Patton electronics S-DTA User manual

The SmartNode 4900 is the ideal solution
for service providers and enterprises
requiring high-density analog connections
for converged Internet-Telephony. Call centers,
multi-tenant-units and PBX/switch extensions
can now access the low-cost benefits of packet
voice while WAN, data and VPN features permit
direct access the IP network with full upstream
and DownStream QoS™.
The SN4900 supports 12 to 32 simultaneous
VoIP calls over standard two-wire FXS connec-
tions. The analog ports are presented on a single
Amphenol telco connector for convenient wiring
closet connection. Local LAN connectivity is pre-
sented via dual 10/100 Ethernet ports. Traffic can
be routed out either port for load-balancing and
redundancy. Dual-redundant power supplies pro-
tect against equipment down-time.
Seamless and secure network integration with
fixed IP, DHCP or PPPoE. Complete access rout-
ing features include NAT/NAPT, Firewall, DynDNS
and the optional IPsec VPN feature license offer
secure data.
Optional WAN uplink modules, available in
V.35/X.21, T1/E1, and xDSL options, eliminate
the need for extra network termination devices
and extra cost.
Quality of Service (QoS) features included
advanced voice prioritization and traffic manage-
ment. DownStreamQoS™ ensures voice without
interruptions even over best-effort internet con-
nections. Packet labeling according to 802.1p,
TOS and DiffServ enable
integration into managed
QoS networks.
Integrated GUI and
Command Line, front
panel status and call load
indicators and a full suite of management inter-
faces ensure efficient setup, continuous trouble-
free operation and cost-effective deployment.
Visit www.patton.com for more information.
The Patton S-DTA brings all advantages of VoIP to ISDN users. It connects multiple terminals to its
BRI So bus, and converts 2 concurrent voice or fax calls to SIP or H.323 —at an incredibly low price.
Smart-DTA Residential
Digital Telephone Adapter
Model S-DTA
VoIP
Special Rates Available
Call for Details
Full SIP and T.38 support
Complete range of industry standard signaling
protocols supported: SIPv2, H.323v4,
MGCP/IUA, ISDN, BRI, T.38, fax and modem
bypass, DTMF relay.
Integrated Management
and Provisioning
Web GUI for easy end-user setup, fully auto-
mated provisioning system and SNMP manage-
ment for mass deployment.
Outstanding Interoperability
Interoperable for voice and fax calls with a wide
variety of ISDN terminals, PBXs, as well as SIP
and H.323 soft switches and application servers.
Transparent Telephony Features
Preserves ISDN features like caller ID and name
(CLIP/CLIR), call transfer, hold, waiting, charg-
ing information (AOC) and much more.
Instant ISDN to VoIP Connectivity
Provides one internally powered So bus for up
to 8 terminals. Simultaneously converts 2 voice
and fax calls to VoIP.
100–240 VAC
external power supply
Front panel indicators
show system status
at-a-glance
Proven
Patton design,
Patton supported
ISDN TE
BRI/So port
10/100Base-T
Ethernet LAN port

07MSDTA-DS5
Patton is a registered trademark and the
terms SmartNode, DownStreamQoS, and
SessionRouter are trademarks of Patton
Electronics Company in the United States
and other countries.
* Specifications subject to change without notice.
S-DTA/P/EUI: ISDN VoIP adapter, 1x BRI/So, 2 voice/fax calls, 1x 10/100 Ethernet,
external UI power (100–240 VAC)
Ordering Information
Specifications*
WAN Connectivity
10/100Base-T Ethernet WAN • Auto-
MDI-X • DHCP Client • PPPoE Client
(multi-session) • SNTP • IP Multi-Netting
IP Quality of Service
IEEE 802.1p, TOS, DiffServ Labeling •
IEEE 802.1Q, VLAN Tag insertion/dele-
tion (4,096 VLANs)
Management
Web-based GUI • Fully documented CLI
• Telnet and HTTP access • TFTP con-
figuration up- and download • TFTP
firmware upgrade • SNMPv1 agent, MIB
II and enterprise MIB • Built-in diagnos-
tic tools • Auto-Provisioning—
Configuration and Firmware
Fax and Modem Support
T.38 fax over IP • Fax relay and bypass
• Modem bypass
ISDN Specification
1 port Euro-ISDN BRI/So RJ-45, NT •
DSS-1, Q.921, Q.931 • Point-to-point &
point-to-multipoint • Line power for
ISDN terminals
Voice Signaling
SIPv2 • H.323v4 • MGCP/IUA • SIP call
transfer, redirect • Overlap or en-bloc
dialing • DTMF in-band & out-of-band •
Configurable call progress tones
Call Routing & Services: Regular
expression number matching • Regular
expression number manipulation •
Least Cost Routing • Number blocking •
Short-Dialing • Digit collection •
Distribution-Groups & Hunt-Groups •
2nd call offering
Voice Processing
G.723.1 (5.3/6.3 kbps) • G.729, G.729a,
G.729ab (8 kbps) • G.726 ADPCM
(16, 24, 32, 40 kbps) • G.168 echo can-
cellation (25 ms) • Transparent ISDN
data • Silence suppression and comfort
noise • Adaptive and configurable dejit-
ter buffer • Configurable packet length
Dimensions
4.2W x 1.5H x 5.0D in.
(10.6W x 3.9H x 12.7D cm)
Weight
< 15.9 oz (450 g)
Power Consumption
< 4W
Operating Temperature
32–104°F (0–40°C)
Humidity
Up to 90%, non condensing
Compliance
FCC Part 15 Class B (US EMC) • CE per
RTTE 99/5/EC (EMC and LVD) •
Safety—EN60950 • TBR-3 (ISDN
BRI/So)
Network Integration
Patton’s Smart Digital Telephony Adapter provides seamless access to
Internet telephony services for ISDN terminals. The S-DTA connects to
any LAN or broadband access provider via modem.
S-Bus
• • •
Up to 8 ISDN phones
Home LAN
PC
Internet
ISDN Home User
S-DTA
