Partner MF-2351 User manual

F1 F2 F3
3 DEF F4 2 ABC
1
6
MNO 5 JKL 4 GHI
9 WXYZ
8 TUV
#..
0
*
7 PQRS
ALPHA
CANCEL
CLEAR
EHTER
MF2351
All in One Mobile Terminal
User's Manual

ii
ENGLISH
Safety Information .............................................................................1
DEVICE STORAGE ...................................................................................... 2
BATTERY HANDLING PRECAUTIONS ....................................................... 2
FEDERAL COMMUNICATIONS COMMISSION (FCC) ............................... 3
DECLARATION OF CONFORMITY ............................................................. 4
COPYRIGHT ................................................................................................ 4
DISCLAIMER ................................................................................................ 4
TRADEMARK RECOGNITION ..................................................................... 4
SAR Information ................................................................................... 4
Federal Communications Commission Statement ............................... 5
RF Exposure Information (SAR) .......................................................... 5
WEEE Notice ....................................................................................... 6
FCC Regulations .................................................................................. 7
Chapter 1 - Introduction ....................................................................8
PRODUCT OVERVIEW ................................................................................ 8
FRONT AND BACK ............................................................................. 8
LEFT AND RIGHT ................................................................................ 9
TOP AND BOTTOM ............................................................................. 10
FEATURES ................................................................................................... 11
PACKAGE CONTENTS ................................................................................ 11
LED INDICATORS ........................................................................................ 12
Chapter 2 - Getting Started ...............................................................13
INSTALLING THE BATTERY ....................................................................... 13
CHARGING THE BATTERY ......................................................................... 15
INSTALLING THE MEMORY CARD ............................................................ 15
INSTALLING THE SIM CARD ...................................................................... 17
INSTALLING THE SAM CARD(S) ................................................................ 19
ATTACHING THE STYLUS .......................................................................... 21
INSTALLING THE PAPER ROLL ................................................................. 22
Chapter 3 - Using the Terminal ........................................................24
POWERING THE DEVICE ON/OFF ............................................................. 24
ENABLING BACKUP BATTERY .................................................................. 25
HOT SWAP MAIN BATTERY ....................................................................... 25
INITIAL SETUP ............................................................................................. 26
CALIBRATING THE TOUCH SCREEN ............................................... 26
SETTING THE DATE AND TIME ......................................................... 27
ADJUSTING THE SCREEN BRIGHTNESS ........................................ 28
CONFIGURING THE TASKBAR AND START MENU ......................... 29
USING THE KEYPAD ................................................................................... 30
Chapter 4 - Using the Stylus ............................................................32
KEYBOARD MODE ...................................................................................... 32
TRANSCRIBER MODE ................................................................................ 34
OPTIONS BUTTON ............................................................................. 35
LETTER SHAPE SELECTOR .............................................................. 37

iii
ENGLISH
MINI KEYBOARD ................................................................................. 38
RECOGNITION MODE ........................................................................ 38
SPACE ................................................................................................. 39
RETURN .............................................................................................. 39
LEFT ARROW, RIGHT ARROW, BACKSPACE .................................. 40
Chapter 5 - Configuring Utilities Settings ....................................... 41
MSR .............................................................................................................. 42
PRINTER ...................................................................................................... 45
WLAN ........................................................................................................... 46
BARCODE SCANNER ................................................................................. 47
RFID ............................................................................................................. 51
IC CARD READER ....................................................................................... 52
CAMERA ...................................................................................................... 53
GPS .............................................................................................................. 54
GENERAL SETTING .................................................................................... 56
BLUETOOTH ................................................................................................ 57
GSM .............................................................................................................. 59
GPRS ............................................................................................................ 63
Chapter 6 - SPECIFICATIONS ..........................................................67
OPTIONAL FEATURES ............................................................................... 68

1
ENGLISH
Preface
Copyright
Copyright © 2013. All rights reserved.
No part of this user manual may be reproduced, transmitted, stored in a retrieval
system, or translated into any language, in any form or by any means, without
permission from the manufacturer.
Windows CE and the Windows CE logo are trademarks of the Microsoft Corporation.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance.
microSD is a trademark of SD Card Association.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
All other products use in this device and trademarks mentioned herein are trademarks
or registered trademarks of their respective owners.
Safety Information
Before installing and using the MF2351, take note of the following precautions:
SAR compliance for body-worn operations requires at least 2 cm of separation
between the device and the user's body
Request service for damaged products: Turn off the product, unplug it from the
electrical outlet, and request service from a service partner under the following
conditions:
• The power cord or plug is damaged
• Liquid has been spilled into the product
• An object has fallen into the product
• The product has been exposed to rain or water
• The product has been dropped or damaged
• The product does not operate normally when you follow the operating instructions
Avoid hot areas: The product should be placed away from heat sources such as
radiators, heat registers, stoves, and other products (such as amplifiers) that produce
heat.
Allow the product to cool: Allow the product to cool before removing covers and
touching internal components.
Avoid wet areas: Never use the product in a wet location.
Avoid inserting objects into product: Never insert objects of any kind into slots or
other openings in the product.
Clean the product properly: Unplug the product from the wall outlet before cleaning
it. Do not use liquid cleaners or aerosol cleaners. Use a soft cloth dampened with
water for cleaning exterior components, but NEVER apply water directly to the product
or to an LCD screen.

2
ENGLISH
Use the product with approved equipment: Use your product only with the
computers and accessories identified as suitable for use with your product.
Adjust the volume: Turn down the volume before using headphones or other audio
devices.
DEVICE STORAGE
When device will not be used for a long period of time, please remove the battery,
place product in a dry box, and store both device and battery in a cool, dark, and dry
place.
Batteries in storage need to be recharged at least once every three months to avoid
degradation.
BATTERY HANDLING PRECAUTIONS
Do not attempt to disassemble or reconstruct the packs. The battery has
integrated protection circuits and safety functions to avoid danger. If battery is
damaged, it may rupture, generate heat, or cause smoke and flame.
Do not short circuit battery. Neither short connect the positive terminal and negative
terminal with metals, nor carry or store the battery with metal objects. If the battery is
short circuited, excessive large current will flow and generate heat, rupture or flame
will occur, and also it will cause heat generation for metals. Please cover the plug with
waterproof cap when not using the battery.
Do not incinerate or heat the battery. This will cause the insulator to melt, damage
the gas release vent, and cause loss of safety function, or electrolyte ignition. Above
mentioned matters will cause battery to rupture, generate heat, or cause smoke and
flame.
Do not use near high temperature areas. Do not use or leave battery near fire,
stove or heated areas of more than 80°C, to avoid melting of the polymer separator
which would cause internal short circuits to occur in individual cells, and cause the
battery to rupture, generate heat, or cause smoke and flame.
Do not immerse the battery in water, seawater, or get it wet. This may cause
internal short circuits to occur within individual cells, and cause the battery to rupture,
generate heat, or cause smoke and flame.
Do not charge battery near fire or under the blazing sun. If the battery protection
circuit does not function properly due to high temperature, or it is broken, the battery
will be charged at an abnormal current, and abnormal chemical reaction may occur,
causing the battery to rupture, generate heat, or cause smoke and flame.
Only use the official product charger and observe the charging requirement. If
the battery is charged in unusual conditions, it will cause loss of safety functions, or
abnormal chemical reactions, causing the battery to rupture, generate heat, or cause
smoke and flame.

3
ENGLISH
Do not try to damage the battery. Do not drive a nail into the battery, strike it with a
hammer, or tread on it. The impact will cause leakage, causing the battery to rupture,
generate heat, or cause smoke and flame.
Do not attempt to solder anything onto the battery. This will cause the insulator to
melt due to heat, or cause the gas release vent to break, causing the battery to
rupture, generate heat, or cause smoke and flame.
Do not connect battery to a plug socket or car-cigarette plug. Connecting high
voltage to the battery, means excessive current will flow in it, and cause the battery to
rupture, generate heat, or cause smoke and flame.
Do not use battery for powering other equipment. If the battery is used for
powering other equipment, it will deteriorate its performance and cycle-life. At worst,
abnormal current will flow, and cause the battery to rupture, generate heat, or cause
smoke and flame.
Do not touch a leaked battery directly. If battery leaks and hands touch leaked
electrolyte, wash your hands with soap immediately. If leaked electrolyte gets into
your eyes, do not rub them, and wash eyes immediately with fresh water. Consult a
doctor immediately.
Do not continue to charge over specified time. If the battery has not finished
charging over recommended time, let it stop charging. There is a possibility that the
battery might be defective, and continued charging may cause the battery to deform,
generate heat, or cause smoke or flame.
Do not insert battery into a microwave or high pressure container. This may
cause battery to deform, generate heat, or cause smoke or flame, because of sudden
heat, intense pressure, or damage to the sealing condition of the battery.
Do not put leaked battery near fire. If liquid leaks from the battery, or the battery
give outs a bad smell, do not leave battery near flammable objects. Otherwise, the
electrolyte leaked from battery will catch on fire.
Do not use an abnormal battery. If battery has a bad smell, changes color, deforms,
or causes something wrong during usage, remove it from equipment or charger, and
do not use. If an abnormal battery is used, it may cause battery to rupture, generate
heat, or cause smoke and flame.
FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.

4
ENGLISH
• Connect the equipment onto an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's
manufacturer could void the user's authority to operate the equipment.
DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC rules. Operation is subject to the
following conditions:
• This device may not cause harmful interference
• This device must accept any interference received, including interference that may
cause undesired operation.
COPYRIGHT
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
Partner Tech Corp.
DISCLAIMER
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the contents in
this document, and specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. The manufacturer reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of the manufacturer to notify any person of such revision or changes.
TRADEMARK RECOGNITION
All product names used in this manual are the properties of their respective owners
and are acknowledged.
SAR Information
THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the
limits for exposure to radio waves recommended by international guidelines. These

5
ENGLISH
guidelines were developed by the independent scientific organization ICNIRP and
include safety margins designed to assure the protection of all persons, regardless of
age and health.
The exposure guidelines for mobile devices employ a unit of measurement known as
the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP guidelines is
2.0 W/kg averaged over 10 grams of tissue. Tests for SAR are conducted using
standard operating positions with the device transmitting at its highest certified power
level in all tested frequency bands. The actual SAR level of an operating device can
be below the maximum value because the device is designed to use only the power
required to reach the network. That amount changes depending on a number of
factors such as how close you are to a network base station. The highest SAR value
under the ICNIRP guidelines for use of the device at the body is 0.403 W/kg. Use of
device accessories and enhancements may result in different SAR values. SAR
values may vary depending on national reporting and testing requirements and the
network band. The device could be used with a separation distance of 0 cm to the
human body.
Federal Communications Commission Statement
This device complies with Par 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
device generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However there is no guarantee that interference will not occur in a
particular installation if this device does cause harmful interference to radio or
television reception, which can be determined by turning the device off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.- Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver connected.- Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of
the U.S. Government. The exposure standard employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.

6
ENGLISH
Tests for SAR are conducted using standard operating positions accepted by the FCC
with the EUT transmitting at the specified power level in different channels.
The highest SAR value for the device as reported to the FCC is 0.75 W/kg when
placed next to the body.
The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this device is on file with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: NDPEM-70B.
This device is compliance with SAR for general population /uncontrolled exposure
limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the
measurement methods and procedures specified in OET Bulletin 65 Supplement C.
WEEE Notice
The WEEE logo on the product or on its box indicates that this product must not be
disposed of or dumped with your other household waste. You are liable to dispose of
all your electronic or electrical waste equipment by relocating over to the specified
collection point for recycling of such hazardous waste. Isolated collection and proper
recovery of your electronic and electrical waste equipment at the time of disposal will
allow us to help conserve natural resources. Moreover, proper recycling of the
electronic and electrical waste equipment will ensure safety of human health and
environment. For more information about electronic and electrical waste equipment
disposal, recovery, and collection points, please contact your local city center,
household waste disposal service, shop from where you purchased the equipment, or
manufacturer of the equipment.

7
ENGLISH
FCC Regulations
15.19(a)(3):
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
15.105(b):
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
About this Manual
The content in this manual is as accurate as possible. However, due to continuous
product improvements, some contents and specifications may have been changed
since this manual was written. In this case, take the actual device as basis.
No part of this user manual may be reproduced, transmitted, stored in a retrieval
system, or translated into any language, in any form or by any means, without a
written permission from the manufacturer.
Information is subject to change without prior notice.

CHAPTER 1 - INTRODUCTION: PRODUCT OVERVIEW
8
ENGLISH
Chapter 1 - Introduction
MF-2351 is a handheld mobile terminal, offering high performance in a compact and
slim full functional body. It includes a 2" thermal printer, wireless 802.11b/g, and many
optional functions such as MSR (ISO7811 Track 1, 2, 3), barcode scanner, RFID,
GPS, and Telecom standards (GPRS/WCDMA/CDMA2000).
PRODUCT OVERVIEW
FRONT AND BACK
No. Item Description
1 RFID reader RFID reader module.
2Thermal printer Thermal printer module for printing purposes.
3 3.5 LCD screen Mobil terminal main screen.
4Speaker Speaker units.
5 Camera 3.0 megapixel digital camera module.
6LED light LED light for the digital camera module.
7 Battery Main battery compartment.
8Handstrap The strap adds ease of use functionality.
F1 F2 F3
3 DEF F4 2 ABC
1
6
MNO5 JKL4 GHI
9WXYZ8TUV
#..
0*
7PQRS
ALPHA
CANCEL
CLEAR
EHTER
1
2
3
4
56
7
8

CHAPTER 1 - INTRODUCTION: PRODUCT OVERVIEW
9
ENGLISH
LEFT AND RIGHT
No. Item Description
1 DC jack Connects to the power adaptor.
2, 6 Function keys Software programmable function keys.
3 RS232 connector Connects to a RS232 cable for data transfer
purposes.
4Fingerprint sensor Fingerprint sensor module to scan fingerprints.
5 Earphone jack Connects to an earphone.
7USB port Connects to a mini USB cable for data transfer
purposes.
1
3
2
5
4
7
6

CHAPTER 1 - INTRODUCTION: PRODUCT OVERVIEW
10
ENGLISH
TOP AND BOTTOM
No. Item Description
1 Barcode scanner
window
Aim this scanner window to read barcodes.
2IC Card IC Card module reads data from smartcards.
3 MSR MSR module reads data from magnetic cards.
1
2
3

CHAPTER 1 - INTRODUCTION: FEATURES
11
ENGLISH
FEATURES
MF-2351 mobile terminal includes the following features.
PACKAGE CONTENTS
Standard Features Optional Features
2” thermal printer Barcode scanner 1D/2D
MSR ISO7811 Track 1, 2, 3 bidirectional RFID ISO 14443 A/B
WLAN 802.11 b/g GPRS/WCDMA/CDMA2000
microSD card reader read/write GPS
ISO7816-EMV2000 Level 1,2 IC card
reader
Fingerprint sensor
3.0 megapixels autofocus camera
DC jack, earphone+microphone jack,
speaker, integrated microphone, vibrator
motor, reset button
MF-2351 mobile terminal AC adaptor Power cord
Battery Stylus and strap USB cable
F1 F2 F3
3 DEF F4 2 ABC
1
6
MNO5 JKL4 GHI
9WXYZ8TUV
#..
0
*
7PQRS
ALPHA
CANCEL
CLEAR
EHTER

CHAPTER 1 - INTRODUCTION: LED INDICATORS
12
ENGLISH
LED INDICATORS
MF-2351 has 4 LED indicators located across the top of the display.
The first LED is the charging indicator. The light will blinks during charging, and lit
when the battery is full.
The last three are software programmable.
Charging
indicator
Software
programmable

CHAPTER 2 - GETTING STARTED: INSTALLING THE BATTERY
13
ENGLISH
Chapter 2 - Getting Started
INSTALLING THE BATTERY
1. Release the strap. Pull the
lower-end of the strap
downward.
2. Pull down the battery latch and
open the cover.
3. Insert the battery. Re-orient the
battery contact side to the
bottom. Push the battery down
until it clicks into place.

CHAPTER 2 - GETTING STARTED: INSTALLING THE BATTERY
14
ENGLISH
4. Replace the cover while pulling
down the battery latch.
5. Replace the hand strap.

CHAPTER 2 - GETTING STARTED: CHARGING THE BATTERY
15
ENGLISH
CHARGING THE BATTERY
1. Plug the power cord to a power outlet.
2. Plug the adapter into the DC jack, located at the right side of the device.
The leftmost LED light will blinks during charging, and lit red when the battery is full.
INSTALLING THE MEMORY CARD
The mobile terminal’s internal space storage can be used to store user files such as
snapshots from the camera module and various applications. This storage can be
expanded with a microSD memory card sized up to 64GB.
1. Open the battery compartment
cover and remove the battery.
1
2

CHAPTER 2 - GETTING STARTED: INSTALLING THE MEMORY CARD
16
ENGLISH
2. Insert the card into the memory
card slot with contact side facing
down, push it until it clicks into
place.
3. Insert the battery. Re-orient the
battery contact side to the
bottom. Push the battery down
until it clicks into place.
4. Replace the cover while pulling
down the battery latch.

CHAPTER 2 - GETTING STARTED: INSTALLING THE SIM CARD
17
ENGLISH
INSTALLING THE SIM CARD
The mobile terminal features a SIM card slot. SIM card is required for internet access.
1. Open the battery compartment
cover and remove the battery.
2. Release the card slot by pulling
it left and upward.
3. Slide the SIM card into the slot.
4. Close it back and push toward
right.
