Parker Velcon VF Series User manual

VEL2199 04/14
Velcon Filtration Division
Effective: April 2014
Standard
Filter Vessel
Installation and
Operation
Manual (VF &
HF)
Parker Hannin Corporation
Velcon Filtration Division
1210 Garden of the Gods Road
Colorado Springs, CO 80907
[phone] Phone
[phone] Fax
www.velcon.com
[e-mail]

2Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
WARNING
DO NOT PRESSURE TEST
THIS VESSEL WITH AIR!
PRESSURE TESTING
WITH AIR IS A
HAZARDOUS PROCEDURE!
THIS VESSEL IS TO BE PRESSURIZED
ONLY WITH THE LIQUID FOR WHICH IT
IS INTENDED TO BE USED AND ONLY
TO THE MAXIMUM DESIGN PRESSURE
SHOWN ON THE VESSEL NAME PLATE.

3Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
TABLE OF CONTENTS
General Description.....................................................................................................................4
Installation of Vessel....................................................................................................................5
Start-Up Procedure .....................................................................................................................6
Operating Information .................................................................................................................7
Cartridge Change or Inspection Procedure ..............................................................................13
Installation Instructions
Open-Ended Filter Cartridges ...................................................................................................10
Torque Requirements for Vessels with O-ring Closures............................................................11
Installing Tie Rods .....................................................................................................................12
Appendix
A - Pleated Media Filter Cartridges .................................................................................... 16-17
B - F0-6xxA3 & FOH-6xxA1 - EI1590 Qualied Filter Cartriges ......................................... 18-19
C - VF Series - Vertical Filter Vessels.................................................................................. 20-21
D - Assembly Torque Recommendations ........................................................................... 22-23
DISCLAIMER: This generic vessel manual is provided for your information with the
understanding that each vessel sent out from Velcon is customized for the particular
vessel and contains accessory information not included in this document. This docu-
ment makes references to other pieces of literature, such as schematics and drawings
that are added to the manual as needed depending on the vessel parameters.

4Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414

5Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
GENERAL DESCRIPTION
The Velcon that you have received consists of the vessel,
filter elements, and accessory equipment to meet your
specific requirements. Descriptive literature covering the
accessories is included near the back of this manual.
A Velcon is specifically designed to remove solid
contaminants from the product being filtered. The product
enters from the inlet nozzle, rising vertically behind a baffle
until it reaches the region above the top of the highest
elements. The elements are arranged in vertical stacks
rising up from a flat division plate. The fluid enters the
outside of each element and flows toward the center of the
element. The flow then goes downward to the outlet.
Velcon are manufactured to meet a variety of different end
uses and specifications. The finest workmanship has gone
into the building of this Velcon. It is of no value, however, if
elements are improperly installed or the unit is improperly
operated. We urge you to read the manual carefully and
follow the instructions given.
NOTE Velcon has qualified the FO-6xxA3 pleated
media filter cartridges to EI Specification 1590,
“Specifications and Qualification Procedures for
Aviation Fuel Microfilters.”
INSTALLATION OF VESSEL
1. Identify the Filter inlet and outlet by the markings
provided on the vessel piping. The Filter must be
installed in the correct direction of ow to perform
properly and to avoid damage to the system.
2. INLET and OUTLET PIPING should be carefully
aligned to avoid stressing the Filter connections
during installation. Installation of shut-off valves on
either side of the Filter is recommended so that it
can be independently drained for cartridge change
or inspection.
CAUTION
STEPS 3 AND 4 SHOULD BE
PERFORMED BEFORE REMOV-
ING HINGE OR PIVOT MOUNTED
COVER TO ENSURE STABILITY OF
THE FILTER.
3. Bolt the lter to a stable base.
4. Carefully install correct gaskets on the inlet and
outlet connections and connect to the inlet and
outlet piping.
5. Connect any accessories that are not already
installed. See Accessory Parts List and literature
as required.
6. Cartridges are normally packed separately.
Open the vessel cover and install cartridges as
explained on page 8 and as per enclosed element
stack drawing. Tighten nuts on tie rods until the
rubber washers begin to curl. Do not over-torque.
sequence.
7. Be sure the cover gasket is in place and properly
aligned. Replace cover and secure tightly.
NOTE FILTERS MUST BE PROVIDED WITH
PRESSURE RELIEF VALVES IF THE
SYSTEM HAS POSITIVE DISPLACEMENT
PUMPS UPSTREAM OR AUTOMATIC
SHUT-OFF VALVES DOWNSTREAM OF
THE VESSEL.
START UP PROCEDURE
If the Velcon Filter has the accessories listed below, they
should be placed in the following positions:
1. Manual drain valves closed.
2. Manual air eliminator valve open.
3. The valves in the inlet and outlet piping should be
closed.
4. The pressure gauge valve to OFF position. For
Filters equipped with selector valves, this is done
by turning the handle outward so that the arrow
points toward the vessel.
For information on operation of accessories, turn to
Accessory Instructions in the back of the manual.
After the valves have been positioned as outlined, the unit
is ready to be filled.
The following operating instructions can be used for initial
start-up and for subsequent start-ups after installation of
replacement elements or servicing of the unit.
1. Start the system pump.
2. Slightly open the inlet valve, allowing the Filter to
slowly ll with uid. (Take about 10 – 15 minutes
to ll the vessel to eliminate the possibility of an
internal re.)
3. If the unit is equipped with a manual air eliminator
valve, leave the valve cracked open until the uid
ows from the opening; then close quickly.
4. If equipped with an automatic air eliminator, the
unit is lled when the air eliminator stops owing
air. When the Velcon Filter is lled with uid, slowly
open the valve on the inlet line, then slowly open

6Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
the valve on the outlet line.
5. When the unit is in operation, open the pressure
gauge, take a differential pressure reading and
record the reading. If there is no pressure differen-
tial, the system should be shut down and the Filter
inspected for broken seals or possibly elements left
out. See Differential Pressure Readings on Page 5
OPERATING INFORMATION
Below are the Velcon recommendations for operating
procedures. Your Company Maintenance and/or Quality
Control procedures may provide alternate instructions on
these matters.
1. FILTER CARTRIDGES should be changed in accor-
dance with one of the following (whichever comes
rst):
A. When the differential pressure reaches the level
specied on the cover page of this manual.
For Filters equipped with differential pressure
gauges, see paragraph 2 below.
B. When the ow rate is reduced to an unaccept-
able level because the cartridges are plugged
with contaminant.
C. Whenever efuent product is unacceptably
contaminated.
2. DIFFERENTIAL PRESSURE READINGS Differential
pressure is the difference between the pressure
upstream and downstream of the Filter. Differential
pressure increases when contaminant is ltered by
the lter cartridges and causes ow restriction.
Readings should be taken when the system
is owing at maximum capacity. If the Filter is
equipped with a direct reading differential pressure
gauge, the reading shown on the gauge is the dif-
ferential pressure across the Filter.
If the Filter is equipped with a pressure gauge and
a selector valve, use the following procedure for
determining differential pressure:
A. Turn the handle one way and record the pres-
sure reading.
B. Turn the handle the other way (90° or 180°,
depending on the type of valve) and record the
pressure reading.
C. Subtract the lower reading from the higher
reading to determine differential pressure. (The
higher reading is inlet pressure.)
If the lter/separator is equipped with a pressure
gauge and a selector valve, use the following
procedure for determining differential pressure:
A. Turn the handle one way and record the
pressure reading.
B. Turn the handle the other way (90° or 180°,
depending on the type of valve) and record the
pressure reading.
C. Subtract the lower reading from the higher
reading to determine differential pressure. The
higher reading is inlet pressure.
Differential pressure readings should be taken at
least once during every operating week and more
frequently in high throughput installations or when
the differential is increasing rapidly. Records of
the differential pressure and throughput should be
maintained to determine when cartridges should
be changed.
A sudden drop in pressure differential is an indica-
tion of a possible problem. Check rst to be sure
that readings were taken at equivalent ow rates.
If so, shut the system down, open the Filter, and
inspect for the following:
A. Collapsed or ruptured cartridges caused by
severe pressure differential or shocks in excess
of design limits.
B. Ruptured seals. Check to see that all O-ring
seals and gaskets seals are in place and have
the same alignment as when the elements and
parts were installed.
C. Broken end plates. Inspect all of the end plates
of the elements.
D. If any of the above are observed, check the
system for possible hydraulic shock condi-
tions. If the system is not provided with ad-
equate surge controls, the sudden start-up of a
high-pressure pump can create extremely high
shock
CARTRIDGE CHANGE OR INSPECTION PROCEDURE
A. Shut off the pump.
B. Close the inlet and outlet pipe valves.
C. Open the drain valves and remove the product
from the Filter.
D. Open the manual air eliminator valve. This will
permit the unit to drain faster.

7Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
E. Open the cover and inspect the cover gasket –
replace the gasket if it is damaged.
F. Completely drain lter chamber.
G. Remove spent cartridges for cartridge change.
H. Wipe off or wash down any foreign matter from
the vessel interior.
I. Install the cartridges in accordance with in-
structions on page 8.
J. Tighten nuts on tie rods until the rubber wash-
ers begin to curl. Do not over-torque.
K. Check the cover gasket for alignment, re-
place the cover and secure tightly. The Filter
is now ready for the start-up procedure.SUMP
CHECKS
NOTE USE ONLY PARKER VELCON
CARTRIDGES IN THIS FILTER. VELCON
CANNOT WARRANT PERFORMANCE
IF ANY OTHER MANUFACTURER’S
CARTRIDGES ARE USED.
To reorder cartridges and replacement parts or
to obtain further information, contact your Velcon
representative:
Parker Hannin Corporation
Filtration Group
Velcon Filtration Division
1210 Garden of the Gods Road
Colorado Springs, CO 80907-3410
Tel: [phone]
Fax: [phone]
[e-mail]
www.velcon.com

8Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414

9Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Installation
Instructions

10 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Installation Instruction for Open-End Filter Cartridges
1. Turn off pump. Close inlet and outlet valves and
open drain valve. Open the air eliminator or manual
bleed valve and drain the vessel.
2. Open vessel after making sure the vessel is com-
pletely drained.
3. Jack-up head and swing aside. Remove the spider
(if installed). Remove nuts and washers, endcaps,
old cartridges, and center plates, if any.
4. Wipe vessel clean whenever possible or ush.
5. Place cartridge over the center rod making sure
the cartridge is centered over the guide bar or
mounting adapter attached to the deck plate. The
cartridge must be seated at against the adapter
or deck plate.
6. For vessels with stacked cartridges, place the rst
tier of lter cartridges in position at all bulkhead
ports (per step 6). Insert center plate onto center
rod and insert into each cartridge. Next, install the
second tier of cartridges over the center plates.
There must always be a center plate between
every two stacked cartridges. Be sure the circular
guide on both sides of the center plate projects
into each cartridge.
7. When all cartridges are loaded, insert sealing cap
over center rod.
8. Install rubber washer, at washer, lock washer, and
nut in that order, onto each center rod. Tighten to 4
to 5 foot pounds of torque. (DO NOT TOUCH THE
OUTER FILTER MEDIA.)
9. Replace the spider as follows (if spider is not in-
cluded proceed to step #10):
Install the flat washer over each cartridge end and
install the spider over the ends of the cartridges.
Affix the spider to the threaded clips on the vessel
walls using the nut and lockwasher.
Adjust the spider clip nuts, so the spider lies flat on
the ends of the cartridges
Install the washer and nut over the ends of the
cartridges, to affix the spider to the cartridge ends.
Snug the nuts. DO NOT TIGHTENYET.
Adjust the ends of each cartridge to create even
separation between the cartridges and between the
cartridge and vessel wall.Cartridges should NOT
be touching each other, nor touching the vessel
wall.The ends of the cartridges can be shifted
within the spider plate holes as follows:
Cartridge
Length Shift Within the Spider Hole
Greater than
33"
Full movement within the spider
hole
30" Less than 5/8" (16 mm)
28" Less than 9/16" (14 mm)
24" Less than 1/2" (12 mm)
22" Less than 1/2" (12 mm)
20" Less than 3/8" (10 mm)
18" Less than 3/8" (10 mm)
16" Less than 1/4" (8 mm)
14" Less than 1/4" (6 mm)
11" Less than 1/4" (5 mm)
9" Less than 3/16" (5 mm)
When the cartridges are spaced properly, tighten
the spider nuts to 5 ft-lbs.
10. Inspect the cover gasket and replace it if neces-
sary. Tighten the cover securely in a cross-pattern
process.
11. Close the drain valve and start the system pump.
12. With the outlet valve closed, slightly open the inlet
valve and allow the vessel to ll SLOWLY with fuel
until the air eliminator closes or uid begins to ow
from the manual air vent. Close the vent valve.
Fully open the inlet valve.
13. Open the outlet valve SLOWLY.
14. When the unit is operating, check the differential
pressure across the cartridges. There should be
indication of positive pressure, normally 1-5 psid.
This insures that all seals have been properly made
during the installation.
OPERATING PROCEDURES
Velcon Recommended Cartridge Changeout (also
reference your company guidelines):
1 year or 15 psid for AVIATION APPLICATIONS
3 years or 25 psid for NON-AVIATION
APPLICATIONS whichever occurs first (INSPECT
VESSEL ANNUALLY)

11 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Torque Requirements for Vessels with “O-Ring Closure”
Bolted pressure vessel closures operate on the premise that
the joint is clamped closed with a force sufficient to resist
the internal pressure yet still maintain a seal. The clamping
force, or pre-load, is applied by the closure bolts and its
magnitude is controlled by the torque applied. Application
of the correct preload is essential to maintaining a
positive seal and avoiding closure failures from fatigue or
overstressed vessel components.
The short term, and most obvious effect of grossly under-
torqued bolts is insufficient clamping force resulting
in a leaking closure. A more ominous result of under-
torqued bolts in systems which see a great number of
pressure cycles (such as refuelers, loading racks etc.), is
bolt fatigue failure. Repeated applications of stress to the
bolt eventually create a small crack at the surface of the
bolt which continues to grow until the bolt breaks and the
closure fails.
It is a good idea to re-torque the closure bolts after they
have been in use for a month or so to ensure the joint has
not “relaxed” and the preload reduced.
Over-torquing closure bolts will result in breaking or
bending vessel bolt clips or actually breaking the bolt
itself. Table One lists guideline torque values for lubricated
bolts for common sizes used for vessel closures. Always
use lubricated bolts, as this reduces the required torque,
improves torque accuracy, and retards corrosion.
A common cause of inaccurate bolt torque is inappropriate
bolt torquing procedures. Key elements to the procedure
are application of the torque in stages and in a specific
cross-torquing sequence. For most applications, torque
is applied to all bolts to 30% of full torque, then to all bolts
to 60% of full torque, and finally to all bolts to 100% of full
torque. Each torquing cycle is carried out in the applicable
cross-torquing sequence. Torquing sequences vary with
the number of bolts on the cover.
The tightening pattern is as follows: Tighten two bolts
diametrically opposite from each other, then tighten a
second pair of bolts diametrically opposite each other,
approximately 90 degrees away from the first pair, and so
on until all bolts have been tightened.
Using a clock as an example, the sequence would be: 12 - 6,
9 - 3, 11 - 5, 10 - 4, 7 - 1, and 8 - 2.
On large vessels, the cross-torquing process is tedious
but the addition of a second operator applying torque
improves the situation vastly.
Correct closure torquing will result in many years of
trouble-free vessel operation. Occasional inspections
for bolt cracks or clip damage is good practice to detect
possible closure problems before they occur.
TABLE ONE*
Bolt Diameter
mm (in.)
Recommended Torque
m-kgs (ft-lb)
13 (1/2) 3 (20)
19 (3/4) 6 (45)
25 (1) 14 (100)
32 (1-1/4) 22 (160)
38 (1-1/2) 36 (260)
*NOTE: These recommended torque values are only for vessels with an
O-Ring closure.

12 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Installation ofTie Rods
REFERENCE MATERIAL
Form 1801- “Assembly Torque Recommendations”
VESSELS WITH TIE RODS
Filter vessels
Clay vessels
Monitor vessels containing 6” Aquacon®cartridges
Filter/separator vessels (for coalescer and separators)
HARDWARE
Tie rods
Hardware (nuts, flat washers, lock washers, seal nuts)
Cartridges
Mounting adapters
Center spacers
End caps
MOUNTING CONFIGURATIONS
With spider
Without spider
With seal nut
VERTICAL OR HORIZONTAL OPEN ENDED
CARTRIDGES WITH SPIDER PLATE:
1. Screw a nut on one end of the tie rod to about 2”
from the end (see note on bottom of page 2).
2. Slide a lock washer up against the nut on the
shortened side of the tie rod.
3. Slide a mounting adapter (on vessels with integral
cast-in or welded-in mounting adapters, no ad-
ditional adapter is required) on the short side of the
tie rod with the cartridge seal side facing the nut
and washer.
4. While holding the mounting adapter on the end of
the rod, screw the short end of the tie rod into the
tie rod bar on the vessel. Screw in about one inch.
5. Install a cartridge over the tie rod and into place on
the mounting adapter.
6. If cartridges are stacked, install center spacers
between cartridges.
7. Place an end seal plate on the top or end of the
cartridge (or cartridge stack) with the tie rod ex-
tending out from the end seal plate tie rod hole.
8. Adjust the tie rod by screwing it in or out until the
amount extending beyond the end cap is 1-5/8”.
Remove the cartridges, spacers, and caps.
9. Screw the nut at the end of the tie rod down
against the mounting adapter while preventing the
tie rod from turning.
10. Tighten the nut to 5 foot pounds of torque.
11. Install the other tie rods so that they extend out
from the mounting adapters the same length as
the rst rod.
VERTICAL OR HORIZONTAL OPEN ENDED
CARTRIDGES WITH NO SPIDER PLATE:
1. Screw a nut on one end of the tie rod to about 2”
from the end. (See note below.)
2. Slide a lock washer up against the nut on the
shortened side of the tie rod.
3. Slide a mounting adapter (on vessels with integral
cast-in or welded-in mounting adapters, no ad-
ditional adapter is required) on the short side of the
tie rod with the cartridge seal side facing the nut
and washer.
4. While holding the mounting adapter on the end of
the rod, screw the short end of the tie rod into the
tie rod bar on the vessel. Screw in about one inch.
5. Install a cartridge over the tie rod and into place on
the mounting adapter.
6. If cartridges are stacked, install center spacers
between cartridges.
7. Place an end seal plate on the top or end of the
cartridge (or cartridge stack) with the tie rod ex-
tending out from the end seal plate tie rod hole.
8. Adjust the tie rod by screwing it in or out until the
amount extending beyond the end seal plate is
one (1) inch.
9. Remove the cartridges, spacers, and seal plates.

13 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
10. Screw the nut at the end of the tie rod down
against the mounting adapter while preventing the
tie rod from turning.
11. Tighten the nut to 5 foot pounds of torque.
12. Install the other tie rods so that they extend out
from the mounting adapters the same length as
the rst rod.
SEPARATOR WITH SEAL NUT (WITH OR WITHOUT
SPIDER PLATE):
1. Screw a nut on one end of the tie rod to about 2”
from the end. (See note below.)
2. Slide a lock washer up against the nut on the
shortened side of the tie rod.
3. Slide a mounting adapter (on vessels with integral
cast-in or welded-in mounting adapters, no ad-
ditional adapter is required) on the short side of the
tie rod with the cartridge seal side facing the nut
and washer.
4. While holding the mounting adapter on the end of
the rod, screw the short end of the tie rod into the
tie rod bar on the vessel. Screw in about one inch.
5. Install a separator over the tie rod and into place
on the mounting adapter so the tie rod extends
from the end seal cap tie rod hole.
6. On double open ended separators, place an end
seal plate on the top or end of the separator, with
the tie rod extending out from the end seal plate tie
rod hole.
7. Adjust the tie rod by screwing it in or out until the
amount extending beyond the end seal plate is
one (1) inch.
8. Remove the cartridges, spacers, and seal plates.
9. Screw the nut at the end of the tie rod down
against the mounting adapter while preventing the
tie rod from turning.
10. Tighten the nut to 5 foot pounds of torque.
11. Install the other tie rods so that they extend out
from the mounting adapters the same length as
the rst rod.
NOTE 1. In AHM06xxx, AVM06xxx, HM06xxx,
and VM06xxx Aquacon® vessels, the
nut should be screwed on to the tie
rod to about 4” from the end instead
of 2”.
2. In three stage HVM-xxxx lter/sepa-
rator vessels, the nut on the separa-
tor tie rods should be screwed on to
the tie rod to about 4” from the end
instead of 2”.

14 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414

15 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Appendix / Accessories

16 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Pleated Media Filter Cartridges
High Efficiency, Long Life Cartridges for Aviation Fuel
FO-412PLxx FO-718PLxxFO-512PLxx FO-644PLFxxTBFO-614PLFxx
FEATURES
Large Surface Area – Allows high
flow rate with low initial pressure
drop and maximum
contaminant holding capacity.
Resin Impregnated Media –
Maintains strength, resists effects
of water and heat.
75 psi Collapse Strength – Heavy
gauge carbon steel endcaps and
center tube give safety margin
against pressure surges.
Coated Steel Components –
Resist corrosion from most
industrial fluids.
Corrugated Media – Prevents
pleat pinch-off, assuring all
filtration media is utilized.
Buna-N Gaskets –The best
general gasket material available
assures positive seal in most
fluids.
Thermoset Bonding Material –
Durable endcap-to-media bond
prevents internal bypassing.
Threaded base filter elements –
Available for easier installation.
SPECIFICATIONS
• 75 psi Collapse strength
• 5 - 9 Operating pH range
• Micron ratings from 1/4 to 75
• 98%+ Nominal filtration
efficiency
• 250°F Maximum operating
temperature
• Recommended changeout
differential pressure - 25 psid
• Multi-pass (Beta Ratio) data
available on request
For information about Flow Ratings with
various viscosity fluids, refer to Form #1532
Please note – The outer wrap of a cartridge can
be either nylon jacket, beaming paper, or PVC-
coated screen wrap. Actual cartridges may not
look exactly like those shown in photo.

17 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
Model Dim.
Nominal
Micron
Rating
Protec-
tive Outer
Wrap
FO-412PL2 4” x 12¼”
x 1¾” ID
2No
FO-412PL5 5No
FO-418PL5 4” x 18”
x 1¾” ID
5No
FO-418PL15 15 No
FO-512PL1/2
For VF-61
Housing
½No
FO-512PL05 5No
FO-512PL25 25 No
FO-614PLF½
6” x 14½”
x 3½” ID
½No
FO-614PLF1 1 No
FO-614PLF2 2 No
FO-614PLF5 5 No
FO-614PLF5M 5 Yes
FO-614PLF10 10 No
FO-614PLF15 15 No
FO-614PLF15M 15 Yes
FO-614PLF25 25 No
FO-614PLF25M 25 Yes
FO-614PLF75 75 No
FO-629PLF1/4
6” x 29”
x 3½” ID
¼Yes
FO-629PLF1/2 ½ Yes
FO-629PLF1 1 Yes
FO-629PLF2 2 Yes
FO-629PLF5 5 Yes
FO-629PLF10 10 Yes
FO-629PLF20 20 Yes
FO-629PLF25 25 Yes
FO-629PLF1/2TB
6” x 29”
Threaded Base
½Yes
FO-629PLF1TB 1 Yes
FO-629PLF2TB 2 Yes
FO-629PLF5TB 5 Yes
FO-629PLF25TB 25 Yes
FO-644PLF1/2
6” x 44”
x 3½” ID
½No
FO-644PLF1M 1 Yes
FO-644PLF2M 2 Yes
FO-644PLF5M 5 Yes
FO-644PLF10M 10 Yes
FO-644PLF15M 15 Yes
FO-644PLF25M 25 Yes
Model Dim.
Nominal
Micron
Rating
Protec-
tive Outer
Wrap
FO-644PLF1/4TB
6” x 44”
Threaded
Base
¼Yes
FO-644PLF1/2TB ½ Yes
FO-644PLF1TB 1 Yes
FO-644PLF2TB 2 Yes
FO-644PLF5TB 5 Yes
FO-644PLF10TB 10 Yes
FO-644PLF25TB 25 Yes
FO-656PLF1M 6” x 56” x 3½” ID 1 Yes
FO-656PLF1/2TB
6” x 56”
Threaded
Base
½Yes
FO-656PLF1TB 1 Yes
FO-656PLF2TB 2 Yes
FO-656PLF5TB 5 Yes
FO-656PLF25TB 25 Yes
FO-718PLP3
6¼” x 18” x 2


16
” ID
0.3 No
FO-718PL1/2 ½ No
FO-718PL01 1 Yes
FO-718PL02 2 Yes
FO-718PL05 5 Yes
FO-718PL10 10 Yes
FO-718PL15 15 Yes
FO-718PL25 25 Yes
FO-718PL50 50 Yes
FO-736PLP3
6¼” x 36”
2


16
” ID
0.3 No
FO-736PL1/2 ½ No
FO-736PL05 5 Yes
FO-736PL15 15 Yes
FO-822PLP3
8” x 22


8
” x 2” ID
0.3 No
FO-822PL1/2 ½ No
FO-822PL05 5 No
FO-829PL05 8” x 29 ½” 2” ID 5 No
FOH
FOH-644PLF1 6” x 44” x 3½” ID 1Yes
FOH-644PLF1/2 6” x 44” x 3½” ID 0.5 Yes
FOH-644PLF1TB 6”x 44”
Threaded Base
1Yes
FOH-644PLF2TB 2 Yes
FOH-644PLF5 6” x 44” x 3½” ID 5Yes
CARTRIDGE INFORMATION
The following table lists a few of the broad range
of available Velcon cartridges. Your local Velcon
representative can provide more complete information.

18 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
F0-6xxA3 & FOH-6xxA1
EI 1590 Qualified Filter Cartridges. 1 and 3 Micron Rated
Cartridges for Aviation Fuel
Description
Primarily designed to be used as prefilter (micronic)
cartridges for use in jet fuel handling systems.
Used to extend the life of coalescer cartridges in filter/
separator vessels described in EI 1581.
Velcon has qualified cellulose and microfiberglass media
filter cartridges to EI Specification 1590, “Specifications
and Qualification Procedures for Aviation Fuel
Microfilters.”
Product Features:
Large Surface Area – Allows high flow rate with low
initial pressure drop and maximum contaminant holding
capacity.
Resin Impregnated Microfiberglass/Cellulose Media –
Maintains strength, resists effects of water and heat.
75 psi Collapse Strength –
Heavy gauge carbon steel
endcaps and center tube give safety margin against pressure
surges.
Coated Steel Components – Resist corrosion from
most industrial fluids.
Corrugated Media – Prevents pleat pinch-off, assuring
all filtration media is utilized.
Buna-N Gaskets – The best general gasket material
available assures positive seal in most fluids.
Epoxy Bonding Material – Endcaps epoxy-bonded to
media to prevent internal bypassing.
Threaded Base also available
FOH-644A1K
FO-614A3

19 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
SPECIFICATIONS
75 psi Collapse strength
1 & 3 micron efficiency (per EI
1590)
5 - 9 Operating pH range
250°F Maximum operating
temperature
CARTRIDGE INFORMATION
VELCON MODEL
NUMBER DIMENSIONS OUTER WRAP API MICRON EFFICIENCY MAXIMUM FLOW RATE
FO-614A3 6” x 141/2” x 31/2” ID NO 3 53
FO-614A3TB 6” x 141/2” x 31/2” ID NO 3 47
FO-629A3 6” x 29” x 31/2” ID YES 3 111
FO-629A3TB 6” x 29” x 31/2” ID YES 3 105
FO-644A3 6” x 44” x 31/2” ID YES 3 171
FO-644A3TB 6” x 44” x 31/2” ID YES 3 165
FO-656A3 6” x 56” x 31/2” ID YES 3 219
FO-656A3TB 6” x 56” x 31/2” ID YES 3 213
FOH-614A1K 6” x 141/2” x 31/2” ID YES 1 53
FOH-614A1TB 6” x 141/2” x 31/2” ID YES 1 47
FOH-629A1K 6” x 29” x 31/2” ID YES 1 111
FOH-629A1TB 6” x 29” x 31/2” ID YES 1 105
FOH-644A1K 6” x 44” x 31/2” ID YES 1 171
FOH-644A1TB 6” x 44” x 31/2” ID YES 1 165
FOH-656A1K 6” x 56” x 31/2” ID YES 1 219
FOH-656A1TB 6” x 56” x 31/2” ID YES 1 213
Please see Data Sheet #1936 for more information about the FOH Series Cartridges.

20 Parker Hannin Corporation
Velcon Filtration Division
Colorado Springs, CO 80907 USA
Velcon Filtration Division
Filter Vessel Installation & Operation Manual
VEL2199 0414
STANDARD DESIGN FEATURES
150 psi welded steel ASME Code
construction.
Choice of micron rating from 0.5
to 75 microns.
Choice of pleated or depth type
media.
Epoxy coated interior, primed
exterior.
Buna-N O-ring cover seals.
RECOMMENDED OPTIONAL
ACCESSORIES
Automatic Air Eliminator
Pressure Relief Valve
Differential Pressure Gauge
Drain Valve(s)
Sampling Probes
ASME Code Stamp
VF Series
Vertical Filter Vessels
DESCRIPTION
Consult our cartridge data sheets
to select the micron rating and
type of cartridge that is right for your
application – PLF Series (pleated sur-
face type filtration), FG Series (fi-
berglass depth type filtration), or
Aquacon® Series (dehydration and
filtration).
Filter vessels VF814 through VF844,
such as the VF814150 shown at
right, have through-bolt covers, NPT
connections, and include fittings for
drain, pressure gauge and air vent.
VF1614 and larger vessels, such as
the VF2044150 shown at top right,
are provided with swing bolt closure,
RF flange connections and fittings
for pressure gauge, air eliminator,
pressure relief valve and drain valve.
Note: In applications where increased dirt
contamination is present, it may be desirable
to oversize filtration equipment.
Contact Velcon for oversizing recommenda-
tions. For API/EI applications, please consult
Velcon
APPLICATION
• Jet Fuel
• Diesel Fuel
• Gasoline
VF814150VF2044150
