Parallax PDT-NSU-0008-MP-I User manual

Operations Manual
PDT-NSU-0008-MP-I
Revision 1.0 –March 2023

Table of Contents
1. Revision History..............................................................................................................................................2
2. Abbreviations..................................................................................................................................................3
3. Safety Information..........................................................................................................................................4
3.1 General Safety Information ....................................................................................................................4
3.2 DC Power Supply ....................................................................................................................................4
4. Packing List .....................................................................................................................................................4
5. Product Overview...........................................................................................................................................5
6. Connectors and Indicators..............................................................................................................................6
6.1 LED Indicators.........................................................................................................................................6
6.2 RJ45 Ports ...............................................................................................................................................6
6.3 Power Supply Connector ........................................................................................................................7
6.4 PoE Compatibility ...................................................................................................................................7
6.5 PoE Power Budget ..................................................................................................................................7
7. Installation Procedures...................................................................................................................................8
7.1 DIN Rail Installation ................................................................................................................................8
7.2 Wall Mount Installation..........................................................................................................................8
8. Connection and Setup ....................................................................................................................................9
8.1 Inspection Checks...................................................................................................................................9
8.2 RJ45 Connections....................................................................................................................................9
8.3 Power Up ................................................................................................................................................9
9. Physical Dimensions .......................................................................................................................................9
10. Hardware Specification ........................................................................................................................... 10

1.Revision History
Date
Rev
By
Comments
Checked
Date
09/03/2023
01
JF
Initial Release
SC
09/03/2023

2.Abbreviations
Abbreviation
Description
AP
Access Point
CCA
Copper Clad Aluminium
DC
Direct Current
IEEE
Institute of Electrical and Electronic Engineers
IP
Internet Protocol
MTBF
Mean Time Between Failures
PD
Power Device
PoE
Power over Ethernet
PSU
Power Supply Unit

3.Safety Information
3.1 General Safety Information
Only trained and authorised personnel should be permitted to work on this equipment. It is
assumed that those using this guide are competent to work on equipment of this nature and will
take appropriate precautions when working with the fault analysis guide.
All devices should be inspected upon receipt for signs of physical damage, which may in turn, affect
operational performance, or the overall safety of the unit. Any damaged items should be returned
to Parallax Digital Technologies Ltd for safety checks.
Parallax Digital Technologies accepts no responsibility for any injury or loss caused by unsafe or
inadequate working practices, or for work carried out by an unauthorised third party.
To prevent possible danger, damage, and bodily harm when handling the equipment, please
observe all warnings, cautions notices contained in this section. Failure to heed the following
danger, warnings, and cautionary statements could lead to serious injury or death.
3.2 DC Power Supply
The Unit should be mains-fed using a DC Power Supply using an appropriately rated cable
assembly, which is protected internally at the power supply device itself. If the device is to be fed
from an alternative power source, then the appropriate circuit protection device should be used
to ensure that the supply circuit is interrupted, in the event that a fault in the device causes too
much current to flow into it, causing an unsafe condition.
4.Packing List
The following items are included in the shipping carton:
•1 x PDT-NSU-0008-MP-I Unmanaged Ethernet Switch
•1 x DIN Rail Mounting Kit (Fitted)
•1 x Wall Mounting Kit
•Operation & Maintenance Manual (May be electronically supplied)
•Declaration of Conformity (May be electronically supplied)

5.Product Overview
The PDT-NSU-0008-MP-I is an Unmanaged Ethernet PoE+ switch, providing 8 x 10/100 PoE+ RJ45
for connectivity, designed to directly connect to devices such as IP Cameras, Wireless APs, IP
Telephones etc.
This model operates from a nominal +48VDC power supply but can utilize supplies in the range
+48-57VDC.
The device is designed for use in harsh industrial environments, and incorporating a rugged
aluminium housing, it can be operated across a wide temperature range (-40°C to +80°C) making
it suitable for most conditions.
A typical application setup can be seen in the following diagram:

6.Connectors and Indicators
Front Panel
6.1 LED Indicators
The Front Panel LEDs display the status of the switch and the associated port connections as
indicated in the table below:
LED
Name
Colour
State
Status
PWR
Power
Green
OFF
Unit Power Off
ON
Unit Power On
T1-8
Link Activity
Green
OFF
No Connection
Flashing
Connection
FX1/2
Not Used
Green
N/A
N/A
6.2 RJ45 Ports
The Front Panel has 8 RJ45 Ports and all are PoE+ compatible, with each port capable of supplying
30W each.

6.3 Power Supply Connector
The device is designed to be supplied by a +48VDC power supply, but can operate in the range +48-
57VDC. Power is supplied via a 6-pin terminal block connector with the following pinout
Note: All Power Supplies should provide over-current and short-circuit protection, and should have
a capacity rating to meet the required output current for the device plus any PoE powered device
requirements
6.4 PoE Compatibility
Model No
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
PDT-NSU-0008-MP-I
●
●
The PoE output for this model is compatible with PoE and PoE+ Standards, as can be seen in the
table above.
6.5 PoE Power Budget
The PoE Power Budget for this unit is 240W and it is advised to connect PWR 1 and PWR 2 to
separate supplies if power supply redundancy is required
Pin
Group
Input
1
PWR 1
GND
2
+48-57VDC
3
N/A
NC
4
NC
5
PWR 2
GND
6
+48-57VDC

Press
Upper
part
Attach the Wall Mount Bracket (if not fitted)
to the switch case using the screws supplied
Mount the switch to the required surface
using appropriate fixings
7.Installation Procedures
7.1 DIN Rail Installation
7.2 Wall Mount Installation
Attach the DIN Rail Bracket (if not fitted) to
the switch case using the screws supplied
Clip the upper edge of the bracket onto the
DIN Rail and push to latch the bottom strip

8.Connection and Setup
8.1 Inspection Checks
Please inspect the unit to ensure that there is no damage to the external casing which could cause a
malfunction of the device or cause a safety critical fault. Any damaged units should be returned to Parallax
Digital Technologies for inspection and testing.
Please ensure that the DC Cables are securely fastened in the terminal block, and that the terminal block is
correctly inserted into the switch power connector housing.
8.2 RJ45 Connections
Ensure all required RJ45 Ports are connected correctly using CAT5e cable or better to the client devices.
The Uplink port should be connected to the host device or network, and the access ports are available for
other devices or connections. All cables should be solid copper and not CCA.
8.3 Power Up
The Unit will automatically power up as soon as DC power is applied to the device. The Power Light will be
illuminated and after approximately 1 second, all of the other LEDs will flash on and off to complete the
initialization sequence. Following this, the Port Status LEDs will display the current state of each of the
ports.
9. Physical Dimensions
All Dimensions are in mm

10. Hardware Specification
ETHERNET
Standards
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
Forwarding and Filtering Rate
14,880pps (10Mbps)
148,800pps (100Mbps)
Packet Buffer
512Kbits
Packet Length
2046B
MAC Address Table
2K
Exchange Property
Backplane Bandwidth 1Gbps
Packet Forwarding Rate 14.88Mbps
INTERFACE
Wired
8 x 10/100/1000 PoE+ RJ45
PoE
Standard
IEEE 802.3af/ 802.3at
Port
RJ45
Power Pin Assignment
4/5 (+) 7/8 (-)
PoE Budget
240W
ENVIRONMENTAL
Operating Temperature
-40°C to +80°C
Storage Temperature
-40°C to +85°C
Relative Humidity
5% - 95% non-condensing
MTBF
200,000 hours
ELECTRICAL
Operating Voltage
+48-57VDC (Terminal Block Connector)
Power Consumption
5W Without PoE Load –245W with Max PoE
Short-Circuit Protection
Auto-Reset
Reverse Polarity
Protected
MECHANICAL
Dimensions
150mm x 110mm x 50mm
Weight
0.6 kg
Casing
Aluminium
Mounting
DIN Rail & Wall Mount
INDICATORS
PWR
Power
T1-8
Link/Activity
FX1/2
Not Used

CERTIFICATION
Electrical Safety
EN 62368-1:2020+A11:2020
Emissions
EN 55032:2015+A1:2020
Radiated Immunity
EN 55035:2017+A1:2020
Harmonic Emissions
EN 61000-3-2:2014
Fluctuations and Flicker
EN 61000-3-3:2013
Electro-Static Discharge
EN 61000-4-2:2009
Electromagnetic Field Immunity
EN 61000-4-3:2010
Electrical Fast-Transients
EN 61000-4-4:2012
Surge
EN 61000-4-5:2014+A1:2017
Conducted Immunity
EN 61000-4-6:2014
Power Frequency Magnetic Field
EN 61000-4-8:2010
RoHS
IEC 63000:2018
For all technical enquiries regarding this product, please contact our technical support team using the
following email address:
[e-mail]
