PASCO SPARKlink PS-2009 User manual

®
Instruction Manual
012-10869A
*012-10869A*
SPARKlink
PS-2009
Introduction
SPARKlink is a sensor interface with two ports to accept
PASPORT sensors and a USB connection to a computer running
SPARKvue software. The built-in temperature and voltage probe
ports and included probes enable measurement right out of the
box with no additional sensors.
SPARKlink works with SPARKvue software running on you
computer to collect data for display and analysis.
Connecting SPARKlink to your
computer
1. Connect the included USB cable to the USB port on the back
of the SPARKlink.
2. Connect the other end of the USB cable to a USB port on
your computer.
3. Start SPARKvue. (If necessary, install SPARKvue on your
computer.)
Note: SPARKlink includes a port for external power, however it is not
necessary for operation because power is supplied from the computer
through the USB cable.
Connecting Sensors to
SPARKlink
Do one or more of the following to connect any sensors that you
would like to use:
•Connect one or two PASPORT sensors to the PASPORT
ports.
PASPORT
port
voltage
port
temperature
port
PASPORT
port
Included Equipment Replacement Part
SPARKlink PS-2009
Temperature Probe PS-2135
Voltage Probe PS-2165
USB Cable PS-2528

®
SPARKlink PS-2009
2
•Connect the included temperature probe to the temperature
port.
•Connect the included voltage probe to the voltage port.
SPARKvue software running on your computer automatically
detects each sensor when you connect it.
See the SPARKvue User’s Guide for information about
collecting, displaying, and analyzing data.
Technical Support
For assistance with any PASCO product, contact PASCO at:
For more information about the SPARKlink and the latest
revision of this Instruction Manual, visit:
www.pasco.com/go?PS-2009
Limited Warranty For a description of the product warranty, see the
PASCO catalog.
Copyright The PASCO scientific 012-10869A
SPARKlink Instruction
Manual
is copyrighted with all rights reserved. Permission is granted to
non-profit educational institutions for reproduction of any part of this
manual, providing the reproductions are used only in their laboratories and
classrooms, and are not sold for profit. Reproduction under any other
circumstances, without the written consent of PASCO scientific, is
prohibited.
Trademarks PASCO, PASCO scientific, PASPORT, SPARK, and
SPARKvue are trademarks or registered trademarks of PASCO scientific,
in the United States and/or in other countries. All other brands, products,
or service names are or may be trademarks or service marks of, and are
used to identify, products or services of their respective owners. For more
information visit www.pasco.com/legal.
Product End of Life Disposal Instructions:
This electronic product is subject to disposal and recycling regulations that
vary by country and region. It is your responsibility to recycle your
electronic equipment per your local environmental laws and regulations to
ensure that it will be recycled in a manner that protects human health and
the environment. To find out where you can drop off your waste equipment
for recycling, please contact your local waste recycle/disposal service, or
the place where you purchased the product.
The European Union WEEE (Waste Electronic and Electrical Equipment)
symbol (to the right) and on the product or its packaging indicates that this
product must not be disposed of in a standard waste container.
Address: PASCO scientific
10101 Foothills Blvd.
Roseville, CA 95747-7100
Phone: [phone] (worldwide)
800-772-8700 (U.S.)
Fax: [phone]
Web: www.pasco.com
Email: [e-mail]
