PARAMINA Typhoon Open Compressor
USER MANUAL
1. General Instructions
CAUTION: High pressure pneumatic device
The PARAMINA Typhoon Open compressor is a high pressure air-compressor offering high quality
breathing air. It is made according to EU directives 98/37 EC machinery and 73/23 EEC regarding low
voltage. Noise complies with 2000/14 EC directive.
The compressor must be used ONLY for producing compressed air as described in this manual.
Any other use is not allowed whatsoever!
Strictly observe all instructions pertaining to the operation and maintenance of this product. Fail to observe
these instructions may lead to serious injury or even death.
The manufacturer accepts no liability for damage or injury due to non-compliance to all instructions of this
manual.
FOR YOUR SAFETY
Thoroughly observe the following:
1. Timely replacement of filter elements and activated carbon - molecular sieve filter.
2. Make sure that the air compressor is installed in a place that guarantees plenty of fresh air, without any
engine’s exhaust gas.
3. Proper cylinder maintenance
4. Proper compressor maintenance
5. Only trained and experienced technicians are allowed to overhaul this compressor.
6. NEVER INTERFERE WITH THE SAFETY DEVICES
7. In case you become aware of any change in the compressor’s operation, call us in order to help you
responsibly troubleshoot the product and to provide you with repair instructions.
8. NEVER USE THE COMPRESSOR FOR ANY OTHER GAS APART FROM ATMOSPHERIC AIR.
The instructions concerning safety are marked with this symbol.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 4
2. Technical Data
High pressure breathing air compressor, 3 cylinders, 3 stages, air-cooled.
Model:
Typhoon Open
15E
18E
15P
18P
15D
Maximum
pressure:
350 bar (5075 psi)
Minimum pressure:
40 bar (580 psi)
Capacity:
15,0 m3/h
250 lit/min
18,0 m3/h
300 lit/min
15,0 m3/h
250 lit/min
18,0 m3/h
300 lit/min
15,0 m3/h
250 lit/min
Maximum ambient
temperature:
45ºC
Oil capacity:
2,2 lit
Speed Rotation:
1100 rpm
1300 rpm
1100 rpm
1300 rpm
1100 rpm
Piston stroke:
60 mm
Cylinder
bore:
1st
stage
80 mm
2nd
stage
36 mm
3rd
stage
14 mm
Operating
pressure:
225 bar 330 bar
1st stage 5,2-5,4 bar 5,4-5,5 bar
2nd stage 38,0-39,0 bar 42,0-43,0 bar
3rd stage 225,0 bar 330,0 bar
Motor/Engine:
5,5kW
/400-
440V/50-
60Hz
7,5kW
/400-
440V/50-
60Hz
6,0kW
Petrol
Honda
8,2kW
Petrol
Honda
6,8kW
Lombardini
Diesel
Dimensions
(LxDxH):
107x54x70cm
128x52x73cm
128x52x73cm
Weight:
185 Kg
195 Kg
171 Kg
189 Kg
198 Kg
Fuses & Cables
MODEL
MOTOR
FUSE BOX
CABLE
KW
AMPS
DIM. (mm2)
LENGTH (m)
TYPHOON 15E
5,5
25A
4 x 4
max. 15m
TYPHOON 18E
7,5
35A
4 x 6
max. 15m

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 5
3. User Instructions
Safety Measures - Warning Signs
HOT SURFACES
Do not touch.
Risk of burns if you touch
cylinders, aftercoolers,
cylinder heads
DANGER
This sign is placed
whenever there is danger
of damage caused to the
unit or its components
HIGH VOLTAGE
Risk of electric shock.
Maintenance work to be
carried out only by a trained
electrician
DIRECTION OF
ROTATION
Make sure for the proper
direction of rotation
USER INSTRUCTIONS
Users must read and fully
comprehend operation
instructions for using and
maintaining the compressor
This sign refers to
timely user instructions for
operating and maintaining
the compressor
AUTOMATIC OPERATION
Caution, the unit may
start its operation
without any prior notice.
Before any work, turn off
mains supply
OBLIGATORY
During control and
operation of this unit you
must wear earplugs
RISK of rotating parts
TECHNICAL
REQUIREMENTS
the operator must take into
account

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 6
Basic safety recommendations
The compressor is manufactured following current EU safety regulations.
The compressor is intended ONLY for compressing atmospheric air with a content of oxygen (21±1)%.
Use of any other gas type is not allowed. The manufacturer is not liable for damages caused by
using the unit any other way than the intended.
Use the compressor after making sure it is in perfect working condition. Any malfunction or failure must
be repaired immediately. Strictly follow the operation and maintenance instructions described in this
manual.
Read carefully the instructions in this manual and follow them. Make sure users of the compressor are
familiar with the user instructions of the unit and its proper operation. Make sure they are authorized,
trained and trustworthy individuals. Make sure you are aware of and implement the current legal and all
other regulations pertaining to avoiding accidents and protecting the environment.
During first start or after maintenance, check motor’s direction of rotation. There is an arrow indicating
proper rotation. If the direction is reversed, interchange two of the three phase leads in the switch box.
Never change leads at the motor terminal board.
Before starting any work pertaining to maintenance of the compressor, turn off the supply from the
mains and press the Emergency Stop.
If regulations dictate it, use means of individual protection.
Pay attention to labels indicating safety and risk for the unit. Strictly follow them and do not destroy
them.
For any change in the operation of the unit, contact immediately the manufacturer.
Any alteration –conversion of the unit without the manufacturer’s prior written consent is not allowed.
Spare parts MUST be genuine –approved by PARAMINA SA.
Get accustomed to the position and use of fire extinguishing equipment that must be near the
compressors.
Instructions for safe operation - risks
Check the unit on the inside and outside on a daily basis in order to make sure it is in good working
condition.
Do not start the operation of the unit if you do not ensure your own safety.
Before you operate the compressor, make sure that requirements are met for the safe and smooth
operation of the unit.
Floor must be even. Adjust the anti vibration pads, so as the unit is in horizontal position and shocks
are minimized.
Place the compressor in a well-ventilated area. Make sure that the intake air for the compressor is
clean and cool. Prevent the hot cooling air from recirculating to the cooling air intake. Make sure
that foreign objects cannot get into the compressor with the intake air. Make sure that the intake air
does not contain any smells, fuel or fumes, explosive or inflammable gases or harmful
substances.
Units with petrol engine or diesel engine should not be used indoors.
Assign the unit (if it uses petrol engine or diesel engine) towards the direction of the wind, so
as fumes are getting away. In this case, use the input hose of the inlet air filter in such a way,
that fumes are avoided to enter the compressor.
Keep the compressor away from flammable material. Do not smoke when opening the fuel tank.
If any malfunction of the unit occurs, stop immediately its operation and check –fix the problem.
Before any maintenance or repair works, inform the users.
When replacing heavy-weight components, strap them carefully on the proper lift truck. Never walk
under such components when they are lifted.
Before any maintenance works, clean the area from out-of-use material, oils, fuel or other liquids from
the unit. Do not use corrosive materials. If you clean the unit by water or steam, make sure that neither
(water nor steam) comes close to the electric motor or the electric system and ensure that they will not
enter open hoses. For cleaning, use lint-free cloth.
After cleaning or repairing the unit, check all hoses for leaks, loose connections, wear or damages.
Tight again all connections and recheck every maintained safety device.
Ensure safe and environmental friendly disposal of consumable materials and old spare parts.
Our company suggests that the compressor should operate with automatic stop, adjusted 10%
above the working pressure.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 7
Special attention
Do not use the compressor in explosive environment.
Connect the compressor only to electrical systems that are compatible with its electrical characteristics
and that are with in it’s rated capacity
Comply with the local mains supply company regulations.
Use only the recommended fuses.
A trained electrician may only execute maintenance in the electrical system.
During any maintenance work in the unit, turn off the power from the mains. It is also recommended
posting a notice warning about maintenance works on the compressor.
In case of having to execute maintenance works on an operating unit, a second person beside the
electrician must be present to handle the main safety switch or the Emergency Stop. Tools to be used
must be isolated.
Regularly check hoses, couplings and fittings for leaks and loose connections.
Regularly check tightening of the electrical connections.
If you replace any cable, you must use the same type.
Decompress all hoses, filters, pressure tanks and, basically, the entire unit, before you carry out any
work.
Never exceed the allowed operating pressure of the cylinders.
Immediately replace cylinders with any kind of damage.
Do not heat the cylinders or any of their parts, because pressure will rise.
For loading –lifting of the unit or heavy parts of it, use the proper lift truck that is handled by trained
stuff.
Make sure you have properly secured the unit during its elevation or transport.
The compressor is not made for use by the sea. In such a case, spray the unit with anticorrosive
material. Portable compressors (if used on a boat/ship) must be stored under the deck after use.
Safety Regulations
The PARAMINA Typhoon Open compressor is a high pressure air-compressor and it is made according
to EU directive 2006/42/EC for the safety of machinery. Noise complies with 2000/14 EC directive.
The manufacturer follows all regulations above and declares that the unit is manufactured accordingly.
Following the safety regulations, an authorized professional in site must supervise compressors that will
be used as filling stations before starting their operation.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 8
4. Installation –Operation
General Specifications 
High pressure compressors are complete units for filling cylinders with compressed air at 225 bar (3200
psi) and 330 bar (4700 psi). They are mostly used for compressing breathing air for divers, fire brigades,
military, paint ball applications, etc.
Typhoon Open is a 3 staged, piston, air cooled compressor with 3 cylinders, 2 intercoolers and 1 final
aftercooler, condensate separator after the second stage aftercooler, accompanied with automatic and
manual drain, mechanical safety valves as well as two (2) filtering stages at the final pressure (after the
third stage):
The first filter contains an element for retaining particles and oil droplets down to 0.01 ppm (Coalescing
element). Then there is the second and final stage of dehumidification with Molecular Sieve and air
purification with Activated Carbon.
The Final stage for Paint Ball application consists of two (2) Molecular Sieve Filters.
Installation - First start of the compressor 
All compressors are tested and pre-adjusted by the manufacturer before they are shipped to the buyer.
They can start their operation immediately on the following conditions that are considered necessary, for
safety and ease.
Anyone who will be handling the unit must read carefully all contents of this manual so as to have full
knowledge of the product.
1. Choose carefully the installation place of the compressor. The place must not be burdened by
unfavorable environmental conditions (toxic substances –explosives –fumes –dirt –debris etc.
2. Place the compressor in a well ventilated area. Make sure that the intake air for the compressor is
clean and cool. Prevent the hot cooling air from recirculating to the cooling air intake. Make
sure that foreign objects cannot get into the compressor with the intake air. Make sure that the
intake air does not contain any smells, fuel or fumes, explosive or inflammable gases or harmful
substances.
3. Turn the compressor using the fly-pulley and make sure it turns freely. Do the same after overhaul
of the unit or a long-term out of service period.
4. Before any start of the compressor, check oil level. It should be between the minimum and
maximum limit.
5. The compressor should be placed in a completely horizontal position. If during operation there are
vibrations, adjust the anti-vibration pads of the stand until vibrations are minimized.
6. During every start of the compressor, in versions without auto drains, open only the drain
valve of the 3rd stage. Then during the regular operation of the compressor open both 2nd
and 3rd stage drain valves every 15 minutes.
ATTENTION:
Larger oil quantity may increase pressures inside the block, cause leaks of larger oil quantity in the
pneumatic air resulting in the creation of chars in the valves, burden the filters and affect their life duration,
as well as the quality of breathing air.
Smaller amount of oil means inadequate lubrication affecting the life duration of the compressor.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 9
Electric version
Electrical connections
The electrical connections are to be carried out according to IEC standards and national regulations for
safety of electrical equipment.
Make sure the operating voltage is correct (max. deviation from the specified voltage ± 5%).
Connect the power supply cable to the compressor main switch. See wiring diagram and technical
specification for the power requirement of the compressor.
-The connection of the earth wire is especially important.
-Only qualified electricians are allowed to carry out the electrical connections.
First start
1. Press the reset button if activated (4).
2. Press the Start button (1).
3. Immediately after switching on the system for the first time, check the direction of the rotation of the
motor using the direction arrow on the unit. If the three-phase motor turns in the wrong direction, the
phases are not connected properly. Shut down unit immediately by pressing the emergency stop
button (3) to make the compressor stop without delay. Isolate the power and interchange two of
the three phase leads in the switch box. Never change leads at the motor terminal board.
3. When the pressure reaches the desired level press the stop button (2) to stop the compressor. In
auto-stop version the compressor stops automatically at the pre-adjusted final pressure.
- Wrong direction of rotation will damage the compressor unit.
- Check the direction of rotation every time the compressor is connected to the power supply.
2
1
3
4

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 10
Petrol/Diesel Version
ENGINE START
First turn engine’s key (1) to position ON and check that the battery gives power to the petrol
engine. Then turn the key right to position START so as to start the engine and the compressor.
For Petrol Version: Before starting the engine turn on the drain switch (2).
ENGINE STOP
When the final pressure is reached turn the key to position ON so as to stop the compressor and
then to position OFF so as to cut the power from the battery too.
For Petrol Version: After finalizing all works do not forget to turn off the drain switch, otherwise
compressor’s battery will be empty!
General instructions
Read carefully engine’s operating instructions
Check the fuel level and fill if necessary.
Check motor oil according to manufacturer’s directions.
Open fuel valve.
Do not disconnect the battery during compressor’s operation. Coils of solenoid valves (auto
drains), will be destroyed (version with auto drains).
2
1
1

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 11
Cylinder filling procedure 
Make sure that filling hoses as well as threads are in perfect condition without cracks or breaks.
Filling hose connectors should be connected on the cylinder without the use of tools. Sealing is achieved
with o-ring and internal pressure. The filling hose connectors used for filling cylinders up to 220 bar are
divided in two categories:
Filling hose connector according to DIN 477
INTERNATIONAL / ‘’A’’ Clamp Adaptor
For pressures at 330 bar, only the use of filling hose connector according to DIN 477 (with different thread
than the one at 220 bar) is allowed. Use of any kind of adaptor is strictly forbidden.
Use cylinders that correspond to the pressures produced by the compressor
Check the cylinder safety pressure (220 or 330 bar) so as to correspond to the preset final pressure of the
compressor.
Connect the cylinder, having the filling hose connector’s valve and the cylinder’s valve turned off, and start
the compressor (see page 8).
Then, first turn on the filling hose connector’s valve and then the one of the cylinder.
DIN filling hose connector for 220 bar
DIN filling hose connector for 330 bar
(ATTENTION: longer thread)
INTERNATIONAL / ‘’A’’ Clamp Adaptor
(Only for 220 bar)
200 bar filling

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 12
When filling is complete, first turn off the cylinder’s valve and then the filling hose connector’s valve and
proceed to evaporation using the relief valve on the connector. Finally, safely disconnect the cylinder.
During the filling procedure, cylinder’s temperature will rise. Let it cool down. Pressure will fall a little. If
you wish, reconnect the cylinder with the filling hose (following the same procedure) and fill until the
maximum filling pressure.
Never open the filling hose connector valve, unless the cylinder is connected to the filling
hose. Hose whipping due to pressurized air out system can cause serious injury!
Automatic stop system
Standard equipment in all electrical versions.
Optional equipment in petrol and diesel versions.
When the pressure reaches the pre-adjusted final level the compressor stops automatically {through the
pressure switch (1)}. The restart of the compressor must be done manually.
Max. operating pressure 350 bar.
Dual pressure filling module
Optional equipment.
It controls the pressure through a pressure regulator (1) (0-345 bar outlet pressure) and gives the
possibility to the user to fill 200 and 300 bar cylinders simultaneously.
300 bar filling
1

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 13
Condensate drainage
Manual drain system
Each time you stop the compressor open the manual drain valves (1,2) so as to remove condensate.
During every start of the compressor, open only BA filter’s drain valve (2). Then during the regular
operation of the compressor open both 2nd (1) and BA filter (2) drains every 15 minutes.
Automatic drain system
Standard equipment in all electric versions.
Optional equipment in petrol and diesel versions.
The system consists of two timer controlled condensate drains, one after the 2nd, and one after the final
stage and the BA filter. The drains are controlled electronically and open automatically.
The user can adjust the interval time (4) from 0,5 - 45 min. and the discharge time (3) from 0,5 - 10 sec.
Max. operating pressure:
2nd stage drain valve: 80 bar
3rd stage drain valve: 250 or 350 bar
In case of emergency (damaged auto drain system), the user may use the two manual drains. During
routine operation open both drain valves every 15 minutes.
Note 1: Condensate color is milky-white. If condensates
suddenly change color or start smelling, this is indication
of oil presence. Immediately check:
1. oil quality
2. oil level
3. filters’ condition and especially the condition of active
carbon filter
4. air inlet filter’s condition
5. piston rings and cylinders condition
Note 2: All petrol compressors are equipped with an auto drain switch (5). Turn on this switch
always before engine start and turn it off after finalizing all works (otherwise compressor’s battery
will be empty).
2
3
4
5
1

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 14
5. Maintenance
Compressor’s long period storage
In case the compressor is intended to stay out of operation for more than three months, special procedure
should be followed for the storage as well as for its re-operation:
Make sure it is stored in a closed, dry, dust-free place.
Run the compressor at normal pressure for 10-15 minutes.
Check filters, hose connections and safety valves for leaks.
Tighten all connections, if necessary.
Open manual drain valves and run the compressor without pressure for 5 minutes.
Stop the compressor, drain well and shut all valves.
Open filters and put special grease used in the food industry or Vaseline on all threads. Filter elements
should normally be in their place.
Let the compressor cool down.
Start the compressor and spray some compressor oil (5-6 c.c.) in the suction while in operation.
Do not let the compressor heat up, stop its operation.
Close all valves.
Wrap the inlet air filter with nylon.
Cover the compressor with a plastic cover to keep the dust out.
Re-Operation of the compressor after a long period of storage
Remove the nylon and place a new inlet air filter.
Follow the procedure related to the first start of the unit.
Run the compressor functioning at normal pressure for 5-10 minutes.
Change the oil.
Place new coalescing filter element, Active Carbon-Molecular Sieve.
Intake air filter
Replace the air intake cartridge every 200 hours or once per year.
According to the environment it is recommended to change the
air filter element at the end of season.
cartridge part nr.: 109460302
Belt adjustment
Check tension of belts after the first 20 hours of operation and
then every 100 hours. Pressing in the center of the belt’s length
applying 5 Kg of force, it should not give way more than 20 mm.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 15
In order to adjust the belts, screw the bolt (1) so as to adjust the spring until the belt reaches proper
tension as per drawing in page 14.
Oil change
Change the oil after the first 20 operating hours and then every 500 hours.
Always check the oil level through the oil sight glass (1) before every start of the compressor. The
level should always be at the top of the sight glass (leaving a small air bubble at the top of the
glass). While the compressor is operating the level should be between the minimum and the
maximum of the sight glass (red mark).
Oil change procedure:
Disconnect the pipe (2) and empty the oil vessel. After emptying the oil re-connect the pipe at the same
position. Pour new oil (2,2 lit.) inside the compressor block through the yellow plug (3) till the upper part of
the oil sight glass (1). Screw the plug (3) at the same position again.
Now you are ready to restart the compressor.
3
2
1
1
1

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 16
Filters Maintenance 
Before installing a new filter cartridge clean very carefully the filter housing from all liquids.
PARAMINA compressors operate at environmental temperatures from +5 0C to +45 0C.
Higher temperatures could cause changes in the quality of breathing air; lower
temperatures may cause a malfunction.
CAUTION: Before any interference in the filter’s housing, make sure there is not inside air
under pressure. Maintenance work on the compressor must always be done with the
compressor stopped and disconnected from the mains supply.
Filter’s housing lifetime is 20 years. Hydraulic Overpressure test, every 5 years.
Molecular Sieve -
Active Carbon filter

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 17
Ø80 x 535 (max. working pressure 350 bar)
Replacement of active carbon –molecular sieve cartridge
1. Unscrew the filter housing by hand and remove it from its base.
2. Unscrew the A.C.-M.S. cartridges from the cartridge connector. Place and hold a wrench on the
cartridge connector while unscrewing the cartridges.
3. Lay a small amount of silicone grease on the o-ring of the filter’s base. If there is a trace of
damage on the o-ring, replace.
4. Remove the new A.C.-M.S. cartridges from their protective cases. If the packaging is damaged or
punctured do not use it.
5. Lay a small amount of silicone grease on the o-rings of the new A.C.-M.S. cartridges.
6. Screw the two A.C.-M.S. cartridges together so as to create a solid body.
7. Screw the new cartridges on the cartridge connector.
8. Clean the inside of the filter housing with a clean cloth.
9. Screw the filter housing carefully until securely fastened onto the base.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 18
Replacement of coalescing cartridge & active carbon –molecular sieve cartridge
1. Unscrew the filter housing by hand and remove it from its base.
2. Unscrew the A.C.-M.S. cartridges along with their connector (cartridge connector) from the tube
connector.
3. Remove the coalescing cartridge from the filter’s base by pulling upwards.
4. Lay a small amount of silicone grease on the o-ring of the filter’s base. If there is a trace of
damage on the o-ring, replace.
5. Install the new coalescing cartridge on filter’s base by fastening it down with your hand.
6. Wrap a small amount of Teflon around the thread of the tube connector.
7. Screw the cartridge connector on the tube connector (on top of the coalescing cartridge).
8. Remove the new A.C.-M.S. cartridges from their protective cases. If the packaging is damaged or
punctured do not use it.
9. Lay a small amount of silicone grease on the o-rings of the new A.C.-M.S. cartridges.
10. Screw the two A.C.-M.S. cartridges together so as to create a solid body.
11. Screw the new cartridges on the cartridge connector.
12. Clean the inside of the filter housing with a clean cloth.
13. Screw the filter housing carefully until securely fastened onto the base.

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 19
BA Filter’s part numbers
Part Nr.
Description
Qty
208000022
Filter housing
1
208000002
Filter base
1
137000040
AC/MS cartridge (active carbon/molecular sieve)
2
137000090
AC/MS/HP cartridge (active carbon/molecular sieve/hopcalite)
208000032
Connector cartridge
1
306049631
Coalescing cartridge
1
208000072
Tube connector
1
127126942
O-ring base
1
190000080
Manual drain complete with seat
1
190008112
Manual drain’s seat
1

User Manual - Typhoon Open – 12/2013 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 20
Air Flow Diagram
Item
Description
1
Air inlet
2
Coalescing cartridge
3
Connector
4
Tube connector
5
Purifier 1 Φ42x180 (AC/MS) or
Purifier 4 Φ42x180 (AC/MS/HP)
6
Filter base
7
Manual drain
8
Safety valve
9
Manual drain outlet
10
Auto drain outlet
11
Air outlet
