Parrot SKYCONTROLLER User manual

User Guide

Table of Contents
.......................................................................................................................................................4
Before starting
...........................................................................................................................................................................................................4Charging the battery
...........................................................................................................................................................................................................4Installing the battery
...........................................................................................................................................................................................................5Installing the neck strap
...........................................................................................................................................................................................................5Installing a smartphone
...........................................................................................................................................................................................................7Installing the sunshade cover
...........................................................................................................................................................................................................7Connecting to the Parrot Bebop Drone
...........................................................................................................................................................................................................9Displaying a video feedback
.......................................................................................................................................................10
Piloting
...........................................................................................................................................................................................................12Orienting the antenna
...........................................................................................................................................................................................................12Movements
...........................................................................................................................................................................................................12Photos and videos
...........................................................................................................................................................................................................13Battery
.......................................................................................................................................................14
Using FPV glasses
.......................................................................................................................................................15
Wi-Fi
.......................................................................................................................................................16
Updating
.......................................................................................................................................................17
General information
...........................................................................................................................................................................................................17Safety precautions and maintenance
...........................................................................................................................................................................................................17Wi-Fi
...........................................................................................................................................................................................................17Warning on invasion of privacy
...........................................................................................................................................................................................................18Battery
...........................................................................................................................................................................................................18Warranty
...........................................................................................................................................................................................................19Modifications
...........................................................................................................................................................................................................19Disposal of this product at the end of its life
...........................................................................................................................................................................................................20Declaration of conformity
...........................................................................................................................................................................................................20Registered trademarks

3

4 Before starting
Before starting
Note: For easy reading, iPhone®, iPad® and other compatible telephones or tablets are
referred to as 'smartphones' in the manual.
Charging the battery
1. Insert the plug converter corresponding to your country to the
transformer.
2. Plug the batteryto the charger.
3. Plug the charger to the mains.
> The charger's led lights up in red when charging. Once the battery
is fully charged, the led turns green. The battery takes about 1 hour
to charge.
Installing the battery
1. Connect the battery to the Parrot Skycontroller powercable.
2. Insert the batteryinto the batterycompartment.

5Before starting
Installing the neck strap
Before the first use, attach the neck strap to the Parrot Skycontroller.
Before each use, ensure that the neck strap is correctlyattached.
Installing a smartphone
The Parrot Skycontroller can be used with a smartphone or tablet in order to have a
video feedback.
1. Place yourdevice horizontally onto the appropriate support:
use the upper compartment for smartphones (A);
use the bottom compartment for tablets (B);
use the adapting support (supplied) for 7-inch tablets (C). Unscrew the
removable part of the bottom compartment to install it.
3. Slide down the upper part of the support by pushing it slightly.
4. Screw the bottom handwheel located on the back of the Parrot Skycontroller to
lock yourdevice on the support.

6 Before starting

7Before starting
Installing the sunshade cover
Install the foldable sunshade cover when you use the Parrot Skycontroller with a tablet
in orderto protect the screen from light reflection.
The sunshade coveris constituted of:
a lowerpart (A);
an upper part (B);
a 7-inch tablet support.
1. Unfold the lowerpart of the sunshade cover.
2. Fixthe support or yourtablet into the lowerpart with the elastic bands. If you use a
7-inch tablet, insert it into the tablet support.
3. Fix yoursunshade cover on the Parrot Skycontroller.
4. Unfold and assemble the upper part to the sunshade cover.
Note: You can use the foldable sunshade cover without the Parrot Skycontroller.
Connecting to the Parrot Bebop Drone
The Parrot Skycontroller automatically connects to the Parrot Bebop Drone it is sold
with.
Switch the Parrot Bebop Drone and the Parrot Skycontrolleron.
> A signal tone indicates that the Parrot Bebop Drone is connected to the Parrot
Skycontroller. The Parrot Bebop Drone batteryleds and the Wi-Fi leds light up. The
Parrot Bebop Drone is ready to be piloted with the Parrot Skycontroller.
If you have bought the Parrot Skycontroller and the Parrot Bebop Drone separately,
connect them manually:

8 Before starting
from your smartphone via the FreeFlight 3 application;
from a screen with HDMI port (includind First Person View glasses).
Manual connection via smartphone
1. Switch the Parrot Skycontroller and the Parrot Bebop Drone on.
2. Search foravailable Wi-Fi®networks on yourdevice:
Ifyou are using an iPhone® or an iPad®, go to Settings> Wi-Fi
If you are using an AndroidTM smartphone, go to Settings > Wireless and
networks > Wi-Fi.
3. Select the Skycontroller_xxxxx network. Wait for your smartphone to connect to
the Parrot Skycontroller Wi-Fi network. The Wi-Fi symbol will usually appear on
your smartphone when connection is complete.
4. Launch the FreeFlight 3 application, available for free on App StoreSM or Google
PlayTM.
5. Press ManagerWi-Fi.
6. Select the Parrot Bebop Drone you want to connect.
> Apop-up asks you to connect yourParrot Bebop Drone.
7. Press OK.
> A signal tone indicates that the Parrot Bebop Drone is connected to the Parrot
Skycontroller. The Parrot Bebop Drone batteryleds and the Wi-Fi leds light up. The
Parrot Bebop Drone is ready to be piloted with the Parrot Skycontroller.
Note: If the FreeFlight 3 main screen does not display the Parrot Bebop Drone video
feedback, press , then, select the Parrot Bebop Drone.
Manual connection via screen with HDMIport
1. Switch the Parrot Skycontroller, the Parrot Bebop Drone and the screen (or First
Person View glasses) on.
2. Plug the HDMI cable (or FPV glasses) on the HDMI port located on the left side of
the Parrot Skycontroller.
3. Press Manager Wi-Fi. For further information about the use of FPV glasses, see
Using FPV glasses.
4. Select your Parrot Bebop Drone.
> Apop-up asks you to connect yourParrot Bebop Drone.
5. Press OK.
> A signal tone indicates that the Parrot Bebop Drone is connected to the Parrot
Skycontroller. The Parrot Bebop Drone batteryleds and the Wi-Fi leds light up. The
Parrot Bebop Drone is ready to be piloted with the Parrot Skycontroller.
Note: If the FreeFlight 3 main screen does not display the Parrot Bebop Drone video
feedback, press , then select the Parrot Bebop Drone.

9Before starting
Displaying a video feedback
You can display the Parrot Bebop Drone video feedback on:
your smartphone via the FreeFlight 3 application;
FVP (First Person View) glasses via HDMI cable.
To display avideo feedback on your smartphone:
1. Switch the Parrot Skycontroller and the Parrot Bebop Drone on.
2. Search foravailable Wi-Fi®networks on yourdevice:
Ifyou are using an iPhone® or an iPad®, go to Settings> Wi-Fi
If you are using an AndroidTM smartphone, go to Settings > Wireless and
networks > Wi-Fi.
3. Select the Skycontroller_xxxxx network. Wait for your smartphone to connect to
the Parrot Skycontroller Wi-Fi network. The Wi-Fi symbol will usually appear on
your smartphone when connection is complete.
4. Launch the FreeFlight 3 application.
> The Parrot Bebop Drone connects to the Parrot Skycontroller automatically.
To display avideo feedback on your FPV glasses:
Note: You can display a video feedback on anyscreen with a HDMI port.
1. Plug the HDMI cable of yourFPV glasses on the HDMI port located on the left side
of the Parrot Skycontroller.
2. Switch the Parrot Skycontroller, the Parrot Bebop Drone, and the FVP glasses on.

10 Piloting
Piloting
You can use the Parrot Skycontrollerwith or without video feedback.
The video feedback enables you to access the FreeFlight 3 application. You can then
change the Parrot Bebop Drone piloting settings. For further information, see the
Parrot Bebop Drone userguide.
Note: It is not possible to perform flips if you use the Parrot Skycontroller without
smartphone.

11Piloting
#
Description
1
Navigation in the Parrot Skycontrollerapplication (with FPV glasses only)
2
Taking photos and orienting the angle of the camera
3
Left joystick
4
Right joystick
5
Previous screen of the Parrot Skycontrollerapplication (with FPV glasses only)
6
Main screen of the Parrot Skycontrollerapplication (with FPV glasses only)
7
Video record
8
Take offand landing
9
Return to starting point
10
Emergencylanding
11
Video record signal
12
Wi-Fi signal
13
Parrot Skycontrollerbatterylevel
14
Parrot Bebop Drone batterylevel

12 Piloting
Orienting the antenna
Steer the antenna towards the Parrot Bebop Drone to improve the Wi-Fi signal
reception.
To lock the antenna, turn the upper handwheel located at the back of the Parrot
Skycontroller.
Movements
Left joystick
Flyupwards ordownwards
Yawning (rotating towards left or right)
Right joystick
Pitching (moving onwards or backwards)
Rolling (turning towards left or right)
Photos and videos
Press the button (2) to take a picture.
Press the button(7) to record a video orto stop the video recording. When the REC
led is red, the Parrot Bebop Drone is recording.
Note: The video mode is activated by default. In video mode, the recording starts
automaticallywhen the Parrot Bebop Drone takes off.
Use the joystick located (2) to change the angle of the camera.
To change the recording settings, see the Parrot Bebop Drone userguide.
Note: The video recording stops after25 minutes of recording.
Note : It is not possible to transfervideo files to the Parrot Bebop Drone.

13Piloting
Battery
The leds located at the bottom right of the Parrot Skycontroller indicate the battery
level:
of the Parrot Skycontroller for the leds located next to the icon. The Parrot
Skycontroller batterylasts 150mn approximately.
of the Parrot Bebop Drone for the leds located next to the icon. The Parrot Bebop
Drone batterylasts 11 mn approximately.
When the batterylevel of the Parrot Skycontroller orthe Parrot Bebop Drone is low, the
last led turns red. The Parrot Skycontroller makes a sound signal every10 seconds.

14 Using FPV glasses
Using FPV glasses
First Person View glasses enable you to:
flythe Parrot Bebop Drone with Head Tracking feature;
access the FreeFlight 3 application.
To navigate in the FreeFlight 3 application with FPV glasses:
Use the joystick (1) to navigate in the menu.
Press (1) to click.
Press (5) to return to the previous screen.
Press (6) to open the main screen.
To access AndroidTM operating system from FPV glasses:
1. Go to the FreeFlight 3 main screen.
2. Press .
> A pop-up asks you if you want to exit the application.
3. Press OK.
> You can navigate through the AndroidTM operating system. Press the FreeFlight 3
icon to launch the application again.

15Wi-Fi
Wi-Fi
Note: Before flying the Parrot Bebop Drone, please ensure that you comply with the
Wi-Fi frequencies restrictions of your place of flight. Certain frequencies may be
restricted or forbidden. For example, in certain countries using the 5 GHz Wi-Fi band
may be prohibited in outdoor mode.
You can connect the Parrot Skycontrollerto the 2.4 GHzor 5 GHzWi-Fi bands.
The 2.4 GHz Wi-Fi band enables you to fly the Parrot Skycontroller from a
greater distance. It is generally more congested than the 5 GHz Wi-Fi band in
urban areas.
The 5 GHz Wi-Fi band enables you to obtain a better connection between the
Parrot Skycontrollerand the Parrot Bebop Drone.
To switch the Wi-Fi band (2.4 GHzor 5 Ghz), hold down the the REC (7) and
Emergencylanding (8) buttons for5 seconds .
When the Wi-Fi signal is low, the Parrot Skycontroller makes a tone signal every 10
seconds.

16 Updating
Updating
Update the Parrot Skycontroller via USB, by downloading the update file from our
website. A computer and an USB flashdrive are necessary.
For further information, see the Parrot Skycontroller update procedures.

17General information
General information
The Parrot Skycontrolleris aimed to remotely fly the Parrot Bebop Drone and is not
suitable foruse bychildren under 14 years of age.
REMINDER: The Parrot Bebop Drone is a model aircraft designed only for
entertainment, and competitions between model aircraft. Fly responsibly. Do not fly
your Parrot Bebop Drone over any populated area, such as beaches, others people’s
backyards, heavily populated parks, or sports ovals where a game is in progress, over
gathering of animals. Do not fly near an airfield. Do not fly for money. If you want to fly
your Parrot Bebop Drone in anypopulated area ornearan air field, do contact yourlocal
aerial authority to get the appropriate authorization.
Do not use spare parts and accessories otherthan those specified byParrot.
Safety precautions and maintenance
The Parrot Skycontroller may be irreversibly damaged if you allow sand or dust to
penetrate it.
Do not use the Parrot Skycontrollerin wet conditions.
Do not leave the Parrot Skycontroller in direct sunlight forlong periods.
Small parts may be swallowed. All materials for fastening or packing purposes are not
part of the product and should be discarded forchildren’s safety.
This equipment is restricted to indoor operation in 5.15 - 5.25GHz.
Wi-Fi
Before flying the Parrot Skycontroller, please ensure that you comply with the Wi-Fi
frequencies restrictions of your place of flight. Certain frequencies may be restricted or
forbidden. For example, in certain countries using the 5 GHz Wi-Fi band may be
prohibited in outdoormode.
Warning on invasion of privacy
Recording and circulating an image of an individual may constitute an infringement of
their image and privacy for which you could be liable. Ask for authorisation before
filming individuals, particularly if you want to keep your recordings and/or circulate

18 General information
images on the Internet or anyother medium. Do not circulate a degrading image or one
which could undermine the reputation ordignityof an individual. The use of the Parrot
Skycontroller for surveillance or espionage is strictly forbidden and could result in your
prosecution under the law. Check that your use of the cameras on board the Parrot
Skycontroller complies with the legal provisions on the protection of privacy.
Battery
Read the entire instruction sheet included with this battery. Failure to follow all
instructions could cause permanent damage to the battery and its surroundings, and
cause bodily harm. Never use anything except a LiPo approved charger. Always use a
LiPo cell balancing charger or a LiPo cell balancer. Never charge through the discharge
lead. Never trickle charge, or allow to discharge below 2.5V per cell. Never allow the
batterytemperature to exceed 140°F (60°C). Never disassemble or modify pack wiring
in anyway or puncture cells. Never place on combustible materials or leave unattended
during charge. Always charge in a fireproof location. Always set charger’s output volts
to match batteryvolts. Always keep out of reach of children. Improper battery use may
result in a fire, explosion orother hazard.
The battery terminals should not be allowed to short-circuit. The product should be
connected onlyto class II appliances which displaythe symbol.
Warranty
Without prejudice to anyapplicable statutory warranty, Parrot warrants that the Parrot
Skycontroller will be free from defects in material and workmanship for a period of 12-
months from the initial date of purchase (excluding consumables which are warranted
during 6 months from the initial date of purchase) upon presentation of proof of
purchase to the retaileror to Parrot (including the date and place of purchase, product
serial number). Return to retailer is not applicable in the USA - return shall be made to
Parrot. During the contractual warranty period, any defective product should be
returned in its original packaging to the retailer’s or Parrot’s after-sales service. After
inspection of the product, Parrot will, at its sole discretion, either repair or replace the
defective part or product, excluding any other indemnification of any nature. Parrot’s
warranty does not cover: defects due to damage caused by an accidental collision or
fall; defects due to abnormal use of the product or if spare parts have been installed
without following the recommendations and instructions provided by Parrot in this
guide or on www.parrot.com or if the Parrot Skycontroller has been customised by the
end-user; defects caused by repairs carried out by the end-user or an unauthorised
third party, except spare parts provided by PARROT; defects due to the use of spare
parts not provided by PARROT in the original packaging.the use of spare parts not

19General information
approved by Parrot, in particular, the use of batteries not approved by Parrot ; defects
caused by anyreason otherthan a defect in material or workmanship the gradual power
loss of the Parrot rechargeable battery(086x) over time, which does not constitute as a
defect in material or workmanship, If upon technical tests being carried out any
product is found non defective we reserve the right to return such product to the
sender at the sender’s cost and to levy a charge to cover Parrot’s technical test fees.
Upon expiration of the 12-month warranty period or if the defect is not covered by the
warranty, any defective product can be returned to Parrot’s after-sales service in order
to be repaired or for a defective part to be replaced at the sender’s costs. Repair will be
carried out onlyafter acceptance of the corresponding quotation. Except in relation to
consumables, spare parts are subject to a 12 month warranty and are subject to the
same terms and conditions as those described above. The warranty does not cover:
damage to non Parrot products, including devices used to operate the Parrot
Skycontroller.
Modifications
The explanations and specifications in this guide are given for information purposes
only and may be modified without prior notice. They are deemed to be correct at time
ofgoing to press. The utmost care has been taken when writing this guide,as part of the
aim to provide you with accurate information. However, Parrot shall not be held
responsible for anyconsequences arising from any errors or omissions in the guide, nor
foranydamage oraccidental loss of data resulting directly or indirectly from the use of
the information herein. Parrot reserves the right to amend or improve the product
design oruser guide without anyrestrictions and without anyobligation to notify users.
As part of our ongoing concern to upgrade and improve our products, the product that
you have purchased may differ slightly from the model described in this guide. If so, a
laterversion ofthis guide might be available in electronic format at Parrot’s website at
www.parrot.com.
Disposal of this product at the end of its life
At the end of this product’s life, please do not dispose of this product in your general
household waste. Instead, in order to prevent possible harm to the environment or
human health from uncontrolled waste disposal, please dispose of this product
separately in accordance with your local laws and regulation. For more information on
the separate collection systems for waste electrical and electronic equipment that are
available for consumers, near your home, free of charge, please contact your local
municipality authority. You can also contact the retailer from which you purchased
your Parrot Skycontroller – he might have put in place recycling services or he may be

20 General information
part of a specific recycling scheme.
Declaration of conformity
Parrot SA, 174 quai de Jemmapes, 75010 Paris, France, declare under their sole
responsibility that the product described in this user guide complies with technical
standards EN 301489-17, EN300328, EN71-1, EN71-2, EN71-3, EN62115 following the
provision of the Radio Equipment, Telecommunication Equipment directive (1999/5/
EC R&TTE), and of the General Safety directive (2001/95/EC).
http://www.parrot.com/ce/?bebop-drone
Registered trademarks
Parrot, Parrot Skycontroller are trademarks orregistered trademarks of Parrot SA.
App Store is a trademark of Apple Inc.
Google Play is a trademark of Google Inc. Wi-Fi® is a registered trademark of Wi-Fi
Alliance®.
All other trademarks mentioned in this guide are protected and are the property of their
respective owners.
