Patching Panda MOON PHASE User manual

IN L
SPAN IMAGER MODE
IN R
QST f
CV f
ST fST IMAGER
SPAN
IN R
Q
IN L
OUT L OUT R
MOON PHASE
USER MANUAL

INSTALLATION:
Sereo 12dB/octave state variable multimode filter with powerful imaging
technique to enhance and alter stereo field.
The resonance behaves differently when stereo imager is open beyond
any other filter when you play with the stereo imager control.
With 8 different combinations and span to separate both filters, you
increase the possibilities to treat your sounds and open them in the
stereo field.
Applying audio rate cv to the stereo imager or span control input and
sweeping the cutoff control will create a unique character to the filter.
The resonant peaks can be shifted around the stereo field, every cv
input can be modulated up to audio rate frequencies creating a wide
palette of sonic combinations.
INTRODUCTION:
* Disconnect your synth from the power source.
* Double check polarity from the ribbon cable, unfortanetly if you damage
the module by powering in the wrong direction it will not be covered by
the warranty.
* After connecting the module check again you have connected the right
way, the red line should be on the -12V

IN L
SPAN IMAGER MODE
IN R
QST f
CV f
ST fST IMAGER
SPAN
IN R
Q
IN L
OUT L OUT R
A
A
B
B
C
C
D
D
E
E
F
FG
G
H
H
I
I
J
J
INSTRUCTIONS
Audio input L
Audio input R
Mode select trigger input
Stereo imager cv input
Audio output L
Audio output R
Gain amount input R
Resonance cv input
Stereo frequency cv input
Span cv input
K
K
L
L
M
M
N
N
2
3
1
84
5
6
7
O
O
P
P
Q
Q
Gain amount input L
Gain amount resonance
Stereo imager control
Mode select switch:
LP + NOTCH
BP + HP
LP + BP
BP + BP
HP + HP
LP + LP
LP + HP
NOTCH + BP
Span attenuverter control
St freq attenuverter control
Stereo frequency control
(Pot in the middle “0” both cutoff
freq are in the same position)
1
2
3
4
5
6
7
8
