Linear HDMI-SW-4X2M User manual

4X2 Switcher For d
Model # HDMI-SW-4X2M
USER MANUAL
www.linearcorp.com

ASKING FOR ASSISTANCE
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
6:30 AM - 4:30 PM PST Monday through Friday.
Email:
[email protected]
Website:
www.linearcorp.com
Notice
Linear LLC reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
© 2008 Linear LLC, All Rights Reserved

TABLE OF CONTENTS
Introduction / Operation Notes
Features
Panel Descriptions
Connecting and Operating the 4X2 Switcher For HDMI
RMT-2 Installation
IR Code Conicts
RS-232 Interface
Wiring Diagram
Specications
Warranty
1
2
3
4
5
6
7
8
9
10

The Linear 4x2 Switcher for HDMI routes high denition video in multiple resolutions
up to 1080p plus multichannel digital audio from any of four sources. Four inputs
accommodate the simultaneous connection of up to four high denition video sources,
suchassatellitesystemsandBlu-rayandHD-DVDplayers.Twooutputssendthehigh
denition audio/video signals up to two high denition displays. A digital audio output
port is available if you need to direct the audio to an audio receiver. Switching is done
via the IR remote that is provided with the unit.
How It Works
You simply connect all your sources to the switcher’s HDMI inputs. Then connect up
to two displays on the switcher’s HDMI outputs. Once the sources, the Switcher and
the display(s) are powered and connected, you simply select which source you want
to view using the IR remote.
INTRODUCTION
1
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE 4X2 SWITCHER FOR HDMI
Display information (EDID) is sent from the display connected to HDMI•
output port 1 to all of the sources connected to the 4X2 Switcher for
HDMI. If there is no display connected to HDMI output port 1, the EDID
from the display connected to HDMI Output Port 2 will be used. (See note
on page 4 for additional information)
The 4X2 Switcher For HDMI can only mirror one input video signal at a time to• both display outputs. The user can choose which of the four HDMI inputs will be
displayed on both HDMI outputs
HDMI/HDCP compliant•
Compatible with all HDMI and DVI* displays•
NOTE: When used with a HDMI to DVI adapter.
OPERATION NOTES

FEATURES
Features
Switch easily between any four HDMI sources•
Outputs are mirrored to two HDMI Displays simultaneously•
Additional digital coax audio output is extracted from the HDMI input for easy• connection to a multi-channel audio receiver
Extends the range of HDMI compliant device by equalizing and reclocking the• HDMI signal
Supports resolutions up to 1080p, 2K and 1920 x 1200•
HDMI/HDCP compliant•
Includes:
(1) 4X2 Switcher For HDMI
(4) 6 ft HDMI cables (M-M)
(1) 5V DC Power Supply
(1) RMT4-IR remote
(1) User’s Manual
2
NOTE: *When used with a HDMI to DVI Adapter

PANEL DESCRIPTIONS
3
Front Panel
Back Panel
Power LED
Indicator
IR Eye
Input LED
Indicator
5V DC Power
Input
HDMI
Input 2 HDMI Input 4
RS-232
Serial Control
Interface Digital Coaxial
Output
HDMI
Output 2
IR Eye
Extension Port
HDMI
Output 1*
*See note on page 4
HDMI
Input 1 HDMI Input 3

CONNECTING THE 4X2 SWITCHER FOR HDMI
OPERATING THE 4X2 Switcher For HDMI
4
Connect the supplied cables from the HDTV HDMI sources (up to four) into the1. HDMI input ports of the 4X2 Switcher for HDMI.
Connect the displays (up to two) to the HDMI output ports* of the 4X2 Switcher2. for HDMI using user supplied cable(s).
Optionally, connect an external audio processor to the 4X2 Switcher For HDMI3. using a user supplied digital coaxial cable.
Plug the 5V DC power supply into the 4X2 Switcher For HDMI.4.
NOTE: *Display information (EDID) is sent from the display connected to HDMI
Output Port 1 to all of the sources connected to the 4X2 Switcher for HDMI. If
there is no display connected to HDMI output port 1, the EDID from the display
connected to HDMI output port 2 will be used. The source will output resolutions
and timings according the EDID that is being fed by the 4X2 Switcher for HDMI.
Therefore, all of the connected displays must be capable of accepting the timings
and resolution output by the source. It is recommended that the display with the
lowest native resolution be connected to HDMI output port 1. This is to ensure that
a compatible video signal will be able to be displayed on all connected monitors.
Switching between the inputs on the 4X2 Switcher For HDMI is done using either
the supplied RMT4-IR remote or through the RS-232 serial control interface.
IR Remote Control
Pressing button one on the remote will select the HDMI source that is connected
to HDMI input port one. Pressing two on the remote will select the HDMI source
that is connected to HDMI input port two. Pressing button three on the remote will
select the HDMI source that is connected to HDMI input port three. Pressing four
on the remote will select the HDMI source that is connected to HDMI input port
four.
RS-232 Serial Control Interface
Please see page 7 for more information on the RS-232 serial control interface.
How to Connect the 4X2 Switcher For HDMI

5
RMT4-IR INSTALLATION
1. Remove battery cover from the back of the RMT4-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position. (See page 6)
3. Insert the battery, hold the battery so that you can see the positive side facing up.
The side that is not marked must be facing down.
4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator
light on the remote will ash once each time you press a button.
WARNING: Do not press multiple buttons simultaneously and do NOT press buttons
rapidly. These actions will cause the remote to reset and steps 1-4 will have to be
repeated.
Note: The RMT4-IR ships with two batteries. One battery is required for operation,
the second battery is complimentary.
The optional IR extender allows you to
relocate your HDMI Switcher and still retain IR
control. Linear part# IR-EXTENDER

6
IR CODE CONFIGURATION
4X2 Switcher For HDMI
Remote Channel 1:
Default
Remote Channel 4:
Remote
Remote Channel 1:
Default
1 2
Remote Channel 2:
1 2
Remote Channel 3:
1 2
Remote Channel 4:
1 2
HowtoResolveIRCodeConicts
In the event that IR commands from other remote controls conict with the supplied
RMT-4IR remote control, changing the remote channel will alleviate this issue. The
RMT-4IR remote control and the 4X2 Switcher for HDMI have DIP SWITCHES for
conguring the remote channel that both units use to communicate. These settings
must match each other for proper operation. The 2 DIP SWITCH bank on the RMT-
4IR is located underneath the battery cover. The 8 DIP SWITCH bank for the 4X2
Switcher for HDMI is located inside of the unit. *DIP SWITCH 1 and 2 on the RMT-
4IR correspond to DIP SWITCH 3 and 4 on the 4X2 Switcher for HDMI.
NOTE: *DIP SWITCHES 1, 2, and 5 through 8 are not used on the 4X2 Switcher for
HDMI.
Because the procedure for changing channels requires the main unit to be
disassembled, this procedure should only be done if there are IR conicts present in
your setup.
To open the 4X2 Switcher for HDMI Unit, remove all screws from the sides and
underside of the unit. Remove the hex nuts above each HDMI connector and on the
RS-232 serial connector. Slide the unit apart carefully to expose the internal PCB and
the 8 DIP SWITCH bank.
12345678
Remote Channel 3:
12345678
Remote Channel 2:
12345678
12345678

7
RS-232 SERIAL CONTROL INTERFACE
Binary Table
ASCII Input Binary
1 1 0011 0001
2 2 0011 0010
3 3 0011 0011
4 4 0011 0100
Terminal Settings
Bits per second ................................................................................................. 19200
Data bits .................................................................................................................... 8
Parity .................................................................................................................. None
Stop bits .....................................................................................................................1
Flow Control ....................................................................................................... None
1 2 3 4 5
6 7 8 9
1 2 3 4 5
6 7 8 9
Only Pins 2 (RX), 3 (TX), and 5 (Ground) are needed to operate RS-232 Interface

WIRING DIAGRAM
8
Maximum HDMI cable length is 15 ft at 1080P resolution without the use of an HDMI-SB or HDMI-CAT5-EXT

9
SPECIFICATIONS
Video Amplier Bandwidth .......................................................... 165 MHz
Input Video Signal ................................................................. 1.2 Volts p-p
Input DDC Signal ............................................................ 5 Volts p-p (TTL)
Single Link Range ...................................................... 1080p/1920 x 1200
HDMI Connector ...................................................... Type A 19 pin female
Digital Audio Output ........................................................................ SPDIF
Remote Control Port ....................................... RS232 female, mini-stereo
Power Consumption .......................................................... 20 Watts (max)
Dimensions .......................................................... 11”W x 1.25”H x 4.25”D
Shipping Weight ............................................................................... 5 lbs.

10
WARRANTY
Note: These products are designed to be installed and serviced by trained professional
installation companies.
Linear LLC warrants this product to be free from defects in material and workmanship. For the
term of the warranty, see the list of products below. The Warranty Expiration Date is reected by
a date code that is afxed to all of Linear’s products. This warranty extends only to wholesale
customers who buy direct from Linear or through Linear’s normal distribution channels. Linear
does not warrant this product to consumers. Consumers should inquire from their selling dealer
as to the nature of the dealer’s warranty. There are no obligations or liabilities on the part of
Linear LLC for consequential damages arising out of or in connection with use or performance
of this product or other indirect damages with respect to loss of property, revenue, or prot, or
cost of removal, installation or reinstallation. All implied warranties, including implied warranties
for merchantability and implied warranties for tness, are valid only until warranty expiration date
as labeled on the product. This Linear LLC Warranty is in lieu of all other warranties express or
implied. Some states and countries do not allow limitations or how long an implied warranty lasts
or the exclusion or limitation or incidental or consequential damages, so the above exclusions
may not apply. The Linear LLC warranty gives specic legal rights in addition to other rights,
which may exist and vary from state to state and country to country.
All products returned for warranty service require a Return Product Authorization Number (RPA#).
Contact Linear Technical Services at 1-800-421-1587 for an RPA# and other important details.
Consumers: If you have trouble locating your installing company, please contact Linear LLC at
1-800-421-1587 and we will assist you with locating a service and Installation Company.
The following warranty period applies to this set of Linear branded products.
Linear High Denition Video products — Two (2) years. There is no warranty offered on the 1. batteries supplied with the IR remote Control.
The warranty is limited to repair or replacement of products returned, freight prepaid, to
Linear LLC. There is NO PROVISION FOR LABOR COST OR OTHER REIMBURSEMENTS
OF ANY KIND.
Failures due to product abuse, negligence, improper installation, improper use, and1. electrical surge including damage from lightning, water damage or other damage due to
natural disasters are not covered by the warranty.
The warranty shall also be voided by any tampering with the date code, labels or other2. markings on the product.
Products that are damaged in transit to Linear LLC due to improper packaging or by the3. carrier (shipping company) will not be covered under the warranty. If the product was
damaged or lost by the carrier, it is the sender’s responsibility to create a claim against the
carrier.
The user is responsible for all labor costs associated with removing, reinstalling and4. returning the product to Linear LLC.
Linear LLC, at its option, will repair or replace the defective product.5.
Replacements will be made from B-Stock. If an exact replacement is not available Linear6. LLC, at its option will select the nearest equivalent product. The user is responsible for
freight charges to Linear LLC.
Linear LLC will return warranted repaired or replacements by UPS Ground or an equivalent7. service. Acustomer may pay the additional costs for second day or next-day service.
