PCB Piezotronics 034T20 User manual

Model 034T20
4-conductor, low noise, shielded, FEP cable, 20-ft, 4-socket plug to triple-splice assembly with
(3) 1-ft coaxial cables each with a BNC plug (labeled X,Y,Z). shield grounded
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.pcb.com

Manual 21354 Rev E
ECN 50523
