Paragon Pro The Troll 2721 User manual

Assembly Instructions
®
MATERIAL HANDLING CART
®
Step 12:
Slide in the adjustable side arms to
one of two positions. Pull down on the
spring-loaded pin to allow movement.
(Note: Outer position of the side arms
will allow 4’ wide material such as wall
board to be centered on the cart.)
Note: Assembly sequence requires
lifting and positioning heavy
components. Procedure may
require two people.
Parts Included:
Frame tubes 4
Axle frames 3
End handle section 2
8” Casters 6
Adjustable side arms 4
Fasteners:
1/2” U Bolts 20
1/2” Flat washers 40
1/2” Lock washers 40
1/2” Hex nuts 40
3/4” x 2” Bolts 2
3/4” Lock nuts 2
3/8” x 1” Bolts 24
3/8” Lock nuts 24
5/16” Flat washers 48
Assembly Instructions
Model 2721
7251 So. 42nd St.
Grand Forks, ND 58201
1.800.441.0551
www.telproinc.com
®
MATERIAL HANDLING CART
Thank you
for choosing one of Telpro’s great products!
Form 42-15-00-00.12-2-02 © 2019 Paragon Pro Manufacturing Solutions All Rights Reserved.
MATERIAL HANDLING CART
®
®
®
®
®
®
®
®

Assembly Instructions
Step 1:
Lay one of the axle frames
upside down on the  oor.
Step 5:
Connect the second set of frame
tubes to the  rst set using two 3/4”
x 2” bolts and lock nuts ( nger tight
only). Be sure “marked” surfaces of
the pivot ears face and touch each
other. This will center the connection
of the offset pivot ears and keep the
frame tubes parallel.
Right......
Step 4:
Insert U-bolts and secure with
washers and nuts. Be sure U-bolts
are aligned square to the frame
tubes at the indicator marks as
the nuts are tightened.
Step 3:
Position the frame tubes
on the axle frame so that
the frame tube end plates
are up against the U-bolt
plates as shown.
Step 2:
Lay two of the frame
tubes on the axle frame
as shown. Be sure that
pivot ears are vertical.
Step 10:
Reconnect the two sections
with the two 3/4” bolts. Tighten
the lock nuts securely. Check
all of the U-bolt connections
and re-tighten if necessary.
Step 8:
Connect the casters to the axle frames
with 3/8” bolts, nuts, and washers.
Step 7:
Insert U-bolts and secure with washers and
nuts. Be sure U-bolts are aligned square to the
frame tubes at the indicator marks as the nuts
are tightened.
Step 6:
Lift the frame tubes and set
the two remaining axle frames
in position at the U-bolt
indicator marks as shown.
Step 9:
Remove the two 3/4” bolts and nuts
from the frame tube pivot ears and
carefully lift and turn each section of
the 2721 Troll Cart® right side up.
Step 11:
Connect the two end handle sections to the
frame tubes as shown. Insert U-bolts and
secure with washers and nuts. Be sure U-bolts
are aligned square to the frame tubes at the
indicator marks as the nuts are tightened.
Wrong......
Completed step
Assembly Instructions
®
Note: Assembly sequence requires lifting and positioning
heavy components. Procedure may require two people.
®
MATERIAL HANDLING CART

Assembly Instructions
®
MATERIAL HANDLING CART
®
Step 12:
Slide in the adjustable side arms to
one of two positions. Pull down on the
spring-loaded pin to allow movement.
(Note: Outer position of the side arms
will allow 4’ wide material such as wall
board to be centered on the cart.)
Note: Assembly sequence requires
lifting and positioning heavy
components. Procedure may
require two people.
Parts Included:
Frame tubes 4
Axle frames 3
End handle section 2
8” Casters 6
Adjustable side arms 4
Fasteners:
1/2” U Bolts 20
1/2” Flat washers 40
1/2” Lock washers 40
1/2” Hex nuts 40
3/4” x 2” Bolts 2
3/4” Lock nuts 2
3/8” x 1” Bolts 24
3/8” Lock nuts 24
5/16” Flat washers 48
Assembly Instructions
Model 2721
7251 So. 42nd St.
Grand Forks, ND 58201
1.800.441.0551
®
MATERIAL HANDLING CART
Thank you
For choosing one of our great products
Form 42-15-00-00.12-2-02 ©2002, Telpro Inc. All Rights Reserved
MATERIAL HANDLING CART
®
®
®
®
®
®
®
®

Chemical Hazard CAS# % By Weight
Arsenic Cancer 7440-38-2 Trace
Cadmium Develpmental 7440-43-9 Trace
Chromium Cancer, Developmental 7440-47-3 Trace
Ethylbenzene Cancer 100-41-4 Trace
Lead Cancer 7439-92-1 Trace
Methanol Developmental 67-56-1 Trace
Methylene Chloride (Dichloromethane) Cancer 75-09-2 Trace
Nickel Cancer 7440-02-0 Trace
Propylene glycol monobutyl ether Cancer 5131-66-8 Trace
Toluene Developmental 108-88-3 Trace
This product contains trace amounts of the following items which are known to cause
cancer and/or developmental harm in the state of California.
These chemicals are not hazardous under product's intended use.
Please review CAS# for more information.
