Parkside PFS 710 E4 User manual

145 mm 140 mm
SABRE SAW
PFS 710 E4
145 mm 140 mm
IAN 336330_1907
SABRE SAW
Operation and safety notes
Translation of the original instructions
KARDFŰRÉSZ
Kezelési és biztonsági utalások
Eredeti használati utasítás fordítása
SABLJASTA ŽAGA
Navodila za upravljanje in varnostna opozorila
Prevod izvirnih navodil
PILA OCASKA
Pokyny pro obsluhu a bezpečnostní pokyny
Překlad původního návodu k používání
CHVOSTOVÁ PÍLA
Pokyny pre obsluhu a bezpečnostné pokyny
Preklad pôvodného návodu na použitie
SÄBELSÄGE
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung

140 mm
GB Operation and safety notes Page 5
HU Kezelési és biztonsági utalások Oldal 22
SI Navodila za upravljanje in varnostna opozorila Stran 39
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 56
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 73
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 90
140 mm

140 mm
A
B
6 82 3 41
16
15
7 9
14 1013 11
5
1.
3.
2.
12

E
H
C
1.
2.2.
G
1.
2.
1.
D
2.
2.
1.
F
1. 2.
D1 D2

5GB
Warnings and symbols used .......................................... Page 6
Introduction............................................................ Page 6
Intended use............................................................ Page 6
Scope of delivery........................................................ Page 7
Parts description......................................................... Page 7
Technical data .......................................................... Page 7
Safety instructions..................................................... Page 8
General power tool safety warnings ......................................... Page 8
Reciprocating saws safety warnings ......................................... Page 11
Vibration and noise reduction .............................................. Page 13
Behaviour in emergency situations........................................... Page 13
Residual risks ........................................................... Page 13
Before first use......................................................... Page 14
Accessories ............................................................ Page 14
Operation.............................................................. Page 14
Adjusting the base plate................................................... Page 14
Turning the rear handle ................................................... Page 14
Selecting a saw blade .................................................... Page 15
Inserting/removing the saw blade ........................................... Page 15
Switching on and off ..................................................... Page 16
Selecting the stroke rate................................................... Page 16
LED work light .......................................................... Page 16
Trial run ............................................................... Page 16
Working instructions .................................................. Page 17
Cleaning and care ..................................................... Page 18
Cleaning............................................................... Page 18
Maintenance ........................................................... Page 18
Repair................................................................. Page 18
Storage ............................................................... Page 18
Transportation .......................................................... Page 19
Disposal................................................................ Page 19
Warranty .............................................................. Page 19
EC declaration of conformity .......................................... Page 21

6 GB
Warnings and symbols used
The following warnings are used in this instruction manual, on the packaging and on the rating label:
Read the instruction manual.
Switch off the product and disconnect
it from the mains before making any
adjustments, performing maintenance,
cleaning and when the product is not
in use.
Follow the warnings and safety notes! Protection class II (double insulation)
Risk of electric shock! Wear protective gloves!
Use in dry indoor rooms only. Wear hearing protection!
Wear eye protection! Wear a dust mask!
Wear protective, slip-resistant
footwear! Alternating current
Lock Unlock
SABRE SAW
PFS 710 E4
Introduction
We congratulate you on the purchase of your
new product. You have chosen a high quality
product. The instructions for use are part of the
product. They contain important information
concerning safety, use and disposal. Before using
the product, please familiarise yourself with all
of the safety information and instructions for use.
Only use the product as described and for the
specified applications. If you pass the product on
to anyone else, please ensure that you also pass
on all the documentation with it.
Intended use
This sabre saw (hereinafter “product” or “power
tool”) is designed for light and medium sawing
through wood, chip board, plastic, metal, and
plaster board.
The product is not intended to handle heavy
sawing work, such as in stones or in workpieces
exceeding the maximum cutting capacity
(see “Technical data”).

7GB
Always use the correct saw blades
according to the intended use! Observe
the technical requirements of this product
(see “Technical data“) when purchasing and
using saw blades!
The LED work light 2on this product is intended
to illuminate the immediate work area.
Any other use or modification of the product
are considered improper use and can result in
hazards such as death, life-threatening injuries
and damage. The manufacturer is not liable
for any damages caused by improper use. The
product is exclusively intended for domestic use.
The product is not intended for commercial use or
for any other use.
Scope of delivery
m WARNING!
uThe product and the packaging are not
children’s toys! Children must not play with
plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
1x Sabre saw PFS 710 E4
1x Metal saw blade
(156 mm / Material: Bi-metal)
1x Wood saw blade
(152 mm / Material: HCS high carbon steel)
1x Carrying case
1x Instruction manual
Parts description
Figure A:
1Locking lever (base plate)
2LED work light
3Chuck ring
4Saw blade holder
5Base plate
6Cover for carbon brushes
7Position arrow
8Lock button (handle)
9Rear handle
10
Power cord with power plug
11
Switch lock
12
On/off switch
13
Adjusting wheel (stroke rate)
14
Front handle
15
Metal saw blade
16
Wood saw blade
Not illustrated:
17
Carrying case
Technical data
Sabre saw PFS 710 E4
Rated voltage: 230 V~, 50 Hz
Rated power consumption: 710 W
Stroke rate: 0 – 2800 min–1
Stroke length: 20 mm
Saw blade intake: Standard
(½" | 12.7 mm)
Protection class: II /
Maximum cutting capacity:
Wood: 160 mm
Aluminium: 18 mm
Metal: 8 mm

8 GB
Noise emission value
The measured values have been determined in
accordance with EN 62841. The A-rated noise
level of the power tool is typically as follows:
Sound pressure level LpA : 88.4 dB(A)
Uncertainty KpA :3 dB
Sound power level LWA : 99.4 dB(A)
Uncertainty KWA : 3 dB
Vibration emission value
Vibration total values (triaxial vector sum)
determined according to EN 62841:
Cutting boards
Handle (max.):
Hand/arm vibration ah,B : 11.696 m/s2
Uncertainty K: :1.5 m/s2
Cutting wooden beams
Handle (max.):
Hand/arm vibration ah,WB : 12.131 m/s2
Uncertainty K : 1.5 m/s2
m WARNING!
Wear ear protection!
NOTE
uThe declared vibration total values and
the declared noise emission values have
been measured in accordance with a
standard test method and may be used for
comparing one tool with another.
uThe declared total vibration values and the
declared noise emission values may also
be used for a preliminary assessment of
exposure.
m WARNING!
uThe vibration and noise emissions during
actual use of the power tool can differ
from the declared values depending on
the manner in which the tool is used,
especially what kind of workpiece is
processed.
Try to minimise exposure to vibration and
noise. Examples of measures to reduce
vibration include wearing gloves when
using the tool and limiting working time. All
parts of the operating cycle must be taken
into account (e.g. times when the power
tool is switched off and when it is running
idle in addition to the trigger time).
Safety instructions
General power tool safety
warnings
m WARNING!
uRead all safety warnings,
instructions, illustrations and
specifications provided with
this power tool. Failure to follow
all instructions listed below may result in
electric shock, fire and/or serious injury.

9GB
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
1) Keep work area clean and well
lit. Cluttered or dark areas invite accidents.
2) Do not operate power tools in
explosive atmospheres, such as in
the presence of flammable liquids,
gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3) Keep children and bystanders
away while operating a power
tool. Distractions can cause you to lose
control.
Electrical safety
1) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power
tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
2) Avoid body contact with earthed
or grounded surfaces, such as
pipes, radiators, ranges and
refrigerators. There is an increased risk
of electric shock if your body is earthed or
grounded.
3) Do not expose power tools to rain
or wet conditions. Water entering a
power tool will increase the risk of electric
shock.
4) Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
5) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk
of electric shock.
6) If operating a power tool in a
damp location is unavoidable, use
a residual current device (RCD)
protected supply. Use of an RCD
reduces the risk of electric shock.

10 GB
Personal safety
1) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the influence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
2) Use personal protective
equipment. Always wear eye
protection. Protective equipment such as
dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
3) Prevent unintentional starting.
Ensure the switch is in the off-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying
power tools with your finger on the switch or
energising power tools that have the switch
on invites accidents.
4) Remove any adjusting key or
wrench before turning the power
tool on. A wrench or a key left attached to
a rotating part of the power tool may result
in personal injury.
5) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
6) Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
7) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use
of dust collection can reduce dust-related
hazards.
8) Do not let familiarity gained from
frequent use of tools allow you to
become complacent and ignore tool
safety principles. A careless action can
cause severe injury within a fraction of a
second.
Power tool use and care
1) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it was designed.
