PEAS VC-530E User manual

User Manual
The technical data may be changed without prior notice
www.peas-pa.com
Guangzhou Q&S Audio Co., Ltd
Post Code: 510000
Tel: [phone]
Website:
Address Room 604 E : , , , - Exchange Center Panyu TianAn Hi tech cological Park,Guangzhou,China
www.peas-pa.com
Guangzhou Q&S Audio Co., Ltd
VC-530E
Volume Controller

1
Guangzhou Q&S Audio Co., Ltd
Preface
Introduction
Features
Thank you for choosing our products. All products have been rigorously tested
before leaving the factory, abide by the quality of commitment. Products are widely
used in schools, gymnasiums, square venues, parks, car parks, railway stations,
airports, villas, shopping malls and other places, is the ideal choice for public
broadcasting.
In order to facilitate your installation, commissioning and use of this product,
please read this manual before installation.
4www.peas-pa.com
● Simple modern appearance
● Streamline design, rounded corners, elegant and agile; the panel
● effectively resist scratches.
● Ergonomic design
● Large knob design, rotation convenient and labor-saving.
Installation
Installation size
Installation steps
1. First gently remove the panel with a screwdriver
2. Then put the product on the hole in the wall, fix the screw, and close the panel.
87
OF F

2www.peas-pa.com 3
Guangzhou Q&S Audio Co., Ltd
Connection Performance Parameters
General Specification
Rated power 30W
Attenuation Per Step 3dB
Total Attenuation 30dB
Attenuation Positions 10 plus off
Material ABS
Finished Color White
Mounting Flush and Surface
The model with “D” means with relay
Dimension(L*W*H)mm
Unit Weight
Gross Weight
87*87*60
160g
5kg/24pcs
Type
Line input
VC-530E/ VC-530D
100V
TRE
K1
SW-1*11WAY
+24V
104
CL1
SRS-24VD C-SH
21
5
64
3OUT
RS1
235BYQ
IN
N1
IN
GND
GND
OUT
G
+24V
DG127-6
6
5
4
3
2
1
CD
100V
Amp.
Speaker
24V 0V OUT IN
