Paramina Typhoon Open 13E User manual

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 1
USER MANUAL
TYPHOON
OPEN

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 2
TABLE OF CONTENTS
Title
Page
1. General Instructions
3
2. Technical Data
4
3. User Instructions
Safety measures –Warning signs
5
Basic safety recommendations
6
Instructions for safe operation - risks
6
Special Attention
7
Safety regulations
7
4. Installation –Operation
General specifications
8
Installation - First start of the compressor
8
Ventilation
9
Transport and lifting
10
Electric version
11
Petrol version
12
Cylinder filling procedure
13
Dual pressure filling module
14
Automatic start & stop system
15
Condensate drainage
16
5. Maintenance
Long period storage of the compressor
19
Operation of the compressor after a long period
19
Intake Air filter
19
Belt adjustment
20
Oil change
21
Electric Box lifting for motor replacement (Typhoon Open 15E & 18E)
22
Filters Maintenance
23
BA Filter Φ80x535
24
BA Filter Φ78x560
28
BA Filter Φ110x495
32
BA Filter Φ110x495
34
General Service Instructions
39
Tightening Torque Values
40
Maintenance Calendar
41
Troubleshooting
42
6. Spare Parts Catalog (ES version pages 52-53)
44
7. P&I Diagram
64
8. Cooling air inlet/outlet –Overall dimensions
65
9. Certificates
67
10. Electrical Drawing
74

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 3
PARAMINA Typhoon Open Compressor
USER MANUAL
1. General Instructions
CAUTION: High pressure pneumatic device
The PARAMINA Typhoon Open compressor is a high pressure air-compressor offering high quality breathing air. It
is made according to EU directives 2006/42/EC for the safety of machinery. Noise complies with 2005/88/EC
directive.
The compressor must be used ONLY for producing compressed air as described in this manual.
Any other use is not allowed whatsoever!
Strictly observe all instructions pertaining to the operation and maintenance of this product. Fail to observe these
instructions may lead to serious injury or even death.
The manufacturer accepts no liability for damage or injury due to non-compliance to all instructions of this manual.
FOR YOUR SAFETY
Thoroughly observe the following:
1. Timely replacement of filter elements and activated carbon - molecular sieve filter.
2. Make sure that the air compressor is installed in a place that guarantees plenty of fresh air, without any
engine’s exhaust gas.
3. Proper cylinder maintenance
4. Proper compressor maintenance
5. Only trained and experienced technicians are allowed to overhaul this compressor.
6. NEVER INTERFERE WITH THE SAFETY DEVICES
7. In case you become aware of any change in the compressor’s operation, call us in order to help you responsibly
troubleshoot the product and to provide you with repair instructions.
8. NEVER USE THE COMPRESSOR FOR ANY OTHER GAS APART FROM ATMOSPHERIC AIR.
The instructions concerning safety are marked with this symbol.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 4
2. Technical Data
High pressure breathing air compressor, 3 cylinders, 3 stages, air-cooled.
Model:
Typhoon Open
13E
15E
18E
15P
18P
15D
Maximum
pressure:
350 bar (5075 psi)
Minimum
pressure:
40 bar (580 psi)
Capacity:
11-12 m3/h
185-200
lit/m
15 m3/h
250 lit/m
18-19m3/h
300-320lit/m
15 m3/h
250 lit/m
18-19m3/h
300-320lit/m
15 m3/h
250 lit/m
Ambient
temperature:
+5ºC to +45ºC
Oil capacity:
2,2 lit
Speed Rotation:
800-900rpm
1100 rpm
1290-
1380rpm
1100 rpm
1290-
1380rpm
1100 rpm
Piston stroke:
60 mm
Cylinder
bore:
1st
stage
80 mm
2nd
stage
36 mm
3rd
stage
14 mm
Operating
pressure:
225 bar 330 bar
1st stage 5,2-5,4 bar 5,4-5,5 bar
2nd stage 38,0-39,0 bar 42,0-43,0 bar
3rd stage 225,0 bar 330,0 bar
Motor/Engine:
4kW /400-
440V/50-
60Hz
5,5kW /400-
440V/50-
60Hz
7,5kW /400-
440V/50-
60Hz
6,3kW Petrol
Honda
8,7kW Petrol
Honda
6,8kW
Lombardini
Diesel
Dimensions
(LxDxH):
109x54x71cm
128x52x73cm
Weight:
185 - 191 Kg
185 - 191 Kg
187 - 211 Kg
171 Kg
189 Kg
198 Kg

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 5
3. User Instructions
Safety Measures - Warning Signs
HOT SURFACES
Do not touch.
Risk of burns if you touch
cylinders, aftercoolers, cylinder
heads
DANGER
This sign is placed whenever
there is danger of damage
caused to the unit or its
components
HIGH VOLTAGE
Risk of electric shock.
Maintenance work to be carried
out only by a trained electrician
DIRECTION OF ROTATION
Make sure for the proper
direction of rotation
USER INSTRUCTIONS
Users must read and fully
comprehend operation
instructions for using and
maintaining the compressor
This sign refers to
timely user instructions for
operating and maintaining
the compressor
AUTOMATIC OPERATION
Caution, the unit may start its
operation without any prior
notice. Before any work, turn
off mains supply
OBLIGATORY
During control and operation
of this unit you must wear
earplugs
RISK of rotating parts
TECHNICAL REQUIREMENTS
the operator must take into
account

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 6
Basic safety recommendations
The compressor is manufactured following current EU safety regulations.
The compressor is intended ONLY for compressing atmospheric air with a content of oxygen (21±1)%. Use of
any other gas type is not allowed. The manufacturer is not liable for damages caused by using the unit any
other way than the intended.
Use the compressor after making sure it is in perfect working condition. Any malfunction or failure must be
repaired immediately. Strictly follow the operation and maintenance instructions described in this manual.
Read carefully the instructions in this manual and follow them. Make sure users of the compressor are familiar
with the user instructions of the unit and its proper operation. Make sure they are authorized, trained and
trustworthy individuals. Make sure you are aware of and implement the current legal and all other regulations
pertaining to avoiding accidents and protecting the environment.
During first start or after maintenance, check motor’s direction of rotation. There is an arrow indicating proper
rotation. If the direction is reversed, interchange two of the three phase leads in the switch box.Never change
leads at the motor terminal board.
Before starting any work pertaining to maintenance of the compressor, turn off the supply from the mains and
press the Emergency Stop.
If regulations dictate it, use means of individual protection.
Pay attention to labels indicating safety and risk for the unit. Strictly follow them and do not destroy them.
For any change in the operation of the unit, contact immediately the manufacturer.
Any alteration –conversion of the unit without the manufacturer’s prior written consent is not allowed.
Spare parts MUST be genuine –approved by PARAMINA SA.
Get accustomed to the position and use of fire extinguishing equipment that must be near the compressors.
Instructions for safe operation - risks
Check the unit on the inside and outside on a daily basis in order to make sure it is in good working condition.
Do not start the operation of the unit if you do not ensure your own safety.
Before you operate the compressor, make sure that requirements are met for the safe and smooth operation of
the unit.
Floor must be even. Adjust the anti vibration pads, so as the unit is in horizontal position and shocks are
minimized.
Place the compressor in a well-ventilated area. Make sure that the intake air for the compressor is clean and
cool. Prevent the hot cooling air from recirculating to the cooling air intake. Make sure that foreign objects
cannot get into the compressor with the intake air. Make sure that the intake air does not contain any smells,
fuel or fumes, explosive or inflammable gases or harmful substances.
Units with petrol engine or diesel engine should not be used indoors.
Assign the unit (if it uses petrol engine or diesel engine) towards the
direction of the wind, so as fumes are getting away. In this case, use the
input hose of the inlet air filter in such a way, that fumes are avoided to
enter the compressor.
Keep the compressor away from flammable material. Do not smoke when opening the fuel tank.
If any malfunction of the unit occurs, stop immediately its operation and check –fix the problem.
Before any maintenance or repair works, inform the users.
When replacing heavy-weight components, strap them carefully on the proper lift truck. Never walk under such
components when they are lifted.
Before any maintenance works, clean the area from out-of-use material, oils, fuel or other liquids from the unit.
Do not use corrosive materials. If you clean the unit by water or steam, make sure that neither (water nor
steam) comes close to the electric motor or the electric system and ensure that they will not enter open hoses.
For cleaning, use lint-free cloth.
After cleaning or repairing the unit, check all hoses for leaks, loose connections, wear or damages. Tight again
all connections and recheck every maintained safety device.
Ensure safe and environmental friendly disposal of consumable materials and old spare parts.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 7
Special attention
Do not use the compressor in explosive environment.
Connect the compressor only to electrical systems that are compatible with its electrical characteristics and that
are with in it’s rated capacity
Comply with the local mains supply company regulations.
Use only the recommended fuses.
A trained electrician may only execute maintenance in the electrical system.
During any maintenance work in the unit, turn off the power from the mains. It is also recommended posting a
notice warning about maintenance works on the compressor.
In case of having to execute maintenance works on an operating unit, a second person beside the electrician
must be present to handle the main safety switch or the Emergency Stop. Tools to be used must be isolated.
Regularly check hoses, couplings and fittings for leaks and loose connections.
Regularly check tightening of the electrical connections.
If you replace any cable, you must use the same type.
Decompress all hoses, filters, pressure tanks and, basically, the entire unit, before you carry out any work.
Never exceed the allowed operating pressure of the cylinders.
Immediately replace cylinders with any kind of damage.
Do not heat the cylinders or any of their parts, because pressure will rise.
For loading –lifting of the unit or heavy parts of it, use the proper lift truck that is handled by trained stuff.
Make sure you have properly secured the unit during its elevation or transport.
The compressor is not made for use by the sea. In such a case, spray the unit with anticorrosive material.
Portable compressors (if used on a boat/ship) must be stored under the deck after use.
Safety Regulations
The PARAMINA Typhoon Open compressor is a high pressure air-compressor and it is made according to EU
directive 2006/42/EC for the safety of machinery. Noise complies with 2005/88/EC directive.
The manufacturer follows all regulations above and declares that the unit is manufactured accordingly.
Following the safety regulations, an authorized professional in site must supervise compressors that will be used as
filling stations before starting their operation.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 8
4. Installation –Operation
General Specifications 
High pressure compressors are complete units for filling cylinders with compressed air at 225 bar (3200 psi) and
330 bar (4700 psi). They are mostly used for compressing breathing air for divers, fire brigades, military, paint ball
applications, etc.
Typhoon Open is a 3 staged, piston, air cooled compressor with 3 cylinders, 2 intercoolers and 1 final aftercooler,
condensate separator after the second stage aftercooler, accompanied with automatic and manual drain,
mechanical safety valves as well as two (2) filtering stages at the final pressure (after the third stage):
The first filter contains an element for retaining particles and oil droplets down to 0.01 ppm (Coalescing element).
Then there is the second and final stage of dehumidification with Molecular Sieve and air purification with
Activated Carbon.
The Final stage for Paint Ball application consists of two (2) Molecular Sieve Filters.
Installation - First start of the compressor 
All compressors are tested and pre-adjusted by the manufacturer before they are shipped to the buyer.
They can start their operation immediately on the following conditions that are considered necessary, for safety
and ease.
Anyone who will be handling the unit must read carefully all contents of this manual so as to have full knowledge of
the product.
1. Choose carefully the installation place of the compressor. The place must not be burdened by unfavorable
environmental conditions (toxic substances –explosives –fumes –dirt –debris etc.
2. Place the compressor in a well ventilated area. Make sure that the intake air for the compressor is clean
and cool. Prevent the hot cooling air from recirculating to the cooling air intake. Make sure that foreign
objects cannot get into the compressor with the intake air. Make sure that the intake air does not contain
any smells, fuel or fumes, explosive or inflammable gases or harmful substances.
3. Turn the compressor using the fly-pulley and make sure it turns freely. Do the same after overhaul of the
unit or a long-term out of service period.
4. Before any start of the compressor, check oil level. It should be between the minimum and maximum limit.
5. The compressor should be placed in a completely horizontal position. If during operation there are
vibrations, adjust the anti-vibration pads of the stand until vibrations are minimized.
6. During every start of the compressor, in versions without auto drains, open only the drain valve of the
2nd stage. Then during the regular operation of the compressor open both 2nd and 3rd stage drain valves
every 15 (2nd stage) & 20 (3rd –final stage) minutes.
7. When Main Switch is installed: After turning on the main switch, user must first press the reset button
and then the start button in order to start the compressor.
ATTENTION:
Larger oil quantity may increase pressures inside the block, cause leaks of larger oil quantity in the pneumatic air
resulting in the creation of chars in the valves, burden the filters and affect their life duration, as well as the quality
of breathing air.
Smaller amount of oil means inadequate lubrication affecting the life duration of the compressor.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 9
Ventilation 
Natural ventilation
Forced ventilation (fan)

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 10
Transport and Lifting
Check compressor's center of gravity.
Do not step under the load
Transport with Lifting
1. Spreader beam between lifting ropes
2. Two support beams underneath
3. The lifting ropes must not squeeze the compressor
casing!
Transport with forklift truck
Exercise great caution when lifting and transporting the
compressor.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 11
Electric version
Electrical connections
The electrical connections are to be carried out according to IEC standards and national regulations for safety of
electrical equipment.
Make sure the operating voltage is correct (max. deviation from the specified voltage ± 5%).
Connect the power supply cable to the compressor main switch. See wiring diagram and technical specification for
the power requirement of the compressor.
-The connection of the earth wire is especially important.
-Only qualified electricians are allowed to carry out the electrical connections.
First start
1. Turn the main switch to ON position (4).
2. Press the Start button (1). [if the electric box is equipped with a reset button and it is enabled, first press the
reset button to disable it and then the start button in order to start the compressor]
3. Immediately after switching on the system for the first time, check the direction of the rotation of the motor
using the direction arrow on the unit. If the three-phase motor turns in the wrong direction, the phases are
not connected properly. Shut down unit immediately by pressing the emergency stop button (3) to make the
compressor stop without delay. Isolate the power and interchange two of the three phase leads in the switch
box. Never change leads at the motor terminal board.
3. When the pressure reaches the desired level press the stop button (2) to stop the compressor. In auto-stop
version the compressor stops automatically at the pre-adjusted final pressure.
4. After finalizing all works, turn the main switch to OFF position.
- Wrong direction of rotation will damage the compressor unit.
- Check the direction of rotation every time the compressor is connected to the power supply.
2
1
3
4

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 12
Petrol/Diesel Version
ENGINE START
First turn engine’s key (1) to position ON and check that the battery gives power to the petrol engine. Then turn
the key right to position START so as to start the engine and the compressor.
For Petrol Version: Before starting the engine turn on the drain switch (2).
ENGINE STOP
When the final pressure is reached turn the key to position ON so as to stop the compressor and then to position
OFF so as to cut the power from the battery too.
For Petrol Version: After finalizing all works do not forget to turn off the drain switch, otherwise compressor’s
battery will be empty!
General instructions
Read carefully engine’s operating instructions
Check the fuel level and fill if necessary.
Check motor oil according to manufacturer’s directions.
Open fuel valve.
Do not disconnect the battery during compressor’s operation. Coils of solenoid valves (auto drains), will be
destroyed (version with auto drains).
2
1
1

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 13
Cylinder filling procedure 
Make sure that filling hoses as well as threads are in perfect condition without cracks or breaks.
Filling hose connectors should be connected on the cylinder without the use of tools. Sealing is achieved with o-ring
and internal pressure.
A. Filling hose connectors used for filling cylinders up to 232 bar are divided in two categories:
Filling Connector according to DIN 200
INTERNATIONAL / ‘’A’’ Clamp Adaptor
B. For cylinders filling at 330 bar, only the use of filling connectors according to DIN 300 (different adaptor
than the one at DIN 200 bar) is allowed.
Use cylinders that correspond to the pressures produced by the compressor. All the using filling cylinders
must be in accordance with international standards and directives. They must have the corresponding mark
(symbol and technical data) at its neck and a valid hydraulic overpressure certificate test. Cylinder valve has to be
DIN200 or DIN300 (according to EN 144-2).
Check the cylinder safety pressure (232 or 330 bar for example) so as to correspond to the preset final pressure of
the compressor.
Connect the cylinder, having the filling hose connector’s valve and the cylinder’s valve turned off, and start the
compressor by pressing the Start button.
Then, first turn on the filling hose connector’s valve and then the one of the cylinder.
200bar filling
DIN 200 filling connector
(Only up to 232 bar)
DIN 300 filling connector
(ATTENTION: longer adaptor)
(Up to 330 bar)
INTERNATIONAL
/ ‘’A’’ Clamp Adaptor
(Only up to 232 bar)

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 14
When filling is complete, first turn off the cylinder’s valve and then the filling hose connector’s valve and proceed to
air venting using the relief valve on the connector. Finally, safely disconnect the cylinder.
During the filling procedure, cylinder’s temperature will rise. Let it cool down. Pressure will slightly drop. If you
wish, re-connect the cylinder with the filling hose (following the same procedure) and fill until the maximum filling
pressure.
Never open the filling hose connector valve, unless the cylinder is connected to the filling hose. Hose
whipping due to pressurized air can cause serious injury!
Automatic stop system
Standard equipment in all electrical versions.
Optional equipment in petrol and diesel versions.
When the pressure reaches the pre-adjusted final level the compressor stops
automatically {through the pressure switch (1)}. The restart of the compressor
must be done manually.
Max. operating pressure 350 bar.
Dual pressure filling module
Optional equipment.
It controls the pressure through a pressure regulator (1) (0-345 bar outlet pressure) and gives the possibility to the
user to fill 200 and 300 bar cylinders simultaneously.
1
300bar filling
1

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 15
Pressure switches adjustment:
Auto Stop = Pressure switch 40-400 bar
Auto Start / Stop = Pressure switch 30-500b dual

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 16
Condensate drainage
Manual drain system
Each time you stop the compressor open the manual drain valves (1, 2) so as to remove condensate. During every
start of the compressor, open only BA filter’s drain valve (1). Then during the regular operation of the compressor
open both 2nd (1) and BA filter (2) drains every 15 (2nd stage) & 20 (3rd –final stage ) minutes.
*If the compressor is equipped with the option of final stage separator, open its manual drain (3) for drainage
instead of BA filter drain (1). In this case, BA filter’s manual drain will be used only for checking BA filter’s
air/condensate quality once per day.
A. Option Two timers –Old version + T.OP.15ED & 18ED:
B. Standard equipment in all electric versions.
C. Optional equipment in petrol and diesel versions.
The system consists of two timer controlled condensate drains, one after the 2nd, and one after the final stage on
the BA filter or the final stage separator. The drains are controlled electronically and open automatically.
Max. operating pressure: 2nd stage drain valve: 80 bar, 3rd stage drain valve: 250 or 350 bar
In case of emergency (damaged auto drain system), the user may use the two manual drains. During routine
operation open both drain valves every 15 (2nd stage) & 20 (3rd –final stage) minutes.
2nd Stage 3rd Stage
2
1
3
1
1
2
2
The user can adjust the interval time (2) from 0,15 -
15 sec (proposed time 1,5sec), and the discharge
time (1) from 0,15 - 15 min (proposed time 15
min),
Note for 2nd Stage drain only: The numerous at
internal time (2) are at a percentage of 15sec. So at
internal time (2) 1,5 sec = 10(%). Respectively the
numerous at discharge time (1) are at a percentage
of 15min, so 15min = 100(%)
The user can adjust the interval time (2) from 0,5 -
45 min (proposed time 20min), and the discharge
time (1) from 0,5 - 10 sec (proposed time 2-3
sec).

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 17
B. Option Two timers –Petrol & Diesel series:
The system consists of two timer controlled condensate drains, one after the 2nd, and one after the final stage and
the BA filter. The drains are controlled electronically and open automatically.
In case of emergency (damaged auto drain system), the user may use the two manual drains. During routine
operation open both drain valves every 20 minutes.
2nd & 3rd Stage
C. Option One timer –New Versions:
The system consists of one timer, located inside compressor’s electrical box. It controls electornically both 2nd & 3rd
stage condensate drains, which open automatically.
In case of emergency (damaged auto drain system), the user may use the two manual drains. During routine
operation open both drain valves every 20 minutes.
Pause Time = 20 min
Signal Time = 2 –3 seconds –set signal time first
Important Note: Do not change manufacturer adjustments.
1
2
The user can adjust the interval time (2) from 0,5 -
45 min (proposed time 20min), and the discharge
time (1) from 0,5 - 10 sec (proposed time 2 sec).

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 18
Note 1: Condensate color is milky-white. If condensates suddenly change color or start smelling, this is indication of
oil presence. Immediately check:
1. oil quality
2. oil level
3. filters’ condition and especially the condition of active carbon filter
4. air inlet filter’s condition
5. piston rings and cylinders condition
Note 2: All petrol compressors are equipped with an auto drain switch (5). Turn on this switch always before
engine start and turn it off after finalizing all works (otherwise compressor’s battery will be empty).
EMERGENCY START TOGGLE SWITCH
IMPORTANT NOTE: DO NOT USE THIS SWITCH UNLESS YOU HAVE FULLY UNDERSTOOD HOW IT WORKS.
USE THIS SWITCH ONLY IF BATTERY IS TOTALLY DRAINED OUT
Attention: This switch deactivates all the operating –safety functions and detours all functions (pressure switch –
low compressor oil alarm), allowing manual engine start.
How to use the emergency toggle switch:
If the battery has drained out and is not possible to start the engine via the electric starter, turn the switch to
MANUAL position (run without battery) and start the engine manually. After engine starts, RETURN the switch to
the RUN position (run with battery).
Attention: Before using this switch, ensure that there is no other reason that prevents the unit from starting
electrically (low oil level in engine or on compressor, high pressure on final stage, engine protection activated,
lack of fuel, or any other reason)
DO NOT RUN THE COMPRESSOR WITH BATTERY DISCONNECTED
5

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 19
5. Maintenance
Compressor’s long period storage
In case the compressor is intended to stay out of operation for more than three months, special procedure should
be followed for the storage as well as for its re-operation:
Make sure it is stored in a closed, dry, dust-free place.
Run the compressor at normal pressure for 10-15 minutes.
Check filters, hose connections and safety valves for leaks.
Tighten all connections, if necessary.
Open manual drain valves and run the compressor without pressure for 5 minutes.
Stop the compressor, drain well and shut all valves.
Open filters and put special grease used in the food industry or Vaseline on all threads. Filter elements should
normally be in their place.
Let the compressor cool down.
Start the compressor and spray some compressor oil (5-6 c.c.) in the suction while in operation.
Do not let the compressor heat up, stop its operation.
Close all valves.
Wrap the inlet air filter with nylon.
Cover the compressor with a plastic cover to keep the dust out.
-Units and motors should always be stored in a dry, vibration - free and dust - free environment.
-Unprotected machined surfaces (shaft –ends and flanges) should be treated with an anti –corrosive.
-It is recommended that units and motors shafts are periodically rotated by hand to prevent grease
migration.
-Anti –condensation heaters are recommended to avoid water condensation in the motor and should
preferably be energized.
Re-Operation of the compressor after a long period of storage
Remove the nylon and place a new inlet air filter.
Follow the procedure related to the first start of the unit.
Run the compressor functioning at normal pressure for 5-10 minutes.
Change the oil.
Place new coalescing filter element, Active Carbon-Molecular Sieve.
Intake air filter
Replace the air intake cartridge every 200 hours or once per year.
According to the environment it is recommended to change the
air filter element at the end of season.
cartridge part nr.: 109460302
Protective cap for air intake filter of electric models.

User Manual - Typhoon Open –01/2018 edition
.
PARAMINA SA –Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: [phone]
Fax: [phone], email: [e-mail] - website: www.paramina-compressors.com 20
Protective cover for air intake filter inlet hose of petrol and diesel models.
Belt adjustment
Check tension of belts after the first 20 hours of operation and
then every 100 hours. Pressing in the center of the belt’s length
applying 5 Kg of force, it should not give way more than 20 mm.
In order to adjust the belts, screw the bolt (1) so as to adjust the spring until the belt reaches proper tension as per
drawing above.
1
1
