Peavey SP 7X User manual

SP™7X
SPECIFICATIONS
Frequency response, 1 meter on-
axis, swept-sine in anechoic
environment:
50 Hz to 19 kHz (±3 dB)
Usable low frequency limit
(-10 d point):
39 Hz
Power handling:
Full Range:
1,000 W continuous
2,000 W rogram
4,000 W eak
Low Frequency Section:
1,000 W continuous
2,000 W rogram
4,000 W eak
High Frequency Section:
80 W continuous
160 W rogram
320 W eak
Sound pressure level, 1 Watt,
1 meter in anechoic environment:
Full Range:
99.0 dB SPL, (2.00 V in ut)
Low Frequency Section:
100.0 dB SPL, (2.00 V in ut)
High Frequency Section:
110.0 dB SPL, (2.83 V in ut)
Maximum sound pressure level
(1 meter):
Full Range:
129.0 dB SPL continuous
135.0 dB SPL eak
Low Frequency Section:
130.0 dB SPL continuous
136.0 dB SPL eak
High Frequency Section:
129.0 dB SPL continuous
135.0 dB SPL eak
Radiation angle measured at -6 d
point of polar response:
80 degrees horizontal by
40 degrees vertical
Transducer complement:
Low Frequency Section:
2x 15 in. woofer, vented
1508-8 HE BWX
High Frequency Section:
1x 1.6 in. exit/100 mm voice coil
com ression driver on CD Horn
44XT (w/o ada ter) on a CH®7
ox tuning frequency:
Low Frequency Section:
50 Hz
Crossover frequency (internal
passive):
Low Frequency - High Frequency:
1,400 Hz
Recommended active crossover
frequency region and slope:
Low Frequency - High Frequency:
1,600 Hz at 12 dB/octave
Time offset:
Low Frequency: delay 0.69 ms
High Frequency: 0.00 ms
Impedance (Z):
Full Range:
Nominal: 4.0 Ω
Minimum: 3.9 Ω
Low Frequency:
Nominal: 4.0 Ω
Minimum: 3.6 Ω
High Frequency:
Nominal: 8.0 Ω
Minimum: 7.1 Ω
Input connections:
2x 1/4 in. hone jack and 1x Neutrik®
NL4 S eakon®(bi-am only)
Enclosure materials and finish:
3/4" OSB finished in black car et
Mounting provisions:
This unit is not designed for overhead
sus ension.
SPECS
PEAVEY ELECTRONICS

Dimensions (H x W x D):
Front:
49.25 in. x 21.38 in. x 23.00 in.
1251 mm x 543 mm x 584 mm
Rear:
49.25 in. x 14.00 in. x 23.00 in.
1251 mm x 356 mm x 584 mm
Net weight:
139 lbs. (63.2 kg)
Features
• 2,000 W rogram, 4000 W eak
• SoundGuard™44 tweeter rotection
• Two 15" BWX Black Widow®4" VC
woofers
• 44XT™4" titanium com ression driver
• Tra ezoidal enclosure design
• Built-in ocket casters for easy trans ort
Description
The latest version of the SP™ 7 has
the new BWX high ower Black Widow
woofers incor orated, as well as a very
nice looking cabinet design. The SP 7X is
a quasi three-way s eaker system
com rised of a air of 15" Black Widow
BWX woofers with Kevlar®im regnated
cones, and a 44XT com ression driver
loaded onto a CH 7 constant directivity
horn.
The SP 7X has a tra ezoidal sha ed
enclosure, which reduces the build-u of
standing waves inside the enclosure,
which minimizes mid-bass and mid-range
colorations due to the cabinet. It is
constructed of 3/4" OSB and is covered
with a durable black car et. The enclosure
corners are reinforced with olymer ca s,
and a black owder-coated ex anded
metal grille covers the lower ortion of the
system to rotect the woofers from
external damage. Built-in ocket casters
on the rear bottom edge ease trans ort
when smooth flooring or aved areas are
resent.
The quasi three-way system consists
of a air of 15" Black Widow BWX woofers
with Kevlar im regnated cones, and a
water-resistant treated cone and dust ca
for su erior environmental stability.
Ca able of over 500 W of continuous
ower handling each (AES Std 2-1984),
the woofers can handle a lot of sheer
ower. The high frequencies are handled
by a 44XT™4" titanium dia hragm
com ression driver, utilizing ferrofluid
cooling, cou led to a CH 7 constant
directivity horn. This horn has a smooth,
even res onse with good attern control.
The 44XT driver features the Radialinear
Planar Phase Correction System, under
US Patent 6,064,745, which rovides
smoother and extended high frequency
res onse.
In ut connection to the system is
made via two 1/4" hone jacks in arallel,
and a 4- in Neutrik switching jack is
rovided for bi-am ing flexibility, while
maintaining su erior signal integrity. The
internal assive crossover features Sound
Guard 44 tweeter rotection circuit, an
advanced to ology crossover with high
erformance com onents, to rovide high
ower handling and reliability. Peavey’s
ro rietary high-frequency driver
rotection circuitry, Sound Guard, rovides
long and medium-term driver overload
rotection when the system is used full-
range, or when it is bi-am ed, without
im airing musical transients or dynamics.
The crossover rovides driver roll-off and
rotection, as well as driver EQ for the
woofers and horn; the sum total is a clean,
clear and smooth res onse. The lower
woofer is rolled off before the mid-range
crossover oint, so it does not interact
adversely with the u er woofer, which
o erates into the mid-range. High-quality,
reliable crossover com onents include
oly ro ylene ca acitors, and linear high
current inductors. The o timal integration
of the crossover with the selected drivers
results in a smooth frequency res onse
from 50 Hz to 19 kHz. A crossover EQ
switch is rovided to tailor the res onse in
the mid-range, roviding a nominally flat
frequency res onse osition, and an EQ’d
osition that ulls the mids back to hel
kee bright rooms from overloading, or to
hel achieve a mellower voicing for those
a lications that refer it, such as DJ use.
With a double 15" woofer based
enclosure and a horn-loaded 2" throat
com ression driver, this system can ut
out some very serious sound levels, and
take 2,000 Watts rogram of clean
am lifier ower, resulting in recise
coverage with awesome clarity and high
reliability.
Frequency response
This measurement is useful in
determining how accurately a given unit
re roduces an in ut signal. The frequency
res onse of the SP 7X is measured at a
distance of 1-meter using a 1 Watt (into
the nominal im edance) swe t-sine in ut
signal. As shown in figure 1, the selected
drivers in the SP 7X combine to give a
smooth frequency res onse from 50 Hz to
19 kHz.
Power handling
There are many different a roaches
to ower handling ratings. Peavey rates
this louds eaker system’s ower handling
using a full-range form of the AES
Standard 2-1984. Using audio band 20 Hz
to 20 kHz ink noise with eaks of four
times the RMS level, this strenuous test
signal assures the user that every ortion
of this system can withstand today’s high
technology music. This rating is contingent
u on having a minimum of 3 dB of
am lifier headroom available.
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
60
70
80
90
100
110
dB SPL (re 20 Pa)
Amplitude Response (1W 1m On-Axis)
EQ
Normal
Switch Position
Figure 1
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
1
2
3
5
10
20
30
50
100 Impedance
Z
()
Figure 2

SP™7X INPUT
Mounting
This unit is not designed for overhead
sus ension.
Architectural and engineering
specifications
The louds eaker system shall have an
o erating bandwidth of 50 Hz to 19 kHz.
The nominal out ut level shall be 99.0 dB
when measured at a distance of one
meter with an in ut of one Watt. The
nominal im edance shall be 4.0 Ohms.
The maximum continuous ower handling
shall be 1,000 Watts, maximum rogram
ower of 2,000 Watts and a eak ower
in ut of at least 4,000 Watts, with a
minimum am lifier headroom of 3 dB.
The nominal radiation geometry shall be
80 degrees in the horizontal lane and 40
degrees in the vertical lane. The outside
dimensions shall be 49.25 inches high by
21.38 inches wide by 23.00 inches dee .
The weight shall be 139 ounds. The
louds eaker system shall be a Peavey
model SP™7X.
3 + 2 YEAR LIMITED WARRANTY
NOTE: For details, refer to the
warranty statement. Co ies of
this statement may be obtained
by contacting Peavey Electronics
Cor oration, P.O. Box 2898, Meridian,
Mississi i 39301-2898.

Features and specifications subject to change without notice.
Peavey Electronics Corporation • 711 A treet • Meridian • M • 39301
[phone] • FAX [phone] • www.peavey.com
©2001 Printed in the U. .A. 5/01
80304855
