NITROBASS PREAMP

B I L L O F M A T E R I A L S R E P O R T
BOARD NAME: NITROPRE REPORT DATE: 30MAY00
ASSEMBLY LEVEL NUMBER: 99010810 DESIGNER: STEVE CLARK
PROJECT NUMBER: P9900086
CBDS
PART PART DESCRIPTION AND
** QTY. NAME VALUE NUMBER DEVICE DESIGNATIONS *************
*************************************************************************
1 98810810 98810810 98810810 PCB
2 .0033M .0033M 70330130 .0033M 5% 50vdc my T&A
C106, C112
1 .0047M .0047M 70330116 .0047 MFD 50VDC 5% MY T&A
C123
1 .0068M .0068M 70330117 .0068mf---5%---50vdc---my---t&a
C121
1 .01 .01 70340011 .01MF-----10%----50VDC----T/C----T&R
C132
1 .018M .018M 70330126 .018M 5% 50vdc my T&A
C122
1 .033M .033M 70330115 .033 MFD 50VDC 5% MY T&A
C113
2 .068M .068M 70330124 .068M 5% 50vdc my T&A
C117, C118
15 .1 .1 70340100 .1MF----+80-20%--50VDC----AXL----T&R
C100, C101, C125, C126, C128, C129,
C131, C139, C140, C143, C145, C146,
C147, C209, C210
2 .33RP2 .33RP2 70330145 .33MF------2%----50VDC----PP----T&A
C102, C103
1 .47SF2 .47SF2 70330148 .47MF 5% 100VDC SF T&A
C111
1 .82M .82M 70330122 .82mf 5% 50vdc my T&A
C104
3 100 100 70240010 100---1/4W--5%----CF--T&R
R146, R212, R219
4 100K 100K 70240034 100K--1/4W--5%----CF--T&R
R118, R158, R165, R218
7 100PF 100PF 70340054 100PF-----10%----50VDC----T/C----T&R
C107, C108, C115, C127, C133, C205, C223
19 10K 10K 70240025 10K---1/4W--5%----CF--T&R
R105, R110, R111, R112, R119, R120,
R121, R122, R124, R125, R127, R130,
R132, R133, R135, R160, R164, R169, R170
8 10KP1 10KP1 70241050 10K---1/4W--1%----MF--T&R
R210, R211, R214, R215, R217, R222,
R228, R229
4 15K 15K 70240027 15K---1/4W--5%----CF--T&R
R100, R102, R113, R129
1 1740 1740 70401740 2SC1740SLN 40V,.1A, NPN, LOW NOISE T&A
Q200
1 180PF 180PF 70340056 180PF-----10%----50VDC----T/C----T&R
C144
1 1K 1K 70240017 1K----1/4W--5%----CF--T&R
R159
2 1M 1M 70240039 1M----1/4W--5%----CF--T&R
R109, R166
12 1N4148 4148 70464148 1N4148 75V 10MA SILICON DIODE
CR100, CR101, CR102, CR103, CR104,
CR105, CR106, CR107, CR108, CR109,
CR110, CR111
2 2.67KP1 2.67KP1 70241018 2.67K-1/4W--1%----MF--T&R
R221, R227
5 2.7K 2.7K 70240021 2.7K--1/4W--5%----CF--T&R
R114, R116, R137, R138, R230
5 220K 220K 70240036 220K--1/4W--5%----CF--T&R
R106, R147, R148, R150, R153
12 22K 22K 70240029 22K---1/4W--5%----CF--T&R
R103, R104, R108, R142, R145, R149,
R151, R152, R154, R155, R156, R157
17 22R50 22R50 70320181 22MF-----20%----50VDC---EL--T&A
C105, C109, C110, C114, C116, C119,
C124, C130, C134, C135, C136, C138,
C141, C206, C208, C218, C222
2 2N3919 3919 70463919 SKA-3919 TO92 NPN TRANS T&A
Q102, Q103
1 330PF 330PF 70340070 330PF-----10%----50VDC----T/C----T&R
C120
1 33K 33K 70240030 33K---1/4W--5%----CF--T&R
R107
2 4.7FP 4.7FP 70240094 4.7FP-1/4W--10%---FP--T&R
R161, R162
2 4.7K 4.7K 70240023 4.7K--1/4W--5%----CF--T&R
R123, R223
5 4560 4560 70414560 4560 DUAL OP AMP IC
U100, U102, U103, U200, U202
2 47 47 70240008 47----1/4W--5%----CF--T&R
R167, R168
5 470 470 70240015 470---1/4W--5%----CF--T&R
R115, R117, R128, R144, R163
2 470PF 470PF 70340058 470PF-----10%----50VDC----T/C----T&R
C137, C142
2 47FP 47FP 70240090 47FP--1/4W--5%----FP--T&R
R224, R226
7 47K 47K 70240031 47K---1/4W--5%----CF--T&R
R101, R139, R143, R213, R216, R225, R231
3 6.8K 6.8K 70240024 6.8K--1/4W--5%----CF--T&R
R131, R136, R220
2 68K 68K 70240032 68K---1/4W--5%----CF--T&R
R126, R134
1 8SRHRAU 73717093 73717093 8--RA-SQ/P-F/LK-HD-100
P101
1 933 933 70400933 2SA933ASLN 40V, .1A, PNP, LOW NOISE T&A
Q201
1 DG211 DG211 70420211 DG211 CJ I.C.
U104
1 HIDMI 71466215 71466215 2 TIP HID JACK INSU W/SPD
J101
6 HIDMNI 71466214 71466214 2 TIP HID JACK NINS W/SPD
J100, J102, J103, J104, J105, J106
1 J174 J174 70460174 J-174 30V TO-92 P-CHAN FET T&A
Q104
1 LEDBICR LEDBICR 70450056 LED BICOLOR (RED/GREEN) RECT., VERT.
CR112
1 MAC97 MAC97 70460097 MAC97-6 400V .6A TO-92 TRIAC T&A
CR113
1 POT0258 71190258 71190258 10K - STD - 9MM
VR202
2 POT0336 71190336 71190336 10K LIN METRIC SPIDER 1MM
VR100, VR106
3 POT0340 71190340 71190340 50K LIN MET SPIDER - W/CTR DTNT 1MM
VR102, VR104, VR105
1 POT0342 71190342 71190342 50K A/RA 20% DL MET SPDR 1MM
VR101
1 POT0343 71190343 71190343 100K 20% DL MET SPDR 1MM
VR103
1 PXLRMVB 71466183 71466183 XLB CONN VERT MALE W/BRKT
J200
1 SPD 73716194 73716194 .250 PC MNT SPADE .093 PCB
P100
5 SUZPP SUZPP 71322251 SUZ P/P SWITCH PC MOUNT
S100, S101, S102, S200, S201
***********************************
* END OF BILL OF MATERIALS REPORT *
***********************************

B I L L O F M A T E R I A L S R E P O R T
BOARD NAME: NITROPWR REPORT DATE: 5JUN00
ASSEMBLY LEVEL NUMBER: 99010800 DESIGNER: JAMES HUGHES
PROJECT NUMBER: NEW
CBDS
PART PART DESCRIPTION AND
** QTY. NAME VALUE NUMBER DEVICE DESIGNATIONS
*************
*************************************************************************
1 98810800 98810800 98810800 PCB
2 .015 .015 70340010 .015MF----10%----50VDC----
T/C----T&R
C105, C119
2 .01CD .01CD 70320248 .01MF----20%---1000VDC---
CD--T&A
C116, C128
8 .1 .1 70340100 .1MF----+80-20%--50VDC----
AXL----T&R
C104, C121, C126, C130,
C133, C134,
C135, C136
1 .1R250MY .1R250MY 70320096 .1 MFD 250VDC MYLAR CA/BR
C117
1 .22SF2 .22SF2 70330114 0.22 MF 5% 100V STCK FILM
t&a
C111
8 .33W5 .33W5 70250003 .33--5W--10%--WW--AXL
R123, R124, R125, R126,
R129, R130,
R131, R132
1 .8UH .8UH 70519917 .8UH AIR CORE COIL / CS1200
L100
2 1.21KP1 1.21KP1 70240046 1.21K-1/4W--1%----MF--T&R
R108, R114
3 1.5K 1.5K 70240018 1.5K--1/4W--5%----CF--T&R
R101, R147, R151
3 100 100 70240010 100---1/4W--5%----CF--T&R
R110, R127, R143
4 1000R35 1000R35 70320186 1000MF----20%----35VDC--
EL--T&A
C124, C125, C131, C132
2 100FP 100FP 70240096 100FP-1/4W--5%----FP--T&R
R117, R139
3 100K 100K 70240034 100K--1/4W--5%----CF--T&R
R102, R136, R152
3 10K 10K 70240025 10K---1/4W--5%----CF--T&R
R118, R137, R138
2 10KUF80V 10KUF80V 70330161 10,000mf @ 80V R/S Capacitor
C110, C115
2 10KW1 10KW1 70210018 10K---1W----5%----MO--T&R
R120, R135
1 10PF 10PF 70340050 10PF------5%--------------
T/C----T&R
C112
1 10R50L 10R50L 70320185 10MF-----20%----50VDC---
LL--T&A
C120
1 12K 12K 70240057 12K---1/4W--5%----CF--T&R
R154
1 13080 13080 70413080 LM3080N CUSTOM SELECTED
U101
1 13886 13886 70413886 SZ-13886-2 DUAL DIODE
CR113
1 1740 1740 70401740 2SC1740SLN 40V,.1A, NPN,
LOW NOISE T&A
Q114
1 180 180 70240012 180---1/4W--5%----CF--T&R
R122
2 180PF 180PF 70340056 180PF-----10%----50VDC----
T/C----T&R
C102, C122
6 1K 1K 70240017 1K----1/4W--5%----CF--T&R
R113, R115, R140, R142,
R145, R148
1 1M 1M 70240039 1M----1/4W--5%----CF--T&R
R107
10 1N4003 1N4003 70464003 1N4003 200V SILICON DIODE
CR100, CR105, CR106, CR111,
CR126,
CR129, CR131, CR132, CR135,
CR136
16 1N4148 4148 70464148 1N4148 75V 10MA SILICON
DIODE
CR102, CR103, CR107, CR109,
CR112,
CR114, CR115, CR118, CR119,
CR122,
CR123, CR124, CR125, CR128,
CR133, CR134
2 1N4744 4744 70440102 SZG40102 15V 5% ZENER DIODE
CR101, CR130
2 1SS142 1SS142 70400142 1ss142 250v SILICON DIODE
CR110, CR120
1 2.2R50 2.2R50 70320180 2.2MF-----20%----50VDC---
EL--T&A
C107
2 2.2R50NP 2.2R50NP 70320184 2.2MF-----20%----50VDC---
NP--T&A
C101, C118
3 2.7K 2.7K 70240021 2.7K--1/4W--5%----CF--T&R
R144, R146, R157
2 2.7KW1 2.7KW1 70210016 2.7K--1W----5%----MO--T&R
R100, R153
2 22K 22K 70240029 22K---1/4W--5%----CF--T&R
R106, R150
8 22R50 22R50 70320181 22MF-----20%----50VDC---
EL--T&A
C100, C103, C108, C113,
C114, C123,
C127, C129
4 2SA1302D 2SA1302D 70458200 200V PLASTIC PNP POWER
TRANSISTOR
Q107, Q108, Q109, Q110
2 2SA1837V 2SA1837V 70401837 PNP TRAN TO-220 230V 1A
VERT
Q112, Q115
4 2SC3281D 2SC3281D 70468200 200V PLASTIC NPN POWER
TRANSISTOR
Q102, Q103, Q104, Q105
1 2SC4793V 2SC4793V 70404793 NPN TRAN TO-220 230V 1A
VERT
Q101
1 33 33 70240004 33----1/4W--5%----CF--T&R
R112
2 330KT 330KT 70240208 330K THERMISTOR
TR01, TR02
1 33K 33K 70240030 33K---1/4W--5%----CF--T&R
R103
2 39PF 39PF 70340052 39PF-------------50VDC----
T/C----T&R
C106, C109
4 4.7FP 4.7FP 70240094 4.7FP-1/4W--10%---FP--T&R
R104, R149, R158, R159
2 4.7K 4.7K 70240023 4.7K--1/4W--5%----CF--T&R
R119, R134
1 4.99KP1 4.99KP1 70241060 4.99K-1/4W--1%----MF--T&R
R156
2 4560 4560 70414560 4560 DUAL OP AMP IC
U100, U102
2 470 470 70240015 470---1/4W--5%----CF--T&R
R116, R141
1 470FP 470FP 70240098 470--1/4W--5%---FP--T&R
R155
3 47K 47K 70240031 47K---1/4W--5%----CF--T&R
R105, R109, R128
2 5.6W5 5.6W5 70250026 5.6--5W--10%--WW--AXL
R121, R133
9 500STW 70901859 70901859 SPCR,R,TA-40X1/2,SW,AL,ST
SO1, SO2, SO3, SO4, SO5,
SO6, SO7, SO8,
SO9
1 6.8KW2 6.8KW2 70250052 6.8K---2W---5%---MF---T&R
R111
1 6531 6531 70466531 MPS-6531 TO92 NPN TRANS.
T&A
Q106
1 6534 6534 70466533 MPS-6533/34 TO-92 PNP TRANS

T&A
Q111
1 7815FVRT 7815FVER 70400318 7815 15V 1A POS TO-220 RG
VERT MNT INS
Q113
1 7915FVRT 7915FVER 70400319 7915 15V 1A NEG TO 220 RG
VERT MNT INS
Q116
1 CAB0091 70600091 70600091 8C-.100--24" W/ 8PIDC
P101
2 CLIP1785 70901785 70901785 screw term, 6-32 - pcb mnt.
BR10, BR11
4 CLP1183 CLP1183 70901183 FUSECLIP, PC MT - T&A
FC100, FC101, FC102, FC103
14 EYE090 73700219 73700219 EYELET .090-DRILL-HOLE
.068-EYELET-HOLE
EY1, EY2, EY3, EY4, EY5,
EY6, EY7, EY8,
EY9, EY10, EY11, EY12,
EY13, EY14
2 FMPU 73711811 73711811 M118-171 C.B. FEMALE MOLEX
PIN
J109, J111
1 J174 J174 70460174 J-174 30V TO-92 P-CHAN FET
T&A
Q100
15 J325 J 70600005 22GA JUMPER WIRES T&R
JP3000, JP3003, JP3004,
JP3005, JP3006, JP3007,
JP3008, JP3009,
JP3010, JP3011, JP3012,
JP3013, JP3014,
JP3015, JP3016,
18 J4 J 70600005 22GA JUMPER WIRES T&R
JP4000, JP4001, JP4002,
JP4003, JP4004,
JP4005, JP4006, JP4007,
JP4008, JP4009,
JP4010, JP4011, JP4012,
JP4013, JP4014,
JP4015, JP4016, JP4017,
17 J5 J 70600005 22GA JUMPER WIRES T&R
JP5000, JP5001, JP5002,
JP5003, JP5004,
JP5005, JP5006, JP5007,
JP5008, JP5009,
JP5010, JP5011, JP5012,
JP5013, JP5014,
JP5015, JP5016,
7 J6 J 70600005 22GA JUMPER WIRES T&R
JP6000, JP6001, JP6002,
JP6003, JP6004,
JP6005, JP6006,
1 J7 J 70600005 22GA JUMPER WIRES T&R
JP7000,
7 J8 J 70600005 22GA JUMPER WIRES T&R
JP8000, JP8001, JP8002,
JP8003, JP8004,
JP8005, JP8006,
1 JMP JMP 70600005 22 GA. JUMPER WIRE T&R
P1
1 KBU6J 70400605 70400605 6A, 600V, INLINE DIODE
BRIDGE RECTIFIER
BR100
1 MMPU 73711812 73711812 R93-12 PN C.B. MALE MOLEX
PIN
J110
2 MR502 MR502 70400502 MR502/1N5402 200V, 3A SILICON
DIODE
CR108, CR121
2 MR812 MR812 70404933 MR812 FAST RECOVERY DIODE
CR104, CR127
2 RASN6165 71466165 71466165 JK R/A 12.5MM NIN STEREO -
88
J100, J103
1 SAC187 SAC187 70400187 SAC187 200V TO220 TRIAC
CR116
1 SBS14 SBS14 70460014 SBS14 8V T0-92 BI-DIRECTIOAL
SWITCH T&A
CR117
3 SPDU 73716194 73716194 .250 PC MNT SPADE .093 PCB
J106, J107, J108
2 SPX2 SPX2 XXXXXXXX 2 EACH OF STAKE PINS
J112, J113
1 WJ6BK26R WJ6BK26R 91090525 BLACK-16GA-26"-CPT TO RA
250 SPADE
J114
2 WJ6BL8 WJ6BL8 91090524 BLUE-16GA-8"-CPT TO CPT
J101, J104
1 WJ6W8RS WJ6W8RS 91090523 WHITE-16GA-8"-CPT TO RA
250 SPADE
J105
1 WJ6Y12RS WJ6Y12RS 91090522 YELLOW-16GA-12"-CPT TO RA
250 SPADE
J102
***********************************
* END OF BILL OF MATERIALS
REPORT *
***********************************
