PCB Piezotronics HTT356A15 User manual

Model HTT356A15
Triaxial, high sensitivity, ceramic shear ICP® accel., 100 mV/g, 2 to 5k Hz, titanium hsg, 4-pin
conn., TEDS, to +325F
Installation and Operating Manual
