Patton electronics 2014 User manual

USER
MANUAL
MODEL 2014
Interface Powered
RS-530 to V.35 Converter
SALES OFFICE
[phone]
TECHNICAL SUPPORT
[phone]
http://www.patton.com
Part #07M2014-C
Doc. #070011UC
Revised 4/22/98
An ISO-9001
Certified Company

1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 2014 components to be
free from defects, and will—at our option—repair or replace the product
should it fail within one year from the first date of shipment.
This warranty is limited to defects in workmanship or materials, and
does not cover customer damage, abuse or unauthorized modification.
If this product fails or does not perform as warranted, your sole
recourse shall be repair or replacement as described above. Under no
condition shall Patton Electronics be liable for any damages incurred
by the use of this product. These damages include, but are not limited
to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronics specifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 2014 generates and uses radio frequency energy, and if
not installed and used properly—that is, in strict accordance with the
manufacturer's instructions—may cause interference to radio and
television reception. The Model 2014 has been tested and found to
comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are
designed to provide reasonable protection from such interference in a
commercial installation. However, there is no guarantee that
interference will not occur in a particular installation. If the Model 2014
does cause interference to radio or television reception, which can be
determined by disconnecting the RS-530 or V.35 interface, the user is
encouraged to try to correct the interference by one or more of the
following measures: moving the computing equipment away from the
receiver, re-orienting the receiving antenna and/or plugging the
receiving equipment into a different AC outlet (such that the computing
equipment and receiver are on different branches).
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Patton
Technical Support.
1
1.3 SERVICE
All warranty and nonwarranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Service at
telephone: [phone],
web address: http://www.patton.com;
email: [email protected].
NOTE: Packages received without an RMA number will not be
accepted.
Patton Electronics’ technical staff is also available to answer any
questions that might arise concerning the installation or use of your
Model 2014. Technical Service hours: 8AM to 5PM EST, Monday
through Friday.
2

2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is warranted
for One Year parts and labor.
If any questions or problems arise during installation or use of this
product, please do not hesitate to contact Patton Electronics Technical
Support at [phone].
2.1 FEATURES
• Bi-directionally converts synchronous RS-530 to V.35
• Data rates to 2 Mbps, full or half duplex
• Transparent to protocol
• No AC power or batteries required
• Various DCE/DTE combinations available
• DB-25 and M/34 connectors with integral 6 foot cable
• Circuitry housed in a miniature case
• Made in the USA
2.2 DESCRIPTION
The Model 2014 RS-530 to V.35 converter lets a synchronous RS-
530 device communicate bi-directionally with a synchronous V.35
device. The Model 2014 requires no AC power or batteries to operate
and supports data rates to 2 Mbps. Operating full or half duplex, the
Model 2014 passes all necessary clocking and control signals, and is
transparent to protocol.
The Patton Model 2014 connects directly to the synchronous
RS-530 interface using a male or female DB-25 connector. A male or
female M/34 connector at the end of an integral 6 foot cable plugs into
the V.35 device. Models with any combination of "DCE" and "DTE"
wiring are available, thus eliminating the need for special crossover
cables.
Housed in an ultra-miniature case measuring only 2.66" x 2.10" x
0.73", the Model 2014 fits easily into tight locations. Like all Patton
products, the Model 2014 is manufactured by Patton Electronics in the
USA.
43
3.0 INSTALLATION
The Patton Model 2014 is very simple to install. Just plug it in like
a normal cable and you're ready to go: no configuration is necessary!
Since the Model 2014 is available in various combinations of genders
and DCE/DTE orientations, many applications are possible. Figures 1
and 2 show two possible applications for the Model 2014.
Figure 1. A common RS-530 DTE to V.35 DCE installation
Figure 2. A common V.35 DTE to RS-530 DCE installation
RS-530 DTE V.35 Modem
V.35 Mini Computer
RS-530 DCE

APPENDIX A
PATTON MODEL 2014 SPECIFICATIONS
Interfaces: EIA RS-530/CCITT V.24 to ITU/CCITT V.35
Data Rates: 0 - 2 Mbps
Transmission Mode: Full or half duplex
Protocol: Transparent to protocol
Clocking: Set by connected devices
Connectors: DB-25 male or female on RS-530 side,
M/34 male or female on V.35 side
Power Supply: No external power required; uses power
from NIC data and control signals
Temperature Range: 0-60°C (32-140°F)
Altitude: 0-15,000 feet (0-5,000 meters)
Humidity: 5 to 95% noncondensing
Dimensions: 2.66"L x 2.10"H x 0.73"W
Weight: 14 oz, including cable and connectors
5 6
APPENDIX B
PATTON MODEL 2014 DCE/DTE BLOCK DIAGRAM
Applies to Models
2014MC-FT 2014FC-MT
2014MC-MT 2014FC-FT

APPENDIX C
PATTON MODEL 2014 DTE/DCE BLOCK DIAGRAM
Applies to Models
2014MT-FC 2014FT-MC
2014MT-MC 2014FT-FC
APPENDIX D
INTERFACE STANDARDS
Copyright © 1998
Patton Electronics Company
All Rights Reserved
DTE
DCE
DCE
DCE
DTE
DTE
DTE
DTE
DTE
A- Unassigned
C- Request to Send
E- Data Set Ready
H- Data Terminal Ready
K- Unassigned
M- Unassigned
P- Transmitted Data (A)
S- Transmit Data (B)
U- Terminal Timing (A)
W- Terminal Timing (B)
Y- Transmit Timing (A)
AA- Transmit Timing (B)
Signal Ground -B
Clear To Send -D
Data Carrier Detect -F
Unassigned - J
Unassigned -L
Unassigned -N
Receive Data (A) -R
Received Data (B) -T
Receive Timing (A) -V
Receive Timing (B) - X
Unassigned -Z
Unassigned BB -NN
Model 2014 V.35 Interface (M/34 Male)
EIA 530 PIN-OUT REFERENCE (DB-25)
Transmit Clock
Recieved Data (Return)
Receiver Clock
Request To Send (Return)
Data Terminal Ready
Data Set Ready (Return)
Data Terminal Ready (Return)
DTE Transmitter Clock
Transmitted Data (Return) 14
15
16
17
18
19
20
21
22
23
24
25
1
2
3
4
5
6
7
8
9
10
11
12
DTE
DCE
DTE
DCE
DCE
DCE
DCE
DCE
DCE
DTE
DCE
DCE
Transmitted Data
Received Data
Request To Send
Clear To Send
Data Set Ready
Signal Ground
Carrier Detect
Receiver Clock (Return)
Carrier Detect (Return)
DTE Transmitter Clock (Return)
Transmitter Clock (Return)
Protective Ground
Clear To Send (Return)
13
Sig. Source
7
