Paxtron Net2 PaxLock Assembly instructions

Smart, Secure Wireless
Technology in a Door Handle
An Installer Guide
Net2 PaxLock

Use the template to drill the
required holes in the door
1.
Install the Net2 PaxLock on the
door and insert the batteries
2.
Add the unit to the Net2 system by
presenting a pre-enrolled token
3.
Access Control in 3
Simple Steps...
Quick and Easy Installation
• Online wireless system
• Battery powered
• Easily replaceable AA batteries keep maintenance to
a minimum
• Communicates using secure Net2Air technology
• Paxton proximity compatible versions for a variety of
site requirements
• Version with key override function for added security
• Robust mechanical design
Net2 PaxLock is a Complete Wireless Security Solution with
Quick and Easy Installation
Net2 PaxLock will save you time and money on site, it can be installed quickly and comes pre-tted with a C keyway core,
also available to t SFIC keyway.
The battery powered unit comprises a networked access control system in a door handle, combining secure wireless
technology with a stylish proximity reader.

Net2 server PC
connected to
IP network
Key override
function for added
security
Easily replaceable
AA batteries keeps
maintenance to a
minimum
Net2 proximity
compatible versions
Secure Net2 Air
frequency range (refer to
installation manual)
The
Network
Communicates wirelessly
with Net2 server PC via PoE
powered Net2Air bridge
Net2 PaxLock communicates with the Net2 software at a central point by a secure, low power radio link, and events are
reported back to the server in real-time. It is designed for use with Net2Air Ethernet bridges to give the advantages of a
wireless networked access control system. Each Net2Air bridge can detect Net2 PaxLock units within an average wireless
radius range of up to 50ft.
Net2 PaxLock is simple to use and quick to install because it is not wired into a mains power source, making it an ideal
solution for internal doors.
How Does it Communicate?
Works with all other
Net2 control units
Robust
mechanical
design
Compatible with
door contacts to
detect ‘door forced’ or
‘door left open’ status
net2
www.paxton-access.com

*Warning: Building structure may aect wireless signal
Net2Air Wireless Range on Site with Multiple Net2 PaxLock Units
Key Benets of Net2 PaxLock Over a Hardwired System
• No separate power supply needed
• No cabling to the door
• Minimal installation time
• Reduced labor costs
• Can be retrotted to existing lock cases
• Simple maintenance
Net2 PaxLock units
connect wirelessly
to Net2Air bridge
PoE powered Ethernet
bridges use site’s
existing LAN/WAN
Wireless radius range can
overlap, allowing the Net2
PaxLock unit to connect to
the bridge with the strongest
signal available*
www.paxton-access.com

• Industry leading technical support
• Simple to manage software
• Trusted Net2 technology
• 30 years of industry experience
• Ultimate returns policy
• Five year warranty
You can now add this innovative unit to your product oering and enjoy all the
benets of Paxton’s market-leading service.
Net2 PaxLock versions
All information and specications correct at the point of publication, but may be subject to change without notice.
• Net2 PaxLock C Keyway and Galaxy
style handle - Sales code - 921-130-US
• Net2 PaxLock C Keyway and Eclipse
style handle - Sales code - 921-131-US
• Net2 PaxLock SFIC and Galaxy style
handle - Sales code - 921-160-US
• Net2 PaxLock SFIC and Eclipse style
handle - Sales code - 921-161-US
Net2 PaxLock Galaxy
style handle
Net2 PaxLock Eclipse
style handle
Contact your local Paxton
distributor to nd out
more today!
There are multiple Net2 PaxLock
versions available to suit C Keyway
and SFIC prole lock cases:
www.paxton-access.com

www.paxton-access.com
877.438.7298 suppor[email protected]
Environment
System specifcations
Electrical
Operating temperature
Moisture resistance
Vandal Resistance
Paxton
EM
50,000
10
15m/50ft
2.4GHz (IEEE 802.15.4)
AES 128bit
50mm/2”
0°C - +55°C
+32°F - +131°F
Yes
Yes
Yes
Yes
Yes
Door open time
Silent operation
1 sec - 60 secs
Maximum total users/tokens
Token compatibility
No
No
No
No
No
Low
Battery type
Battery life 20,000 operations
Communication
Recommended wireless devices
per Net2Air Bridge
Optimum wireless range
Encryption
UL
Handsfree compatible
Features
Door contact
Door widths supported
Low battery warning
Rear handle exit request
Flat battery jumpstart terminals
Lock case compatibility
Backset
Rotation
Lockset
Escape function
Cylindrical lockset
Refer to Paxton support
regarding compatibility
UL 10C listed (20 min re
doors)
70°
70mm/2.75”
4 x AA 1.5V Alkaline
Normal power mode:
Low power mode: 30,000 operations
TCP/IP
Wireless
RS485
Dimensions
205 mm
8”
95 mm
3.8”
175 mm
6.9”
44 mm
1.7”
33 mm
1.3”
77 mm
3”
145 mm
35 mm
35 mm
1.4”
5.7” 1.4”
Net2 PaxLock Specications
