Parmco In-bench 600mm User manual

Installation
and Operating
Instructions
As part of Parmco Appliances commitment to improving and updang product ranges,
we reserve the right to alter, change and update technical specicaons and appearance
aributes of all Parmco Appliances products. E&OE.
Models:
In-bench 600mm
In-wall 600mm
In-wall 900mm
Side Riser 600mm
Rear Riser 600mm
Rear Riser 900mm

Dear Valued Customer,
Thank you and congratulations on purchasing your new Parmco appliance.
All Parmco products are made to the highest quality and design standards. We are
sure you will enjoy your new appliance.
As a note, please read through these instructions carefully, as these will assist you
in gaining a complete understanding of the functions and features oered by your
appliance.
Please take special note of all detailed technical information and installation
instructions. It is essential that you only allow a qualied technician to install this
appliance to ensure the safety and reliability of this appliance.
Furthermore, not using appropiate personnel to install this appliance may aect any
future warranty claims lodged, so please check with Parmco Appliances before any
installation is carried out.
We hope you enjoy your new appliance. If you would like to nd out more about
this product or any other products in Parmco’s extensive range, visit us on the web
at www.parmco.co.nz.
Regards,
The Parmco Team

INDEX

PAGE
ImportantSafetyInformation2
Beforeusingthisappliance3
BeforeInstallation4
DuctingRequirements5
MotorMounting6
Installation6
In‐benchwithoutcontrols6
In‐benchwithcontrols 7
SideRiser7
RearRiser8
In‐wall600mmand900mm13
ChangingfromP1toP1‐9‐1motor15
ElectricalConnection16
UseandCare 17
TechnicalSpecifications19
WarrantyInformation24





2
IMPORTANTSAFETYINFORMATION

Forbestperformanceandtoextendthelifeofyourappliancewerecommendthatyoureadthe
instructionsinthisownersmanualthoroughlybeforeusingyournewappliance.Itwillprovideyou
withalltheinformationyouneedtoensureitssafeinstallation,properuseandmaintanence.
Retainthisownersmanualforfuturereference.

Tomaintaintheefficiencyandsafetyofthisappliancewerecommendthefollowing:

BEFOREUSINGTHISAPPLIANCE
Thisapplianceisdesignedfornon‐commercial,householduseonlyandmustnotbealteredin
anyway.
Thisappliancecanonlybeusedsafelywhenitiscorrectlyconnectedtoanefficientearthing
systemincompliancewithNewZealandElectricalStandardsrequirements.
Beforemaintainenceorcleaning,alwaysensurethattheapplianceisdisconnectedfromthe
mains.
Packagingitemssuchasplasticbags,polystyrene,etc.thatthisapplianceisdeliveredinare
potentiallydangerous,andthereforeappropriatemeasuresmustbetakentopreventchildren
fromcomingintocontactwiththem.
Thisappliancemustonlybeusedbyadults.Makesurethatchildrendonottouchthecontrols
orplaywiththeappliance.Youngchildrenshouldbesupervisedtoensuretheydonotplay
withtheappliance.
Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensory,ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
givensupervisionorinstructionconcerningtheuseofthisappliancebyapersonresponsible
fortheirsafety.
Theexposedpartsofthisappliancemayheatupduringthecookingprocessandremainhotfor
sometimeaftewards,evenafterithasbeenswitchedoff.Keepchildrenwellawayduring
operationandwhiletheunitiscoolingdown.CAUTION:Accessiblepartsmaybecomehot
whenusedwithcookingappliances.
Keeptheappliancethoroughlycleaned.Foodresiduesmaycausefirerisks.Thereisafireriskif
cleaningisnotcarriedoutinaccordancewiththeinstructions.
DONOTuseasteamcleanertocleanthisappliance.
Donotuseharshabrasivecleanersorsharpmetalscraperstocleantheapplianceastheycan
scratchthesurfaceandprematurelyremovegraphics.
Afterusingtheappliance,pleaseensurethatallcontrolsareinthe“OFF”position.
Avoidimproperordangeroususeofthisappliance.
Donotobstructtheventilationorslots.
Donotallowpowercablesofotherappliancestocomeintocontactwithhotpartsofthis
appliance.
Thisapplianceisintendedforindooruseonly.Avoidexposingtheappliancetoatmospheric
elementssuchasdirectsunlightandrain.
Foranyenquiries,pleasecontactParmcoAppliances(09)5735678.




3













































IMPORTANT

Whenthein‐benchDowndraftisplacednexttoagashob,theunitmustneverbe
operatedunlesstheflamedeflectorisinplace.

Theflamedeflectorisavailableinsingleanddoublesidedoptions.Pleaserefertothe
picturesbelow.

4

BEFOREINSTALLATION
Important:
Thedowndraftcanonlybeusedforventingexhaustgasandfumesoutside,andisnotsuitable
forrecirculating.
Theintakeshouldnotbepositionednexttogasapplianceswithoutspecialprecautions.
TheDowndraftisnotafireratedappliance.
Itssurroundingsurfacesmustnotexceed80degreescentigrade.
FlamemustneverbeallowedtoentertheintaketotheDowndraft.
Neverputahandorotherobjectintotheairintakeorexhaustofmotorunitwhenthepower
isconnected.
DUCTINGREQUIREMENTS
GeneralDuctingRequirements
Ductingcomponentsrequiredtoducttheexhaustairtotheoutside
Onlyuseductingsuitablefortheventingofkitchenexhaustgasandfumes.ParmcoAppliances
haveacomprehensiverangeofductingcomponentsavailable.
Foroptimumefficiency,ensuretheuseof:
shortsmoothexhaustpipe
asfewpipebendsaspossible
pipediametersof150mm
Thereshallbeadequateventilationoftheroomwhentherangehoodisusedatthesametime
asappliancesburninggasorotherfuels(notapplicabletoappliancesthatonlydischargetheair
backintotheroom).
Asaruleofthumb,each90degreebendisequivalenttoabout5metresofsmoothbore
ducting.Flexibleductingorductingthatdoesnothaveasmoothboreshouldbeusedwithcare
duetotheadverseeffectonairflowperformance.
Foroptimumefficiency,totalductinglengthincludingbendsandallowanceforductingnot
havingasmoothboreshouldnotbemorethantheequivalentof15metresof150mmdiameter
orlargerdiameterducting.







5

ReturnAirFlow
TheParmcoDowndraftisdesignedtoremovelargeamountsofairfromthekitchen.Foritto
operateefficiently,airmustbeallowedtoenterthekitchenareafromtheoutside.
Insomesituations,additionalductingmayhavetobeinstalledtoallowtheflowofthisReturn
Airbackintothekitchen.
SpecialRequirements
Theexhaustairmustnotbedischargedintoanoperatingsmokeorexhaustflue,orintoashaft
usedforventilatingroomsinwhichfireplacesarelocated.Theairmustnotbedischargedintoa
fluethatisusedforexhaustingfumesfromappliancesburninggasorotherfuels(notapplicable
toappliancesthatonlydischargetheairbackintotheroom).
Therequirementsoftheauthoritiesconcernedhavetobeobservedfordischargingairthrough
smokeorexhaustfluesnotinuse.
WhentheDowndraftisoperatedatthesametimeaschimneydependentfireinstallationsare
used(eg.gas,oilorcoalfiredheatingsystems,continuousheatersorhotwaterboilers)
provisionmustbemadeforanadequatesupplyofairwhichthefireinstallationsrequirefor
combustion.
Harmlessoperationispossibleiftheunderpressureintheroomwherethefireplaceis
installeddoesnotexceed4Pa(0.04mbar).
Thiscanbeachievedifthecombustionaircanflowthroughnonclosableopeningssuch
asindoors,windows,intake/exhaustwallboxes.

NOTE:Inassessingthispossibility,theentirecombinedventilationofthehomemustbetaken
intoconsideration.Thisruledoesnotapplyforoperationofcookingappliancessuchascooking
topsandgascookers.
Thepertinentregulationsorguidelinesofthecountrymustbeobserved.




6
MOTORMOUNTING
Benchmountunits(In‐bench,sideriserandrearriser)
Themotorcanbepositionedoneithersideoftheairboxwiththeoutlettotherearorfacing
downwards.
InWallunits
Themotormustbemountedremotefromtheairbox/airintake.RefertoTechnicalsectionof
thismanualforvariousoptions.
Ductingisrequiredfromtheairboxtothemotor,anddischargedtotheoutsideatthemost
convenientpoint.

INSTALLATION
IN‐BENCHWITHOUTCONTROLS
GeneralInstructions
Theairboxissymmetricalandcanbemountedwiththemotoroneitherside.
Theairboxisdesignedtobesupportedatthesides,andthreemountingholesareavailableon
eachside.
TheintakemustnotbenexttoagashobunlesstheGasFlameDeflectorisusedwhenthe
Downdraftisbeingoperated.
SpecificElectricalRequirements
TheDowndraftunitcanbeoperatedthroughasimpleon/offswitchinthewallabovetheunitand
a3pinsocketunderthebenchtogetpowersupplytothemotorORavariablecontrolsuchasfan
dimmerinthewallanda3pinsocketunderthebench.
CutOutDimensions
CutoutfortheIn‐BenchDowndraftwithoutControlsshouldbe410mmx85mm.
DetailedInstructions
CentretheDowndraftpositionalongsidethehob.Markthepositiononthebenchtopandcut
out.
Theairboxissymmetrical,andshouldbeinstalledwiththemotorholeontherequiredside.
Installtheairboxinthecutoutandsecurewiththescrewsprovided.
Fitthesurroundontopoftheairboxandsecuretotheairboxwiththescrewsprovided.
MounttheMotoronthesideoftheairboxanddoupthe4nutsworkingdownthroughthetop
oftheDowndraftensuringtheairsealiscomplete.
FittheexhaustDuctingeithertotherearoutthewallordownthroughthefloor.

7
TheDowndraftcanbeinstalledwiththemotormountedremote(inanotherposition)using
Parmco’smountingandductingaccessories.
IftheMotorismountedremotely,apowersupplyfromthecontrolswitchisrequiredatthat
place.
FittheGrilleintotheSurround.
Plugthemotorintothepowersocket.

IN‐BENCHWITHCONTROLS
PowerSupply
Aconventional3pinpoweroutletshouldbeprovidedunderthebenchtosupplypowertothis
unit
CutOutDimensions
CutoutfortheIn‐BenchDowndraftWithControlsshouldbe475mmx114mm.
DetailedInstructions
Markoutthecutoutandcutthebenchtotheappropriatesize.
InstalltheSurroundCarrierintothecutoutandsecure.
TheAirboxissymmetrical,andshouldbeinstalledinthebenchwiththemotorholeonthe
requiredsideandtotherearoftheCarrier.
PlacethetopSurroundontopoftheAirboxandsecuretotheAirboxbymeansoftwoscrews
provided.
MounttheMotorontheairboxanddoupthe4nutsworkingdownthroughthetopofthe
Downdraftensuringthattheairsealiscomplete.
TheDowndraftcanbeinstalledwiththemotormountedremote(inanotherposition)using
Parmco’smountingandductingaccessories.
FittheGrilleintoplaceintheSurround.
VenttheDowndrafteithertotherearorthroughthefloor.
PlugtheDowndraftMotorintothesocketonthespeedcontrollerandthePowerleadintothe
poweroutlet.

SIDERISER
SpecificElectricalRequirements
Aconventional3pinwallmountedpoweroutletunderthebenchisallthatisrequired.
PartsSupplied
Airboxmountedonthebench.Needstobefullysupportedatbothends.
Risercolumnwhichrisesabovethebenchwhenactivated.
Surround(hidesthecutoutinthebench).
Thecoverplate/sontheairboxmustberemovedbeforeattachingthemotor.

8
MotorunitcanbemountedoneithersideoftheairboxorremotemountedusingParmco’s
mountingandductingaccessories.
AirIntakeCap.
Singleintake‐stronglyrecommendedwhenallthecookingisdonetoonesideofthe
Downdraft,i.e.wheninstalledadjacenttoa600mmhob.
Doubleintake‐wheretheaircancomeinbothsidesoftheDowndraft,i.e.wheninstalled
betweenParmcoDominounits.
PriortoMakingtheCutOutintheBench
Determinethepositionoftheairboxandsurroundonthebenchtop.Finishedsizeonbenchis
500mmx122mm.
Determinewhichsidethemotorshouldbefastenedtotheairbox.
Notethatthiswillinfluenceductingrequirements.
Pipes,nogsorothermaterialinanywallsorfloormayhavetobecuttoaccommodatethe
ducting.
CutOutDimensions
CutoutfortheSideRiserDowndraftshouldbe472mmx96mm.

REARRISER
GeneralInstructions
Thisunitcanbefittedasfollows:

Adjacenttoa600mmParmcogas/electrichob‐(excludingceramic).
Whenbeingplacednexttogashobs,a75mmwidespacebetweenthehobandthe
downdraftunitissufficientspaceforawokorlargefryingpantositontheburner
withoutinterferingwiththeoperationoftheParmcoRiserDowndraft.
Adjacenttoanybrandofhob(includingParmcoceramic)‐withagapbetweenthehoband
ParmcoRiserDowndraft.
ForModelP2R‐3SSensureifanyairintakeisnotinuse,itmustbecoveredbyitsoriginalcover
plate.

SpecificElectricalRequirements
Aconventional3pinwallmountedpoweroutletunderthebenchisallthatisrequired.
Thecoverplate/sontheairboxmustberemovedbeforeattachingthemotor.
MotorunitcanbemountedoneithersideoftheairboxorremotemountedusingParmco’s
mountingandductingaccessories.
AirIntakeCap.
Singleintake‐stronglyrecommendedwhenallthecookingisdonetoonesideofthe
Downdraft,i.e.wheninstalledadjacenttoa600mmhob.
Doubleintake‐wheretheaircancomeinbothsidesoftheDowndraft,i.e.wheninstalled
betweenParmcoDominounits.

9
Whenconnectingtherisermotorplug,doublelayeredheatshrink(supplied)mustbeinserted
overtheplugconnectionsandcabletiedateachend.Heatmustbeappliedtotheheatshrink
toallowittoformtothecableandplugfittingfirmly.Heatshrinkmustalsobefittedrightupto
themotorcasingcoveringtherubberbushingasperphoto.

PriortoMakingtheCutOutInTheBench
Determinethepositionoftheairboxandsurroundonthebenchtop.Finishedsizeoftheuniton
benchis500mmx122mm.
Determinewhichsidethemotorshouldbefastenedtotheairbox.
Notethatthiswillinfluenceductingrequirements.
Pipes,nogsorothermaterialinanywallsorfloormayhavetobecuttoaccommodatethe
ducting.
CutOutDimensions
Thecutoutisdependentonthetypeofinstallationsasfollows.
InstalledOnItsOwn
Benchcutoutis554mmx84mmfor600mm.
Benchcutoutis834mmx84mmfor900mm.
ParmcoRiserDowndraftmustbesupportedatbothendsoftheunit.
Ifinstalledagainstacabinetside,cutoutmustbe475mmx100mmassidecovercannotbe
removedtomountmotor(motorboltsaredoneupfrominsiderisercolumn).

Whenplaceddirectlyadjacenttotherearofthecookinghob.



10
ONECUTOUTHOLEISREQUIREDINTHEBENCHTOPFORBOTHTHEHOB&THEREARRISER.DO
NOTCREATEASEPARATECUTOUTFOREACH.
Thedepthoftheoverallcutoutshouldequalto:RearRisercutoutdepth+yourHobcutout
depth.

CutOutDimensionstoallowfortheRearRiser

600mmRearRiser‐Depth85mmWidth550mm
900mmRearRiser‐Depth85mmWidth830mm


RISER&HOB
REARRISERISSUSPENDEDINTOTHECAVITY&SITSFIRMLYAGAINSTTHEBACKOFTHECUTOUT.













THEBACKEDGEOFTHEHOBSITSONTOPOFTHEOVERLAPLIP.
One cut out for both the
R
ea
r Ri
se
r
&
t
h
e
H
ob
Overlap flange
MDF Strip 16mm x 20mm
Place here on underside of
lip

11


Thecooktopcannowbemountedintothebenchcutoutwiththebackedgeofthecooktopsitting
overtheflangeonthesurround,withcooktoppushedbackasfarasitwillgo.Therewillbeagap
ofapprox5mmbetweentheedgeofthecooktopandtheDowndraftunit.
Securethefrontofthecooktoptothebenchusingtheclampssupplied.
Placethe16mmx20mmpieceofMDFalongtheundersideoftheDowndraftflangeand
secureitinplacewiththerearclampsforthecooktop.ThiswillensuretheDowndraftunit
andcooktoparesecuredtogether.
Hob is placed on top of the
li
p

12
InstallationP2R‐2SS(600mmRearRiser)
Placetheairboxintothebenchcutout:
Dependingonthepositionoftheairbox,themotorsmaybeattachedatthistime.
Fastentheairboxontothebenchusingclipssupplied.
TheParmcorearriserisdesignedtobefittedintoabench
withathicknessof26mm–55mm.
Forabench55mm–75mmthick,undotheretaining
clampsandre‐attachthemtothelowerholes.
Fastenthemotorstotheairboxinthecorrectorientation
asrequired.
Motorscanbeattachedtotheairboxasfollows:
1. RemovethecoverplateonthesideoftheAirbox.
2. Undothemotormountingnuts.
Thisunitfittedonlyinthebenchbehindthecooktop
usuallybetweenthewallandcooktop.Itcanalso
beusedinanislandcooktopsituation.
AirboxMotorMounting
Positionthemotorsintheircorrectorientation
onthedesiredsideoftheairbox,androtatethem
sothattheyareoneithersideoftheairboxwith
theexhaustfacingdownwards.
OR
Theexhaustoutletsaredirectedsidewaysfrom
eithersideoftheairbox.
THEN
Firmlytightenthemotormountingnutsensuring
thatthereisagoodairsealbetweenthemotorsand
airbox.
FINALLY
Re‐fastenthecoverplatestotheairboxandplugthe
motorsintothesocketonthefrontsideoftheairbox.













HOWTOWORKOUTTHECUTOUTSIZE(for600mmRearRiser)
IneveryapplicationtheRearRiserDowndraftandcooktopcutoutsarecombinedintoasingle
cutout.

EXAMPLECooktop……………………………………….500mmx580mm
RearRiser……………………………………85mmx580mm
Totaloverall585mmx580mm

Lessoverlapallowance20mm

Totalcutoutrequired565mmx580mm

Pleasenotethisisanexampleonlyandallcalculationsshouldbecarriedoutonsitebyskilled
professionalsbeforeanycutoutismadetothebenchtop.

13







InstallationP2R‐3SS(900mmRearRiser)
Placetheairboxintothebenchcutout:
Dependingonthepositionoftheairbox,themotorsmaybeattachedatthistime.
Fastentheairboxontothebenchusingclipssupplied.
TheParmcorearriserisdesignedtobefittedintoabench
withathicknessof26mm–55mm.
Forabench55mm–75mmthick,undotheretaining
clampsandre‐attachthemtothelowerholes.
Fastenthemotorstotheairboxinthecorrectorientationasrequired.
Motorscanbeattachedtotheairboxasfollows:
Removethecoverplateonthesideofthe
airbox.
Undothemotormountingnuts.
Thisunitfittedonlyinthebenchbehindthecooktop
usuallybetweenthewallandcooktop.Itcanalso
beusedinanislandcooktopsituation.
AirboxMotorMounting
Positionthemotorsintheircorrectorientation
onthedesiredsideoftheairbox,androtatethem
sothattheyareoneithersideoftheairboxwith
theexhaustfacingdownwards.
OR
Theexhaustoutletsaredirectedsidewaysfrom
eithersideoftheairbox.
THEN
Firmlytightenthemotormountingnutsensuring
thatthereisagoodairsealbetweenthemotorsand
airbox.
FINALLY
Re‐fastenthecoverplatestotheairboxandplugthe
motorsintothesocketonthefrontsideoftheairbox.

Thecooktopcannowbemountedintothebenchcutoutwiththebackedgeofthecooktopsitting
overtheflangeonthesurround,withcooktoppushedbackasfarasitwillgo.Therewillbeagap
ofapprox5mmbetweentheedgeofthecooktopandtheDowndraftunit.

WARNING:
Pleaseensurethatthepowerisswitchedoffbeforepluggingtheunitinasthefan
bladescanrotate

14
Securethefrontofthecooktoptothebenchusingtheclampssupplied.
Placethe16mmx20mmpieceofMDFalongtheundersideoftheDowndraftflangeand
secureitinplacewiththerearclampsforthecooktop.ThiswillensuretheDowndraftunit
andcooktoparesecuredtogether.





















INWALL600mmand900mm
PowerSupply
TheIn‐WallDowndraftcanbeoperatedwithaon/offswitchinthewallorasimplevariable
control,i.e.FanDimmerandpowersuppliedtoaconvenientplacetosupplypowertothemotor.

DetailedInstructions

TheIn‐WallDowndraftmotorisalwaysmountedremotefromtheairbox.
WheninstallingtheIn‐WallDowndraftinanexistingkitchen,thewallliningwillneedtobe
removed.
Theairboxshouldbecentredbehindthecooktopandinstalledbetweenwallstudsand
securedtoahorizontalnogginordwang.
Theoptimumfittedheightoftheairboxis250‐300mmabovethebenchtoptothebottomof
theintakeopening.

CutOutDimensions

600mmIn‐wall‐Height300mmWidth408mm
900mmIn‐wall‐Height278mmWidth784mm

WARNING:
Pleaseensurethatthepowerisswitchedoffbeforepluggingtheunitinasthefan
bladescanrotate.
HOWTOWORKOUTTHECUTOUTSIZE(for900mmRearRiser)
IneveryapplicationtheRearRiserDowndraftandcooktopcutoutsarecombinedintoasingle
cutout.

EXAMPLECooktop………………………………………..500mmx860mm
RearRiser……………………….……………85mmx860mm
Totaloverall585mmx860mm

Lessoverlapallowance20mm

Totalcutoutrequired565mmx860mm

Pleasenotethisisanexampleonlyandallcalculationsshouldbecarriedoutonsitebyskilled
professionalsbeforeanycutoutismadetothebenchtop.

15
Wheninstalledbehindagashob,theairboxshouldbepositionedsothatthebottomofthe
intakeisataminimumheightof150mmabovethehobtopreventthegasflamebeingdrawn
intotheintake.Foroptimumperformanceinstallhigher,asabove.
Wheninstalledbehindanelectrichob,theairboxshouldbeinstalledasforgasbut,canbe
positionedsothatthebottomoftheintakesurroundisatbenchlevel.Howeverforoptimum
performanceitshouldbeinstalled250‐300mmabovethebench.
TheairboxshouldbeconnectedtothemotorusingSupertubeandalljointssealedwithduct
tapetopreventairleaks.
ToinstallSupertubethewallnogginsordwangswillneedtobecheckedout60mmtoallow
flushfittingbeforethewallliningisfitted.Alternatively,thenogscanberemovedandthe
airboxcanbeframedasforawindowandductingcanbemountedbetween“jack”studs.
DuctingrequiredforthisunitisSupertubeandmustbesealedtotheairboxusingParmco
ducttape.EnsurethatalljoinsinthesuctionsideoftheMotoraresealed.
Ifitisnecessarytouseflexi‐ductinthisconnection,careshouldbetakennottodamageorcut
theflexi‐ductinsidethewall.
Thewallliningfitsinbehindtheflangeonthefrontoftheair‐box.
Ductingfromwallductingtothemotorcanthenbeinstalledensuringalljointsaresealed.
Ifasplashbackistobeinstalled,theGrille&Surroundwillneedtobecutintothesplashback
andtheSurroundshouldbesuppliedbeforethecutismade.
CHANGINGFROMP1toP1‐9‐1MOTOR
600mmRearRiser/600mmSideRiser




16
900mmRemoteRiser


CutOutDimensions

IftheMotorP1‐9‐1isgoingtoberemotelymountedtothefloor,thereneedstobeaminimum
clearanceof10mmwidthoneachsideand10mmheightbetweentheenclosureofthemotorand
surroundingstructures.

ELECTRICALCONNECTION
DowndraftunitsmustbeinstalledinfullaccordancewiththeNewZealandElectricalStandards
regulations.AnyLocalelectricalauthorityregulationsmustbeobservedwhenfittingthis
appliance.
WARNING:THISAPPLIANCEMUSTBEEARTHED

Thewiresinthemainsleadarecolouredinaccordancewiththefollowingcode:
Green&Yellow‐Earth
Blue‐Neutral
Brown‐Live
Forpluginconnection
Anelectricalplugisfittedasstandardtoalldowndraftsystems.Itcanbepluggedintoanynormal
householdsupplycomplyingwiththeElectricalDatarequirementsspecified.Pleasereferto
specificinstructionstoconnecteachtypeofDowndraft.

TheDowndraftmayonlybeconnectedtoaproperlyinstalledsocketwithnon‐fusedearth
contact.
Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsserviceagentor
similarlyqualifiedpersonsinordertoavoidahazard.

17
Forfixedconnection
Connectionmustbecarriedoutbyaregisteredelectrician.

Ensurethattheexistingvoltageandmainsfrequencyisthesameaslistedonthelabel.
Aseparatormustbeprovidedontheinstallationside.Switcheswithacontactopeningofmore
than3mmthatswitchoffallpolesareregardedasseparators,includingon‐loadswitchesand
contactors.

ElectricalData
P1MOTOR
Lengthofconnectingcable: 1.5m
Powerconsumption: 80wattsperfanmotor
Anadditional50wattswhentheriserunitismovingup/down
Supplyvoltage: 220to240voltsACat50Hz
ThisappliancesatisfiestheECregulationsforradioscreening.

P1‐9MOTOR
Lengthofconnectingcable: 1.5m
Powerconsumption: 400wattsfortheHTmotorusedinthe900in‐wallunit
Supplyvoltage: 220to240voltsACat50Hz

ThisappliancesatisfiestheECregulationsforradioscreening.

Beforeundertakinganyrepairs,theappliancemustalwaysbedisconnectedfromthemains.
USEANDCARE
Disconnectpowersupplybeforecleaning.
Frequentlyremoveandcleanthegreasefilter.
Donotusecorrosive,alkalioralcoholbasedcleaners.
Neveroperatetheunitwithoutafilterinplace.
Filters
Thealuminiummeshfiltercanbecleanedinadishwasherorwithhotsoapywater.Donotuse
causticoralkalicleaners.



18
FilterRemoval
FortheParmcoDowndraftwithorwithoutspeedcontrol
Removethegrillatthetopoftheairintake.
Rotatetheclipholdingthefilterinplace.
Carefullyremovethealuminiummeshfilter.
FortheParmcoRiserDowndraft
Turnthecontrolswitchontomakethecolumnriseupfromthebench.
TurntheDowndraftoffatthewallswitch‐riserwillremaininanuprightposition.
Removethetopcap.
Carefullyremovethealuminiummeshfilter.
Removalfromthebenchtop
Disconnecttheelectricalconnection.Iftheunitispluggedin,removetheplug.Iftheunitisa
fixedconnection,removalmayonlybecarriedoutbyasuitablyqualifiedelectrician
Disconnecttheductingconnections.
Workthroughtheinstallationinstructionsinreverse.
RemovetheDowndraftunittakingcarenottodamagethesurroundingappliancesorbench.
