Partilink P4K-HUL4E1 User manual

User manual
P4K-HUL4E1 4K UHD HDMI & USB Over IP Extender
P4K-HUL4E1-P 4K UDH HDMI & USB Over IP Extender with PoE
P4K
-
HRSUL4E1
/
P4K
-
LHRSU1E4
P4K-HRSUL4E1-P/ P4K-LHRSU1E4-P
Partilink Technology Co., Ltd Copyright @2016

Table of Contents
1. Introduction 4
2. Features & Application 5
3. Specifications 6
4. Hardware Description 7
4.1 Transmitter 7
4.2 Receiver 9
5. Installation 11
5.1 Device Connection 11
5.2 IP Configuration 15
6. Web User Interface Configuration 18
6.1 System 18
6.1.1 Version Information 18
6.1.2 Update Firmware 19
6.1.3 Utilities 21
6.1.4 Statistics 22
6.2 Video Wall 24
6.2.1 Basic Setup 24
6.2.2 Advanced Setup 30

6.3 Network 35
6.3.1 IP Setup 36
6.3.2 Casting Mode 37
6.4 Functions 38
6.4.1 IP Setup 39
6.4.2 Casting Mode 41
6.4.3 Serial over IP 42
7. Broadcast Configuration Example 44
7.1 Multicast 44
7.2 Unicast 45
7.3 Matrix 45
7.4 Video Wall 46
7.4.1 Basic Setup 46
7.4.2 Advanced Setup 47
8. Package Contents 51

4
Partilink Technology Co., Ltd Copyright @ 2016
1. INTRODUCTION
The 4K HDMI & USB over IP Extender is a solution for
audio, video and USB signal extension via Local Area
Network (LAN). It can be used as audio, video and
KVM extender over IP and applied to point to point,
point to multi-point, multi-point to multi-point and screen
wall broadcast system controlled by USB, RS-232, IR
and configured the 4K HDMI & USB over IP Extender
by web browser. An easy installation system built up
with Giga Ethernet switch which has IGMP function and
CATx cable for extension or broadcast. The
P4K-HUL4E1-P supports PoE (Power over Ethernet)
function.

Partilink Technology Co., Ltd Copyright @ 2016
5
2. FEATURES & APPLICATIONS
 4K HDMI over IP extension
 USB 2.0 over IP extension
 RS-232 bi-directional extension
 4-bit DIP switch for 16 stream channel selection
 HDCP 1.4 compliant and Blu-Ray ready
 Support two way IR extension
 Output video rotation
 Output video partial enlargement
 Automatic EDID configuration
 Networking environment under Giga Ethernet switch
and CATx cable
 Point to point extension, unicast, multicast and
screen wall system.
 Point to point extension via CAT5e cable without
Ethernet switch up to 100M
 Ethernet webpage management
 RS-232 Serial control command management
 P4K-HUL4E1-P supports Power over Ethernet

6
Partilink Technology Co., Ltd Copyright @ 2016
3. SPECIFICATION
P4K-HUL4E1
P4K-HUL4E1-P
4K UHD HDMI
Over IP Extender
P4K-HRSUL4E1
P4K-HRSUL4E1-P
Transmitter
P4K- LHRSU1E4
P4K-LHRSU1E4-P
Receiver
VIDEO INPUT
HDMI Type
-
A female
connector None
VIDEO OUTPUT
HDMI Type
-
A female
connector for loop through
VGA DB-15 female local
output
HDMI Type-A female connector
IR
2x 3.5mm phone jack for IR emitter and receiver to control video
source device
COMPRESSION Visual lossless compression
HDMI
INPUT RESOLUTION
3840x2160 30/24, 1080p 60/50, 1080p 30/25, 1080i 60/50
720p 60/50, 480i 60/50, 480p 60/50
HDMI
OUTPUT RESOLUTION
3840x2160 30/24, 1080p 30/25, 1080i 60/50,720p 60/50
480i 60/50, 480p 60/50
VGA
OUTPUT RESOLUTION
1080p 30/25, 1080i 60/50, 720p 60/50
480i 60/50, 480p 60/50
AUDIO FORMAT Stereo 192Kbps
IP PROTOCOL TCP, UDP, RTSP, RTP, DHCP, IGMP, Multicast, IPV4
LAN PORT RJ45 connector for Giga Ethernet
SERIAL DB-9 male connector for RS-232 extension
MANAGEMENT
LAN port None
Embedded webpage
management HDMI Type-A female connector
POWER INPUT 2.0mm power jack for DC12V/2A input
OPERATING TEMPERATURE
0~55℃
OPERATING
HUMIDITY 5%~90% RH
POWER SUPPLY Power adapter AC in 100~240V (50~60Hz)
ESD
ESD protection air gap discharge ±8KV,
contact discharged ±4KV
DIMENSION 194 x 114 x 28 mm
WEIGHT TX 620g, RX 610g
** Product specifications are subject to change without notice.

Partilink Technology Co., Ltd Copyright @ 2016
7
4. HARDWARE DESCRIPTION
4.1 Transmitter
P4K-HUL4E1/ 4K-HUL4E1-P (TX)
1. 12 VDC power supply with locking for 4K HDMI &
USB over IP Extender.

8
Partilink Technology Co., Ltd Copyright @ 2016
2. RCA connector for stereo audio output.
3. RCA connector for stereo audio input.
4. HDMI video input connector
5. 10/100/1000 Mbps self-adaptive Ethernet interface.
6. ACT LED indicator turns green when 4K HDMI &
USB over IP Extender is powered up.
7. LINK LED indicator flickers green when network
connection is waiting for video source, turns green
when network connection and video source is
functioning properly
8. DB9 connector for RS-232 remote extension
9. Connect IR extension cable to IR port and position
the emitters near the devices you want to control
10. PC USB port for remote additional device such as
USB mouse, USB keyboard and USB pen drive
connecting to PC
11. Group configuration, 4-bit DIP switch to set up the
group ID
12. Restart the 4K HDMI & USB over IP extension by
pressing RESET button
13. Press EDID button for manual EDID copy function
14. DB9 connector for VGA local display

Partilink Technology Co., Ltd Copyright @ 2016
9
4.2 Receiver
P4K-LHRSU1E4/ P4K-LHRSU1E4-P (RX)
1. 12 VDC power supply with locking for 4K HDMI &
USB over IP Extender.
2. RCA connector for stereo audio output.

10
Partilink Technology Co., Ltd Copyright @ 2016
3. RCA connector for stereo audio input.
4. HDMI video input connector
5. 10/100/1000 Mbps self-adaptive Ethernet interface.
6. ACT LED indicator turns green when 4K HDMI &
USB over IP Extender is powered up.
7. LINK LED indicator flickers green when network
connection is waiting for video source, turns green
when network connection and video source is
functioning properly
8. DB9 connector for RS-232 remote extension
9. Connect IR extension cable to IR port and position
the emitters near the devices you want to control
10. Group configuration, 4-bit DIP switch to set up the
group ID
11. Restart the 4K HDMI & USB over IP extension by
pressing RESET button
12. Press EDID button for manual EDID copy function
13. 4 USB ports for additional USB devices such as
USB mouse, USB keyboard and USB pen drive.
