Paxton Access 351-110-US User manual
PAGE 1
Ins-40077-US TOUCHLOCK K and KP series - UL
Mounting
K75 Screw connector option
NOTE: The unit should be mounted
in conjunction with an electrical
backbox to achieve the required
clearance for the connector.
If an adaptor plate (310-750-US)
is tted, the mountings on the
backbox can also be used.
This keypad is designed to provide a Clock and Data output for Paxton (Net2 / Switch2).
Technical help is available: Monday - Friday from 02:00 AM - 8:00 PM (EST)
1.800.672.7298 [email protected]
This unit is for Indoor use only
NOTE: Illustrations in this instruction show the standard keypad.
The Stainless Steel version installs and operates in exactly the same manner.
The KP series readers will also read Paxton tokens (Hitag2) and EM4100 tokens.
Documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
Readers mounted together
Mounted on metal surface
Suitability
Security sensitive doors
Wet environments
K KP
between readers
12 inches
Paxton
03/14/2012
Technical Support
For instructions in alternative languages - http://paxton.info/1000
PAGE 2
Cable extensions
Red 12v dc
Brown
Orange
Green
Yellow
Blue
Mauve
Black/White
Brown
Yellow
Reader 1
Orange
Keypad 1
+12v
0v
N.C.
N.O.
Com
N.C.
N.O.
Com
Alarm Output
0v
Contact
0v
Exit
0v
Tamper
PSU
Rx
Tx
Relay 1
Relay 2
Exit
Contact
Tamper
PSU
OK
5v
12v
Red
Brown
Orange
Green
Yellow
Blue
Mauve
Black/White
Brown
Yellow
Orange
Reader 2
Keypad 2
Power
Relay 1Relay 2Inputs
Network
CAT5 cable coding
White/Green
Green
White/Orange
Orange
1
2
3
4
Screen or spare cores
from network cable
CAUTION: for 12v d.c. readers only. For
correct connection of old 5v readers, refer to
instructions.
Serial number
241821
Test ID: 012345678901
z-1440
3 24898 00000 4
xR
Green
White/Green 1
Screen or spare cores from
network cable
White/Orange3
Orange4
K1redaeR da
pye 1
12V
Alarm Output
R le ay 2
N.C.
N.O.
Com
N.C.
N.O.
Com
0 V
0V
Exit
0 V
PSU
0V
Contact
Tamper
R le ay 1
V2
1
V
5
KO
T ep
ma r
tcatnoC
t
i
xE
R le ay 1
xT
U
S
P
Keypad 2 Reader 2
stupnI P ewo r
R le ay2
CA nidoc
e
lbac
5T g
kr
ow
teN
+V out
Red LED
Amber LED
Green LED
Data/D0
Clock/D1
Media Detect
0V out
Data
Load
Clock
tu
oV+
DELdeR
DEL
re
bmA
DELneerG
0D/ata
D
1D/kc
olC
tceteD
aideM
tuoV0
ataD
daoL
kcolC
Net2
2
12 3
456
789
0 #
*
Wiring
Use Max length Type
Reader / Keypad 500 feet 8 core, shielded - Belden 9538, Alpha 1298C (22AWG) General Cable
C0744A / C0745A (22AWG)
Cable Specication
Part number Description
351-110-US TOUCHLOCK K50 keypad
371-110-US TOUCHLOCK K75 keypad
371-120-US TOUCHLOCK K75 keypad - screw connection
352-110-US TOUCHLOCK K50 keypad - stainless steel
372-110-US TOUCHLOCK K75 keypad - stainless steel
372-120-US TOUCHLOCK K75 keypad - screw connection - stainless steel
355-110-US TOUCHLOCK KP50 keypad
375-110-US TOUCHLOCK KP75 keypad
375-120-US TOUCHLOCK KP75 keypad - screw connection
Options
Net2 control unit
12 3
456
789
0 #
*
Red 12V
Brown
Orange
Green
Yellow
Blue
Mauve
Exit
Contact
Black
Card reader or keypad
12v
0v
N.C.
N.O.
Com
Bell
PowerDoor relay
Alarm
witch
2
S
Control
unit
Inputs
CAUTION: For 12V d.c. readers
only. For corr ect connection of old
readers, refer to instructions .
Card reader or keypad
Inputs
Door relay Power
Alarm
Bell
12V
0V
N.C.
N.O.
COM
CAUTION: For 12Vd.c.
readers only. For correct
connection of old readers,
refer to instructions.
Contact
Exit
Switch2
12V
Red LED
Amber LED
Green LED
Data/D0
Clock/D1
Media Detect
0V
Switch2 control unit
PAGE 3
Option Part number Description
K50 & KP50 Fitting Kit fk1-059 (5) Cable clips
(3) No6 x 3/4 woodscrew - zinc
(3) Wall plugs 22mm
(1) 8mm x 3mm small self tapping screw - zinc
K75 & KP75 Fitting Kit fk1-061 (5) Cable clips
(3) No8 x 1 woodscrew - zinc
(3) Wall plugs 35mm
(1) 8mm x 3mm small self tapping screw - zinc
Parts Kit
Standard Unit - Drill a hole in the surface for the rear data cable. Secure the unit to the surface with three screws
as per tting diagram on page 1. 3 suitable screws and xings are provided for tting the unit to a wall. Ensure
the data cable has free access at the rear.
A choice of black and white covers are also provided. Hook the required cover over the top of the reader, press
home at the bottom and secure with the single xing screw.
Screw Terminal Unit - The adapter (310-750-US) is mounted to a standard backbox using the xing screws
provided. The 75mm reader is then mounted onto the adapter using the tting kit provided with the reader.
KP series - When chosing a location for the reader, ensure that it is a least 12 inches from other readers. This will
include readers mounted on the other side of the same wall as the radio signal will cause interference and reduce
the read range. The reader should not be used on metal surfaces as the reected signal will also reduce the range.
Powering up the keypad will cause all the LEDs to come on. Once the control unit has been congured to accept
keypad input (see controller instructions) pressing any key will make the keypad sound a bleep. Check the
following FAQ section for assssistance if any problems are encountered.
FCC Compliance
Class B digital devices.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Class A digital devices.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This unit is for Indoor use only
Following the completed installation of this equipment, no further maintenance or testing is required.
It is advisable to ensure that any third party backup power supplies or recovery procedures are checked regularly
to ensure that the operation of the Paxton system is not compromised.
Unit installation / test Maintenance/
PAGE 4
12V DC
180 mA
600 µs
125 kHz
KP50 2 inch 4 inch 5/8 inch
KP75 3 inch 5 1/2 inch 5/8 inch
KP50 3 inch 2 inch 4 feet
KP75 4 inch 2 1/2inch 5 feet
Voltage
Clock and data bit period
-35 °C (-31 °F) +66 °C (+151 °F)
IPX7
9V DC 13V DC
120 mA
600 µs
K50 2 inch 4 inch 5/8 inch
K75 3 inch 5 1/2 inch 5/8 inch
Specications
Operating temperatures - all items
Electrical
Environment
Dimensions
Min Max
Width Height Depth
Current
Cable length
Backlight Not with Stainless Steel keypad
Carrier frequency
Read Range Token Keyfob Hands Free Token
Max
Min
Voltage
Clock and data bit period
Electrical Min Max
Width Height Depth
Current
KP Specic
Dimensions
10 feet
Outdoor use
Indoor use
Waterproof - K75 - Screw connection
Waterproof - Fixed cable
The use of any add-on, expansion, memory or other module manufactured or supplied by the manufacturer's
representative will invalidate the CAN/ULC-S319 certication.
For CAN/ULC-S319 installations, terminals, leads and wiring methods must comply with CSA, C22.1,
Canadian electrical code, Part 1, safety standards for electrical installations.
Product compliance and limitations
To comply as a UL listed installation, the following conditions must apply:-
Server based functions (Antipassback, Time and Attendance, etc) have not been evaluated by UL and cannot be
used for UL 294 installations.
The use of Wiegand readers and the conguration software has not been evaluated by 'UL'
Wiring: - Where an equivalent cable / wire is used it must be ' UL Listed '
All interconnecting devices must be UL Listed.
Wiring methods shall be in accordance with the National Electrical Code (ANSI/NFPA70), local codes, and the
authorities having jurisdiction.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
