Paxton Access TOUCHLOCK K Series User manual

Ins-30076 TOUCHLOCK compact K series
123
456
789
0#
*


Technical Support
Technical help is available: Monday - Friday from 07:00 - 01:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
[email protected][phone]
Quickstart guide
Exit
Exit button
(push to make)
Electric release
To 12V DC
power supply
12V DC release current rating must be less than 1A.
This supplement is a brief guide to installing a TOUCHLOCK K series compact system. Further
information is available for download at: http://paxton.info/140 or call the communications
team on: [phone].
Documentation on all Paxton Access products can be found on our web site - http://www.paxton.co.uk/
The readers default indication has all the LEDs on. Access granted is
denoted with a single ashing Green LED, Access Denied is a single steady

K75 Screw connector option
12v DC
0v
Lock 12V
Lock 0V
Exit input
Exit 0V
123
456
789
0#
*

Wiring
NOTE: The unit should be mounted in
conjunction with an electrical backbox
to achieve the required clearance for
the connector.
If an adaptor plate (310-750) is tted,
the mountings on the backbox can
also be used.
Bell 12V
Bell 0V
NOTE: Illustrations in
this instruction show the
standard keypad.
The Stainless Steel
version installs and
operates in exactly the
same manner.

A 6 digit Programming Code must be set by the user rst. To do this press the following:
IMPORTANT NOTE: Do not set the Programming Code to 123456
The default user code is 1234 - the programming code must not include 1234 in the same order.
The door lock will release after 1234 and ignore any remaining numbers.
The default user code is now set to 1234
This box can be used to write down the Programming Code for future reference.
Ensure that this information is stored in a secure place.
Factory reset
1. Power down the system.
2. Power the system up whilst pressing and holding 3.
3. All 3 LED’s will ash and the unit will beep 3 times a second.
4. Go to TOUCHLOCK programming guide. - Initialising a new system.
Initialising a new system
You can now set up the user codes and features using the chart opposite.
Example: - Setting a user code to unlock the door under normal conditions.
Enter user code
4-8 digits
Re-enter
user code 4
8
Enter 6 digit
Programming
Code
Hold for 3 secs
The unit will beep and the LED ashes faster
Enter 6 digit
Programming
Code
Re-enter 6 digit
Programming
Code
Normal

X
Single or multiple
codes
Silent operation
20 wrong keystrokes
= 60 second lockout
Door open time
(seconds)
Change
Programming Code
Exit button
Set a
user code
Data Reset (except
Programming code)
OR
One code only Multiple codes allowed
Silent
Beep on
OFF ON
Enter time in seconds
(default = 07, max = 60)
Open door for
time in option 5
Toggle door open
until pressed again or
toggle code entered
Enter user code
4-8 digits
Re-enter
user code
Enter 6 digit
Programming
Code
= Delete
= Normal
= Toggle
= Duress
Enter 6 digit
Programming
Code
Re-enter 6 digit
Programming
Code
6
OR
OR
X
OR
2
4
6
8
OR
OR
OR
Lock wire setting Fail locked Fail open
OR
2
2
2
2
2
2
1
3
4
7
5
6
9
8
6
6
6
6
9
START - Enter the 6 digit Programming Code and hold down a function key
----- for 3 seconds. - The unit beeps and the LED ashes faster.
Continue the key sequence to set the option - The keypad returns to operating mode.
= default setting
= Hold down for 3 secs

Keypad bezels
Additional bezels are available in black, white, grey, blue and silver.
Registered installers can order these free of charge by logging onto the
secure installer extranet: https://extranet.paxton-access.co.uk/index.asp.
If you are not a registered installer please call us on: [phone]
for more information.
Fitting

Here is the list of topics about this product that receive the most technical support enquiries.
We list them here to help you speed up the installation and trouble shooting process.
1 - Can I use a fail open release (e.g. Maglock)?
QThe lock wires from a compact keypad provide 12V DC to the electric lock. By default, the compact is
set to operate with a fail locked release - providing 12V on the lock wires when a valid entry is made. To
use a fail open release, the lock wire setting needs to be changed (Program option 1)
2 - Can I put a relay across the lock wire output?
QYes - All compact systems have been designed to drive relays.
3 - Integration with an entry phone system.
QThe output from the entry phone system is used to simulate an exit button for the Paxton equipment.
No voltage should be applied to the exit input wires (Blue / Mauve) of a compact unit. Most phone
systems will provide a powered pair to release the door lock; this voltage must be used to drive an
independent relay. The relay contacts must be ‘normally open going closed’ to mimic a ‘push to make’
exit button. Only a volt free output pair can be connected directly to the exit input wires.
4 - What are the keypad code types used for?
QNormal - Releases the door for the time period set in Option 5 ( 7 secs default)
QToggle - Releases the lock until the code is entered for a second time.
QDuress - Releases the lock (as in Normal) but also energizes the bell output for 30 seconds.
QDelete - Used to remove a specic code that has already been entered in Multiple mode.
5 - Connecting a compact with another control unit.
QThis cannot be done. Paxton Compact systems have the control electronics built in and no direct data
output is provided. The Switch2 and Net2 system use a different type of data input.
QNote: The compact system will control the door unit on its own.
6- Read in and read out on one door.
QYou cannot wire two compact systems in parallel to a common lock as this may result in damage to
your system. They will both power the door lock independently and will not offer single point control. We
recommend using one Switch2 controller with two compatible keypads or readers.
7 - Use with External doors.
QCompact system are less secure than a system with a separate controller. It is strongly recommended
that a Switch2 based system is used in place of a compact as the control electronics are secure on the
inside of the property.
Frequently asked questions

1 50
4 digits 8 digits
1 60 secs
1 2
11V DC 14V DC
170 mA
1A
12V DC
- 20 °C + 55 °C
IPX7
K38 38 mm 78 mm 13 mm
K50 50 mm 100 mm 15 mm
K75 75 mm 143 mm 16 mm
© Paxton Access 2008 Ins-30076 TOUCHLOCK compact K series
Outdoor Use
Yes
Yes
Yes
Yes
3 metres
No
K series compact keypad
Black and White keypad bezels or Stainless Steel bezel
Compact relay module
Documentation
Fitting Kit fk1-060 3 Pozi pan self tapping screw - zinc
3 Wall Plugs
1 Pozi pan self tapping screw - small
5 Cable clips
Switchable current
Backlight
Features
Code length
Door open time
Time zones (with additional time clock)
Silent operation
Can be used with fail OPEN locks
Can be used with fail CLOSED locks
Exit button input
Door Contact input
Alarm/bell output
Number of Users
Cable length
Min Max
Voltage
Specications
Operating temperatures - all items
Electrical
Environment
Current
Waterproof
Dimensions
Min
Width Height
Max
Min Max
Depth
Contents in box
Qty
Not with Stainless Steel keypad
Description
04/08/2008
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
