . . A-8

Contents
iv May 2002 7990-A2-GB20-00

G.703 Interface Options for Model 7996 . . . . . . . . . . . . . . . . . . . . . . . A-12

System Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-14

Communication Port Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17

Management and Communication Options Menu . . . . . . . . . . . . . . . . A-21
Telnet Session Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-21
Communication Protocol Options . . . . . . . . . . . . . . . . . . . . . . . . . A-23
General SNMP Management Options . . . . . . . . . . . . . . . . . . . . . . A-26
SNMP NMS Security Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28
SNMP Traps Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30
B Standards Compliance for SNMP Traps

SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
ifIndex Variable Binding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
warmStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
authenticationFailure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
linkUp and linkDown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Enterprise-Specific Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
C Connectors, Cables, and Pin Assignments

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Power Input Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

COM Port Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

COM Port-to-PC Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

COM Port-to-LAN Adapter Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4

G.703 Network Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5

EIA-530-A Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6

EIA-530-A-to-X.21 Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7

EIA-530-A-to-RS-449 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9

EIA-530-A-to-V.35 Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-11

DSL Network Interface Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-13
D Technical Specifications
Index

7990-A2-GB20-00 May 2002 v
About This Guide
Document Purpose and Intended Audience
This guide contains information needed to set up, configure, and operate the
Hotwire Time Division Multiplexer Symmetric High-bit-rate Digital Subscriber Line
(TDM SHDSL) Endpoint, Models 7995 and 7996, and is intended for installers and
operators.
Document Summary
Section Description
Chapter 1, About the TDM
SHDSL Endpoint
Describes the unit’s features and capabilities.
Chapter 2,
Using the
Asynchronous Terminal Interface
Provides instructions for accessing the user interface
and navigating through the screens.
Chapter 3,
Initial Startup and
Configuration
Provides procedures for setting up the user interface
and for configuring the unit using the asynchronous
terminal interface.
Chapter 4,
Configuring the Unit
Using the Internal Switches
Provides procedures for configuring the unit using the
internal switches instead of the asynchronous
terminal interface.
Chapter 5,
Security Presents procedures for creating a login, setting the
effective access levels, and controlling SNMP
access.
Chapter 6,
Monitoring and
Troubleshooting
Describes using the LEDs, status messages, and
network statistics to monitor the unit and detect and
correct problems.
Chapter 7,
Testing Provides information about available tests and test
setup.
Appendix A,
Configuration
Options
Contains all configuration options, possible settings,
and default settings.
Appendix B,
Standards
Compliance for SNMP Traps
Contains SNMP trap compliance information.
Appendix C,
Connectors, Cables,
and Pin Assignments
Contains connector and interface information.

About This Guide
vi May 2002 7990-A2-GB20-00
A master glossary of terms and acronyms used in Paradyne documents is
available online at www.paradyne.com. Select
Library
→
Technical Manuals
→
Technical Glossary.
Product-Related Documents
Complete documentation for this product is available online at
www.paradyne.com. Select
Library →Technical Manuals →Hotwire DSL
Systems
.
To order a paper copy of a Paradyne document:

Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

Outside the U.S.A., call 1-727-530-8623
Appendix D,
Technical
Specifications
Contains physical and regulatory specifications,
network and port interfaces, power consumption
values, and accessory part numbers.
Index
Lists key terms, acronyms, concepts, and sections in
alphabetical order.
Section Description
Document Number Document Title
7990-A2-GN10
Hotwire TDM SHDSL Endpoints, Models 7995 and 7996,
Installation Instructions
8799-A2-GB20
Hotwire 8799 TDM SHDSL Line Card with G.703 Interface
User's Guide

7990-A2-GB20-00 May 2002 1-1
1
About the TDM SHDSL Endpoint
TDM SHDSL Overview
Hotwire®Time Division Multiplexer Symmetric High-bit-rate Digital Subscriber Line
(TDM SHDSL) products maximize customer service areas by varying the DSL line
rate. This ensures symmetric DSL connectivity over a wide range of telephone line
distances and transmission line qualities.
Hotwire products support autorate. Units first synchronize to the highest line rate
that the 2-wire loop supports, then automatically configures the unit to the highest
multiple of 64 Kbps supported by that line rate. Thirty-one line rates are available.
At all rates, a 3 Kbps Embedded Operations Channel (EOC) is available, which
enables functions such as firmware downloads to remote units. Units can also be
configured manually to full or fractional E1 rates.
Hotwire products transport data over a 2-wire, full-duplex circuit over varying
distances based on the conditions of the loop. Using 24 AWG cable, these
TDM SHDSL products have a loop reach greater than 15,000 feet (4.6 km) at
2.048 Mbps.

1. About the TDM SHDSL Endpoint
1-2 May 2002 7990-A2-GB20-00
TDM SHDSL Endpoint Features
Hotwire TDM SHDSL Models 7995/7996 are endpoints for the chassis-mounted
Hotwire 8799 Line Card that is housed in the Hotwire 8600 or 8800 Series Digital
Subscriber Line Access Multiplexer (DSLAM).
Two Hotwire TDM SHDSL endpoints can also be configured to operate in a central
office SHDSL Transceiver Unit, Central Site (STU-C)-to-customer premises
SHDSL Transceiver Unit, Remote Terminal Site (STU-R) environment.
Hotwire TDM SHDSL endpoints have these standard features:

Embedded Operations Channel (EOC). Provides remote management and
download capabilities via an SNMP or Telnet session over the DSL network on
a 3 Kbps channel.

Asynchronous Terminal Interface (ATI). Provides a menu-driven
VT100-compatible terminal interface for configuring and managing the
endpoint locally or remotely by Telnet session.

Local Management (endpoint). Provides local management using a:
—Terminal or equivalent through the COM port of the unit
—Telnet through the COM port of the unit

Remote Management (DSLAM card). Provides remote management using:
—VT100-compatible terminal or PC via the Management Serial port of the
DSLAM
—NMS through the MCC 10BaseT port of the DSLAM
—Telnet over the EOC

Alarm Indication. Provides front panel status LEDs.

Diagnostic Testing. Provides the capability to diagnose device and network
problems and perform digital loopbacks, pattern tests, and self-test.

Device and Performance Monitoring. Provides the capability of tracking and
evaluating the unit’s operation, including health and status, and error-rate
monitoring.

SNMP (Simple Network Management Protocol) Management. Provides
network management via an industry-standard SNMP management system.

Automatic Configuration Capability. Simply connecting the units to the line
automatically configures the customer for the maximum data rate supported
by the local loop. Units can also be configured at fixed line speeds to achieve
maximum distances.

1. About the TDM SHDSL Endpoint
7990-A2-GB20-00 May 2002 1-3
Network Configuration
Figure 1-1, Sample Configurations, shows a network application using a DSLAM
in a central office (CO). In this configuration, a frame relay switch and router are
connected through the endpoint to partner units supporting a host or router and
frame relay encapsulated or unframed data. The figure also shows a
standalone-to-standalone configuration. Supported standalone-to-
standalone configurations are shown in Table 1-1, Supported Standalone
STU-R/STU-C Combinations.
Figure 1-1. Sample Configurations
Table 1-1. Supported Standalone STU-R/STU-C Combinations
STU-C (CO):
STU-R (CP)
Synchronous G.703 Framed G.703 Unframed
Synchronous ✓Not Supported Not Supported
G.703 Framed ✓✓ Not Supported
G.703 Unframed ✓Not Supported ✓
✓=Supported
Frame
Relay
Switch
Router
T1 Host
(Frame Relay
Encapsulated
Data)
02-17056
Router
(Frame Relay
Encapsulated
Data)
Router
8799 Line Card
in DSLAM
CO Site
799x
799x
799x
799x 799x
CP
STU-R
CO Site
STU-C
DSL
Customer Premises (CP)
DSL
DSL
G.703 or V.35
DSL
STU-C STU-R

1. About the TDM SHDSL Endpoint
1-4 May 2002 7990-A2-GB20-00
Front Panel LED Status Indicators
Figure 1-2 and Figure 1-3 show the front panels of the Hotwire TDM SHDSL
Endpoints. For more information about the front panel LEDs, refer to
Front Panel
LEDs
in Chapter 6,
Monitoring and Troubleshooting
.
Figure 1-2. Hotwire 7995 TDM SHDSL Endpoint with Synchronous Interface
Front Panel
Figure 1-3. Hotwire 7996 TDM SHDSL Endpoint with G.703 Interface
Front Panel
POWER ALARM TEST DSL DTE
7995TDM SHDSL
TM
®
01-17053
POWER ALARM TEST DSL G.703
7996TDM SHDSL
TM
01-17054

1. About the TDM SHDSL Endpoint
7990-A2-GB20-00 May 2002 1-5
Rear Panel Interfaces
Figure 1-4 and Figure 1-5 show the physical interfaces of the endpoints. For more
information about the rear panel interfaces, refer to Appendix C,
Connectors,
Cables, and Pin Assignments
.
Figure 1-4. Hotwire 7995 TDM SHDSL Endpoint with Synchronous Interface
Rear Panel
Figure 1-5. Hotwire 7996 TDM SHDSL Endpoint with G.703 Interface
Rear Panel
POWER DSLCOM
00-15880-01
PORT
O
I
POWER DSLCOM TX RX
G.703
75Ω120Ω
00-16005-01
O
I

1. About the TDM SHDSL Endpoint
1-6 May 2002 7990-A2-GB20-00
SNMP Management Capabilities
Hotwire Model 7995/7996 endpoints support SNMP Version 1, and can be
managed by any industry-standard SNMP manager and accessed by external
SNMP managers using SNMP.
Management Information Base (MIB) Support
For a detailed description of the supported MIBs, visit Paradyne’s Web site at
www.paradyne.com. Select
Technical Support
→
Online Support
→
MIBs.
The following MIBs are supported:

MIB II (RFC 1213 and RFC 2863 (was 1573)) –Defines the general objects
for use with a network management protocol in TCP/IP internets and provides
general information about the unit. MIB II is backward-compatible with MIB I.


Entity MIB (RFC 2037) –Supports all DSLAM cards.

DS1/E1/DS2/E2 MIB (RFC 2495 (was 1406)) –Reports the performance
status of the interface and supports the features found on the Performance
Statistics screen.

RS-232-Like MIB (RFC 1659) –Defines objects for managing RS-232-type
interfaces (e.g., V.35, RS-422, RS-423, etc.) and supports the synchronous
data port on the DSU.

Paradyne Enterprise MIB –Supports configuration, status, statistics, and
tests.

SHDSL MIB (draft-ietf-adslmib-hdsl2.txt) –Supports SHDSL.

1. About the TDM SHDSL Endpoint
7990-A2-GB20-00 May 2002 1-7
SNMP Trap Support
The Hotwire Model 7995/7996 Endpoint supports traps as defined in RFC 1215.
Figure 1-6, DSL SNMP Configuration, illustrates a typical DSL SNMP
configuration. Figure 1-7, DSL Local SNMP Configuration, shows a DSL SNMP
configuration where the NMS is connected directly to the endpoint’s
Communications Port. Figure 1-8, Peer IP Address Assignment, shows an
example of an IP addressing scheme.
Figure 1-6. DSL SNMP Configuration
Figure 1-7. DSL Local SNMP Configuration
Figure 1-8. Peer IP Address Assignment
01-17057
DSLAM
Network
799x
AC
INPUT
AC
48VDCCLASS 2 OR
LIMITEDPWR SOURCE
RTN48V
AAB B
T5A
2
46
AB
.
.
.
3.
1
2
POSITION
STACKALM A
IN
B
DCFUSES
T4A,MIN. 48V 5DC PWR
FAN
OUT SERIAL MCC 1 3
1
2
3
SYSTEM
OKAlrm Test
250V
SYSTEM
OKAlrm
Test 1234
G.703ALRM
DSLPORT
LINK-UP
1234
SYSTEM
OKAlrm
Test 1234
G.703ALRM
DSLPORT
LINK-UP
SDSL
8715
1234
Router
SNMP NMS
Ethernet
Interface
DSL
EOC Data
Operation, Maintenance
and Provisioning Center
Ethernet
LAN
1234
G.703ALRM
DSLPORT
LINK-UP
1234
8799
01-17058
799x
SNMP NMS
DSL
EOC
Router Router
799x COM
02-17207
799x
SNMP NMS
Peer IP Address
125.35.1.17
EOC
Router STU-C
PPP
STU-R
799x
Router
LAN Adapter
Node Address
126.35.1.16

1. About the TDM SHDSL Endpoint
1-8 May 2002 7990-A2-GB20-00

7990-A2-GB20-00 May 2002 2-1
2
Using the Asynchronous
Terminal Interface
User Interface Access
You can communicate with the Hotwire TDM SHDSL endpoint with an
asynchronous terminal interface (ATI) using one of the following methods:

Direct connection through the COM port of the endpoint or through the serial
port of the DSLAM management card.

Telnet session through the Embedded Operations Channel (EOC).
NOTE:
Only one terminal interface session can be active at a time, and another user’s
session cannot be forced to end.
Security can limit ATI access several ways. To limit user access or set up login
IDs, refer to Chapter 5,
Security
.
Communication Port Settings
Ensure that the device you connect communicates using these settings:

Data rate set to 9.6 Kbps

Character length set to 8

Parity set to None

Stop Bits set to 1

2. Using the Asynchronous Terminal Interface
2-2 May 2002 7990-A2-GB20-00
Initiating an ATI Session
The Main Menu screen is displayed unless a login ID and password is required or
the ATI is already in use.
If the ATI is already in use, you will see:

A connection refused or connection failed message (if you are
using a Telnet session), or

The IP address of the other user (if you are using the Management Serial
port).
If security is enabled on the unit and you used Telnet to access it directly (you did
not log in through the DSLAM management card), the system prompts you for a
login ID and password.
Login
Model: 799x
LOGIN
Login ID:
Enter Password:
--------------------------------------------------------------------------------
Ctrl-a to access these functions Exit

2. Using the Asynchronous Terminal Interface
7990-A2-GB20-00 May 2002 2-3
After you enter a valid login ID and password, the Main Menu appears. If you enter
an invalid login ID and password after three attempts, the Telnet session closes or
the terminal connection returns to an idle state. Refer to Chapter 5,
Security
.
Entry to all of the TDM SHDSL endpoint’s tasks begins at the Main Menu screen.
The four branches of the Main Menu are as follows:
After selecting an option, what appears on the screens depends on the:

Current configuration –How your unit is currently configured.

Effective security access level –An access level that is typically set by the
system administrator for each interface and each user.

Data selection criteria –What you entered in previous screens.
main Access Level: Administrator
Model 799x
MAIN MENU
Status
Test
Configuration
Control
--------------------------------------------------------------------------------
Ctrl-a to access these functions Exit
Screen
Area
Function Keys
and
Message Area
Select . . . To . . .
Status View system status, diagnostic test results, statistics, LEDs, and device
identity information.
Test Select and cancel tests for the endpoint’s interfaces.
Configuration Display and edit the configuration options.
Control Change the device identity, administer logins, download new firmware, or
initiate a power-on reset of the endpoint.

2. Using the Asynchronous Terminal Interface
2-4 May 2002 7990-A2-GB20-00
Menu Hierarchy
The following illustration shows the menu paths to the different ATI screens.
Main
Status Test
System and
Test Status Performance Statistics Display LEDs Identity
DSL
Error
StatisticsDSL
Performance
Statistics
Configuration Control
Factory
Config
Configuration
Loader
Current Configuration
Edit/Display
System
Options Communication Port Management and
Communication
Change
Identity
Administer
Logins
Download
Code Apply
Download
Reset
Device
Device
Tests
Abort
All
Tests
02-17046
DSL Port
General SNMP
Management SNMP NMS Security
Communication
Protocol SNMP Traps
7995: (Not Applicable)
7996: G.703 Statistics
7995: DSL Tests
7996: DSL and G.703 Tests
7995: Sync Data Port Tests
7996: (Not Applicable)
7995: Sync Port
7996: G.703
Current
DSL
Performance
DSL Port
Threshold
Traps
Telenet
Session
